CS798 - GFS Presentation
AD9783中文资料
CLKP CLKN
LVDS INTERFAቤተ መጻሕፍቲ ባይዱE
D[15:0] VIA, VIB
DEINTERLEAVING LOGIC
Full programmability is provided through a serial peripheral interface (SPI) port. Some pin-programmable features are also offered for those applications without a controller.
Dual 12-/14-/16-Bit,
LVDS Interface, 500 MSPS DACs
AD9780/AD9781/AD9783
GENERAL DESCRIPTION
The AD9780/AD9781/AD9783 include pin-compatible, high dynamic range, dual digital-to-analog converters (DACs) with 12-/14-/16-bit resolutions, and sample rates of up to 500 MSPS. The devices include specific features for direct conversion transmit applications, including gain and offset compensation, and they interface seamlessly with analog quadrature modulators such as the ADL5370.
