在线考试系统JAVA
题目在线考试系统
1、实验目的
①熟练运用JAVA开发环境及工具、并用JAVA语言编写程序;
②掌握面向对象的概念;
③掌握系统功能模块的合理划分,并实现各模块接口的连接;
④掌握C/S结构的编程方法;
⑤设计数据库模型。
2、实验容
①编辑生成试题库,随机生成本次考试试题,同时提供在线评分并保存结果。
②选择ACCESS作为后台的数据库。
3、实验过程
3.1
题库管理:用于对单个试题的增、删、改、查等基本维护,还可对题库进行数据备份和数据还原。我们针对不同题型、不同应用围及不同科目对试题进行维护。试卷管理:可进行三种组卷方式的维护:随机组卷、人工组卷、综合组卷。还可对考生的基本信息进行维护。
考试管理:对考试分配试卷,并对考试的基本信息进行维护。相当于人工安排考试的过程
评卷管理:对试卷的客观题分配评卷人,并对评卷人基本信息进行管理。
成绩管理:对每次考试的学生成绩的基本信息进行维护,并提供学生成绩的统计管理。
用户管理:对使用本系统的用户基本信息进行维护,用户多数为:系统管理员、
老师、教务处人员、其他
权限管理:对系统的访问权限进行管理,并对用户可进行权限的分配。
系统应该具备的基本功能 各模块需完成以下功能:
题型维护:对试题的题型进行增、删、改、查操作。在操作之后会自动刷新主页,以使信息更新。
围维护:对试题的应用围进行增、删、改、查操作。在操作之后会自动刷新主页,以使信息更新。
科目维护:对试题的科目进行增、删、改、查操作。在操作之后会自动刷新主页,以使信息更新。
试题维护:对试题的基本信息进行增、删、改、查操作。在操作之后会自动刷新主页,以使信息更新。
其他维护:对试题信息的批量查询,并可进行数据导出、数据备份、数据恢复。
随机组卷:用户只需对试卷题型进行设置就可组卷的方式。 人工组卷:可使用户选择试卷的题型中的试题的组卷方式。 综合组卷:是随机组卷与人工组卷的混合组卷方式,即用户对某一类型的试题可进行选择,也可对试题不进行选择。
试卷其他维护:对试卷信息的批量查询,对试题的数据备份与还原。
护。
评卷人评卷:对分配试卷的评卷人可以在此进行评卷。 考生成绩维护:对考试的考生成绩信息进行统计与汇总,对有权限的人可进行成绩的增、删、改、查操作。
成绩其他维护:对考生成绩信息的批量查询,并可进行数据导出、数据备份、数据恢复。
删、改、查操作。
信息基本维护:我们的信息除了有关考试的信息外,还有公告、新闻、留言信息需要我们维护,其中公告、新闻由后台有权限的人进行增、删、改、查操作,而留言是由前台的用户(学生)或游客录入的,我们要防止垃圾数据显示,即对留言有权更改等操作。
3.2系统结构图
○1、本系统分为学生前台子系统和考试管理子系统,整个系统的结构图如下:
3.3 数据库设计
试题类型表(questionType_table):其中包括了试题的类型的基本信息,如类型名称、答题方式、说明信息等字段;录入时,我们将答题方式确定为大概几种类型:填空方式,选择方式,问答方式,判断方式,综合方式。
试题围表(questionBound_table):用于控制试题应用的围,如同样的科目语文,在小学、初中、高中、大学都有,由此我们设定了此表,此表中有围名称、围说明等基本信息;
所属科目表(questionSubject_table):用于录入试题相关的科目应用,它可以有不同的应用围。如上所述,我们只需录入一次的科目,就可方便我们在录入试题时每次都录。各种题库表:我们采用一种类型的题存储在一个表中,由此我们
会有填空题表(question_blanc_table)、单选题表
(question_selectone_table)、多选题表(question_selectMany_tabel)一题多问表(question_askone_table)、一题多问表(question_askMany_table)、判断题表(question_judge_table)等试题表
试卷表(exam_table):用于报存考试中试卷的基本信息,如出卷方式(有随机出卷、人工出卷、综合出卷)、试卷名称、试卷应用围(与试题围相对应)、试卷所属科目(与试题科目相对应)、试题标题级别、试题标题容、试题总类型、试题个数、试题总ID等基本信息。
学生表(student_table):用于保存学生的考试的用户名及登陆密码。
成绩表(grade_table):用于存储学生的考试成绩。
评题表(appraiser_question_table):对于主观题的答案我们须要评卷人(有权限的用户)进行手工评卷,本表用来存储评卷人评卷的一些信息。
答案表(student_answer_table):用于存储学生问答题的答案,如试卷ID,学生ID及各种试题类型的答案字段。
用户表(user_table):用于保存用户的登陆的基本信息及分配的权限。
权限表(purview_table):用于存储用户组织的的权限,通过分配操作模块的权限组织权限。
4、关键代码及其分析
4.1----------------ServerGui.java------------------
public void actionPerformed(ActionEvent e) { if (e.getSource() == log) { // boolean b=login();
String username =
JOptionPane.showInputDialog(this, "请输入用户名",
"输入用户名", JOptionPane.QUESTION_MESSAGE).tri m();
String password = JOptionPane.showInputDialog(this, "请输入密码",
"输入密码", JOptionPane.QUESTION_MESSAGE).tri m();
if (username == null || password == null) {
username = "temp";
password = "temp";
return;
}
adminCheck(username, password);// 验证管理员
if (tf == true) {
JOptionPane.showMessageDialog( this, "登陆成功!", "成功",
https://www.360docs.net/doc/9a15539285.html,RMATION_MESS AGE);
toolBar1.setVisible(true);
split_one.setVisible(true);
} else {
JOptionPane.showMessageDialog( this, "登陆失败!", "失败",
JOptionPane.ERROR_MESSAGE);
return;
}
} else if (e.getSource() == setCount) {
userCount =
JOptionPane.showInputDialog(this, "请输入本次考试的人数");
inittest(); // 数据库信息初始化
} else if (e.getSource() == startSer) {
if (settime == true && setcount == true) {
new ServerManager();
serArea.append("服务器已启动\n预设考试人数为:" + userCount + "\n考试时间为:"
+ timeCount + "\n");
start = true;
} else {
JOptionPane.showMessageDialog( this, "你还没有设置考试信息", "警告信息",
https://www.360docs.net/doc/9a15539285.html,RMATION_MESS AGE);
}
} if (start == true)
{
linkArea.append(ServerManager
.linkShow(ServerManager.linkstatu s)
+ "\n");
} else {
JOptionPane.showMessageDialog( this, "服务器还没有启动不能进行操作", "警告信息",
https://www.360docs.net/doc/9a15539285.html,RMATION_MESS
AGE);
}
} else if (e.getSource() == userButton) {
if (start == true)
{
userArea.append(ServerManager
.userShow(https://www.360docs.net/doc/9a15539285.html,erstat us)
+ "\n");
userArea.append(ServerManager.c ountShow(ServerManager.ucount));
} else {
public void adminCheck(String s1, String s2)
ConnectBean cb=new ConnectBean();
if (!cb.openConnection()) {
System.out.println("连接数据失败");
System.exit(1);
return;
}
4.2-----------------Server_login.java----------------- // 定义一个接收用户登陆的类
public void run() {
String s = null; try {
s = in.readUTF(); // 接收考
试号和密码,然后分别取出
StringTokenizer st = new StringTokenizer(s, ",");
if (st.hasMoreTokens()) {
str1 = st.nextToken();
str2 = st.nextToken();
System.out.println("username :" + str1);
System.out.println("password :" + str2);
}
} catch (IOException e) {
e.printStackTrace();
}
// 读取数据库里的用户信息并进行验证
try {
ConnectBean cb = new ConnectBean();
if (!cb.openConnection()) {
System.out.println("连接数据失败");
System.exit(1);
return;
}
cb.createPreparedStatement("selec t flag from stuinfo where sno='"
+ str1 + "'
ResultSet r = cb.executeQuery();
String m ="";
while (r.next()) {
m=r.getString("flag");
}
System.out.println("标识:"+m);
if ( !m.equals("0") ) {
out.writeUTF("用户已经完成考试,不能再考试");
} else {
cb.createPreparedStatement(
"select sname,spass from stuinfo where sno='" + str1
+ "'", false);
ResultSet rs = cb.executeQuery();
while (rs.next()) {
dbn = rs.getString("sname");
dbp = rs.getString("spass");
System.out.println("用户: " + str1 + " 你的用户名为:" + dbn
+ ", 你的密码为:" + dbp);
}
// 验证用户密码,如果登录成功将登录标志设为1
if
(str2.equals(dbp.trim())) {
out.writeUTF("用户" + dbn + " 登陆成功");
System.out.println("用户" + dbn + " 登陆成功");
out.close();
String sql1 =
"update stuinfo set flag = '1' where sno= '"+str1+"'";
PreparedStatement ps = cb.createPreparedStatement(sql1);
ps.executeUpdate();
System.out.println("用户成功登录");
}
else {
out.writeUTF("密码错误");
System.out.println("登陆密码错误");
out.close();
}
cb.close();
4.3-----------------ServerManager.java----------------
public ServerManager() {
Thread td1 = new Thread() {
public void run() {
serstatus= "login thread start!\n";
serShow(serstatus);
ServerSocket ss1 = null;
Socket you = null;
int port1 = 8001;
try {
ss1 = new ServerSocket(port1);
serstatus = "listener the port:" + port1;
serShow(serstatus);
} catch (IOException e) {
e.printStackTrace();
}
while (true) {
try {
you = ss1.accept();
} catch (IOException e) {
e.printStackTrace();
}
if (you != null) {
counter++;
ucount = "现在参加考试的人数为:" + counter;
countShow(ucount);
if (counter < Maxcount) {
userstatus= "user's IP" + you.getInetAddress()
+ " connected " + port1 + "进行登陆";
userShow(userstatus);
// 第一个
线程启动
new Server_login(you).start();
} else {
userstatus = "user's IP" + you.getInetAddress()
+ " connected " + port1 + "中断线程启动";
userShow(userstatus);
// 中断线程启动
new Maxcounter(you);
};
td1.start();
// 启动一个响应客户端读取试题的线程
Thread td2 = new Thread("two") {
public void run() {
serstatus= "thread 2 start!";
serShow(linkstatus);
ServerSocket ss2 = null;
int port2 = 8002;
try {
ss2 = new ServerSocket(port2);
linkstatus = "listener the port:" + port2;
linkShow(serstatus);
} catch (IOException e) {
e.printStackTrace();
}
while (true) {
Socket you2 = null;
try {
you2 = ss2.accept();
} catch (IOException e) {
e.printStackTrace();
}
if (you2 != null) {
userstatus = "user's IP" + you2.getInetAddress()
+ " connected " + port2 + "进行读题";
userShow(userstatus);
new
Server_readTest(you2).start();
}}}
};
td2.start()
// 启动一个接收用户答应并存储的线程
Thread td3 = new Thread("three") {
ServerSocket ss3 = null;
int port3 = 8003;
public void run() {
serstatus="thread 3 start!";
serShow(serstatus);
try {
ss3 = new ServerSocket(port3);
linkstatus="listener the port:" + port3;
linkShow(linkstatus);
} catch (IOException e) {
e.printStackTrace();
}
while (true) {
Socket you3 = null;
try {
you3 = ss3.accept();
} catch (IOException e) {
e.printStackTrace();
}
if (you3 != null) {
userstatus="user's IP" + you3.getInetAddress()
+ " connected " + port3 + "提交答案";
userShow(userstatus);
// 第3个线程启动
new
Server_readScore(you3).start();
}
}
}
};
td3.start();
// 启动一个用户查询的线程
Thread td4 = new Thread("four") {
ServerSocket ss4 = null;
int port4 = 8004;
public void run() {
serstatus="thread 4 start!";
serShow(serstatus);
try {
ss4 = new ServerSocket(port4);
linkstatus="listener the port:" + port4;
linkShow(linkstatus);
} catch (IOException e) {
e.printStackTrace();
}
while (true) {
Socket you4 = null;
try {
you4 = ss4.accept();
} catch (IOException e) {
e.printStackTrace();
}
if (you4 != null) { userstatus="user's IP" + you4.getInetAddress()
+ " connected " + port4 + "进行查询";
userShow(userstatus);
4.4-------------Server_readTest.java----------------
public void run() {
String sql2; // 定义查询语句
String dbt = "以下为试题"; // 试题
String ts = null; // 接收用户发送的考试科目
int tcount = 0; // 试题的数目
try {
// 网络连接部分
out.writeUTF("你连接成功");
ts = in.readUTF();
System.out.println(ts);
// 数据库连接部分
// 查询客户端所选试题
ConnectBean cb = new ConnectBean();
if (!cb.openConnection()) {
System.out.println("连接数据失败");
System.exit(1);
return;
}
//在数据库选题
sql2 = "select * from exam where eid='" + ts + "'";
cb.createPreparedStatement(sql2, false);
ResultSet rs = cb.executeQuery();
while (rs.next()) {
dbt += "^"+"\n"+rs.getString(2) +
"\t" + "\n" + rs.getString(3) +" ^";
tcount++;
}
cb.close();
System.out.println(dbt);
System.out.println(tcount);
out.writeUTF(Integer.toString(tcou nt));
out.writeUTF(dbt); // 将读到的试题返回到客户端
//传送考试时间
out.writeUTF(""+Timecount);
out.flush();
out.close();
System.out.println("读取试题成功!!");
} catch (SQLException e) {
e.printStackTrace();
System.out.println("not connect db");
} catch (IOException e1) {
System.out.println("not read client select!");
}
}
4.5--------------/Server_readScore.java------------------
// 定义一个接收用户答案的类,判断对错,将分数返回到用户端,并将成绩存入数据库
public Server_readScore(Socket socket) {
// ----------------------创建网络连接----------------------------------//
this.socket = socket; .........
public void run() {
// ------------------------- 接收用户提交的答案---------------------------//
try {
readkey = in.readUTF();
System.out.println(readkey);
} catch (IOException e1) {
e1.printStackTrace();
}
StringTokenizer stc = new StringTokenizer(readkey, ",");
if (stc.hasMoreTokens()) {
// 客户传来答案的第一个字符为用户名,第二个字符为考试科目
str1 = stc.nextToken().trim();
System.out.println("用户为:" + str1);
uno = Integer.parseInt(str1);
}
if (stc.hasMoreTokens()) {
//第二个字符为考试科目
str2 = stc.nextToken().trim();
System.out.println("试题类型为:" + str2);
}
................
// ------------------------------在数据库获取正确答案-------------------------//
try {
ConnectBean cb = new ConnectBean();
if (!cb.openConnection()) {
System.out.println("连接数据失败");
System.exit(1);
return;
}
..............
}
// ------------------------判断分数---------------------------------//
for (int i = 0; i if
