使用nfsen+sflow+netflow分析网络流量

使用nfsen+sflow+netflow分析网络流量一.前言因为发现有一台hp交换器的负载特别高，但要找出那个IP 造成的，单以tcpdump 分析起来会很难发现问题，因此想要利用hp 交换机具有的sflow功能并搭配nfsen 来分析sflow 结果，如此可以帮助我们分析网络中的流量组成，抓取实施带宽使用情况，帮我找出"hog"。

最终也让我达到目的，感谢open source 相关组织及多位不计付出的IT 前辈。

需求系统及软件OS: CentOS 6.8 X64 / CentOS 7.6 X64nginx-1.9.15.tar.gzphp-7.1.15.tar.bz2nfdump-1.6.13.tar.gznfsen-1.3.7.tar.gz二.下载资源/download/download/nginx-1.9.15.tar.gz/nfsen/nfsen-1.3.7.tar.gz/project/nfdump[注]/nfsen预设下载的版本是 1.3.6p1 ，但这个版本我在centos 6.8 及7.3 都发生相同的错误，也许是运气不佳，但使用nfsen-1.3.7.tar.gz 到是没什么问题三.ngnix 及php 的安装相关rpm 安装yum -y install gcc-c++ pcre pcre-devel zlib zlib-devel openssl openssl-develyum -y install libxml2 install libxml2-devel openssl openssl-devel \curl curl-devel libjpeg libjpeg-devel libjpeg libjpeg-devel libpng \libpng-devel freetype freetype-devel pcre pcre-devel libxslt \libxslt-devel bzip2 bzip2-devel libxslt libxslt-devel[ngnix 安装]useradd wwwtar -xvf nginx-1.9.15.tar.gzcd nginx-1.9.15/configure --prefix=/ap/nginx＃＃你可以不加--prefix这这参数，这样会安装在/usr/loca/ngnix 目录下make && make install[ ngnix.conf 设定档修改](1)user www www; ##必须加上group 否则会有nginx: [emerg]getgrnam("www") failed in ... 错误(2)location / {root html;index index.php index.html index.htm;}(3)location ~ \.php$ {root html;fastcgi_pass 127.0.0.1:9000;fastcgi_index index.php;fastcgi_param SCRIPT_FILENAME /php$fastcgi_script_name;include fastcgi_params;}[php-fpm]tar -xvf php-7.1.15.tar.bz2cd php-7.1.15./configure --prefix=/usr/local/php --with-curl --with-freetype-dir --with-gd --with-gettext \--with-iconv-dir --with-kerberos --with-libdir=lib64 --with-libxml-dir --with-mysqli --with-openssl \--with-pcre-regex --with-pdo-oci=instantclient,/usr/instantclient,11.2 \--with-pdo-mysql --with-pdo-sqlite --with-pear \--with-png-dir --with-jpeg-dir --with-xmlrpc --with-xsl --with-zlib \--with-bz2 --with-mhash --enable-fpm --enable-bcmath --enable-libxml \--enable-inline-optimization --enable-gd-native-ttf --enable-mbregex \--enable-mbstring --enable-opcache --enable-pcntl --enable-shmop \--enable-soap --enable-sockets \--enable-sysvsem --enable-sysvshm --enable-xml --enable-zipmake && make installcp php.ini-development /usr/local/php/lib/php.inicp /usr/local/php/etc/php-fpm.conf.default /usr/local/php/etc/php-fpm.confcp sapi/fpm/php-fpm /usr/local/bincp /usr/local/php/etc/php-fpm.d/www.conf.default /usr/local/php/etc/php-fpm.d/www.conf[edit /usr/local/php/lib/php.ini]cgi.fix_pathinfo=0date.timezone = Asia/Shanghai[edit /usr/local/php/etc/php-fpm.conf]pid = run/php-fpm.pid[edit /usr/local/php/etc/php-fpm.d/www.conf ](1)security.limit_extensions = .php .php3 .php4 .php5 .php7(2)location / {root html;index index.php index.html index.htm;}(3)location ~ \.php$ {root html;fastcgi_pass 127.0.0.1:9000;fastcgi_index index.php;fastcgi_param SCRIPT_FILENAME /php$fastcgi_script_name;include fastcgi_params;}[start php & nginx]/usr/local/php/sbin/php-fpm/ap/nginx/sbin/nginx[stop php & nginx]kill -INT `cat /usr/local/php/var/run/php-fpm.pid`##需搭配[edit /usr/local/php/etc/php-fpm.conf]/ap/nginx/sbin/nginx -s stop四.nfdump 及nfsen 的安装[相关rpm]yum -y install rrdtool rrdtool-devel libpcap-develyum install perl perl-Sys-Syslog rrdtool-perl perl-Data-Dumper perl-MailTools perl-Socket6[nfdump 安装]tar -xvf nfdump-1.6.13.tar.gzcd nfdump-1.6.13./configure --enable-nfprofile --enable-nftrack --enable-sflow \--enable-nfpcapd --with-rrdpathmake && make install[说明] --enable-nfpcapd for netflow[建立帐号，目录]mkdir -p /data/nfsenuseradd netflow -g www[错误记录]##错误configure: error: Can not link librrd configure failed!##原因rpm rrdtool-devel 未安装##错误nfpcapd.c:90:18: fatal error: pcap.h: No such file or directory##原因rpm libpcap-devel 未安装##错误nfpcapd.c:86:3: error: #error missing bpf headermake clean ; ./configure ...[nfsen-1.3.7 安装]tar -xvf nfsen-1.3.7.tar.gzcd nfsen-1.3.7cp etc/nfsen-dist.conf etc/nfsen.conf[ edit etc/nfsen.conf ]$BASEDIR= "/data/nfsen";$HTMLDIR = "/php/nfsen";$WWWUSER = "www";$WWWGROUP = "www";$PREFIX = '/usr/local/bin';%sources = ('H3C' => { 'port' => '8603','col' => '#0000ff', 'type' => 'sflow' },'upstream1' => { 'port' => '9995', 'col' => '#0000ff', 'type' => 'netflow' },);[edit libexec/NfProfile.pm]no strict 'refs'; #加上这一行[安装]./install.pl etc/nfsen.confcd /php/nfsen ; cp -rp css icons js /ap/nginx/html/[错误]##错误ERROR: nfsend connect() error: Permission denied!## ERROR: nfsend - connection failed!!## ERROR: Can not initialize globals!## 实在不清楚m 这个档案是那个用户需要权限，怎么设定都不行，只有chmod 666 才能正常，而且每次重斆服务的时候都要再执行一次##解决chmod a+rw /data/nfsen/var/run/m[start]/data/nfsen/bin/nfsen startchmod a+rw /data/nfsen/var/run/m[stop]/data/nfsen/bin/nfsen start五.完工后的画面六.HP 交换机设定sflow 的方式[检查目前状态]coreswitch2(config)# show sFlow 1 destinationSFlow Destination InformationDestination Instance : 1sflow : DisabledDatagrams Sent : 0Destination Address :Receiver Port : 6343Owner :Timeout (seconds) : 0Max Datagram Size : 1400Datagram Version Support : 5OOBM Support : Disabledcoreswitch2(config)# show sFlow 1 samplingSFlow Sampling Information| Sampling Dropped | Polling Port | Enabled Rate Header Samples | Enabled Interval----- + ------- -------- ------ ---------- + ------- --------sFlow 1 destination 10.21.2.83 8603 ##default port 6343sFlow 1 sampling all 500 ##开始发送封包[确认封包发送]coreswitch2(config)# show sFlow 1 destinationSFlow Destination InformationDestination Instance : 1sflow : EnabledDatagrams Sent : 168Destination Address : 10.21.2.83Receiver Port : 8603Owner : Administrator, CLI-Owned, Instance 1Timeout (seconds) : 2147483603Max Datagram Size : 1400Datagram Version Support : 5OOBM Support : Disabled[取消封包发送]no sFlow 1 destination 10.21.2.81[以tcpdump 确认主机是否收到封包]tcpdump host 10.21.3.7tcpdump: verbose output suppressed, use -v or -vv for full protocol decodelistening on eth0, link-type EN10MB (Ethernet), capture size 65535 bytes14:49:42.950699 IP 10.21.3.7.53504 > 10.21.2.83.8603: UDP, length 1284七.CISCO netflow 如何设定需要在支持NETFOLW功能的交换机上进行相关配置ip flow ingress infer-fieldsip flow ingress layer2-switchedip flow-export version 5ip flow-export destination X.X.X.X. 9995 (要和NFSEN.CONF里面的埠号一致)ip route-cache flow infer-fields八.如何操作nfsenhttp://XXXXX/php/nfsen.php九.END。
