XY2AU使能开关
非常适合手持操作的人机工学设计产品
> 圆弧流线型的外形，方便手持操作
> 置于手柄正面的大面积薄膜按钮，使操作人员可以轻松自如得控制手持设备> 独特设计的3位置带肯定断开触点
> CE，UL，CSA，BG 认证
使能开关XY2AU1
> IP66防护等级
> 2NO+1NC触点
> 预制电缆，或者ISO M20
使能开关XY2AU2
> IP65防护等级
> 2NO+1NC触点
> 手柄顶部另带一个按钮NO辅助触点
> 预制电缆，或者ISO M20
附件
> XY2AZ1用于墙壁安装手柄支撑
> XY2AZ2可以配合门开关钥匙，使控制手柄与XCS安全门开关配合使用
使能开关与XPS安全模块配合使用，可以达到EN954安全等级4
质保期：18个月
安全时刻保持
●使能开关XY2AU有紧凑和人性化的设计，保证操作人员能舒适和安全得进行机器
组态，调试和维修。
●遵循EN574和ISO13851，手持使用该设备可以保证操作员的人身安全
当维修加工中心或机械手时，用于操作员的个人防护。
