祥兴电脑提花机显示屏操作说明书
车床电脑显示屏操作方法
车床电脑显示屏操作方法
车床电脑显示屏主要用来控制和监视车床的操作，以下是一般的操作方法：
1. 开启显示屏：按下显示屏上的电源按钮，显示屏将开始启动。
2. 登录系统：显示屏启动后，会显示一个登录页面。
输入正确的用户名和密码，按下确认键，即可登录系统。
3. 主界面操作：登录成功后，将进入主界面。
主界面通常会显示车床的状态、参数、菜单等信息。
通过触摸屏或键盘进行操作。
4. 菜单操作：根据需求选择菜单栏中的功能按钮。
可以使用触摸屏进行选择，或者使用键盘上的方向键和确认键进行操作。
5. 参数设置：在菜单中选择相应的参数设置功能，根据需要调整车床的工作参数，如转速、进给速度等。
6. 监视和控制：显示屏可以实时显示车床的状态，如刀具位置、工件进给等。
可以通过操作显示屏上的按钮，控制车床的运行。
7. 保存和加载程序：在显示屏上可以保存和加载加工程序。
通过菜单中的功能按钮，进行文件的保存和加载操作。
8. 关闭显示屏：在完成操作后，按下显示屏上的关机按钮，按照提示进行关机操作。
请注意，以上操作方法仅适用于一般的车床电脑显示屏，不同品牌和型号的显示屏可能会有略微的差异。
在具体操作时，请参考相关的用户手册或咨询相关人员。
显示屏使用说明书
1.2 屏体功率和电流的计算
1.2.1 总开关选择说明: 整屏总功率/线电压(380)×安全系数(1.5) = 所选开关电流值 单个箱体漏电流×箱体数×系数(1.5) = 所选开关的总漏电流 标准箱体的 P16 和 P20 的全彩屏,单个箱体的漏电流为 2 毫安； 1.2.2 分开关的选择说明: 本开关所控制屏体的总电流×安全系数(1.5)=分空气开关的电流值 1.2.3 总线的选择说明: 整屏的总功率/线电压(380)/每平方毫米安全载流量×安全系数(1.5)＝总线的截 面积 1.2.4 一般铜线安全计算方法是： 2.5 平方毫米铜电源线的安全载流量－－28A 4 平方毫米铜电源线的安全载流量－－35A 6 平方毫米铜电源线的安全载流量－－48A 10 平方毫米铜电源线的安全载流量－－65A 16 平方毫米铜电源线的安全载流量－－91A 25 平方毫米铜电源线的安全载流量－－120A
硬件配置
CPU: 奔腾双核 2.0G 以上.硬盘 250G 以上 主板:3 个 PCI 插槽，1 个 PCI-E 插槽，1 个 com 口 内存:2G 显卡:GF9400 以上 相关软件 微软公司的媒体播放器(MediaPlayer)--必须安装 OFFICE2003--如需 WORD 文件必须安装 RealPlayer--如需播 RealPlayer 文件必须安装 安装相应的视频解码器
图 1-2
如图 1-2 所示，红色的卡是显卡，安装在 PCI-E 插槽里。绿色的卡是发送
显示屏的使用流程解说明
显示屏的使用流程解说明一、连接显示屏1.将显示屏电源插头插入电源插座。
2.使用HDMI线将显示屏连接到电脑或其他设备的HDMI接口上。
3.确保显示屏和电脑或其他设备都已打开。
二、调整显示屏设置1.打开电脑或其他设备，并登录系统。
2.右键点击桌面空白处，选择“显示设置”（或类似选项）。
3.在显示设置界面中，可以看到显示屏的图标和设置选项。
4.点击显示屏图标，可以选择显示屏的分辨率、方向和缩放比例等设置。
5.根据个人需求，调整显示屏的设置。
三、显示屏的基本操作1.打开显示屏的电源开关，显示屏开始亮起。
2.使用显示屏上的菜单按钮或遥控器，可以进行菜单导航和设置操作。
3.菜单中通常包括亮度、对比度、色彩、音量等调节选项，可以根据需要进行调整。
4.一些显示屏还配备了触摸功能，可以通过手指触摸屏幕来进行操作。
四、显示屏的常见问题解决1.如果显示屏无法正常亮起，首先检查电源线是否插好，电源开关是否打开。
2.如果显示屏上显示的画面模糊或颜色异常，可以调整显示屏的亮度、对比度、色彩等设置。
3.如果显示屏无法与电脑或其他设备连接，可以尝试更换HDMI线或重新启动设备。
4.如果显示屏上有黑屏、闪烁等问题，可以尝试重新插拔HDMI线或重新启动设备解决。
五、显示屏的注意事项1.使用显示屏时，注意避免长时间连续使用，应适时休息眼睛。
2.避免将显示屏放置在过热的环境中，以免影响显示效果和寿命。
3.不要用尖锐的物体触摸或碰撞显示屏，以免损坏屏幕表面。
4.当显示屏长时间不使用时，建议关闭电源开关以节省能源和延长显示屏寿命。
以上是显示屏的使用流程解说明，包括连接显示屏、调整显示屏设置、显示屏的基本操作、显示屏的常见问题解决和显示屏的注意事项。
通过按照以上流程和操作步骤进行，用户可以正确使用显示屏并解决常见问题，以获得更好的显示效果和使用体验。
电脑花样机功能键1介绍说明书
电脑花样机功能键1介绍说明书
【一、电脑花样机功能键1的基本信息】
电脑花样机功能键1，顾名思义，是电脑花样机上的一款重要功能键。
它主要用于控制和调节花样机的各种功能，让操作更加便捷高效。
电脑花样机功能键1的设计紧凑，操作简便，无论是初学者还是专业人士，都能轻松上手。
【二、电脑花样机功能键1的操作方法】
1.开机后，按下电脑花样机功能键1，进入功能选择界面。
2.通过上下键调整所需功能，然后按下确认键即可启用相应功能。
3.在操作过程中，如需取消当前功能，可按下电脑花样机功能键1旁的取消键。
【三、电脑花样机功能键1的应用领域】
电脑花样机功能键1广泛应用于服装纺织、家居纺织、工艺礼品、广告装饰等行业。
通过使用电脑花样机功能键1，可以轻松实现各种图案的花样设计，满足各类加工需求。
【四、电脑花样机功能键1的注意事项】
1.在操作过程中，请勿用手触摸正在运转的部件，以免发生意外伤害。
2.定期检查电脑花样机功能键1的连接线和开关，确保设备正常工作。
3.如有异常现象，应立即停止使用，并联系售后服务人员进行处理。
【五、总结与建议】
电脑花样机功能键1为用户提供了便捷的操作体验，是服装纺织、家居纺织、工艺礼品、广告装饰等行业的好帮手。
为了充分发挥其性能，建议用户熟
悉并严格遵守操作规程，同时关注设备的日常维护与保养。
只有这样，电脑花样机功能键1才能为您带来更长久的效益。
液晶显示设备使用说明书
液晶显示设备使用说明书一、前言液晶显示设备（以下简称显示设备）是一种通过液晶技术实现图像显示的高科技产品。
本使用说明书旨在为用户提供正确、安全和有效地使用显示设备的指导。
在使用前，请仔细阅读本说明书，并按照说明进行操作。
二、产品概述显示设备是一种视觉输出设备，主要通过液晶屏幕将数字图像或视频信号转化为可视化图像，并向用户展示。
本产品采用高清液晶屏，具有色彩饱满、高清晰度和广视角等特点。
同时，本显示设备还配备了易操作的控制面板，方便用户进行设置和调整。
三、安全注意事项1. 请勿将水或其他液体溅到显示设备上，以免损坏产品或引起电路短路等安全隐患。
2. 请勿将重物放置在显示设备上，以免造成屏幕压力过大，导致屏幕损坏或碎裂。
3. 请勿在潮湿或者有大量灰尘的环境中使用显示设备，以免影响产品的正常使用寿命。
4. 如果您需要清洁屏幕，请先关闭显示设备，并使用柔软的纤维布轻轻擦拭，切勿用力过大或使用化学溶液。
四、产品功能1. 颜色调节：本显示设备支持对图像的亮度、对比度以及色彩进行调节，以满足不同用户对图像效果的要求。
2. 屏幕分辨率：本显示设备拥有高分辨率的屏幕，可以呈现更加清晰、细腻的图像画面。
3. 视角范围：本产品具有广视角特点，用户可以在较大的角度范围内观看到清晰的图像。
4. 接口连接：显示设备配备了多种接口（如HDMI、VGA等），以便用户连接各类设备（如电脑、游戏机等）进行图像传输。
五、使用步骤1. 将显示设备与电源连线，并插入电源插座。
2. 打开电源开关，待显示设备亮起后，按需将其他设备（如电脑、游戏机）与显示设备连接。
3. 使用控制面板上的按键进行亮度、对比度和色彩的调节，以达到最佳的图像效果。
4. 确保所需图像源设备正常工作并输出信号，通过操作显示设备的输入源选择功能，选择正确的输入信号源。
5. 使用遥控器或者控制面板上的菜单键，调节并设置显示设备的其他功能和选项。
六、故障排除1. 如果显示设备无法正常开机，请检查电源插头是否插入稳固，电源开关是否处于开启状态。
全电脑提花袜机简易培训手册
（参考机型：THS-F6PT）索引：一．机器操作（适用于挡车工和初学保全工）1．机器认识2．操作面板操作3．输入输出操作4．操作规程5．其它操作6．几种常见故障二．袜子设计（适用于袜子打样设计人员）1．原料认识2．机器简介3．袜子构成4．画图及程式简单修改5．设计流程三．机器维修（适用于代班保全工）1．技术特征2．机器组成及零件名称代码和作用3．编程4．故障显示5．毛病产生的原因及维修方法<DIV class=t_msgfont id=postmessage_3780>一．机器操作1．机器认识此机型适合生产平纹和毛圈两种袜子，每一行列加主口可做六色，一般正常袜子每班每台机产量可生产150双，可做双罗口，单罗口Y跟等多种款式，采用吸风装置，每一个袜子结束自动掉下。
自动供油，并有袜子计数及控制功能，能显示每班产量。
机器共有六口，从机器正面看，由左往右，分为第一口，第二口，第三口，第四口，第五口，第六口也称主口。
主口有8个梭子，由右往左称为1号，2号，3号，4号，5号，6号，7号，8号梭子，其它副口每口有3个梭子，由左往右称1号，2号和3号，主口1号2号梭子一般穿棉纱，常用于做袜子面纱，3号梭子一般用于做机头线，4号常穿尼龙用于做挂口线，5号梭子一般穿棉纱用于做头跟面纱，6号梭子一般穿氨纶常用于做袜子底纱，7号8号梭子常穿尼龙或氨纶用于做罗口底线。
2.操作面板操作机器面板右边有三个按钮，分别为停止钮，起动钮和点动钮，机器在停止状态下，按一下点动钮，机器就寸动一下，转动的速度由面板上L图标控制，在停止状态下按一下起动钮，机器运转。
而在机器运转状态下，按一下停止钮，机器停止运转。
面板上F1,F2,F3,F4为功能键，在不同的状态下其功能不一样。
在工作状态下。
F1为限速键，按120然后按F1，机器运转时不超过每分钟120转。
F2为停链，表示机器不执行平链条和花型的步序，而在原步一直运转。
F3为终点停机键，表示一个袜子结束后机器自动停止。
电脑横机操作说明书
电脑横机操作说明书一、安装准备1. 打开电脑横机包装箱，确认配件齐全。
2. 将电脑横机放置在工作台上，确保空间宽敞、通风良好。
3. 连接电源线到电源插座，并确保电源开关处于关闭状态。
4. 将显示器连接线插入电脑横机的显示器接口上，并确保连接稳固。
二、开机操作1. 确保电源线已连接到电源插座，并确保电源开关处于关闭状态。
2. 按照显示器的说明书操作，将显示器开机。
3. 打开电脑横机的电源开关，待电脑横机启动完成后，进入操作系统登录界面。
三、操作说明1. 桌面图标：在电脑横机启动完成后，屏幕上会显示一个桌面，桌面上有多个图标，分别代表各种软件和文件夹。
2. 鼠标操作：使用鼠标左键点击图标或者文件夹，即可打开相应的软件或者文件夹。
使用鼠标右键点击图标或者文件夹，会弹出一系列操作选项。
3. 键盘操作：除鼠标操作外，还可以使用键盘进行操作。
使用方向键可以移动光标，使用回车键可以确认选择。
4. 文件管理：在电脑横机上打开文件夹，可以进行文件的查看、复制、粘贴、删除等操作。
通过双击文件可以打开相应的软件进行编辑或者查看。
5. 网络连接：电脑横机可以通过有线或者无线方式连接到互联网。
在操作系统中设置网络连接方式并输入正确的网络密码，即可实现上网操作。
6. 软件安装：在电脑横机上安装软件时，请按照软件提供的安装向导进行操作，并注意勾选合适的选项。
7. 软件使用：不同的软件功能各异，使用时请参考软件的操作指南或者帮助文件。
四、关机操作1. 在操作系统界面，点击左下角的"开始"菜单，选择"关机"选项。
2. 在弹出的关机对话框中，选择"关闭电脑"并点击确认按钮。
3. 等待电脑横机完全关闭后，即可断开电源连接。
五、故障排除在使用电脑横机过程中，可能会遇到一些故障情况，以下是一些常见的故障及解决方法：1. 电脑横机无法启动：检查电源线连接是否松动，确认电源插座正常工作。
显示器操作指南说明书
TABLE OF CONTENTSIMPORTANT INFORMATION --------------------------------------------------------- 1 PRECAUTIONS ---------------------------------------------------------------------- 2 SPECIAL NOTES -------------------------------------------------------------------- 3 TAKE CARE OF THE MONITOR ------------------------------------------------ 3BEFORE YOU OPERATE THE MONITOR ---------------------------------------- 4 FEATURES ---------------------------------------------------------------------------- 4 PACKING LIST ----------------------------------------------------------------------- 4 INSTALLATION INSTRUCTIONS ---------------------------------------------- 5 ADJUSTING THE VIEWING ANGLE ------------------------------------------- 7 OPERATING INSTRUCTIONS ------------------------------------------------------- 8 GENERAL INSTRUCTIONS ------------------------------------------------------ 8 HOW TO RECONFIGURE ---- -------------------------------------------------- 9 OSD MENU TABLE ---------------------------------------------------------------- 10 PLUG AND PLAY ------------------------------------------------------------------- 12TROUBLESHOOTING (FAQ) --------------------------------------------------------- 13 ERROR MESSAGE & POSSIBLE SOLUTION ---------------------------- 14 APPENDIX ---------------------------------------------------------------------------------- 15 SPECIFICATIONS ------------------------------------------------------------------- 15 PRESET TIMING TABLE ---------------------------------------------------------- 16 CONNECTOR PIN ASSIGNMENT ---------------------------------------------- 17IMPORTANT INFORMATIONBefore operating the monitor, please read this User Guide thoroughly. This User Guide should be retained for future reference.FCC Class B Radio Frequency Interference StatementWARNING: (FOR FCC CERTIFIED MODELS)NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:1. Reorient or relocate the receiving antenna.2. Increase the separation between the equipment and receiver.3. Connect the equipment into an outlet on a circuit different from that to which the receiveris connected.4. Consult the dealer or an experienced radio/TV technician for help.NOTICE:1. The changes or modifications not expressly approved by the party responsible forcompliance could void the user's authority to operate the equipment.2. Shielded interface cables and AC power cord, if any, must be used in order to complywith the emission limits.3. The manufacturer is not responsible for any radio or TV interference caused byunauthorized modification to this equipment. It is the responsibilities of the user to correct such interference.As an E NERGY S TAR®Partner our company has determined that this product meets the E NERGY S TAR® guidelines for energy efficiency.WARNING:To prevent fire or shock hazard, do not expose the monitor to rain or moisture. Dangerous high voltages are present inside the monitor. Do not open the cabinet. Refer servicing to qualified personnel only.PRECAUTIONSl Do not use the monitor near water, e.g. near a bathtub, washbowl, kitchen sink, laundry tub, swimming pool or in a wet basement.l Do not place the monitor on an unstable cart, stand, or table. If the monitor falls, it can injure a person and cause serious damage to the appliance. Use only a cart or stand recommended by the manufacturer or sold with the monitor. If you mount the monitor on a wall or shelf, use a mounting kit approved by the manufacturer and follow the kit instructions.l Slots and openings in the back and bottom of the cabinet are provided for ventilation. To ensure reliable operation of the monitor and to protect it from overheating, be sure these openings are not blocked or covered. Do not place the monitor on a bed, sofa, rug, or similar surface. Do not place the monitor near or over a radiator or heat register. Do not place the monitor in a bookcase or cabinet unless proper ventilation is provided.l The monitor should be operated only from the type of power source indicated on the label.If you are not sure of the type of power supplied to your home, consult your dealer or local power company.l The monitor is equipped with a three-pronged grounded plug, a plug with a third (grounding) pin. This plug will fit only into a grounded power outlet as a safety feature. If your outlet does not accommodate the three-wire plug, have an electrician install the correct outlet, or use an adapter to ground the appliance safely. Do not defeat the safety purpose of the grounded plug.l Unplug the unit during a lightening storm or when it will not be used for long period of time.This will protect the monitor from damage due to power surges.l Do not overload power strips and extension cords. Overloading can result in fire or electric shock.l Never push any object into the slot on the monitor cabinet. It may short circuit parts causing a fire or electric shock. Never spill liquids on the monitor.l Do not attempt to service the monitor by yourself; opening or removing covers can expose you to dangerous voltages and other hazards. Please refer all servicing to qualified service personnel.l To ensure satisfactory operation, use the monitor only with UL listed computers which have appropriate configured receptacles marked between 100 - 240V AC, Min. 5A.l The wall socket shall be installed near the equipment and shall be easily accessible.SPECIAL NOTESThe following symptoms are normal with the monitor and do not indicate a problem.•Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears.•You may find slightly uneven brightness on the screen depending on the desktop pattern you use.•The LCD screen has effective pixels of 99.99% or more. It may include blemishes of0.01% or less such as a missing pixel or a pixel lit all the time.•Due to the nature of the LCD screen, an afterimage of the previous screen may remain after switching the image, when the same image is displayed for hours. In this case, the screen is recovered slowly by changing the image or turning off the Power Switch for hours.•When the screen becomes black or flashing, or cannot illuminate any more, contact your dealer or service center to replace parts. Don’t repair the screen by yourself!TAKE CARE OF THE MONITOR•Do not install the monitor in a location near heat sources such as radiators or air ducts, or in a place subject to direct sunlight, or excessive dust or mechanical vibration or shock. •Save the original shipping carton and packing materials, as they will come in handy if you ever have to ship your monitor.•For maximum protection, repackage your monitor as it is originally packed in the factory. •To maintain cleanness of your LCD display, wipe it periodically with clean and soft cloth.The screen may be damaged by any liquid splash.•To keep the monitor looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly dampened with mild detergent solution. Never use strong solvents such as thinner, benzene, or abrasive cleaners, since these will damage the cabinet. As a safety precaution, always unplug the monitor before cleaning it.BEFORE YOU OPERATE THE MONITOR FEATURES•43.2cm(17”) TFT Color LCD Monitor.•Recommended Resolutions: SXGA 1280 X 1024 @60Hz.•8ms (Tr+Tf) Quick Response Time.•SPLENDID™ Video Enhancement Technology.• 5 Video Preset Modes Switiched by Hotkey• 3 Skin-Tones Selection for Users’ Preference.•Microsoft Windows 95/98/2000/XP Compliance•VESA Display Data Channel (DDC)1/2B Compliance •VESA Wall Mount Compliance (100x100mm).•EPA ENERGY STAR® and Ergonomic Design.•Cabel Binder and Compact Case Design for Space Saving. •Both VGA and DVI-D Inputs. (for MM17T only)• 1.2Wx2 Stereo Speakers / Earphone Jack. (for MM17T only) PACKAGE LISTThe product package should include the following items:1. LCD Monitor2. Quick Start Guide3. User Guide (CD)4. Power Cord5. VGA Cable6. Audio Cable (for MM17T only)INSTALLATION INSTRUCTIONSASSEMBLING THE MONITOR BASEInstall RemoveFigure 1POWER CORD / POWER SOURCE1. Make sure that the power cord is the correct type required in your area.2. This LCD monitor has an internal universal power supply that allows operation in either100/120V AC or 220/240V AC voltage area (No user adjustment is required.)3. Connect the power cord into your LCD monitor’s power input socket, and then plug theother end into a 3-pin AC power outlet. The power cord may be connected to either a wall power outlet or the power outlet socket on your PC, depending on the type of power cord supplied with your LCD monitor.NOTESA certified power supply cord has to be used with this equipment. The relevant national installation and/or equipment regulations shall be considered. A certified power supply cord not lighter than ordinary polyvinyl chloride flexible cord according to IEC 60227 (designation H05VV-F 3G 0.75mm2 or H05VVH2-F2 3G 0.75mm2) shall be used. Alternative a flexible cord be of synthetic rubber according to IEC 60245 (designation H05RR-F 3G 0.75mm2) shall be used.MAKING THE CONNECTIONSConnecting the Signal Cable:Plug one end of the VGA Cableto the LCD monitor’s VGA port, the other end to the computer's VGA socket and tighten the two screws on the cable connector. Moreover, for MM17T, you can buy an extra 24-Pin DVI-D cable from your dealer for the digital signal connection if preferred.Connecting the Power Cord: Plug one end of the AC-power cord to the LCD monitor’s AC input socket, the other end to the power outlet.Connecting the Audio Cable (MM17T only):Plug the audio cable between the computer multi-media (or audio) card's audio output and monitor's audio jack.Caution:If the AC outlet is not grounded (with three holes), install the proper grounding adapter (not supplied).Figure 21. AC Input Socket2. Audio Jack (MM17T only)3. DVI-D Port (MM17T only)4. VGA (D-SUB) Port5. Earphone Jack (MM17T only)6. Cable BinderADJUSTING THE VIEWING ANGLE•For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference.•Hold the stand so you do not topple the monitor when you change the monitor’s angle. •You are able to adjust the monitor’s angle from -5° to 20°.Figure 3NOTES•Do not touch the LCD screen when you change the angle. It may cause damage or break the LCD screen.•Careful attention is required not to catch your fingers or hands when you change the angle.OPERATING INSTRUCTIONSGENERAL INSTRUCTIONSPress the power button to turn the LCD monitor on or off. The other control buttons are located on the front bezel (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences.•The power cord should be connected.•Connect the signal cable from the LCD monitor to your computer.•Press the power button to turn on the LCD monitor. The power indicator will light up.Figure 41. SPLENDID™ Button :•Hotkey for switching between 5 advanced video preset modes (Scenery Mode, Standard Mode, Theater Mode, Game Mode, Night Mode) with SPLENDID™Video Enhancement Technology.•Automatically adjust the image to its optimized position, clock, and phase by pressing the button for 2 seconds.•Exit the OSD menu or go back to the previous menu as the OSD menu is active.Button :2. －•Decrease the level of the function selected or move to the previous function as the OSD menu is activated.3. Power Button / Power LED Indicator:•Switch the LCD monitor on or off.•LED lights blue(MM17T)/green(MM17D): normal operation mode.•LED lights amber: power saving mode.•LED is off: power off mode.4. ＋•Activate Brightness adjustment menu.•Increase the level of the function selected or move to the next function as the OSD menu is activated.5. Menu Button :•Activate the OSD (On-Screen Display) main menu.•Enter/select the icon(function) highlighted as the OSD menu is activated.HOW TO RECONFIGURE1. Press the MENU-button to activate the OSD main menu (Figure 5).2. Pressto change the settings of the selected function.3.4. To exit and save, select the exit function. If you want to adjust any other function, repeatsteps 2-3.Figure 5OSD MENU TABLEThe table describes the function of each OSD iconMain Menu ItemMain Menu Icon Sub Menu Item SubMenuIconDescriptionSceneryModeAdvance for general Windows use (SPLENDID ™Off) Theater ModeAdvance for game use withSPLENDID ™ Video EnhancementScenarioAdvance for dark-display use withSPLENDID™ Video EnhancementColor RAdjust greengain RGBAdjust blue gainReddishSelect natural skin stone SkinToneSelect yellowishskin stone CoolNormal imagecolor. (7500°K) Color AdjustWarmAdjust brightness levelLuminanceAdjust contrast levelOSD SetupAdjust horizontal position of theOSDOSD V-PositionAdjust OSD timeout PhaseClockAdjust horizontal position of theimage Image PositionAdjust verticalposition of theimage Image SetupAutomatically adjust the horizontal /vertical positions, phase and clock of the image Input SelectShow the resolution,H/V frequency and input port of current input timing LanguageRecall default setting ExitPLUG AND PLAYPlug & Play DDC2B FeatureThis monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities.The DDC2B is a bidirectional data channel based on the I²C protocol. The host can request EDID information over the DDC2B channel.THIS MONITOR WILL APPEAR TO BE NON-FUNCTIONAL IF THERE IS NO VIDEO INPUT SIGNAL. TO OPERATE PROPERLY, THERE MUST BE VIDEO INPUT SIGNAL. This monitor meets the Green monitor standards as set by the Video Electronics Standards Association (VESA) and/or the United States Environmental Protection Agency (EPA) and The Swedish Confederation Employees (NUTEK). This feature is designed to conserve electrical energy by reducing power consumption when there is no video-input signal present. When there is no video input signal this monitor, following a time-out period, will automatically switch to an OFF mode. This reduces the monitor's internal power supply consumption. After the video input signal is restored, full power is restored and the display is automatically redrawn. The appearance is similar to a "Screen Saver" feature except the display is completely off. The display is restored by pressing a key on the keyboard, or clicking the mouse.USING THE RIGHT POWER CORD :The accessory power cord for the Northern American region is the wallet plug with NEMA 5-15 style and is UL listed and CSA labeled. The voltage rating for the power cord shall be 125 volts AC.Supplied with units are intended for connection to power outlet of personal computer: Please use a cord set consisting of a minimum No. 18 AWG, type SJT or SVT three conductors flexible cord. One end terminates with a grounding type attachment plug, rated 10A, 250V, CEE-22 male configuration. The other end terminates with a molded-on type connector body, rated 10A, 250V, having standard CEE-22 female configuration.Please note that power supply cord needs to use VDE 0602, 0625, 0821 approval power cord in European counties.TROUBLESHOOTING (FAQ)Problem & Question Possible SolutionPower LED is not ON l Press the Power Button to check if themonitor is in the ON mode.l Check if the Power Cord is properlyconnected the monitor and the poweroutlet.The Power LED lights amber and there is no screen image l Check if the monitor and the computer are in the ON mode.l Make sure the Signal Cable is properly connected the monitor and the computer. l Inspect the Signal Cable and make sure none of the pins are bent.l Connect the computer and another available monitor to check if the computer is properly working.Screen image is too light or dark l Adjust the Contrast and Brightness settings via OSD.Screen image is not centered or sized properly l Press the SPLENDID™ Button for 2 seconds to automatically adjust theimage.l Adjust the H-Position or V-Position settings via OSDScreen image bounces or a wave pattern is present in the image l Make sure the Signal Cable is properly connected the monitor and the computer. l Move electrical devices that may cause electrical interference.Screen image has color defects(white does not look white) l Inspect the Signal Cable and make sure that none of the pins are bent.l Perform Reset via OSD.l Adjust the R/G/B color settings or select the Color Temperature via OSD.Screen image is blurry or fuzzy l Press the SPLENDID™ Button for 2 seconds to automatically adjust theimage.l Adjust the Phase and Clock settings via OSD.No sound or sound is low (MM17T only). l Ensure that the Audio Cable is properly connected the monitor and the computer l Adjust the volume settings of both your monitor and computer.l Ensure the computer sound card driver is properly installed and activated.ERROR MESSAGE & POSSIBLE SOLUTIONNO SIGNAL︰1. Check that the signal-cable is properly connected , If the connector is loose, tighten theconnector’s screws.2. Check the signal-cable’s connection pins for damage.OUT OF RANGE︰Your computer has been set to unsuitable display mode ,set the computer to display mode given in the following Preset Timing Table.APPENDIXSPECIFICATIONSModel MM17T MM17DVisible Diagonals 17.0" (43.2cm)Screen Size Horizontal : 337.92mm, Vertical : 270.34mm Max. Resolution SXGA 1280x1024@75HzPixel Pitch 0.264mmBrightness 300cd/㎡ (Typ.), 400cd/㎡ (Max.)Contrast Ratio 500:1 (Typ.), 600:1 (Max.)Viewing Angle (CR≧10) 150°(H)/ 130°(V)Display Colors 16.2MResponse Time 8msSignal Frequency Horizontal: 30~80 kHz, Vertical: 55 ~ 75HzMax. Pixel Clock 135MHzPlug & Play VESA DDC2B TMVideo Input DVI-D & D_Sub D_SubAudio Input/ Earphone 3.5mm Mini-jack --Speaker (Built-in) 1.2W x 2 Stereo --Tilt +20°~ -5°VESA Wall Mount 100x100mmPower Source 100~240VAC,47~63HzPower Consumption Power On: <40W, Standby: <2WPhys. Dimension 380(W) x 390(H) x 180mm(D)Net Weight 4 kg (approx.)Environmental Conditions Operating Temp: 5° to 35°C Storage Temp.: -20° to 60°C Operating Humidity: 10% to 85%Regulatory Approvals TCO99, Energy Star, UL/cUL, TUV-GS, CB, CE, FCC, CCC, BSMI, Gost-R, C-Tick, VCCI,ISO13406-2 ClassIIPRESET TIMING TABLESTANDARD RESOLUTION HORIZONTALFREQUENCYVERTICALFREQUENCYDos-mode 640 × 350 31.47kHz 70Hz Dos-mode 720 × 400 31.47kHz 70Hz640 × 480 31.47kHz 60Hz640 × 480 35.00kHz 66.6Hz640 × 480 37.50kHz 75Hz VGA640 × 480 37.86kHz 72Hz800 × 600 37.879kHz 60Hz800 × 600 46.875kHz 75Hz800 × 600 35.16kHz 56Hz800 × 600 48.01kHz 72Hz SVGA832 × 624 49.725kHz 75Hz1024 × 768 48.363kHz 60Hz1024 × 768 56.476kHz 70Hz XGA1024 × 768 60.02kHz 75Hz1280 × 1024 64.00kHz 60Hz SXGA1280 × 1024 80.00kHz 75HzCONNECTOR PIN ASSIGNMENT15 - Pin Color Display Signal CablePIN NO.DESCRIPTION PIN NO.DESCRIPTION 1. Red 9. +5V2. Green 10. Detect Cable3. Blue 11. RXD4. TXD 12. DDC-Serial Data5. Ground 13. H-Sync6. R-Ground 14. V-Sync7. G-Ground 15. DDC-Serial Clock 8.B-Ground24 - Pin Color Display Signal Cable(MM17T only)PIN NO. DESCRIPTIONPI N NO.DESCRIPTION 1. TMDS Data 2- 13. TMDS Data 3+ 2. TMDS Data 2+ 14. +5V Power 3. TMDS Data 2/4 Shield15. Ground(for+5V)4. TMDS Data 4- 16. Hot Plug Detect5. TMDS Data 4+ 17. TMDS Data 0-6. DDC Clock 18. TMDS Data 0+7. DDC Data 19. TMDS Data 0/5Shield8. N.C. 20. TMDS Data 5- 9. TMDS Data 1- 21. TMDS Data 5+ 10. TMDS Data 1+ 22. TMDS Clock Shield 11. TMDS Data 1/3 Shield23. TMDS Clock +12. TMDS Data 3- 24. TMDS Clock -。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
祥兴电脑提花机显示屏操作说明书
操作面板图示说明：
一、读盘：打开电源后按F2（USB）键，进入图二界面，
二、选择读盘，按√（Sure）键确认，按上下箭头选取需读入的版号，
三、按F2键选取。
四、按√键确认选取读入系统。
五、开始读盘入系统。
六、按F2（USB）键，按上下键选择《选择》键，进入系统电子版目录，
七、选取需要的电子版，按F2（USB）选取。
八、按√（Sure）键确认。
九、按F4（EXIT）键退回主界面，
十、如需前后错纬，选取纬号，按上下键就可前或后一纬，按按√（Sure）键确认。
十一、系统电子版太多，无法读入新版，需将系统旧版删除掉，操作同读版一样，只是需选择删除然后进入操作。
