图像处理专业词汇+图像处理专业英语
最近学Matrox Imaging Library很头疼,全英文的书1000多页,考验我啊!搜集了很多图像处理的专业词汇,希望对有缘人有点小帮助。等我把整本书学完,我会总结全书的词汇,小试着翻译一下,呵呵。。。。gushan 09-25/09
Good luck!
FFT 滤波器 FFT filters VGA 调色板和许多其他参数 VGA palette and many others
按名称排序 sort by name
包括角度和刻度 including angle and scale
保持目标 keep targets
保存 save
保存和装载 save and load
饱和度 saturation
饱和加法和减法 add and subtract with saturate
背景淡化 background flatten
背景发现 find background
边缘和条纹测量 Edge and Stripe/Measurement
边缘和条纹的提取 find edge and stripe
编辑 Edit
编辑 edit
编辑或删除相关区域 edit or delete relative region 编码 Code
编码条 Coda Bar
变换 forward or reverse fast Fourier transformation 变量和自定义的行为 variables and custom actions
变量检测 examine variables
变形 warping
变形系数 warping coefficients
标题 tile
标注和影响区域 label and zone of influence
标准 normal
标准偏差 standard deviation
表面弯曲 convex
并入图像 merge to image
采集栏 digitizer bar
采集类型 grab type
菜单形式 menu item
参数 Preferences
参数轴和角度 reference axis and angle
测量 measurement
测量方法提取 extract measurements from
测量结果显示和统计 display measurement results and statistics
测量转换 transfer to measurement
插入 Insert
插入 insert
插入条件检查 Insert condition checks
查找最大值 find extreme maximum
长度 length
超过50 个不同特征的计算 calculate over 50 different features area 撤销 undo
撤销次数 number of undo levels
乘 multiply
尺寸 size
抽取或融合分量红 red/
处理 Processing
处理/采集图像到一个新的窗口 processed/grabbed image into new window 窗口 window
窗口监视 watch window
窗位 window leveling
创建 create
垂直边沿 vertical edge
从 Windows
从表格新建 new from grid
从工具条按钮 from toolbar button
从用户窗口融合 merge from user form
粗糙 roughness
错误纠正 error correction
错误匹配 fit error
打开 open
打开近期的文件或脚本 open recent file or script
打印 print
打印设置 print setup
打印预览 print preview
大小和日期 size and date
带通 band pass
带有调色板的8- bit
带有动态预览的直方图和x, y 线曲线椭圆轮廓 histogram and x, y line curve ellipse profiles with dynamic preview
带阻 band reject
代码类型 code type
单步 single step
单一 simple
单帧采集 snap shot
导入 VB
等等 etc.
低通 low pass
第一帧 first
点 point
调色板预览 palette viewer
调试方式 debug mode
调用外部的 DLL
调整大小 resize
调整轮廓滤波器的平滑度和轮廓的最小域值 adjust smoothness of contour filter and minimum threshold for contours
定点除 fixed point divide
定位精度 positional accuracy
定义一个包含有不相关的不一致的或无特征区域的模板 define model including mask for irrelevant inconsistent or featureless areas
定制制定-配置菜单 Customize - configure menus
动态预览 with dynamic preview
读出或产生一个条形或矩阵码 read or generate bar and matrix codes
读取和查验特征字符串 erify character strings
断点 break points
对比度 contrast
对比度拉伸 contrast stretch
对称 symmetry
对模板应用“不关心的”像素标注 apply don't care pixel mask to model
多边形 polygon
二进制 binary
二进制分离 separate binary
二值和灰度 binary and grayscale
翻转 reverse
返回 return
放大或缩小7 个级别 zoom in or out 7 levels
分类结果 sort results
分水岭 Watershed
分析 Analysis
分组视图 view components
腐蚀 erode
复合视图 view composite
复合输入 combined with input
复制 duplicate
复制 duplicateselect all
傅立叶变换 Fourier transform
改变热点值 change hotspot values
感兴趣区域 ROI
高级几何学 Advanced geometry
高通 high pass
格式栏 formatbar
更改默认的搜索参数 modify default search parameters 工具 Utilities
工具栏 toolbar
工具属性 tool properties
工具条 toolbar
工作区 workspace bar
共享轮廓 shared contours
构件 build
构造表格 construct grid
关闭 close
和逆 FFT
画图工具 drawing tools
缓存 buffer
换算 convert
灰度 grayscale
恢复目标 restore targets
回放 playback
绘图连结 connect map
获得/装载标注 make/load mask
获取选定粒子 draw selected blobs
或从一个相关区域创建一个 ROI or create an ROI from a relative region
基线 score
基于校准映射的畸变校正 distortion correction based on calibration mapping 极性 polarity
极坐标转换 polar coordinate transformation
几何学 Geometry
记录 record
加粗 thick
加法 add
间隔 spacing
间距 distance
兼容 compatible
简洁 compactness
剪切 cut
减法 subtract
减小缩进 outdent
交互式的定义字体参数包括搜索限制 ine font parameters including search constraints 脚本栏 script bar
角度 angle
角度和缩放范围 angle and scale range
接收和确定域值 acceptance and certainty thresholds
结果栏 result bar
解开目标 unlock targets
精确度和时间间隔 accuracy and timeout interval
矩形 rectangle
矩形 rectangular
绝对差分 absolute difference
绝对值 absolute value
均匀 uniform
均值 average
拷贝 copy
拷贝序列 copy sequence
可接收的域值 acceptance threshold
克隆 clone
控制 control
控制 controls
快捷健 shortcut key
宽度 breadth
宽度 width
拉普拉斯 Laplacians
拉伸 elongation
蓝 blue
类型 type
粒子 Blob
粒子 blob
粒子标注 label blobs
粒子分离 segment blobs
粒子内的孔数目 number of holes in a blob 亮度 brightness
亮度 luminance
另存为 save as
滤波器 filters
绿 green
轮廓 profile overlay
轮廓极性 contour polarity
逻辑运算 logical operations
面积 area
模板编辑 edit model
模板覆盖 model coverage
模板和目标覆盖 model and target coverage 模板索引 model index
模板探测器 Model Finder
模板位置和角度 model position and angle 模板中心 model center
模糊 mask
模块 import VB module
模块 modules
模式匹配 Pattern matching
默认案例 default cases
目标 Targets
目标分离 separate objects
目标评价 target score
欧拉数 Euler number
盆 basins
膨胀 dilate
匹配率 match scores
匹配数目 number of matches
平方和 sum of the squares
平滑 smooth
平均 average
平均 averaged
平均值 mean
平移 translation
前景色 foreground color
清除缓冲区为一个恒量 clear buffer to a constant
清除特定部分 delete special
区域增长 region-growing ROI
取反 negate
全部删除 delete all
缺省填充和相连粒子分离 fill holes and separate touching blobs
任意指定位置的中心矩和二阶矩 central and ordinary moments of any order location: X, Y
锐化 sharpen
三维视图 view 3D
色度 hue
删除 delete
删除帧 delete frame
设置 settings
设置相机类型 enable digitizer camera type
设置要点 set main
示例 demos
事件发现数量 number of occurrences
事件数目 number of occurrences
视图 View
收藏 collectionDICOM
手动 manually
手绘曲线 freehand
输出选项 output options
输出选择结果 export selected results
输入通道 input channel
属性页 properties page
数据矩阵 DataMatrix
数字化设置 Digitizer settings
双缓存 double buffer
双域值 two-level
水平边沿 horizontal edge
搜索 find
搜索和其他应用 Windows Finder and other applications 搜索角度 search angle
搜索结果 search results
搜索区域 search area
搜索区域 search region
搜索速度 search speed
速度 speed
算法 arithmetic
缩放 scaling
缩放和偏移 scale and offset
锁定目标 lock destination
锁定实时图像处理效果预览 lock live preview of processing effects on images 锁定预览 Lock preview
锁定源 lock source
特定角度 at specific angle
特定匹配操作 hit or miss
梯度 rank
替换 replace
添加噪声 add noise
条带直径 ferret diameter
停止 stop
停止采集 halt grab
同步 synchronize
同步通道 sync channel
统计 Statistics
图像 Image
图像大小 image size
图像拷贝 copy image
图像属性 image properties
图形 graph
退出 exit
椭圆 ellipse
椭圆 ellipses
外形 shape
伪彩 pseudo-color
位置 position
文本查看 view as text
文件 File
文件 MIL MFO font file
文件 load and save as MIL MMF files
文件 load and save models as MIL MMO files OCR
文件中的函数 make calls to functions in external DLL files 文件转换器 file converterActiveMIL Builder ActiveMIL Builder 无符号抽取部分 Extract band -
细化 thin
下一帧 next
显示表现字体的灰度级 ayscale representations of fonts
显示代码 show code
线 lines
相对起点 relative origin
像素总数 sum of all pixels
向前或向后移动 Move to front or back
向上或向下 up or down
校准 Calibration
校准 calibrate
新的/感兴趣区域粘贴 paste into New/ROI
新建 new
信息/ 图形层 DICOM information/overlay
形态 morphology
行为 actions
修改 modify
修改路径 modify paths
修改搜索参数 modify default search parameters 序列采集 sequence
旋转 rotation
旋转模板 rotate model
选择 select
选择 selector
循环 loops
移动 shift
应用过滤器和分类器 apply filters and classifiers
影响区域 zone of influence
映射 mapping
用户定义 user defined
用基于变化上的控制实时预览分水岭转化结果阻止过分切割 live preview of resulting watershed transformations with control over variation to prevent over segmentation
用某个值填充 fill with value
优化和编辑调色板 palette optimization/editor
有条件的 conditional
域值 threshold
域值 thresholding
预处理模板优化搜索速度循环全部扫描 preprocess model to optimize search speed circular over-scan
预览 previous
元件数目和开始(自动或手动) number of cells and threshold auto or manual
元件最小/最大尺寸 cell size min/max
源 source
允许的匹配错误率和加权 fit error and weight
运行 run
在目标中匹配数目 number of modelmatches in target
暂停 pause
增大缩进 indent
整数除 integer divide
正 FFT
正常连续 continuous normal
支持象征学 supported symbologies: BC 412
直方图均衡 histogram equalization
执行 execute
执行外部程序和自动完成 VBA only execute external programs and perform Automation VBA only
指定 specify
指数 exponential Rayleigh
中值 median
重复 repeat
重建 reconstruct
重建和修改字体 restore and modify fonts
重新操作 redo
重心 center of gravity
周长 perimeter
注释 annotations
转换 Convert
转换 convert
装载 load
装载和保存模板为 MIL MMO
装载和另存为 MIL MFO
装载和另存为 MIL MMF
状态栏 status bar
资源管理器拖放图像 drag-and-drop images from Windows ExplorerWindows 自动或手动 automatic or manual
自动或手动模板创建 automatic or manual model creation
字符产大小 string size
字符串 string
字体 font
最大 maximum
最大化 maximum
最大数 maxima
最后一帧 last frame
最小 minimum
最小化 minimum
最小间隔标准 minimum separation criteria
最小数 minima
坐标盒的范围 bounding box coordinates
scene 景,场景
enhancement 增强
wherein 在那(哪)方面
radiance光辉,发光intensity强度
comprise包含,构成
sensor传感器,感应器comparable可比的underappreciated认识不足的novice新手,初学者engineer 设计,策划spreadsheet电子表格constraint约束,限制impose施加
camcorder手持摄像机monochrome单色的
ambient周围的
spectrum频谱,光谱
strobe闪光
decent 得体的,适当的contrast对比度,反差photometric光度的calibration校准
matte表面粗超的
specularly镜面反射地diffuse扩散的,散开的acquisition获取
