格兰仕微波炉-说明书word版本
格兰仕微波炉用户手册说明书
Specifications
Model: Rated Voltagcrowave): Rated Output Power(Microwave): Rated Input Power(Grill): Oven Capacity: Turntable Diameter: External Dimensions: Net Weight:
EN-4
surface, and do not cover any vents on the oven. 20. Do not let cord hang over edge of table or counter. 21. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation. 22.The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns. 23. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container. 24.The appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. 25.Children should be supervised to ensure that they do not play with the appliance. 26.The appliances are not intended to be operated by means of an external timer or separate remote-control system. 27. Accessible parts may become hot during use. Young children should be kept away. 28.Steam cleaner is not to be used. 29.During use the appliance becomes hot. Care should be taken to avoid touching heating elements inside the oven. 30.Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a
Galanz微波炉用户手册说明书
211111111121212131414141414151515161616 3Precautions to avoid possible exposure to excessive microwave energy: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3Unpacking instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4Grounding Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5Cookware and cooking materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6Materials you can use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6Materials to be avoided . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7Package contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7Microwave oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7CONTROL PANEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8ACCESSORIES INSTRUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Name of accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Preparation before using . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . 109910SETTING UP YOUR MICROWAVE OVEN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .OPERATION INSTRUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11Setting up your microwave oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . Setting the Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Express Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Microwave Cooking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Roast Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Sensor Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . AirFry Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Convection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Microwave+Convection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . .. . . .Steam Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Weight Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Time Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1LB Defrost . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Auto Cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Use the Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Use the Vent Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Use the Turntable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Add Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Child Lock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .CLEAN AND CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17Cleaning the outside of your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Cleaning the inside of your microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17Cleaning and replacing the lters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18Changing the light bulbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21PRODUCT WARRAMTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22WARRAMTY REGISTRATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .SAVE THESE INSTRUCTIONS413Cooking utensils may become hot because of heat transferred from the heated food. Potholders may be needed to handle the utensil.14Do not cover or block any openings on the appliance.15Do not store or use this appliance outdoors. Do not use this product near water, for example, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.16Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly, or if it has been damaged or dropped.17Do not immerse the cord or plug in water. Keep the cord away from heated surfaces. Do not let the cord hang over the edge of a table or counter.18Use only thermometers which are speci cally designed for use in microwave ovens.19Be certain the glass tray and roller rings are in place when you operate the oven.20This appliance should be serviced only by quali ed service personnel. Contact the nearest authorized service facility for examination, repair, or adjustment.21When cleaning surfaces of the door and oven that come together on closing the door, use only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth.22VENTILATING HOODS:a) Clean Ventilating Hoods Frequently-Grease should not be allowed to accumulate on hood or lter.b) When aming foods under the hood, turn the fan on.23Use care when cleaning the vent-hood lter. Corrosive cleaning agents, such as lye-based oven cleaners, may damage the lter.24252627To reduce the risk of re and electric shock, install only above electric cooking equipment. If the over-the-cooktop microwave oven is intended to be used with either a gas or electric range, the following words or the equivalent shall be included: Suitable for use above both gas and electric cooking equipment.Unpacking instructionsCarefully remove the microwave from the box. Save the box as it may make installation easier.1Remove all packing materials from inside the oven cavity. However, DO NOT REMOVE THE WAVEGUIDE COVER, which is located on the right side in the oven cavity. Make sure that you have all items from the ‘’Package contents’’ on page 7. Read and save the instructions.2Remove the feature sticker from the outside of the door, if there is one.3Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surfaces, broken or loose door hinges and latches, and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact your dealer.See the Installation Guide for more information.This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.Please note that changes or modi cations of this product is not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.”Section15.105 Class B NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:-- Reorient or relocate the receiving antenna.-- Increase the separation between the equipment and receiver.-- Connect the equipment into an outlet on a circuit di erent from that to.SAVE THESE INSTRUCTIONS 5a) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating of the appliance.b) The extension cord must be a grounding-type 3-wire cord, and the longer cord should be arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over unintentionally.c) If it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug, and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance.Notes •If you have any questions about the grounding or electrical instructions, consult a quali ed electrician or service person. •Galanz does not accept any liability for damage to the oven or personal injury resulting from failure to observe the electrical connection procedures.Radio or TV interferenceShould there be any interference caused by the microwave oven to your radio or TV, make sure that the microwave oven is on a di erent circuit. Relocate the radio or TV as far away from the oven as feasible or check the position and signal of the receiving antenna.GROUNDING INSTRUCTIONSThis appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.WarningImproper use of the grounding plug can result in a risk of electric shock. Consult a quali ed electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded.Electrical requirementsThe electrical requirements are a 120 volt 60 Hz, AC only, 20 amp outlet. It is recommended that a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded.Power Supply Cord 1 A short power supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over a longer cord.2Longer cord sets or extension cords are available and may be used if care is exercised in their use.3If a long cord or extension cord is used:Cookware and cooking materialsWarningPersonal Injury HazardTightly-closed containers could explode. Closed containers should be openedand plastic pouches should be pierced before cooking.Cookware and other materials must t on the turntable. Always use oven mitts or pot holders because cookware may become hot.Refer to the Materials you can use and Materials to be avoided tables as a guide, then test before using.Cookware and Materials Test:1Fill a microwave-safe container with 1 cup (250 ml) of cold water, along with the cookware or materials in question.2Cook on maximum power for one minute. Do not exceed one minute cooking time.3Carefully feel the cookware or material. If the empty cookware or material is warm, do not use it for microwave cooking.Materials you can useMATERIAL REMARKSAluminum foil Use as shielding only. Small, smooth pieces can be used to cover thin parts of meat or poultry to prevent overcooking. Arcing can occur if the foil is wrinkled or too close to oven walls. The foil should be at least 1 inch (2.5 cm) away from oven walls.Browning dish Follow the manufacturer’s instructions. The bottom of the browning dish must be at least 3/16-in.(5mm) above the turntable. Incorrect usage may cause the turntable to break.Dinnerware Use microwave-safe only. Follow the manufacturer's instructions. Do not use cracked or chipped dishes.Glass jars Always remove the lid. Use only to heat food until just warm. Most glass jars are not heat resistant and may break.Glassware Use heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use cracked or chipped dishes.Oven cooking bags Follow the manufacturer’s instructions. Do not close with a metal tie. Make slits to allow steam to escape.Paper plates andcups Use for short–term cooking/warming only. Do not leave the oven unattended while cooking.Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for short-term cooking only.Parchment paper Use as a cover to prevent splattering or a wrap for steaming.Plastic Use only if labeled “Microwave Safe.” Follow the manufacturer’s instructions. Some plastic containers soften as the food inside gets hot. “Boiling bags” and tightly closed plastic bags should be slit, pierced, or vented, as indicated on the package.Plastic wrap Use microwave-safe only. Use to cover food during cooking to retain moisture. Do not allowplastic wrap to touch food.Thermometers Use microwave-safe only (such as meat and candy thermometers).Wax paper Use as a cover to prevent splattering and retain moisture.Materials to be avoidedMATERIAL REMARKSAluminum tray May cause arcing. Use a microwave-safe dish instead.Food carton withmetal handle May cause arcing. Use a microwave-safe dish instead.Metal or metaltrimmed utensils Metal shields the food from microwave energy. The metal trim may cause arcing.Metal twist ties May cause arcing and could cause a re in the oven.Paper bags May cause a re in the oven.Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to high temperature.Wood Wood will dry out when used in the microwave oven and may split or crack.SAVE THESE INSTRUCTIONS6FEATURES7Features•7 AirFry Programs•7 auto-cook settings•11 variable power level•1000 watts of power•Press number pad to express cooking•Exhaust fan with four speeds•Hidden vent•LED lighting•Child lock•12.8-inch glass turntable• 1.7 Cu.Ft. over-the-range microwave oven•Air Fry Kit•Steam Kit•Turntable(with ring)•Installation Hardware•Grease Filter•Exhaust Damper•Installation Guide•User GuidePackage contentsMicrowave oven1. Door Safety Lock System2. Oven Window3. Plastic Roller Ring4. Plastic Shaft5. Control Panel6. Glass Turntable7. Air Fry Kit8. Steam Kit15432678CONTROL PANEL8#ITEM DESCRIPTION1Display The display includes a clock and indicators to tell you time of day, cookingtime settings and cooking functions selected.2Cook Menus Press to set auto cooking and sensor cooking programs.3Time Defrost Use to set defrost program based on time.4Weight Defrost Use to set defrost program based on weight.Press to defrost frozen food quickly.Press number pads to enter cooking time, power level, weight or temperatureand you can set express cooking program by pressing 1~6 pad.5 1 LB DefrostNumber Pad6TimerPress once to temporarily stop cooking, or twice to cancel cooking altogether,and use to set child lock.Press to set timer function.7Clock Press to set clock time.8Start Press to start the oven.Micro9Roast Press this button to start roast program.11121310+1 Min Press to add time.Conv Press to set convection cooking program.15161714AirFryLight On/OMicro + ConvPress to set AirFry cooking program.Press to set the controls of the light outside the oven.Press to set microwave and convection cooking program.Vent 4 Speed Press this button to change vent speed.1918Turntable On/O Press to turn on/o the turntable..181319Stop/CancelPress to set microwave cooking program.ACCESSORIES INSTRUCTION9Accessories InstructionMulti-function Steam Kit QZ2550DA Around 0.6Gal (2.5L)10.2×6.4 in. (258mm×163mm)1.1LB (0.5kg)4°F to 248°F(-20℃-120℃)Air Fry KitQJ876S/10.63×3.94 in. (270mm×100mm)1.6lb (0.7kg)<500°F (260℃)Product Name Model Number Volume Dimension(D×H)Net Weight Temperture Name of accessoriesPreparation before using•AirFry Pan•Seal Ring•Base12345Please check all the components. Please do not use if any component is missing or damaged.Please make sure the screw on the carry handle is tight before using. Please tighten the screw if it is loose. Please make sure the silica ring is properly tted. Please do not use the steam kit without the silica ring. Please clean the steam kit after using.Please carefully read the instruction before using this steam kit.Notes•Please always use the steam kit with water.•Please only use the airfry kit in convection, roast and airfry programs.•Stainless steel lid •Steam kit base •Steam basket •Silica ringUsing the LightThis feature is designed for the convenience of doing things outside the oven. To turn on the light at the bottom of the oven, press LIGHT ON/OFF buttonPress LIGHT ON/OFF buttonDisplay Once HIGH Twice LOW 3 timesOFFUsing the Vent FanYour oven can be used as a range hood. When it is turned on, the fan motor starts ltering out smoke, odors, and grease generated from cooking.In standby mode, the vent fan is manually control, continuous press VENT 4 SPEED can choose ve cycle gears:Auto CookIn standby mode, press the SOUP, POPCORN, or BEVERAGE button once. Use number button “1”,”2” or "3" to select food weight or servings. Press START button to con rm.123Press the SOFTEN/MELT button once, the display will show “PRESS 1--SOFTEN BUTTER 2--MELT BUTTER 3--SOFTEN ICE CREAM 4--SOFTEN CHEESE”.Use number pad to select food type, the display shows “PRESS 1--STICK 2—STICKS” or shows “PRESS 1--4oz 2--8oz”.Use number pad to select food serving or weight. Press START button to con rm.1234Menu Press numberWeight/ServingTime SOUP1 1 bowl2:30 2 2 Bowls 3:40 33 Bowls 4:50 POPCORN1 3.5 oz 2:0523 oz 1:50 BEVERAGE 11 cup 1:302 2 cups 2:40 33 cups3:50Menu Press Number Press number Weight/ServingTime SOFTEN BUTTER 1 1 1 stick 1:20 2 2 sticks 1:40 MELT BUTTER 2 1 1 stick 1:20 2 2 sticks 1:40 SOFTEN ICE CREAM 3 1 4 oz 2 8 oz 0:45 SOFTEN CHEESE41 4 oz 1:00 28 oz1:30For Soup, Popcorn, or Beverage:For Soften Butter, Melt Butter, Soften Ice Cream, or Soften Cheese:150:30Cleaning the outside of your microwaveExteriorThe outside surface is precoated steel and plastic. Clean the outside with mild soap and water, then rinse and drywith a soft cloth. Do not use any type of household or abrasive cleaner.DoorWipe the window on both sides with a damp cloth to remove any spills or spatters. Metal parts will be easier tomaintain if wiped frequently with a damp cloth. Avoid the use of spray and other harsh cleaners as they may stain, streak, or dull the door surface.Control panelIf the control panel is dirty, open the microwave door before cleaning. Wipe the panel with a cloth dampenedslightly with water only. Dry with a soft cloth. Do not scrub or use any sort of chemical cleaners. Close the door and press Stop to clear any buttons you may have pressed.Cleaning the inside of your microwaveInteriorWipe with a soft cloth and warm water. Do not use abrasive or harsh cleaners or scouring pads. For baked-on food, use baking soda or a mild soap, then rinse thoroughly with hot water.Waveguide coverThe waveguide cover is located on the ceiling inside the microwave cavity. It is made from mica so requires special care. Keep the waveguide cover clean to assure good microwave performance. Carefully wipe with a damp cloth any food spatters from the surface of the cover immediately after they occur. Built-up splashes may overheat and cause smoke or possibly catch re. DO NOT REMOVE THE WAVEGUIDE COVER.Removing odorsOccasionally, a cooking odor may remain in the microwave. To remove, combine one cup water, grated peel andjuice of one lemon, and several whole cloves in a two-cup glass measuring cup. Boil for several minutes using 100% power, then let it cool in the microwave. Wipe the interior with a soft cloth.Turntable and turntable supportRemove the turntable and turntable support and wash them in mild, sudsy water. For stubborn stains, use a mildcleanser and non-abrasive scouring sponge. You can also wash them in the top rack of a dishwasher.The turntable motor shaft is not sealed, so excess water or spills should be wiped up immediately.1723WARRANTY REGISTRATIONOPERATION INSTRUCTIONS Please mail this warranty card to the address below within 30 days of purchase.Galanz Americas, 55 Challenger Road, Suite 503, Ridge eld Park, NJ 07660.NameAddressCityState ZIPPhoneEmail Model NumberPurchase Location PLEASE PRINT CLEARLY.Serial NumberYou must attach a copy of your purchase receipt to validate your registration.。
格兰仕MODEL IM30SE3 30升微波炉 安裝及操作手冊说明书
MODEL IM30SE3-The temperature of accessible surfaces may be high when the appliance is operating.IMPORTANT SAFETY INSTRUCTIONSREAD CAREFULLY AND KEEP FOR FUTURE REFERENCE- The appliance is not intended for use by persons including children with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervised or instructionconcerning use of the appliance by a responsible person for their safety.-WARNING:if the door or door seals are damaged,the oven must not be operated until it has been repaired by a competent person;-WARNING:it is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy;-WARNING:liquids and other foods must not be heated in sealed containers since they are liable to explode- Young children should be supervised to ensure that they do not play with the appliance.-only use utensils that are suitable for use in microwave ovens-when heating food in plastic or paper containers,keep an eye on the oven due to the possibility of ignition;-if smoke is observed,switch of f or unplug the appliance and keep the door closed in order to stifle any flames;-microwave heating of beverages can result in delayed eruptive boiling,therefore care must be taken when handling the container;-the contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption,in order to avoid burns;-eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode,even after microwave heating has ended;-the oven should be cleaned regularly and any food deposits removed;-failure to maintain the oven in a clean condition could lead todeterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation;-if the supply cord is damaged,it must be replaced by the manufacturer,its service agent or similarly qualified persons in order to avoid a hazard.2SPECIFICATIONSPower consumption: Output:Operating Frequency: Outside Dimensions: Oven Cavity Dimensions:Oven Capacity: Uncrated Weight:220-240V~50Hz,1450W900W2,450MHz520mm(W) X 430mm(D) X 300mm(H)350mm(W) X 372mm(D) X 232mm(H)30litresApprox. 17.5kg3BUILDING-IN the IM30SE3 DQG ,0 6(The IM30SE3 and IM30SE4 can be built in with stainless trim kit to surround the microwave oven,matching trim to kitchen doors or simply placed in an opening in the kitchen furniture. Proper airflow must be present around the microwave oven in any of these installations.Building in the microwave oven above an oven requires an additional vertical pieceof board (A)to ensure the heat from the oven does not mix with the microwave oven generated heat as this could cause damage to the microwave oven.NB:The microwave oven is not to be installed under bench unless optimum airflow around the microwave oven can be guaranteed to eliminate the risk of overheating.The IM30ST3 trim kit is supplied with detailed built-in instructions and fixings.Air flow recommendedspace requirement : 4cm minimum4BEFORE YOU CALL FOR SERVICE1. If the oven will not perform at all, the display does not appear or the display disappears:a) Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet, wait 10 seconds and plug it in again securely.b) Check the premises for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating properly,test the outlet with another appliance.2. If the microwave power does not function:a) Check to see whether the timer is set.b) Check to make sure that the door is securely closed to engage the safety interlocks. Otherwise, the microwave energy will not flow into the oven.IF NONE OF THE ABOVE RECTIFIES THE SITUATION,THEN CONTACT THE AUTHORIZED SERVICE AGENT.RADIO INTERFERENCEMicrowave oven may cause interference to your radio, TV, or similar equipment. When interference occurs, it may be eliminated or reduced by the following procedures.a. Clean the door and sealing surface of the oven.b. Place the radio, TV, etc. as far away from your microwave oven as possible.c. Use a properly installed antenna for your radio, TV, etc. to get a strong signal reception.Note:The appliance is for household use for heating food and beverages using electromagnetic energy and for indoor use only.INSTALLATION1. Make sure all the packing materials are removed from the inside of the door.2. Inspect the oven after unpacking for any visualdamage such as:Misaligned DoorDamaged DoorDents or Holes in Door Window and ScreenDents in CavityIf any of the above are visible, DO NOT use theoven.3.This Microwave Oven weighs 17.5 kg and must be placed on a horizontal surface strong enough toWARNING-THIS APPLIANCE MUST BE EARTHED.1. The plug socket should be within easy reachof the power cord2. This oven requires 1.5 KVA for its input. consultation with service engineer issuggested when installing the oven. support this weight.4. The oven must be placed away from high temperature and steam.5. DO NOT place anything on top of the oven.6. DO NOT remove the turn -table drive shaft.7.As with any appliance, close supervision is necessary when used by children.CAUTION:This oven is protected internally by ac 250V,10Amp Fuse.IMPORTANTThe wires in this mains lead are coloured in accordance with the following code:Green-and-yellow : EarthBlue : NeutralBrown : LiveAs the colours of the wires in the mains leads of the appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows:The wire which is coloured green-and-yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol coloured green of green-and-yellow.The wire which is coloured blue must be connected to the terminal which is marked with the letter N or coloured black.The wire which is coloured brown must be connected to the terminal which is marked with the letter L or coloured red.5SAFETY INSTRUCTIONS FOR GENERAL USEListed below are, as with all appliances, certain rules to follow and safeguards to assure top performance from this oven:1.Always have the glass tray, roller arms, coupling and roller track in place when operating the oven.2. Do not use the oven for any reason other than food preparation, such as for drying clothes, paper, or any other nonfood items, or for sterilizing purposes.3. Do not operate the oven when empty.This could damage the oven.4. Do not use the oven cavity for any type of storage,such a papers, cookbooks, etc.5.Do not cook any food surrounded by a membrane,such as egg yolks,potatoes,chicken livers,etc without first being pierced several times with a fork.IMPORTANT SAFETY INSTRUCTIONS-WARNING: If the door or door seals are damaged, the oven must not be operated until it has been repaired by a competent person;-WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy;-WARNING: liquids and other foods must not be heated in sealed containers since they are liable to explode.-WARNING: Only allow children to use the oven without supervision when adequate instructions have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use;-The oven must have sufficient air flow.Keep from top of the - Only use utensils that are suitable for use in microwave ovens.- When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition;- If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stifle any flames;- Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when handling the container;-The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked before consumption, in order to avoid burns;- Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode, even after microwave heating has ended;- When cleaning surfaces of door, door seal, cavity of the oven, use only mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth.-The oven should be cleaned regularly and any food deposits removed;- Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation;- If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.6oven.Don't remove oven's feet, do not block air events of the oven.6. Do not insert any object into the openings on the outercase.7. Do not at any time remove parts from the oven such as the feet, coupling, screws, etc.8. Do not cook food directly on the glass tray. Place foodin/on proper cooking utensil before placing in the oven.9. IMPORTANT-COOKWARE NOT TO USE IN YOURMICROWAVE OVENDo not use metal pans or dishes with metal handles.Do not use anything with metal trim.Do not use paper covered wire twist-ties on plastic bags. Do not use melamine dishes as they contain a material which will absorb microwave energy.This may causethe dishes to crack or char and will slow down thecooking speed.Do not use Centura Tableware.The glaze is not suitable for microwave use. Corelle Livingware closed handlecups should not be used.Do not cook in a container with a restricted opening,such as a pop bottle or salad oil bottle, as they mayexplode if heated in a microwave oven.Do not use conventional meat or candy thermometers.There are the thermometers available specifically formicrowave cooking. These may be used.10. Microwave utensils should be used only inaccordance with manufacturer's instructions.11. Do not attempt to deep-fry foods in this oven.12. Please remember that a microwave oven onlyheats the liquid in a container rather than thecontainer itself.Therefore, even though the lidof a container is not hot to the touch when removed from the oven, please remember thatthe food/liquid inside will be releasing the sameamount of steam and/or spitting when the lid isremoved as in conventional cooking.13.Always test the temperature of cooked foodyourself especially if you are heating or cookingfood/liquid for babies. It is advisable never toconsume food/liquid straight from the oven butallow it to stand for a few minutes and stir food/liquid to distribute heat evenly.14. Food containing a mixture of fat and water,e.g.stock,should stand for 30-60 seconds in theoven after it has been turned off.This is to allowthe mixture to settle and to prevent bubbling when a spoon is placed in the food/liquid or a stock cube is added.15. When preparing/cooking food/liquid and remember that there are certain foods, e.g. Christmaspuddings, jam and mincemeat, which heat up very quickly. When heating or cooking foods with a high fat or sugar content do not use plastic containers. 16. Cooking utensil may become hot because of heattransferred from the heated food. This is especially true if plastic wrap has been covering the top andhandles of the utensil. Potholders may be neededto handle the utensil.17.To reduce the risk of fire in the oven cavity:(a)Do not overcook food. Carefully attend microwaveoven if paper, plastic, or other combustible materials are placed inside the oven to facilitate cooking.(b)Remove wire twist-ties from bags before placingbag in oven.(c)If materials inside the oven should ignite, keep oven door closed, turn the oven off at the wall switch, or shut off power at the fuse or circuit breaker panel.FEATURE DIAGRAM(1) Door Safety Lock System(2) Oven Window(3) Oven Air Vent(4) Roller Ring(5) Glass Tray(6) Control Panel7CONTROL PANEL(1)Micro (4)DISPLAY WINDOW(7)Defrost/Time setting(5(68b) Press the button "Start/Reset", the microwave oven will work on 100% power for 1 minute.anti-clockwise to set the weight 0.5kg Select the food weight, it will automatically help you to adjust the power level and time.4.Auto-MenuYou only need to select the food type and weight, it will help you to automatically adjust the power and time.Example: Auto cooking 0.4 kg fisha) Press "Auto Menu" button until "A-5"displayed.b) Rotate the knob "Defrost/Time Setting" to set the weight 0.4kg.etc.Touching times12345Microwave power100%70%50%30%10%Display P100P70P50P30P10b) Press "Start/Reset"c) Press "Start/Reset"Example:defrost 0.5kg frozen meat.The weight of meat must be less than 2 kg.3.Auto weight defrostc) Press "Start/Reset"twicea) Rotate the knob "Defrost/Time Setting"b) Press "Start/Reset".9Weight Touching Times10.10.2(A-1)(A-2)(A-3)(A-4)(A-5)(A-6)0.30.40.50.10.20.30.40.50.60.20.30.40.50.60.81.01223456789MenuRiceVegetableMeatsNoodle 0.20.10.30.40.50.60.80.91.00.10.20.30.40.50.6FishReheat(kg)5.Setting the ClockThe oven has a 24-hour digital clock,To input the time, for example to 4:30pm:a) Press "Clock/Timer ", the display will flash, adjust the hour with the knob "Defrost/Time Setting" b) Press "Clock/Timer " again, adjust the minute with buttons "Defrost/Time Setting". c ) Press "Clock/Timer " again and the clock will be set.6.TimerThis allows you to set the microwave oven start and finish cooking at pre-set time.The clock must be set before you use this feature.Example:The current time is 16:30 and you want to start cooking at 18:15 on 70% power for 10minutes:b) Press "Micro" twice to select 70% power. c) Set cooking time for 10 minutes. d) Press "Start/Reset" This allows the microwave to be used as a countdown timer only, without activating the microwave oven. Example: You want to simmer food on your cook top for 15 minutes and it does not have its own timer. The current time display is 16.00.d ) If you want to change the time, repeat above procedure.a)Set timer start time to 18.15 by following procedures a) and b) under section ‘5. setting the Clock’.should remain flashing.Time 10a) Press “Clock/Timer” twice and the minute display will flash. b) Rotate the “Defrost/Time Setting” knob until it reads 16.15.c) Press the “Start/Reset” button once. A small clock symbol will be displayed above the time display. d) At 16.15 the appliance will beep 10 times. The small clock symbol will no longer be displayed.D 8VH DV D &RXQWGRZQ 7LPHU7. Child-safety-lock .To activate the child safety lock, press "Auto menu" and "Clock/Timer" at the same time for 2 seconds.Press "Auto menu" and "clock/Timer" at the same time for 2 seconds again, it will unlock the machine.8. Start/Reseta) In the course of operation, pressing "Start/Reset" button will stop operation.b) If any program was set before pressing start, pressing this button will cancel all the set program.9. Memory cooking function:T his function will memorize one favourite cooking programme to avoid manually entering the time or power setting.a) If no memory has been set press "memory" button "1" will be displayed, input cooking power and time, press"memory" again, the set program will be memorized. If you press “Start/Reset” instead of "memory" button, theoven will start working, and the program will still be memorized.b) I f memory has been set already, when you press "memory" button, "1" will be displayed, theoven will operate according to the memorized program after you press "Start" button.The programmme will not be kept when the electricity is off.CARE OF YOUR MICROWAVE OVEN1.Turn the oven off and remove the power plug from the wall socket before cleaning.2.Keep the inside of the oven clean.When food splatters or spilled liquids adhere to oven walls,wipe with a damp cloth.The use of harsh detergent or abrasives is not recommended.3.The outside oven surface should be cleaned with a damp cloth.To prevent damage to the operating parts inside the oven,water should not be allowed to seep into the ventilation openings.4.Do not allow the Control Panel to become wet. Clean with a soft, damp cloth, Do not use detergents,abrasives or spray-on cleaners on the control Panel.5.If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth.This may occur when the microwave oven is operated under high humidity conditions and in no way indicates malfunction of the unit.6.It is occasionally necessary to remove the glass tray for cleaning.Wash the tray in warm sudsy water or ina dishwasher.7.The roller ring and oven cavity floor should be cleaned regularly to avoid excessive noise.Simply wipe the bottom surface of the oven with mild detergent,water or window cleaner and dry.The roller ring may bewashed in mild sudsy water or dish washer.Cooking vapour collect during repeated use but in no wayaffect the bottom surface or roller ring wheels.When removing the roller ring from cavity floor for cleaning,be sure to replace it in the proper position.8.Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in adeep microwaveable bowl. Microwave for 5 minutes,wipe thoroughly and dry with a soft cloth.9.When it becomes necessary to replace the oven light,please consult a dealer to have it replaced.10. Clean door seals on a regular basis of any food residue. This will ensure ongoing performance, safety and a hygienic environment of the microwave oven*CIRCUIT SUBJECT TO CHANGE WITHOUT NOTICESCHEMATIC DIAGRAM(DOOR OPENED,COOK OFF CONDITION)SWC: THE MONITOR INTERLOCK SWITCH SWB: SECONDARY INTERLOCK SWITCH SWA: PRIMARY INTERLOCK SWITCH FM: FAN MOTORTM: TURNTABLE MOTOR。
格兰仕微波炉说明书.pdf_1699244455.306078
INSTRUCTION MANUAL MM-EG25P(BK)22. T he appliance is intended to be used freestanding.23. T he rear surface of appliances shall be placed against a wall.24. T he appliances are not intended to be operated by means of an external timer or separate remote-control system.25. T he temperature of accessible surfaces may be high when the appliance is operating.26. W ARNING: When the appliance is operated in the combination mode, children should only use the oven underadult supervision due to the temperatures generated.READ CAREFULLY AND KEEP FOR FUTURE REFERENCETo Reduce the Risk of Injury to PersonsGrounding InstallationElectric Shock HazardTouching some of the internal components can cause serious personal injury or death. Do not disassemble this appliance.Electric Shock HazardImproper use of the grounding can result in electric shock.Do not plug into an outlet until appliance is properly installed and grounded.This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric shock by providing an escape wire for the electric current.This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt exists as to whether the appliance is properly grounded.If it is necessary to use an extension cord, use only a 3-wire extension cord.1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping overa longer cord.2. I f a long cord set or extension cord is used:1) T he marked electrical rating of the cord set or extension cord should be at least as great as the electrical ratingof the appliance.2) T he extension cord must be a grounding-type 3-wire cord.3) T he long cord should be arranged so that it will not drape over the counter top or tabletop where it can bepulled on by children or tripped over unintentionally.4A) Control panel Grill Rack ( C an not be used i nmicrowave functionand must be placedon the glass tray)B CD EG FTurntable InstallationTurntable ring56911• POTATO(a) P ress “POTATO” repeatedly until the number you wish appears in the display, “1”, “2”, “3” will display in order.“1”SET : 1 potato (approximate 230 gram)“2”SETS: 2 potatoes (approximate 460 gram)“3”SETS: 3 potatoes (approximate 690 gram)For example, press “POTATO” once, “1” appears.(b)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.• FROZEN VEGETABLE(a)P ress“FROZEN VEGETABLE” repeatedly until the number you wish appears in the display, “150”, “350”, “500”grams will display in order.For example, press “FROZEN VEGETABLE” once, “150” appears.(b)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.• BEVERAGE(a)P ress“BEVERAGE” repeatedly until the number you wish appears in the display, “1”, “2”, “3” cup will display inorder. One cup is about 120ml. For example, press “BEVERAGE” once, “1” appears.(b)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.• MEAT FunctionA. C HICKEN menu(a) P ress “MEAT” once to choose chicken menu,”CHIC” displays.(b) P ress “START/+30 SEC.“ to confirm the menu. “400” displays.(c) K eep pressing “MEAT” to choose chicken weight. “600”, “800”, “1000” or “1200” grams can be selected.(d)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.B. B EEF menu(a) P ress “MEAT” twice to choose beef menu,”BEEF” displays.(b) P ress “START/+30 SEC.” to confirm the menu. “300” displays.(c) K eep pressing “MEAT” to choose beef weight. “500”, “700”, “900” or “1100” grams can be selected.(d)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.C.PORK menu(a) P ress “MEAT” thrice to choose pork menu,”PO” displays.(b) P ress “START/+30 SEC.” to confirm the menu. “150” displays.(c) K eep pressing “MEAT” to choose pork weight. “300”, “450”, “600” or “750” grams can be selected.(d)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.• DINNER PLATE(a)P ress“DINNER PLATE” repeatedly until the number you wish appears in the display, “250”, “350”, “500” gramswill display in order.For example, press “DINNER PLATE” once, “250” appears.(b)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.• FROZEN PIZZA(a)P ress“FROZEN PIZZA” repeatedly until the number you wish appears in the display, “100”, “200”, “400” gramswill display in order.For example, press “FROZEN PIZZA” once, “100” appears.(b)P ress“START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes, buzzer sounds five times and thenturn back to waiting state.12。
格兰仕微波炉使用说明书
CONTENT (2)IMPORTANT SAFETY INSTRUCTIONS (3)GROUNDING INSTRUCTIONS (5)INSTALLATION GUIDE (5)COOKING UTENSILS GUIDE (6)SPECIFICATIONS (7)PART NAMES (7)CONTROL PANEL (8)OPERATION INSTRUCTIONS (9)Setting the clock (9)Timer function (9)+30 sec function (9)Express cooking (9)Microwave cooking (10)Time defrost (10)Weight defrost (10)Popcorn (11)Toast (11)Bagel (11)Broil (11)Bake (12)Pizza (12)Potato (13)Warm (13)Auto cook (13)Auto reheat (14)Soften/melt (15)Child lock (15)Turntable (15)Failure diagnose (16)CLEANING AND CARE (17)to excessive microwave energy:1. Read all instructions before using the appliance.2. Read and follow the specific "PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TOEXCESSIVE MICROWAVE ENERGY" on page 1.3. This appliance must be grounded. Connect only to properly grounded outlet. See"GROUNDING INSTRUCTIONS" on page 4.4. Install or locate this appliance only in accordance with the provided installationinstructions.5. Do not operate the oven when empty.6. Some products such as whole eggs and sealed containers -for example, closed glassjars- are able to explode and should not be heated in this oven.7. Use this appliance only for its intended use as described in this manual. Do not usecorrosive chemicals or vapors in this appliance. This type of oven is specifically designed to heat, cook, or dry food. It is not designed for industrial or laboratory use.8. As with any appliance, close supervision is necessary when used by children.9. To reduce the risk of fire in the oven cavity:a) D o not overcook food. Carefully attend appliance when paper, plastic, or othercombustible materials are placed inside the oven to facilitate cooking.b) R emove wire twist-ties from paper or plastic bags before placing bag in oven.c) If materials inside the oven should ignite, keep oven door closed, turn oven off, anddisconnect the power cord or shut off power at the fuse or circuit breaker panel.d) D o not use the cavity for storage purposes. Do not leave paper products, cookingutensils or food in the cavity when not in use.10. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling pointwithout appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the container is removed from the microwave oven is not always present.THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS INSERTED INTO THE LIQUID. To reduce the risk of injury to person:a) D o not overheat the liquid.b) S tir the liquid both before and halfway through heating it.c) Do not use straight-sided containers with narrow necks.d) A fter heating, allow the container to stand in the microwave oven for a short timebefore removing the container.e) U se extreme care when inserting a spoon or other utensil into the container.11. Do not heat oil or fat for deep-frying. It is difficult to control the temperature of oil inmicrowave oven.12. Do not cover or block any openings on the appliance.13. Do not store or use this appliance outdoors. Do not use this product near water, forexample, near a kitchen sink, in a wet basement, near a swimming pool, or similar locations.14. Do not operate this appliance if it has a damaged cord or a plug, if it is not workingproperly or if it has been damaged or dropped.15. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not letcord hang over edge of table or counter.16. This appliance should be serviced only by qualified service personnel, contact nearestauthorized service facility for examination, repair, or adjustment.17. When cleaning surfaces of door and oven that comes together on closing the door, useonly mild, nonabrasive soaps, or detergents applied with a sponge or soft cloth.18. Oversized food or oversized metal utensils should not be inserted in a microwave/toasteroven as they may create a fire or risk of electric shock.19. Do not clean with metal scouring pads. Pieces can burn off the pad and touch electricalparts involving a risk of electric shock.20. Do not use paper products when appliance is operated in the toaster mode.21. Do not store any material s, other than manufacturer’s recommended accessories, in thisoven when not in use.22. Do not cover racks or any other part of the oven with metal foil. This will causeoverheating of the oven.23. This equipment has been tested and found to comply with Part 18 of the FCC Rules.Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the product.24. This equipment generates, uses and can radiate radio frequency energy and, if notinstalled and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:⚫Reorient or relocate the receiving antenna.⚫Increase the separation between the equipment and receiver.⚫Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.⚫Consult the dealer or an experienced radio/TV technician for help.SAVE THESE INSTRUCTIONSreduces risk of electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly installed and grounded.WARNING!-- Improper use of the grounding plug can result in a risk of electric shock. Consult a qualified electrician or serviceman if the grounding instructions are not completely understood, or if doubt exists as to whether the appliance is properly grounded, and if it is necessary to use an extension cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extension cord shall be equal to or greater than the electrical rating of the appliance.Electrical RequirementsThe electrical requirements are a 120 volt 60 Hz, AC only, 20 amp. It is recommended that a separate circuit serving only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must be plugged into a wall outlet properly installed and grounded. Power Cord1. A short power supply cord is provided to reduce the risks resulting from becomingentangled in or tripping over a longer cord.2. Longer cord sets or extension cords are available and may be used if care is exercisedin their use.3. If long cord or extension cord is used：a) The marked electrical rating of the cord set or extension cord should be at least asgreat as the electrical rating of the appliance.b) The extension cord must be a grounding-type 3-wire cord, and The longer cord shouldbe arranged so that it will not drape over the counter top or table top where it can be pulled on by children or tripped over unintentionally.1. Make sure that all the packing materials are removed from the inside of the door.2. This microwave oven must be placed on a flat.3. For correct operation, the oven must have sufficient airflow. Allow minimum 20cm of free spacenecessary above the top surface of the oven and 5cm at both sides. The microwave oven rear plate must be placed close to the wall. Do not cover or block any openings on the appliance. Do not remove feet.4. The appliance shall be only used on a countertop over 3 feet(914mm) above the floor.5. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.6. Make sure that the power cord is undamaged and does not run under the oven or over any hot orsharp surface.7. The socket must be readily accessible so the microwave oven can be easily unplugged in anemergency.This section lists which utensils can be used in this microwave, which have limited use for short periods, and which should not be used in this microwave.RECOMMENDEDMicrowave browning dish—Use to brown the exterior of small items such as steaks, chops, or pancakes. Follow the directions provided with your browning dish.Microwaveable plastic wrap— Use to retain steam. Leave a small opening for some steam to escape and avoid placing it directly on the food.Paper towels and napkins— Use for short-term heating and covering; these absorb excess moisture and prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite. Glass and glass-ceramic bowls and dishes— Use for heating or cooking.Paper plates and cups— Use for short-term heating at low temperatures. Do not use recycled paper, which may contain metal and could ignite.Wax paper— Use as a cover to prevent spattering.Thermometers— Use only those labeled "Microwave Safe" and follow all directions. Check the food in several places. Conventional thermometers may be used on microwave food once the food has been removed from the oven.LIMITED USEAluminum foil— Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum foil and cavity.Ceramic, porcelain, and stoneware— Use these if they are labeled "Microwave Safe". If they are not labeled, test them to make sure they can be used safely.Plastic— Use only if labeled "Microwave Safe". Other plastics can melt.NOT RECOMMENDEDGlass jars and bottles— Regular glass is too thin to be used in a microwave. It can shatter and cause damage and injury.Paper bags— These are a fire hazard, except for popcorn bags that are designed for microwave use. Styrofoam plates and cups— These can melt and leave an unhealthy residue on food.Plastic storage and food containers— Containers such as margarine tubs can melt in the microwave. Metal utensils — These can damage your oven. Remove all metal before cooking.Note:Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and microwave on HIGH for 30 seconds. A dish which becomes very hot should not be used.1. Door Safety Lock System2. Oven Window3. Glass Tray4. Control Panel5. Wave Guide (Please do not remove themica plate covering the wave guide)6. Gasket7. Top Grill Heater 4256137CONTROL PANEL⚫DISPLAY SCREENCooking time, power, indicators and present time are displayed.⚫TOAST/BAGEL/PIZZA/POPCORN/POTATOUse to cook toast, bagel, pizza, popcorn and potato.⚫BROIL/BAKEUse to broil and bake food.⚫CLOCK/TIMERPress to set the clock time.Press to set timer function.⚫WARMUse to set keeping warm function.⚫LOCK/TURNTABLE OFFUse to set child lock function.Use to turn turntable on or off.⚫AUTO COOKPress to set auto cooking program.⚫AUTO REHEATPress to reheat food. ⚫+30 SECPress to add cooking time.⚫MICROPress to set microwave cooking program.⚫DEFROST/TIME/WEIGHTPress to defrost food based on time.Press to defrost food based on weight.⚫SOFTEN/MELTPress to cook soft and melt food.⚫STOP/CANCELPress to clear all previous settings before cooking starts.Press once to stop cooking temporarily or twice to cancel cooking altogether.⚫STARTPress to start cooking or defrosting program.⚫MENU/TIME/WEIGHT (dial)Turn to select food menus, enter time, temperature, food weight or servings.Press to confirm setting or start the oven.➢When the oven is first plugged in, beep will sound and the display will show "12:00" (":" flashing).➢In the process of setting, broke about 20 seconds the oven will return to standby mode.➢During cooking, if press STOP/CANCEL button once, the program will be paused, then press START button or press MENU/TIME/WEIGHT dial to resume, but if press STOP/CANCEL button twice, the program will be canceled.➢After cooking end, the screen will display End and beep will sound every two minutes until user press STOP/CANCEL button or open the door.➢If there is not any operation for 1 minute, the display will becomes weakly bright, press any button to light the screen.This is a 12- or 24- hour clock. You can choose to set the clock time in 12- or 24- hour cycle by pressing the CLOCK/TIMER button in standby mode.1. In standby mode, press and hold CLOCK/TIMER button for 3 seconds to select 12- hour clock,press the button again to select 24- hour clock.2. Turn MENU/TIME/WEIGHT dial until the correct hour is displayed.3. Press CLOCK/TIMER or START or MENU/TIME/WEIGHT dial once .4. Turn MENU/TIME/WEIGHT dial until the correct minute is displayed.You can use the timer feature, when you need to be reminded of the cooking or some other things.1. In standby mode, press CLOCK/TIMER button once.2. Turn MENU/TIME/WEIGHT dial to enter desired time. The longest time is 95 minutes.3. Press MENU/TIME/WEIGHT dial or START button to confirm.NOTE: When the countdown ends, the buzzer will beep to remind you. You can check the countdown time by pressing CLOCK/TIMER button. But if STOP/CANCEL button is pressed when the display showsDuring cooking, you can add cooking time by pressing +30 SEC button repeatedly. The longest time is 95 minutes.Use this feature to program the oven to microwave food at 100% power conveniently.In standby mode, turn MENU/TIME/WEIGHT dial to enter cooking time, and then press theMENU/TIME/WEIGHT dial or START button once. The oven will start working automatically.1. In standby mode, press MICRO button once.2. Turn MENU/TIME/WEIGHT dial to select power level.3. Press MENU/TIME/WEIGHT dial or START button.4. Turn MENU/TIME/WEIGHT dial to enter cooking time. The longest time is 95 minutes.5. Press MENU/TIME/WEIGHT dial or START to confirm.The defrosting power is adjusted automatically once the cooking time is programmed.1. In standby mode, press DEFROST/TIME/WEIGHT button once.2. Turn MENU/TIME/WEIGHT dial to enter defrosting time. The longest time is 95 minutes.3. Press MENU/TIME/WEIGHT dial or START button to confirm.NOTE: During defrosting program, the system will pause to remind you to turn over the food, after that,The defrosting time and power level are automatically set once the food category and the weight are programmed.1. In standby mode, press DEFROST/TIME/WEIGHT button twice.2. Turn MENU/TIME/WEIGHT dial to select a food code (dEF1-Meat, dEF2-Poultry, dEF3-Seafood).3. Press MENU/TIME/WEIGHT or START once.4. Turn MENU/TIME/WEIGHT dial to enter the food weight.5. Press MENU/TIME/WEIGHT dial or START to start.NOTE:Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of a pound to ounces using the following chart.During defrosting program, the system will pause and sound to remind you to turn over the food,1. In standby mode, press POPCORN button once.2. Turn MENU/TIME/WEIGHT dial to adjust cooking time.3. Press MENU/TIME/WEIGHT dial or START button once to start.1. In standby mode, press TOAST button once.2. Turn MENU/TIME/WEIGHT dial to select servings (1~4 PC).3. Press MENU/TIME/WEIGHT dial or START button.4. Turn MENU/TIME/WEIGHT dial to select the darkness (1-light, 2-moderate, 3- dark).1. In standby mode, press BAGEL button once.2. Turn MENU/TIME/WEIGHT dial to select servings (1~4 PC).3. Press MENU/TIME/WEIGHT dial or START button.4. Turn MENU/TIME/WEIGHT dial to select the darkness (1-light, 2-moderate, 3- dark).5. Press MENU/TIME/WEIGHT dial or START button to start.NOTE: After cooking end, open the oven door, the display will show "END" for 3 minutes and then the oven will return to standby mode. You can add the cooking time by pressing +30 SEC button within the 3For food code "Ar-1", "Ar-2" and "Ar-3":1. In standby mode, press BROIL button twice.2.3. Press MENU/TIME/WEIGHT dial or START button once.4. Turn MENU/TIME/WEIGHT dial to enter the food weight.5. Press MENU/TIME/WEIGHT dial or START button once to start. For others food:1. In standby mode, press BROIL button once.2. Turn MENU/TIME/WEIGHT dial to select temperature (400℉→425℉→350℉→375℉). 3. Press MENU/TIME/WEIGHT dial or START button once. 4. Turn MENU/TIME/WEIGHT dial to enter cooking time. For food code "Ab-1", "Ab-2" and "Ab-3": 1. In standby mode, press BAKE button twice.2.3. Press MENU/TIME/WEIGHT dial or START button once to start preheat.4. After preheating end, open the door and place container of food at the center of the turntable.5. Press MENU/TIME/WEIGHT dial or START button to start. For others food:1. In standby mode, press BAKE button once.2. Turn MENU/TIME/WEIGHT dial to select temperature (350℉→375℉→400℉→325℉).3. Press MENU/TIME/WEIGHT dial or START button once.4. Turn MENU/TIME/WEIGHT dial to enter cooking time.5. Press MENU/TIME/WEIGHT dial or START button once to start preheat.6. After preheating end, open the door and place container of food at the center of the turntable. 1. In standby mode, press PIZZA button once.2. Turn MENU/TIME/WEIGHT dial to select temperature (400°F →425°F →350°F →375°F).3. Press MENU/TIME/WEIGHT dial or START button once.4. Turn MENU/TIME/WEIGHT dial to enter cooking time. The longest time is 35 minutes.5. Press MENU/TIME/WEIGHT dial or START button to start.NOTE: During cooking, you can press +30 SEC button repeatedly to add cooking time an up to 35 minutes.1. In standby mode, press POTATO button once.2. Turn MENU/TIME/WEIGHT dial to enter food weight (8-24 oz).1. In standby mode, press WARM button once.2. Turn MENU/TIME/WEIGHT dial to select temperature (160°F, 170°F, 180°F, 190°F, 200°F).3. Press MENU/TIME/WEIGHT dial or START button once.4. Turn MENU/TIME/WEIGHT dial to enter cooking time. The longest time is 95 minutes.5. Press MENU/TIME/WEIGHT dial or START button to start.NOTE:During cooking, you can press +30 SEC button repeatedly to add cooking time an up to 951. In standby mode, press AUTO COOK button once.2. Turn MENU/TIME/WEIGHT dial to select a food code.3. Press MENU/TIME/WEIGHT dial or START once.4. Turn MENU/TIME/WEIGHT dial to select food weight or servings.5. Press MENU/TIME/WEIGHT dial or START to start.1. In standby mode, press AUTO REHEAT button once.2. Turn MENU/TIME/WEIGHT dial to select a food code.3. Press MENU/TIME/WEIGHT dial or START once.4. Turn MENU/TIME/WEIGHT dial to select food weight or servings.5. Press MENU/TIME/WEIGHT or START to start.1. In standby mode, press SOFTEN/MELT button once or twice to select code "SF-1" or "SF-2".2. Press MENU/TIME/WEIGHT dial or START button once.3. Turn MENU/TIME/WEIGHT dial to enter food servings.The child proof lock prevents unsupervised operation by children.To set the child proof lock: Press and hold LOCK/TURNTABLE OFF button more than 3 seconds, the indicator light will come on. In the lock state, all buttons are disabled.To cancel the child proof lock: Press and hold LOCK/TURNTABLE OFF button more than 3 seconds, theDuring cooking, the turntable is default working. You can turn the turntable on or off by pressingLOCK/TURNTABLE OFF button.NOTE: Sometimes the turntable may become too hot to press. Be careful to touch the turntable. When the turntable is set in standby mode, the setting of the turntable will not take effect immediately, but will take effect when cooking is started.NOTE: For "Er10 ~ Er13", the display shows the code and continues to beep, after pressing STOP/CANCEL button, the system comes back to normal standby mode.1. Turn off the oven and unplug the power cord from the wall when cleaning.2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipewith a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using spray or other harsh cleaners. They may stain, streak or dull the door surface.3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operatingparts inside the oven, water should not be allowed to seep into the ventilation openings.4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a dampcloth to remove any spills or spatters. Do not use abrasive cleaner.5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the controlpanel, leave oven door open to prevent oven from accidentally turning on.6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This mayoccur when the microwave oven is operated under high humidity condition. And it is normal.7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy wateror in a dishwasher.8. The roller ring and oven floor should be cleaned regularly to avoid excessive noise. Simply wipe thebottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or in a dishwasher. When removing the roller ring, be sure to replace it in the proper position.9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in amicrowaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.10. If the light bulb burns out, please contact customer service to have it replaced.11. The oven should be cleaned regularly and any food deposits should be removed. Failure to maintainthe oven in a clean condition could lead to deterioration of surface that could adversely affect the life of the unit and could possibly result in a hazardous situation.12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed to theparticular disposal center provided by the municipalities.13. When the microwave oven with grill function is first used, it may produce slight smoke and smell. Thisis a normal phenomenon, because the oven is made of a steel plate coated with lubricating oil, and the new oven will produce fumes and odor generated by burning the lubricating oil. This phenomenon will disappear after a period of using.。
格兰仕微波炉使用说明书
燒烤功能 按 1 次 無預熱
按 2 次 有預熱
若使用無預熱燒烤功能，可直接把食物放入機器內， 温度調整為 100-230°C：
關上爐門，按一次 “ 燒烤 ” 键，即可調整温度和時間。 時間調整為 5 秒 -90 分鐘。
ቤተ መጻሕፍቲ ባይዱ
● 預熱是為了使爐腔的温度達到烘焙或燒烤的初始 温度 無需設定時間，在預熱過程中請不要放入食 物。
快速入門指南
當機器首次使用或首次連接電源時，為省電模式，需拉開微波爐門激活程序。
水盒使用
廢水盒
淨水盒
觀察窗
使用說明 用於承接爐門下方滴落的水珠，和爐腔清潔時產 生的水。
使用說明 ● 用於帶有蒸氣功能與清潔功能時所需的純淨
水。 ● 當機器顯示“ ”時，請清空和洗淨水盒，並
重新加入純淨水。 注意
使用前，淨水盒裝水後，請蓋緊水盒蓋，避 免水盒傾斜產生漏水的情況。
操作指引
純蒸功能
使用純蒸功能後，會產生一定量的積水，建議使用完畢後及時清潔爐腔上的 冷凝水。 若未清潔並使用其他功能時，出現蒸氣屬正常現象。
温度調整為 50-100°C： 時間調整為 5 秒 -90 分鐘。
微波功能
微波功能下，請不要將烤盤、烤架、錫紙等任何 金屬 器皿放置在爐腔内。
旋轉旋鈕選擇火力，時間皆為 5 秒 -95 分鐘，詳情請參考入 門指南。
温度調整為 100-230°C
● 提醒預熱結束後，即可拉開爐門放入食物；
預熱後時間調整範圍為 5
拉開爐門後，機器將會自動跳轉到時間設定界面。 秒 -90 分鐘。
菜單 可通過順時針或逆時針來選擇菜單編號
順時針菜單編號 逆時針菜單編號
01-41 41-01
當微波爐腔體內溫度高於 65°C 時，顯示屏顯示高溫圖標 “ ”，此顯示為注 意高溫提示，屬正常狀態，請注意預防溫度過高，以免燙傷。
D4W一S20格兰仕微波的说明书
D4W一S20格兰仕微波的说明书微波炉的使用在家庭中是非常普遍的。
因为微波炉不仅可以用来加热美食，也可以制作美食。
微波炉的使用其实也非常简单。
我们一起来看看格兰仕的微波炉是如何使用的吧。
选择相应的工作模式，按照自己的需求选择需要烹饪的时间。
将需要加热的食物放入微波炉中。
用陶瓷的、玻璃的专用塑料的容器放置，关闭盖子。
等听到完成提示音后，用隔热手套取出即可。
清洗好微波炉，放入食物，选择模式，选择时间，运行后等待，取出食物。
格兰仕微波炉是常用的厨房电器，便捷省事，但是在使用格兰仕微波炉的时候是有很多的注意事项的，我们一起去看一下格兰仕微波炉说明书，了解一下。
格兰仕微波炉说明书一、操作方法1、若设置的烹调时间少于二，则先将“定时器”开关旋转至超过三位置，再回旋到所需烹调时间的位置上。
2、当微波炉不急需工作时，应将“定时器”旋转到“0”（关闭）位置，必免微波如空载运行损坏机器。
3、在烹调过程中，如需打开炉门可暂停烹调程序，再关紧炉门，微波炉会自动启动剩余烹调程序；若旋转“定时器”到“0”位置就取消了当前烹调程序，并发出一声铃响。
?? 微波炉烹调技巧1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在墙体内底板剧中位置后关紧炉门。
3、旋转“功能选择器”到“中火”位置。
4、旋转“定时器”到“5”位置，微波炉即开始工作。
光波烹调1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在腔体内底板居中位置后关紧炉门。
3、旋转“功能选择器”到“光波”位置。
4、旋转“定时器”到“6”位置，微波炉即开始工作。
组合烹调1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在腔体内底板居中位置后关紧炉门。
3、旋转“功能选择器”到“组合1”“组合2”或“组合3”任一位。
G8023 YSL-V2 (银色) 格兰仕微波炉操作指导书
1.目的规范G8023 YSL-V2 (银色) 格兰仕微波炉的使用和维护，指导安全操作，提高工作效率，确保设备使用寿命。
2.范围适用于G8023 YSL-V2 (银色) 格兰仕微波炉的使用和维护保养。
3.职责3.1操作人员严格按本设备操作要求执行操作、清洁和保养。
3.2设备维护人员负责对本设备进行维护和保养。
4.内容4.1按需要选定杀菌“微波杀菌”、“光波杀菌”、“微波火力”等功能键。
4.2旋转旋钮至所需时间。
4.3按下“启动”键。
5.保养及注意事项：5.1微波炉应放在空气流通的平台上，两侧及背面与墙壁至少有5-10厘米的距离，保证顶部排风口排气顺畅。
5.2勿放置高温、潮湿的地方，勿靠近电视机、收音机等带磁场的电器。
5.3不能空烧：即微波炉工作时炉腔内不能无食物，否则会损坏微波炉。
5.4使用适当的器皿：抗热的玻璃制品或陶瓷制品、耐热的塑料制品、耐热膜；木制的碗、盘、柳条制的篮子、一次性纸餐盒，餐巾也可以在微波炉内作短时间加热。
5.5不可以使用的器皿：金属容器(包括内衬铝箔的软包装)、带有金属装饰条纹的玻璃和陶瓷器具、易碎的玻璃器皿、采用粘和方式制作的器具、内壁涂有彩色或油漆的各种容器。
5.6每次加热的食物不宜过多过厚。
5.7加热鸡蛋、板粟等带壳无孔的食物，应先刺穿，以防爆裂。
5.8使用保鲜膜覆盖加热食物时，需留有小孔；不能将密封的瓶子放在炉内加热，应将瓶盖打开，窄口瓶或缸装食品不可以直接加热。
5.9不使用微波炉时，必须将定时器旋转到“停”的位置。
5.10在使用烧烤型微波炉时，食物与加热管应保持一定的距离。
5.11在微波炉和烧烤过程中可随时打开炉门，检查或翻转食物。
打开炉门时定时器停止旋转，关上门微波炉继续加热。
由于加热管温度很高，打开炉门时切勿用手触摸加热管，以免烫伤。
要带上隔热手套，方可翻转或搅拌食物。
5.12冷冻食品需先解冻，再烹调，否则会出现食物外部已熟透而中间未解冻的现象。
5.13不宜将食品直接放在玻璃转盘上烹调，食品应放在合适的器皿中，再将器皿放在玻璃转盘上烹调。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
格兰仕微波炉-说明书
格兰仕微波炉使用说明书
一、操作方法
1、若设置的烹调时间短于二分钟，则先将“定时器”旋转至超过三分钟位置，再
回旋到所需烹调时间的位置。
2、当微波炉不需要急需工作时，应将“定时器”旋转到“0”（关闭）位置，以免微
波如空载运行损坏机器。
3、在烹调过程中，打开炉门可暂停烹调程序，再关紧炉门，微波炉会自动启动
剩余烹调程序；若旋转“定时器”到“0”位置可取消当前烹调程序，并发出一声铃响。
微波烹调
1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在墙体内底板剧中位置后关紧炉门。
3、旋转“功能选择器”到“中火”位置。
4、旋转“定时器”到“5”位置，微波炉即开始工作。
光波烹调
1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在腔体内底板居中位置后关紧炉门。
3、旋转“功能选择器”到“光波”位置。
4、旋转“定时器”到“6”位置，微波炉即开始工作。
组合烹调
1、先将“定时器”旋转到“0”位置。
2、将盛放食物的合适器皿放在腔体内底板居中位置后关紧炉门。
3、旋转“功能选择器”到“组合1”“组合2”或“组合3”任一位置。
4、旋转“定时器”到“15”位置，微波炉即开始工作。
