产品概览DIMENSION概念型精品Q系列DIN导轨电源最突出的特点是转换效率极高、体积小，这得益于同步整流及其它技术设计。
150%的大功率储备足以支持启动直流电机或电容性负载等重负载。
因此，在许多情况下可以使用低功率电源以节省空间和成本。
对快速脉冲群和浪涌电压的抗性高、电磁辐射低，使得本电源几乎可用于任何可能的环境。
UL 60950-1Class I Div 2Marine EMC, LVD, RoHS输入输出输入电流2A/DIV3x400Vac 24Vdc100ms/DIVQ 系列24V/40A 三相输入7. 断电保持时间3AC 400V *)3AC 480V *)断电保持时间 典型值 50ms 50ms 24V, 20A 时，请参阅图7-1 最小值 40ms 40ms 24V, 20A 时，请参阅图7-1 典型值 25ms 25ms 24V, 40A 时，请参阅图7-1最小值20ms20ms24V, 40A 时，请参阅图7-1*)关于仅使用三相2线系统的运行曲线和数值，请参阅第25.4节图7-1 断电保持时间与输入电压图7-2 关断性能，定义01020304050ms 3203604004403x480Vac输入电压断电保持时间24V, 20A ，典型值24V, 40A ，典型值24V, 20A ，最小值24V, 40A ，最小值-5%断电保持时间输出电压输入电压L1 L2 L3Q 系列24V/40A 三相输入8. DC-OK 继电器触点此功能监控电源自身产生的输出电压。
该输出电压与电源输出并联的电源所产生的回馈电压相隔离。
触点闭合 输出电压达到设定输出电压的90%时。
触点断开 输出电压突降至设定输出电压以下10%时。
短时间突降会延长至250ms 的信号长度。
不足1ms 的突降将被忽略。
触点再次闭合 输出电压超过设定电压的90%时。
触点规格 最大值 60Vdc 0.3A, 30Vdc 1A, 30Vac 0.5A 电阻性负载 最小值5Vdc 时1mA最小容许负载隔离电压 见第21章的绝缘强度表。
