User Interface Technologies for Windows Embedded CE
今天晚上看了一个关于Wince UI的webcast，印象很深刻，介绍给大家。
主讲工程师一直强调的这个技术是unlock the potential。以后移动开发我们不再需要处理UI问题了，
例如transparency，alpha blending等等，因为开发移动应用由两个角色组成，Designer & Developer。
而且我觉得Designer比Developer重要，因为这个例子Developer只是需要1，2个小时的工作，而
Designer花的时间远远多于Developer。我打算去学一个设计课程，好好补一下这方面的知识。
