03 MSA测量系统分析报告五性之线性
零件编号 Part Name :量具名称 Gage Name :评价人Appraiser :特性 Characteristics :直径量具编号 Gage No.:α水准 α
Level :
0.05
规范 Specifications :量具型式 Gage Type.:
单位 Units :mm
日期 Date :2019.08.20
线性研究数据线性研究-中途的结果
零件编号 Part Name :量具名称 Gage Name :评价人Appraiser :特性 Characteristics :直径量具编号 Gage No.:α水准 α
Level :
0.05
规范 Specifications :量具型式 Gage Type.:
单位 Units :mm
日期 Date :2019.08.20
R-Sq=0.1%
|t a
|=0.22094≤t gm-2,1-α/2|t b |=0.21873
≤
t gm-2,1-α/2
计算最适合的线及该线的置信度区间。
Calculate the best fit line and the confidence band of the line using the following equations.
Y=-0.00021X-0.008692
评审图示,观察是否存在特殊原因,以及线性是否可接受:
Review the graph for indications of special causes and the acceptability of the linearity :
结果分析-数值法
Analysis of Results - Numerical
结果分析-图示法
Analysis of Results - Graphical
由于“偏倚=0”的整个直线都位于置信度区间以内,该测量系统的线性是可接受的。
The “ bias = 0 ” line lie entirely within the confidence bounds of the fitted line , so the measurement system linearity to be acceptable .
由图示法分析得到的结论经过了数值法分析的证实——本测量系统不存在线性问题。
The result obtained from the graphical analysis is reinforced by numerical analysis - there isn't a linearity problem with this measurement system .
