J2EE-web工程ProGuard代码混淆07_28

ProGuard代码混淆1.混淆器的选择ProGuard下载地址：/index.html#downloads.html 2.优化策略因为公司项目都是 SSH 或者 SSJ 框架，涉及到非常多的配置文件，所以a.必须保留实现Action类中的公有的，友好的，私有的属性和公有的方法。

b.因为配置文件中的类名是一个完整的类名，如果经过处理后就有可能找不到这个类。

c.类中的属性是jsp页面所需要的，如果经过处理jsp页面就无法得到action中的数据。

所以混淆器的配置需要根据工程使用的技术、标准的编码规范以及pro配置编写人员对工程的深入理解,否则极易导致工程无法正常运行。

ProGuard混淆时运行 proguard.jar, 并读取配置文件 ***.proProGuardUI 图形化界面不能完全满足需要，需要单独配置 pro 文件，但通过图形界面配置可以很方便的查看配置内容。

如图：3.命令java -jar ProGuard4.8\lib\proguard.jar @path\TrueCMS.pro4.为混淆器增加内存使用proguard进行混淆时，若项目比较大，经常会报OutOfMemory错误，则需要增加混淆器的内存java -Xms256m -Xmx512m -jar proguard.jar @configuration.projava -Xms256m -Xmx512m -jar proguardgui.jar configuration.pro注意：要在ProGuard 目录的bin下运行这些命令5.参数简介参数：-include {filename} 从给定的文件中读取配置参数-basedirectory {directoryname} 指定基础目录为以后相对的档案名称-injars {class_path} 指定要处理的应用程序jar,war,ear和目录-outjars {class_path} 指定处理完后要输出的jar,war,ear和目录的名称-libraryjars {classpath} 指定要处理的应用程序jar,war,ear和目录所需要的程序库文件-dontskipnonpubliclibraryclasses 指定不去忽略非公共的库类。

-dontskipnonpubliclibraryclassmembers 指定不去忽略包可见的库类的成员。

保留选项：-keep {Modifier} {class_specification} 保护指定的类文件和类的成员-keepclassmembers {modifier} {class_specification} 保护指定类的成员，如果此类受到保护他们会保护的更好-keepclasseswithmembers {class_specification} 保护指定的类和类的成员，但条件是所有指定的类和类成员是要存在。

-keepnames {class_specification} 保护指定的类和类的成员的名称（如果他们不会压缩步骤中删除）-keepclassmembernames {class_specification} 保护指定的类的成员的名称（如果他们不会压缩步骤中删除）-keepclasseswithmembernames {class_specification} 保护指定的类和类的成员的名称，如果所有指定的类成员出席（在压缩步骤之后）-printseeds {filename} 列出类和类的成员-keep选项的清单，标准输出到给定的文件压缩：-dontshrink 不压缩输入的类文件-printusage {filename}-whyareyoukeeping {class_specification}优化：-dontoptimize 不优化输入的类文件-assumenosideeffects {class_specification} 优化时假设指定的方法，没有任何副作用-allowaccessmodification 优化时允许访问并修改有修饰符的类和类的成员混淆：-dontobfuscate 不混淆输入的类文件-printmapping {filename}-applymapping {filename} 重用映射增加混淆-obfuscationdictionary {filename} 使用给定文件中的关键字作为要混淆方法的名称-overloadaggressively 混淆时应用侵入式重载-useuniqueclassmembernames 确定统一的混淆类的成员名称来增加混淆-flattenpackagehierarchy {package_name} 重新包装所有重命名的包并放在给定的单一包中-repackageclass {package_name} 重新包装所有重命名的类文件中放在给定的单一包中-dontusemixedcaseclassnames 混淆时不会产生形形色色的类名-keepattributes {attribute_name,...} 保护给定的可选属性，例如LineNumberTable, LocalVariableTable, SourceFile, Deprecated, Synthetic, Signature, and InnerClasses -renamesourcefileattribute {string} 设置源文件中给定的字符串常量6.详细说明(07/27补充)A.综述这是一个不应该在开源社区出现的东西，但它的的确确是一个开源的项目，正像它的名字一样，Proguard，即Program Guard（程序卫士），它代表了开源的相对面－－代码保护。

经过几天的摸索，终于对Proguard 应用于实际项目有一些不成熟的见解。

上面提过，对于Web工程，公司都是用了SSH/SSJ框架，这类框架中所有action/service/dao/domain以及包结构都固定写死在对应的配置文件中，这使得Proguard 发挥的空间仅限于service/dao内的方法、各部分的通用工具方法及util工具类，Proguard 灵活配置的优势便显现出来了。

B.使用说明1.在Eclipse中选中需要混淆的工程，右键Exprot->选择jar文件导出备用2.打开proguard4.8\lib 目录下的proguardgui.jar，在input/output 选项中增加输入文件，找到刚才导出的jar文件并确定，然后增加输出文件。

3.在中增加工程lib文件夹下所有的jar包，以及java jre4.Shrinking(压缩)中不设置任何配置如图5.Obfuscation如下图配置其中jss.txt 是我们提供给proguard 进行混淆的字符串,若为空，ProGuard会按小写英文字母a,b,c,d….顺序混淆。

6.Optimization如图配置rmation 如图配置Target中选择当前jdk版本8.在Process选项中选择，将配置保存成**.pro文件9.打开pro文件在配置后加入-keep class WebRoot.WEB-INFO.lib.* ---不混淆lib文件夹中所有jar包-keep class * extends .trueway.platform.** {public <methods>;} #不混淆继承于platform的所有类其他配置请根据实际情况进行添加10.配置完成后在ProGuradUI中->，加载配置文件，->即开始混淆，混淆完的文件会根据配置文件输出到指定位置。

也可以使用命令行完成上述动作，且执行效率会有质的飞跃。

命令为：(java -Xms256m -Xmx512m –jar D:\proguard4.8\lib\proguard.jar @D:\ rm.pro)7.注意要点A.在产品的开发过程中，应养成良好的代码习惯，将可重复利用的代码都封装成私有方法或工具类，便于代码维护及代码混淆的效果。

B.工程比较大时，请使用命令行方式混淆，效率会提高10倍以上。

C.通配符:' ?“为任意单个字符,‘*’的任意数量的字符(不包扩分隔符),“**”为任意数量的字符,‘%’对于任何原始类型,“***”为任何类型,和“…“为任意数量的参数。

D.虽然ProGuard声称支持war包，但遗憾的是混淆完的war包会丢失所有class,所以一定需要war包的情况下需要先对jar包混淆，再将jar包内的class替换到war 包内，可正常运行，未出现异常。

E.配置文件中如下配置一定不能颠倒顺序，否则会无法生成outjar。

-injars 'D:\bak\pg\in\rm.jar'-outjars 'D:\bak\pg\in\rmout.jar'F.需要注意web.xml中配置的filter, listener等需要被skip掉。

G.ProGuardUI 可以看做是一个配置文件生成器，而不适合做混淆动作。

H.一个完整的配置例子：*****************************************************************************-injars 'D:\bak\pg\in\rm.jar'-outjars 'D:\bak\pg\in\rmout.jar'-libraryjars 'D:\eclipse_v34\jdk\jdk1.5.0_11\jre\lib\rt.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\FastInfoset-1.2.7.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\XmlSchema-1.4.5.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\abdera-core-0.4.0-incubating.jar'-libraryjars'D:\workspace\rm\WebRoot\WEB-INF\lib\abdera-extensions-json-0.4.0-incubating.jar'-libraryjars'D:\workspace\rm\WebRoot\WEB-INF\lib\abdera-extensions-main-0.4.0-incubating.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\abdera-i18n-0.4.0-incubating.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\abdera-parser-0.4.0-incubating.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\activation.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\ant-1.6.5.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\antlr-2.7.7.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\aopalliance-1.0.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\asm-2.2.3.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\aspectjrt.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\aspectjweaver.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\aspriseTIFF.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\axiom-api-1.2.7.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\axiom-impl-1.2.7.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\baseframework.jar'-libraryjars 'D:\workspace\rm\WebRoot\WEB-INF\lib\bcprov-jdk15-1.43.jar'...-dontskipnonpubliclibraryclassmembers-target 1.5-dontshrink-dontoptimize-useuniqueclassmembernames-keeppackagenames-keepattributesExceptions,InnerClasses,Signature,Deprecated,SourceFile,LineNumberTable,LocalVariable*Table, *Annotation*,Synthetic,EnclosingMethod-keepparameternames-dontpreverify-dontwarn-ignorewarnings-keep class WebRoot.WEB-INFO.lib.*-keep class * extends .trueway.platform.** {public <methods>;}-keep class * extends org.springframework.orm.hibernate3.support.HibernateDaoSupport { public <methods>;}-keep class **.model.** {public private protected <fields>;public <methods>;}-keep class .trueway.resourceAllocation.application.domain.* {public private protected <fields>;public <methods>;}-keep class **.service.impl.* {public <methods>;}-keep class .trueway.platform.** {public private protected <fields>;public <methods>;}-keep class .trueway.resourceInterface.service.** {public private protected <fields>;public <methods>;}-keep class **.po.* {public private protected <fields>;public <methods>;}-keep class .trueway.sso.* {public private protected <fields>;public <methods>;}-keep class .trueway.startup.AdminFilter {public private protected <fields>;public <methods>;}# Keep names - Native method names. Keep all native class/method names.-keepclasseswithmembers,allowshrinking class * {native <methods>;}# Keep names - _class method names. Keep all .class method names. This may be # useful for libraries that will be obfuscated again with different obfuscators.-keepclassmembers,allowshrinking class * {ng.Class class$(ng.String);ng.Class class$(ng.String,boolean);}# Remove - System method calls. Remove all invocations of System# methods without side effects whose return values are not used.-assumenosideeffects public class ng.System {public static long currentTimeMillis();static ng.Class getCallerClass();public static int identityHashCode(ng.Object);public static ng.SecurityManager getSecurityManager();public static java.util.Properties getProperties();public static ng.String getProperty(ng.String);public static ng.String getenv(ng.String);public static ng.String mapLibraryName(ng.String);public static ng.String getProperty(ng.String,ng.String); }# Remove - Math method calls. Remove all invocations of Math# methods without side effects whose return values are not used.-assumenosideeffects public class ng.Math {public static double sin(double);public static double cos(double);public static double tan(double);public static double asin(double);public static double acos(double);public static double atan(double);public static double toRadians(double);public static double toDegrees(double);public static double exp(double);public static double log(double);public static double log10(double);public static double sqrt(double);public static double cbrt(double);public static double IEEEremainder(double,double);public static double ceil(double);public static double floor(double);public static double rint(double);public static double atan2(double,double);public static double pow(double,double);public static int round(float);public static long round(double);public static double random();public static int abs(int);public static long abs(long);public static float abs(float);public static double abs(double);public static int max(int,int);public static long max(long,long);public static float max(float,float);public static double max(double,double);public static int min(int,int);public static long min(long,long);public static float min(float,float);public static double min(double,double);public static double ulp(double);public static float ulp(float);public static double signum(double);public static float signum(float);public static double sinh(double);public static double cosh(double);public static double tanh(double);public static double hypot(double,double);public static double expm1(double);public static double log1p(double);}# Remove - Number method calls. Remove all invocations of Number# methods without side effects whose return values are not used.-assumenosideeffects public class ng.* extends ng.Number { public static ng.String toString(byte);public static ng.Byte valueOf(byte);public static byte parseByte(ng.String);public static byte parseByte(ng.String,int);public static ng.Byte valueOf(ng.String,int);public static ng.Byte valueOf(ng.String);public static ng.Byte decode(ng.String);public int compareTo(ng.Byte);public static ng.String toString(short);public static short parseShort(ng.String);public static short parseShort(ng.String,int);public static ng.Short valueOf(ng.String,int);public static ng.Short valueOf(ng.String);public static ng.Short valueOf(short);public static ng.Short decode(ng.String);public static short reverseBytes(short);public int compareTo(ng.Short);public static ng.String toString(int,int);public static ng.String toHexString(int);public static ng.String toOctalString(int);public static ng.String toBinaryString(int);public static ng.String toString(int);public static int parseInt(ng.String,int);public static int parseInt(ng.String);public static ng.Integer valueOf(ng.String,int);public static ng.Integer valueOf(ng.String);public static ng.Integer valueOf(int);public static ng.Integer getInteger(ng.String);public static ng.Integer getInteger(ng.String,int);public static ng.Integer getInteger(ng.String,ng.Integer); public static ng.Integer decode(ng.String);public static int highestOneBit(int);public static int lowestOneBit(int);public static int numberOfLeadingZeros(int);public static int numberOfTrailingZeros(int);public static int bitCount(int);public static int rotateLeft(int,int);public static int rotateRight(int,int);public static int reverse(int);public static int signum(int);public static int reverseBytes(int);public int compareTo(ng.Integer);public static ng.String toString(long,int);public static ng.String toHexString(long);public static ng.String toOctalString(long);public static ng.String toBinaryString(long);public static ng.String toString(long);public static long parseLong(ng.String,int);public static long parseLong(ng.String);public static ng.Long valueOf(ng.String,int);public static ng.Long valueOf(ng.String);public static ng.Long valueOf(long);public static ng.Long decode(ng.String);public static ng.Long getLong(ng.String);public static ng.Long getLong(ng.String,long);public static ng.Long getLong(ng.String,ng.Long); public static long highestOneBit(long);public static long lowestOneBit(long);public static int numberOfLeadingZeros(long);public static int numberOfTrailingZeros(long);public static int bitCount(long);public static long rotateLeft(long,int);public static long rotateRight(long,int);public static long reverse(long);public static int signum(long);public static long reverseBytes(long);public int compareTo(ng.Long);public static ng.String toString(float);public static ng.String toHexString(float);public static ng.Float valueOf(ng.String);public static ng.Float valueOf(float);public static float parseFloat(ng.String);public static boolean isNaN(float);public static boolean isInfinite(float);public static int floatToIntBits(float);public static int floatToRawIntBits(float);public static float intBitsToFloat(int);public static int compare(float,float);public boolean isNaN();public boolean isInfinite();public int compareTo(ng.Float);public static ng.String toString(double);public static ng.String toHexString(double);public static ng.Double valueOf(ng.String);public static ng.Double valueOf(double);public static double parseDouble(ng.String);public static boolean isNaN(double);public static boolean isInfinite(double);public static long doubleToLongBits(double);public static long doubleToRawLongBits(double);public static double longBitsToDouble(long);public static int compare(double,double);public boolean isNaN();public boolean isInfinite();public int compareTo(ng.Double);public <init>(byte);public <init>(short);public <init>(int);public <init>(long);public <init>(float);public <init>(double);public <init>(ng.String);public byte byteValue();public short shortValue();public int intValue();public long longValue();public float floatValue();public double doubleValue();public int compareTo(ng.Object);public boolean equals(ng.Object);public int hashCode();public ng.String toString();}# Remove - String method calls. Remove all invocations of String # methods without side effects whose return values are not used. -assumenosideeffects public class ng.String {public <init>();public <init>(byte[]);public <init>(byte[],int);public <init>(byte[],int,int);public <init>(byte[],int,int,int);public <init>(byte[],int,int,ng.String);public <init>(byte[],ng.String);public <init>(char[]);public <init>(char[],int,int);public <init>(ng.String);public <init>(ng.StringBuffer);public static ng.String copyValueOf(char[]);public static ng.String copyValueOf(char[],int,int);public static ng.String valueOf(boolean);public static ng.String valueOf(char);public static ng.String valueOf(char[]);public static ng.String valueOf(char[],int,int);public static ng.String valueOf(double);public static ng.String valueOf(float);public static ng.String valueOf(int);public static ng.String valueOf(ng.Object);public static ng.String valueOf(long);public boolean contentEquals(ng.StringBuffer);public boolean endsWith(ng.String);public boolean equalsIgnoreCase(ng.String);public boolean equals(ng.Object);public boolean matches(ng.String);public boolean regionMatches(boolean,int,ng.String,int,int);public boolean regionMatches(int,ng.String,int,int);public boolean startsWith(ng.String);public boolean startsWith(ng.String,int);public byte[] getBytes();public byte[] getBytes(ng.String);public char charAt(int);public char[] toCharArray();public int compareToIgnoreCase(ng.String);public int compareTo(ng.Object);public int compareTo(ng.String);public int hashCode();public int indexOf(int);public int indexOf(int,int);public int indexOf(ng.String);public int indexOf(ng.String,int);public int lastIndexOf(int);public int lastIndexOf(int,int);public int lastIndexOf(ng.String);public int lastIndexOf(ng.String,int);public int length();public ng.CharSequence subSequence(int,int);public ng.String concat(ng.String);public ng.String replaceAll(ng.String,ng.String);public ng.String replace(char,char);public ng.String replaceFirst(ng.String,ng.String);public ng.String[] split(ng.String);public ng.String[] split(ng.String,int);public ng.String substring(int);public ng.String substring(int,int);public ng.String toLowerCase();public ng.String toLowerCase(java.util.Locale);public ng.String toString();public ng.String toUpperCase();public ng.String toUpperCase(java.util.Locale);public ng.String trim();}# Remove - StringBuffer method calls. Remove all invocations of StringBuffer# methods without side effects whose return values are not used.-assumenosideeffects public class ng.StringBuffer {public <init>();public <init>(int);public <init>(ng.String);public <init>(ng.CharSequence);public ng.String toString();public char charAt(int);public int capacity();public int codePointAt(int);public int codePointBefore(int);public int indexOf(ng.String,int);public int lastIndexOf(ng.String);public int lastIndexOf(ng.String,int);public int length();public ng.String substring(int);public ng.String substring(int,int);}# Remove - StringBuilder method calls. Remove all invocations of StringBuilder# methods without side effects whose return values are not used.-assumenosideeffects public class ng.StringBuilder {public <init>();public <init>(int);public <init>(ng.String);public <init>(ng.CharSequence);public ng.String toString();public char charAt(int);public int capacity();public int codePointAt(int);public int codePointBefore(int);public int indexOf(ng.String,int);public int lastIndexOf(ng.String);public int lastIndexOf(ng.String,int);public int length();public ng.String substring(int);public ng.String substring(int,int);}2012/07/27 By lv☂E-mail:lvjianw@。
