烧机油的判断 Oil being burnt judgement
• • • • • • 1 气门导管油封漏油 2 油底壳机油量过多 3 活塞环对口 4 活塞环装反,卡死 5 活塞环,活塞,缸套磨损间隙过大,烧机油 6增压器漏油,也可导致烧机油(判断方法:拆下 发动机进气支管,看进气孔是否潮湿的) • 注:拆下发动机排气管可以判断哪个缸烧机油
从呼吸器口排机油或下排气严重 Oil coming out from breather or severe blow-by
• Cylinder pressure normally more than 2.8Mpa
•
• • • • •
1,Oil level too high in oil pan
2,When cylinder is seized ,the gas goes into crankcase 3,Inside push rod chamber, the oil return hole is too small 4,The oil sealing cups of both sides of the rocker arm shafts falling off 5,Piston ring being broken or damaged Cylinder liner premature wear, too large clearance between cylinder liner and piston, causing severe blow-by
4102BZLQ Engine vehicle application
• In Columbia market • Applied to JAC HFC1048,1061 • Medium buses HFK 6603,6730
4102BZLQ发动机主要特征
• • • • • • • 五十铃发动机技术 发动机标定功率88Kw(120hp) 最大扭矩/转速343N.m(35)/1400-1800rpm 排量3.856L 气缸数-缸径X行程：4-102X118mm 各缸点火顺序：1-3-4-2 压缩比：17.5:1
4102BZLQ Engine main operation attention points
•
4102BZLQ Engine main operation attention points
Radiator water flee,cylinder gasket gas flee and cylinder gasket being clashed and broken
水箱窜水,缸垫窜气.哧缸垫
Radiator water flee, cylinder gasket gas flee between cylinders and cylinder gasket being clashed and • • broken 1,Cylinder head bolt torque insufficient or not even (118127N.m/12-13kgf.m) 2,Cylinder liner protrusion above the top surface of the cylinder block over the tolerance (normally the protrusion 0.05-0.12mm,adjacent two cylinders protrusion height tolerance not exceeding 0.03mm) 3,Fuel supply time too early (fuel supply too early will cause engine working too roughly, cylinder pressure suddenly increasing and temperature increasing ,which will greatly cause cylinder gasket being clashed and broken) 4,Misassembly of non- turbocharged cylinder head gasket on turbocharged diesel engine, which will cause gasket being clashed and broken. 5,Cylinder head being deformed, torsional uneven ,which will cause cylinder head gasket broken (due to cylinder head bolt tightening torque not even) 6,If many time the gasket broken in the same place, check the cylinder protrusion.
4102BZLQ发动机使用主要注意要事项
• 长期停放的发动机在使用前，必须拧开增压器上面的进油接头， 注入润滑油。 • 发动机怠速运转不要超过10分钟，以免导致增压器漏油 • 油底壳加机油在油尺上限和下限之间,到上限，可以，但一定不能 超过上限，那样会造成烧机油。 • 发动机磨合期5000KM 过后，要把喷油泵上限速螺钉上的尼龙帽 拿掉。以免发动机功率不足 • 检查调整气门间隙，冷车进排气门均为0.4mm.气门调整螺钉一定 要扭紧。
4102BZLQEngine main characteristics
• • • • • • • ISUZU technology Rated power 88Kw(120hp) Max. torque/speed 343N.m(35)/1400-1800rpm Displacement 3.856L Cylinder No.-Bore X Stroke：4-102X118mm Firing order：1-3-4-2 Compression ratio： 17:1
Connecting rod bolt 118-127N.m(12-13kgf.m)87-94lbf.ft Flywheel bolt 196-216N.m(19-21kgf.m)145-160lbf.ft Flywheel housing bolt 127-147N.m(13-15kgf.m)94-109lbf.ft Camshaft gear pressure plate bolt 108-118（11-12kgf.m) 80-87lbf.ft Crankshaft front nut 392-441N.m(40-45kgf.m)290-326lbf.ft
Intake and exhaust valve clearance 0.4 mm (cold state) • Compression clearance（TDC，distance between piston top and the bottom surface of cylinder head) 0.9-1.1mm • Injector nozzle tip protrusion height out of cylinder head bottom 3.2-3.7mm • Oil pressure：Idle oil pressure ≥118kPa Working oil pressure 196-540kPa
4102BZLQ发动机主要技术参数
进排气门间隙0.4mm(冷车) • 压缩余隙（TDC，活塞顶面与缸盖底面之间的距离） 0.9-1.1mm • 喷油嘴高出缸盖底面高度3.2-3.7mm • 机油压力：怠速油压≥118kPa
工作油压196-540kPa
4102BZLQ Engine main technical data
4102BZLQ Engine main operation attention points
• • • • • 1,Engine long time no use, before operation, the oil inlet connection on the top of turbocharger must be open and fill fresh oil for lubrication 2,Engine running should not exceed 10minutes,in case of turbocharger oil leaking 3,Oil in oil pan should be filled between the upper mark and lower mark of oil dipstick, no problem for the max. level, be sure do not exceed the max .level. which will cause oil being burnt 4,After engine run-in 5000KM,the nylon cap on the limit speed screw of fuel pump should be removed, in case of insufficient power. 5,Mantenance period, check and adjust intake and exhaust valve clearance 0.4mm(cold state) and be sure the adjusting screw must locked
• • • • • •
4102BZLQ Engine main bolt tightening torque
• • • • • • • Cylinder head bolt Main bearing cap bolt 118-127N.m(12-13kgf.m) 87-94 lbf.ft 216-235N.m(22-24kgf.m)160-174lbf.ft
• １，气缸盖螺栓扭紧力矩不够或不均 • ２，缸套突出机体上平面尺寸超差(突出高度0.050.12mm.相邻气缸高度差小于0.03mm） • ３，供油时间过早（供油时间过早引起柴油机工作粗 暴，汽缸压力骤然增加，温度增加，极易引起汽缸垫 冲坏） • ４，错将非增压机缸垫装在增压柴油机上导致哧缸垫 • ５，缸盖变形，扭曲不平，导致哧缸垫（由于缸盖螺 栓拧紧力矩不均所至） • 6如果多次哧缸垫,重要检查哧缸垫的位置是否为同一 位置,如果是,则为该缸缸套突出高度超差
