66063SINGLE-CHANNEL, VERY HIGH SPEED, LEADLESS CHIP CARRIER OPTOCOPLERMii OPTOELECTRONIC PRODUCTSDIVISIONFeatures:•Electrically similar to 6N134•Hermetically sealed 24 Pin LCC•Very high speed•5MHz bandwidth typical•Performance guaranteed over -55°C to +125°C ambient temperature range•Standard and high reliability screened parts available •TTL compatible input and output•High common mode rejection•1000 Vdc isolation test voltage •Leadless chip carrier package•Faraday shield provides high common mode rejectionDESCRIPTIONThe 66063 single channel optocoupler consists of an LED optically coupled to a high speed, high gain inverting detector gate. Maximum isolation can be achieved while providing TTL output capable of switching with propagation delays of 55ns typical. The 66063 is a 24 pin hermetically sealed leadless chip carrier and is available in standard and screened versions or tested to customer specifications.ABSOLUTE MAXIMUM RATINGS(No derating required up to 125°C)Storage temperature ...........................................................................................................................................-65°C to +150°C Operating temperature.........................................................................................................................................-55°C to +125°C Lead solder temperature ....................................................................................................................................260°C for 10 sec. Peak forward input current ........................................................................................................................40 mA (<1ms duration) Average forward input current ..............................................................................................................................................20mA Input power dissipation........................................................................................................................................................35 mW Reverse input voltage - V R. (5V)Supply voltage - V CC................................................................................................................................7V (1 minute maximum)66063 SINGLE–CHANNEL, VERY HIGH SPEED, LEADLESS CHIP CARRIER OPTOCOUPLER, ContinuedELECTRICAL CHARACTERISTICSOVER RECOMMENDED TEMPERATURE (T A = -55°C to +125°C) unless otherwise specifiedPARAMETERSYMBOLMIN TYP**MAXUNITSTEST CONDITIONSNOTEHigh Level Output Current I OH 5250µAV CC = 5.5V, V O = 5.5V,I F = 250 µA Low Level Output Voltage V OL 0.50.6VV CC = 5.5V, I F = 10mA,I OL (Sinking ) = 10mA 6High Level Supply Current I CCH 1828mAV CC = 5.5V, I F = 0(Both Channels )Low Level Supply Current I CCL 2636mA V CC = 5.5V, I F = 20mA(Both Channels )Input Forward VoltageV F 1.51.75V I F = 20mA, T A = 25°C Input Reverse Breakdown Voltage BV R 5VI R = 10µA, T A = 25°C Input-Output Insulation Leakage CurrentI I—O1.0µAV I-0 = 1000Vdc,Relative Humidity = 45%T A = 25°C, t = 5s.1Propagation Delay Time To High Output Levelt PLH 65100nsR L = 510Ω, C L = 15pF,I F = 13mA, T A = 25°C 2, 6Propagation Delay Time To Low Output Levelt PHL55100nsR L = 510Ω, C L = 15pF,I F = 13mA, T A = 25°C3, 6**All typical values are at V CC = 5V, T A = 25°CTYPICAL CHARACTERISTICSAT T A = 25°C, V CC = 5VPARAMETERSYMBOLMIN TYPMAX UNITSTEST CONDITIONSNOTEInput Capacitance C IN60pF V F = 0, f = 1MHzInput Diode Temperature Coefficient∆v F ∆T A-1.9mV/°CI F = 20mA Resistance (Input-Output)R I- O 1012ΩV I-O = 500V 1Capacitance (Input-Output)C I-O 1.7pF f = 1MHz 1Output Rise-Fall Time (10-90%)t r , t f 35ns R L = 510Ω, C L = 15pF,I F = 13mA6Common Mode Transient Immunity at High Output CM H100010000V/µsV CM = 10V (peak)V O (min.) = 2V,R L = 510Ω, I F = 0mA4Common Mode Transient Immunity at Low OutputCM L100010000V/µsV CM = 10V (peak)V O (max.) = 0.8V,R L = 510Ω, I F = 10mA5NOTES:1. Measured between pins 1 and 2 shorted together, and pins 10, 14 and 15 shorted together.2. The t PHL propagation delay is measured from the 6.5mA point on the trailing edge of the input pulse to the 1.5V point on the trailing edge of the outputpulse.3. The t PHL propagation delay is measured from the 6.5mA point on the leading edge of the input pulse to the 1.5V point on the leading edge of the outputpulse.4. CM H is the max. tolerable common mode transient to assure that the output will remain in a high logic state (i.e. V O > 2.0V).5. CM L is the max. tolerable common mode transient to assure that the output will remain in a low logic state (i.e. V O < 0.8V).6. It is essential that a bypass capacitor (.01 to 0.1µF, ceramic) be connected from pin 10 to pin 15.RECOMMENDED OPERATING CONDITIONSParameterSYMBOLMIN MAX UNITS Input Current, Low Level Each Channel I FL 0250µA Input Current, High Level Each Channel I FH 12.520mA Supply VoltageV CC 4.5 5.5V Fan Out (TTL Load) Each Channel N 6Operating TemperatureT A-55+125°C。
