C O N F I D E N T I A LTHIS DOCUMENT MUST NOT BE REPRODUCED OR CIRCULATED TO THE THIRD PARTIESWITHOUT PRIOR WRITTEN CONSENT BY FIAT AUTO S.P.A. IN CASE OF DISPUTEnormazioneCodeCh.-2TMD-5044914 June 2000MATERIALSTANDARDSCRATCH HARDNESS/SURFACE ABRASION TEST FOR PAINTS AND/OR PLASTIC BACKING USING BRUSH TESTER1/5PUBLISHED BY SATIZ - NORMAZIONETHE ONLY VALID REFERENCE IS THE ORIGI

N

AL ITALIAN EDITION

ANY HARD COPY IN YOUR POSSESSION SHOULD BE CONSIDERED NOT UP-TO-DATE. SEE RELEVANT WEB SITE FOR UP-TO-DATE DOCUMENT

PURPOSEThis Standard covers a method for testing scratch hardness using equipment for simulating rotary brushcar washing.

This Standard consists of 5 pages.=Feb. '89Edition 1-New.(BM)=14.06.00Edition2-Completely revised.(FD)PageChange504492

PUBLISHED BY SATIZ - NORMAZIONEC O N F I D E N T I A LTHIS DOCUMENT MUST NOT BE REPRODUCED OR CIRCULATED TO THE THIRD PARTIESWITHOUT PRIOR WRITTEN CONSENT BY FIAT AUTO S.P.A. IN CASE OF DISPUTETHE ONLY VALID REFERENCE IS THE ORIGI

N

AL ITALIAN EDITION

| § ``A'' : TEST EQUIPMENT A-1)Brush tester, paint and/or plastic backing scratch hardness.NOTE:Equivalent test equipment may be substituted but must be equal or superior in performance. Anytest equipment indicated in the documents listed in § 󰀚B" below shall be added to that indicatedabove.

| § ``B'' : REFERENCES|9.55772|Non-metallic synthetic enamels for motor vehicle body paintwork. CMD|9.55776/01|Two-coat metallic enamels for passenger car and derivative vehicle bodies.CMD

|9.55776/02|Two-coat synthetic nonĆmetallic enamels for automotive bodywork. CMD|9.55777|Enamels for plastic components. CMD|9.55778/01|OneĆcoat nonĆmetallic enamel for van body painting. CMD|9.55842/01|Painting of plastic parts. CMD|9.03140/09|Transparent painted plastic external pillar trim. CCA

| § ``C'' : ANNEXES| =|================PageChange504493

PUBLISHED BY SATIZ - NORMAZIONEC O N F I D E N T I A LTHIS DOCUMENT MUST NOT BE REPRODUCED OR CIRCULATED TO THE THIRD PARTIESWITHOUT PRIOR WRITTEN CONSENT BY FIAT AUTO S.P.A. IN CASE OF DISPUTETHE ONLY VALID REFERENCE IS THE ORIGI

N

AL ITALIAN EDITION

| § ``D'' : DESCRIPTION OF TEST EQUIPMENTD/1PAINT AND/OR PLASTIC BACKING SCRATCH HARDNESS TESTERTester (ref. § A-1) is shown schematically below.

SCRATCH HARDNESS TESTER

SpecimenBrush movementSpecimen carĆriage

Spray nozzlesRotation

speedcontrol

Water linePumpPageChange504494

PUBLISHED BY SATIZ - NORMAZIONEC O N F I D E N T I A LTHIS DOCUMENT MUST NOT BE REPRODUCED OR CIRCULATED TO THE THIRD PARTIESWITHOUT PRIOR WRITTEN CONSENT BY FIAT AUTO S.P.A. IN CASE OF DISPUTETHE ONLY VALID REFERENCE IS THE ORIGI

N

AL ITALIAN EDITION

1

SCOPETest provides an accelerated means of simulating effects of washing vehicle using rotary brush equipĆment.

2PRELIMINARY OPERATIONS2.1Specimen preparation

2.1.1Prepare specimens with dimensions 150 x 70 or 100x 200 mm from painted components (plastic compoĆnents and metal and/or plastic backing) as per Procurement Specifications 9.55772, 9.55776/01,9.55776/02,9.55777, 9.55778/01, 9.55842/01, and 9.03140/09.

3TEST PROCEDURE3.1Test environment (unless otherwise specified)

Temperature :23 ± 5 °CAtmospheric pressure :860 to 1060 mbarRelative humidity :45 to 70 %

3.2Using pulse counter, set the number of times which painted specimen is to be brushed. If not otherwiseindicated on applicable Procurement Specification, specimen shall be subjected to a total of 80 passes,including 50 with automotive detergent and 30 with mains water.

NOTE:Each, pass corresponds to one complete brush stroke forward and backward. Brushes shall bechanged every 500 hours of operation. Quality of bristle material is guaranteed by Supplier.

3.3Position specimen in seat on tester.

3.4Set spray pump and brush rotation selectors to automatic position.

3.5Using solenoid valve-controlled pneumatic cylinder, bring brush into contact with specimen.

3.6Start brush rotation, spray pump and specimen carriage forward-back movement (brush thrust on speĆcimen is provided by a 7 kg mass).

3.7Upon reaching set number of passes, stop pump, brush rotation and specimen carriage.

3.8Remove specimen and blow dry with compressed air.
