编译原理课程设计报告C-语言词法与语法分析器的实现

编译原理课程设计报告

课题名称：编译原理课程设计

C-语言词法与语法分析器的实现

提交文档学生姓名：

提交文档学生学号：

同组成员名单：

指导教师姓名：

指导教师评阅成绩：

指导教师评阅意见：

.

.

提交报告时间：年月日

C-词法与语法分析器的实现

1.课程设计目标

（1）题目实用性

C-语言拥有一个完整语言的基本属性，通过编写C-语言的词法分析和语法分析，对于理解编译原理的相关理论和知识有很大的作用。通过编写C-语言词法和语法分析程序，能够对编译原理的相关知识：正则表达式、有限自动机、语法分析等有一个比较清晰的了解和掌握。（2）C-语言的词法说明

①语言的关键字：

else if int return void while

所有的关键字都是保留字，并且必须是小写。

②专用符号：

+ - * / < <= > >= == != = ; , ( ) [ ] { } /* */

③其他标记是ID和NUM，通过下列正则表达式定义：

ID = letter letter*

NUM = digit digit*

letter = a|..|z|A|..|Z

digit = 0|..|9

注：ID表示标识符，NUM表示数字，letter表示一个字母，digit表示一个数字。

小写和大写字母是有区别的。

④空格由空白、换行符和制表符组成。空格通常被忽略。

⑤注释用通常的c语言符号/ * . . . * /围起来。注释可以放在任何空白出现的位置(即注释不能放在标记内)上，且可以超过一行。注释不能嵌套。

（3）程序设计目标

能够对一个程序正确的进行词法及语法分析。

2.分析与设计

（1）设计思想

a.词法分析

词法分析的实现主要利用有穷自动机理论。有穷自动机可用作描述在输入串中识别模式的过程，因此也能用作构造扫描程序。通过有穷自动机理论能够容易的设计出词法分析器。b.语法分析

语法分析采用递归下降分析。递归下降法是语法分析中最易懂的一种方法。它的主要原理是，对每个非终结符按其产生式结构构造相应语法分析子程序，其中终结符产生匹配命令，而非终结符则产生过程调用命令。因为文法递归相应子程序也递归，所以称这种方法为递归子程序下降法或递归下降法。其中子程序的结构与产生式结构几乎是一致的。

（2）程序流程图

程序主流程图：

词法分析: 语法分析：

3.程序代码实现

整个词法以及语法的程序设计在一个工程里面，一共包含了8个文件，分别为main.cpp、parse.cpp、scan.cpp、util.cpp、scan.h、util.h、globals.h、parse.h,其中scan.cpp和scan.h为词法分析程序。

以下仅列出各个文件中的核心代码：

Main.cpp

#include "globals.h"

#define NO_P ARSE FALSE

#include "util.h"

#if NO_PARSE

#include "scan.h"

#else

#include "parse.h"

#endif

int lineno=0;

FILE * source;

FILE * listing;

FILE * code;

int EchoSource = TRUE;

int TraceScan=TRUE;

int TraceParse=TRUE;

int Error = FALSE;

int main(int argc,char * argv[])

{

TreeNode * syntaxTree;

char pgm[120];

scanf("%s",pgm);

source=fopen(pgm,"r");

if(source==NULL)

{

fprintf(stderr,"File %s not found\n",pgm);

exit(1);

}

listing = stdout;

fprintf(listing,"\nC COMPILA TION: %s\n",pgm); #if NO_PARSE

while(getToken()!=ENDFILE);

#else

syntaxTree = parse();

if(TraceParse){

fprintf(listing,"\nSyntaxtree:\n");

printTree(syntaxTree);

}

#endif

fclose(source);

return 0;

}

Parse.cpp

#include "globals.h"

#include "util.h"

#include "scan.h"

#include "parse.h"

static TokenType token; /* holds current token */

/* function prototypes for recursive calls */

static TreeNode * declaration_list(void);

static TreeNode * declaration(void);

static TreeNode * params(void);

static TreeNode * param_list(void);

static TreeNode * param(void);

static TreeNode * compound_stmt(void);

static TreeNode * local_declarations(void);

static TreeNode * statement_list(void);

static TreeNode * statement(void);

static TreeNode * expression_stmt(void);

static TreeNode * if_stmt(void);

static TreeNode * while_stmt(void);

static TreeNode * return_stmt(void);

static TreeNode * expression(void);

static TreeNode * var(void);

static TreeNode * simple_exp(void);

static TreeNode * additive_expression(void);

static TreeNode * term(void);

static TreeNode * factor(void);

static TreeNode * args(void);

static TreeNode * arg_list(void);

static void syntaxError(char * message)

{ fprintf(listing,"\n>>> ");

fprintf(listing,"Syntax error at line %d: %s",lineno,message); Error = TRUE;

}

/*判断读取的字符*/

static void match(TokenType expected)

{

if(token==expected)

{

token=getToken( );

}

else

{

syntaxError("unexpected token -> ");

printToken(token,tokenString);

fprintf(listing," ");

}

}

/*进行语法分析，构建语法树*/

TreeNode * declaration_list(void)

{

TreeNode * t= declaration();

TreeNode * p= t;

while ((token==INT) || (token==VOID) )

{

TreeNode *q = declaration();

if (q!=NULL) {

if (t==NULL) t = p = q;

else /* now p cannot be NULL either */

{

p->sibling = q;

p = q;

}

}

}

return t;

}

TreeNode * declaration(void)

{ TreeNode * t = NULL;

switch (token)

{

case VOID :

case INT :

t = newStmtNode(DecK);

if(token == INT)

t->type =Integer;

else

t->type = V oid;

match(token);

switch (token)

{

case ID:

t->https://www.360docs.net/doc/474855467.html, = copyString(tokenString);

t->kind.stmt = V arDK;

match(ID);

switch (token)

{

case LZKH:

t->kind.stmt = V arDK;

t->type = IntArray;

match(LZKH);

match(NUM);

match(RZKH);

match(SEMI);

break;

case LPAREN:

t->kind.stmt = FunDK;

match(LPAREN);

t->child[0] = params();

match(RP AREN);

t->child[1] = compound_stmt();

break;

default: match(SEMI);break;

}

break;

default:syntaxError("unexpected token -> ");

printToken(token,tokenString);

token = getToken();

break;

}

break;

default : syntaxError("unexpected token -> ");

printToken(token,tokenString);

token = getToken();

break;

} /* end case */

return t;

}

TreeNode * params(void)

{

TreeNode * t = NULL;

if(token == VOID)

{

match(token);

t = newStmtNode(ParamList);

t->child[0] = newStmtNode(ParamK);

t->child[0]->type = V oid;

}

else if(token == RP AREN)

t=NULL;

else

{

t = param_list();

}

return t;

}

TreeNode * param_list(void)

{

TreeNode * t = newStmtNode(ParamList);

int i = 1;

t->child[0] = param();

while(token != RP AREN)

{

match(DOT);

t->child[i] = param();

i++;

}

return t;

}

TreeNode * param(void)

{

TreeNode * t = NULL;

match(INT);

t= newStmtNode(ParamK);

t->type=Integer;

t->https://www.360docs.net/doc/474855467.html,=copyString(tokenString);

match(ID);

if(token == LZKH)

{

t->type=IntArray;

match(LZKH);

match(RZKH);

}

return t;

}

TreeNode * compound_stmt(void)

{

TreeNode * t = newStmtNode(ComK);

match(LDKH);

t->child[0] = local_declarations();

t->child[1] = statement_list();

match(RDKH);

return t;

}

TreeNode * local_declarations(void)

{

TreeNode * t = newStmtNode(LocalDecK);

int i=0;

while(token == INT || token == VOID)

{

t->child[i] = declaration();

i++;

}

return t;

}

TreeNode * statement_list(void)

{

TreeNode * t = newStmtNode(StmtList);

int i=0;

while(token != RDKH)

{

t->child[i] =statement();

i++;

}

return t;

}

TreeNode * statement(void)

{

TreeNode * t ;

switch (token) {

case IF : t = if_stmt(); break;

case WHILE : t = while_stmt(); break;

case ID :

case SEMI:

t = expression_stmt(); break;

case RETURN : t = return_stmt(); break;

case LDKH : t=compound_stmt();break;

default : syntaxError("unexpected token -> ");

printToken(token,tokenString);

token = getToken();

break;

} /* end case */

return t;

}

TreeNode * expression_stmt(void)

{

TreeNode * t = newStmtNode(ExpstmtK);

if(token == SEMI)

match(SEMI);

else

{

t = expression();

match(SEMI);

}

return t;

}

TreeNode * if_stmt(void)

{

TreeNode * t = newStmtNode(IfK);

if(t!=NULL)

{

match(IF);

match(LPAREN);

t->child[0] = expression();

match(RP AREN);

t->child[1] = statement();

if (token==ELSE)

{

match(ELSE);

if (t!=NULL) t->child[2] = newStmtNode(ElseK);

t->child[2]->child[0] = statement();

} }

return t;

}

TreeNode * while_stmt(void)

{

TreeNode * t = newStmtNode(WhileK);

match(WHILE);

match(LPAREN);

if (t!=NULL) t->child[0] = expression();

match(RP AREN);

if (t!=NULL) t->child[1] = statement();

return t;

}

TreeNode * return_stmt(void)

{

TreeNode * t = newStmtNode(RetK);

if(token == RETURN)

match(RETURN);

if(token == SEMI)

match(SEMI);

else

{

t->child[0] = expression();

match(SEMI);

}

return t;

}

TreeNode * expression(void)

{

TreeNode * t = simple_exp();

return t;

}

TreeNode* var(void)

{

TreeNode* t = newExpNode(IdK);

if ((t!=NULL) && (token==ID))

t->https://www.360docs.net/doc/474855467.html, = copyString(tokenString);

match(ID);

if(token == LZKH)

{

match(token);

t->type = ArrayUnit;

t->child[0] = expression();

match(RZKH);

}

return t;

}

TreeNode * simple_exp(void)

{

TreeNode * t = additive_expression();

if(t!=NULL){

if (token == L T || token == LE|| token == MT || token == ME||token ==EQ||token ==NEQ) {

TreeNode * p = newExpNode(OpK);

if(p!=NULL)

{

p->attr.op = token;

p->child[0] = t;

match(token);

p->child[1] = additive_expression();

t=p;

}

}

}

return t;

}

TreeNode* additive_expression(void)

{

TreeNode * t = term();

while(token == PLUS || token == MINUS)

{

TreeNode * p = newExpNode(OpK);

p->attr.op = token;

p->child[0] = t;

match(token);

p->child[1] = term();

t = p;

}

return t;

}

TreeNode * term(void)

{

TreeNode * t = factor();

while ((token==TIMES)||(token==OVER))

{

TreeNode * p = newExpNode(OpK);

if (p!=NULL) {

p->child[0] = t;

p->attr.op = token;

match(token);

p->child[1] = factor();

t = p;

}

}

return t;

}

TreeNode * factor(void)

{

TreeNode * t = NULL;

switch (token)

{

case NUM :

t = newExpNode(ConstK);

if ((t!=NULL) && (token==NUM))

t->attr.val = atoi(tokenString);

match(NUM);

break;

case ID :

t = var();

if (token == ASSIGN)

{

TreeNode* p = newStmtNode(AssignK);

p->https://www.360docs.net/doc/474855467.html, = t->https://www.360docs.net/doc/474855467.html,;

match(token);

p->child[0] = expression();

t = p;

}

if (token == LP AREN )

{

TreeNode * p = newStmtNode(CallK);

p->https://www.360docs.net/doc/474855467.html, = t->https://www.360docs.net/doc/474855467.html,;

t=p;

match(token);

p->child[0] = args();

match(RP AREN);

}

break;

case LPAREN :

match(LPAREN);

t = expression();

match(RP AREN);

break;

default:

syntaxError("unexpected token -> ");

printToken(token,tokenString);

token = getToken();

break;

}

return t;

}

TreeNode * args(void)

{

TreeNode * t = newStmtNode(ArgList);

if(token != RPAREN)

{

t->child[0] = arg_list();

return t;

}else

return NULL;

}

TreeNode * arg_list(void)

{

TreeNode * t = newStmtNode(ArgK);

int i = 1;

if(token != RPAREN)

t->child[0] = expression();

while(token!=RP AREN)

{

match(DOT);

t->child[i] = expression();

i++;

}

return t;

}

TreeNode * parse(void)

{ TreeNode * t;

token = getToken();

t =declaration_list();

if (token!=ENDFILE)

syntaxError("Code ends before file\n");

return t;

}

scan.cpp

#include "globals.h"

#include "util.h"

#include "scan.h"

/*对扫描的字符进行匹配判断*/ TokenType getToken(void)

{ /* index for storing into tokenString */ int tokenStringIndex = 0;

/* holds current token to be returned */

TokenType currentToken;

/* current state - always begins at START */ StateType state = ST ART;

/* flag to indicate save to tokenString */

int save;

while (state != DONE)

{ int c = getNextChar();

save = TRUE;

switch (state)

{ case START:

if (isdigit(c))

state = INNUM;

else if (isalpha(c))

state = INID;

else if (c == '=')

state = INEQUAL;

else if (c == '<')

state = INLE;

else if (c == '>')

state = INME;

else if ((c == ' ') || (c == '\t') || (c == '\n')) save = FALSE;

else if (c== '!')

state = INNEQ;

else if (c == '/')

{

if(getNextChar()!='*')

{

ungetNextChar();

state = DONE;

currentToken = OVER;

break;

}

else

{

save = FALSE;

state = INCOMMENT;

}

}

else

{ state = DONE;

switch (c)

{ case EOF:

save = FALSE;

currentToken = ENDFILE;

break;

case '+':

currentToken = PLUS;

break;

currentToken = MINUS;

break;

case '*':

currentToken = TIMES;

break;

case '(':

currentToken = LP AREN;

break;

case ')':

currentToken = RP AREN;

break;

case ';':

currentToken = SEMI;

break;

case '[':

currentToken=LZKH;

break;

case ']':

currentToken=RZKH;

break;

case '{':

currentToken=LDKH;

break;

case '}':

currentToken=RDKH;

break;

case ',':

currentToken=DOT;

break;

default:

currentToken = ERROR;

break;

}

}

break;

case INCOMMENT:

save = FALSE;
