电气测试报告 中英文对照全面
1. Test diagram 测试图示
2. Test result 测试结果
温度:28℃/湿度:75%
5PCS
/
2014-9-22
Full-automatic integrative conduction test machine LX-750全自动导通综合测试机LX-750Test environment
测试环境
Drawing NO.
工程图号HDMI M/M Ni Plated 30AWG OD:5.0 L=1.5/2.0M Black
/Sample Q'ty 样品数量
Part/No.产品料号Test machine 测试设备Test Item 测试项目
SHENZHEN EAST-TOPTECH ELECTRONIC TECHNOLOGY CO.,LTD
深圳市东景盛电子技术有限公司
Electrical Test Report 电 气 测 试 报 告
Product name 样品名称
Product spec.
产品规格
HDMI AM TO AM 30AWG 1.4REV. OD :5.0mm Length :1.5/2.0M
Customer 客户名称/
Test date 测试日期
Match condition 符合条件No appearance defects 外观良好Condution risistance & Insulation risistance & DC voltage test 导通阻抗&绝缘阻抗&DC 耐电压测试
Result of measurement 测 试 结 果
Test Requirement 测 试 要 求
1. DC voltage :300V, time:10ms, Condution risistance 3Ω Max, Insulation risistance 10MΩ Min, No open/short & miss wire, No NG at moment.
DC 电压300V,持续时间10ms, 导通阻抗≦3Ω,绝缘阻抗≧10M Ω,无开路,短路和错接,无瞬间不良现象;2. Connect the cable to the test machine, when testing, Two-hands catch the cable swing up and down at 30 degree; 将线材与测试机连接,当测试时,两手抓住线材做上下30度的摇摆;3. After test, no appearance defects; 测试后外观良好;
OK Match condition 符合条件■ PASS 合格 □ NG 不合格
Note 备注
According to ANSI/EIA-364-23No appearance defects 外观良好OK Match condition 符合条件No appearance defects 外观良好OK OK Sample No.样品编号
1#DC 300V/0.01s CR ≦3Ω IR ≧10MΩ Swing 30°
Visual Inspection 外观检验Judgement 综合判定
2#3#4#5#Test result description 结果描述
Judgement 判定
Match condition 符合条件No appearance defects 外观良好OK Match condition 符合条件
No appearance defects 外观良好
OK
TEST TECH
CT-8688
O/S
Cond Hipot File
Save Leam Stat
Mode Test
Reset
←BS Shift Exit Enter Print
Setup
fune
A PASS
FAIL Hipot
Pin Search
UNIVERSAL CABLE/HARNESS TESTER
B
Hipot Calibraho
线材综合测试机
牛角接头
测试线
表单编号:DJS-QR-045
