环形加热炉安装施工方案Document Title:Erection Method Statement for Mechanical & Steel Structure of Rotate Hearth Furnace (RHF)AMTPJSaudi ArabLIU JUNHONG YAO YONG LU HAITAOINTRODUCTION本方案根据RHF的设备图纸和LOI(天津)提供的安装说明(Erection manual)编制的,安装标准采用DIN标准。

AMTPJ Rotate Hearth Furnace(RHF)是钢坯连续加热炉。

RHF床绕炉中心旋转,被加热件从进料炉门装入并在炉内分阶段加热后,从出料炉门处取出。

进、出料炉门相邻,在炉膛内两门以隔墙相隔。

RHF由转动炉底和固定炉墙、炉顶组成。

结构上沿炉子圆周方向上共分9个区段,自出钢机端依次为:装出料区(12°)、热回收段(46.25°)、第一预热段(35°)、第二预热段(35°)、第一加热段(35°)、第二加热段(55°)、第三加热段(55°)、第一均热段(35°)、第二均热段(32.5°)。

RHF基本尺寸:中径:Φ4500 mm炉膛宽度:6228 mm炉底有效宽度:5780 mm预热段、第一、二、三加热段炉膛高度:2800 mm第一、二、三加热炉膛高度:2200 mm;第一、二均热段炉膛高度:1500mm RHF设备安装范围包括:环形旋转炉床,炉底支承辊、定心辊、驱动装置,炉体钢结构,加热烧嘴,进、出料炉门,水封装置以及其他辅助设备。

施工方法和具体步骤1.1. 施工工序流程图设备基础验收中心标板和标高基准点设置安装工艺垫板施工内、外支承辊、定心辊、驱动装置安装下层炉底钢结构安装内、外立环柱安装上层炉底钢结构安装炉底机械部分试运转耐火材料砌筑水封槽安装1.2. 平面布置图见附图1.3. RHF中心标板、基准点的埋设布置1.3.1.永久中心标板和永久标高点: 制作样式如下:永久中心标板永久标高点1.3.2.环炉区域临时中心标板:不等边角钢75×50×5,长度150mm。
