Contents lists available at ScienceDirect
Systems & Control Letters
journal homepage: /locate/sysconle
1. Introduction During the past years, distributed coordination for networks of dynamical agents has been an active area of research due to the broad applications of multi-agent systems in such areas as sensor networks, rendezvous tasks, swarming and flocking models, consensus problem, and congestion control in communication networks. One of the critical problems is how to design a network ‘‘consensus algorithm’’ (or protocol) such that the group of agents can reach consensus on the shared information in the presence of limited or unreliable information exchanges and dynamically changing network topologies. The consensus problem for agents with first-order dynamics has recently been investigated from various perspectives [1–13]. Taking into account the fact that second-order dynamics can be used to model more complicated processes in reality, cooperative control for second-order agents have been studied in
✩ This work was partially supported by National Natural Science Foundation of China (60825303, 60834003, 61028008), the 973 Project of China (2009CB320600), the Foundation for the Author of National Excellent Doctoral Dissertation of China (2007B4), the Key Laboratory of Integrated Automation for the Process Industry Northeastern University, Ministry of Education, China, and by a research grant from the Australian Research Council. ∗ Corresponding author. Fax: +61 2 4736 0867. E-mail addresses: qinjiahu301@ (J. Qin), hjgao@ (H. Gao), w.zheng@.au (W.X. Zheng).
Article history: Received 28 July 2010 Received in revised form 25 January 2011 Accepted 17 March 2011 Available online 17 April 2011 Keywords: Consensus Second-order agents Graphic method Switching topology Time delay
Second-order consensus for multi-agent systems with switching topology and communication delay✩
Jiahu Qin a,b , Huijun Gao a , Wei Xing Zheng b,∗
a b
Space Control and Inertial Technology Research Center, Harbin Institute of Technology, Harbin 150001, China School of Computing and Mathematics, University of Western Sydney, Penrith NSW 2751, Australia
article
info
abstract
In this paper, two kinds of consensus problems for second-order agents under directed and arbitrarily switching topologies are investigated, that is, the cases without and with communication delay. For the former, by constructing a new kind of digraph and employing a new graphic method, we can specify the least convergence rate for all the agents to reach consensus. For the latter, in virtue of a matrix inequality method, a sufficient condition in the form of feasible matrix inequalities is presented for all the agents to reach consensus. This, on the other hand, shows that consensus can be reached if the delay is small enough. Finally, two numerical examples are given to demonstrate the effectiveness and advantages of the proposed results. © 2011 Elsevier B.V. All rights reserved.
[14–23]. In particular, extensions of first-orde second-order case with undirected network topology are discussed in [21], while [19] proposes and analyzes a different consensus algorithm for second-order agents under directed and fixed network topology under the assumption that the velocity information is measurable by the neighboring agents. A generalized consensus algorithm of those considered in [19,21] is investigated in [24] under directed and fixed topology. [18] considers various consensus algorithms for second-order dynamics by using different methods also under fixed topology. It is worth mentioning that the case with directed network topology is much more challenging than that of the undirected one due to the fact that the Laplacian matrix of a digraph is usually nonsymmetric. On the other hand, it is well known that communication delay and switching of the network topology are the key factors which may destabilize the multi-agent systems. So far, little attention has been paid to the consensus as well as the related convergence rate analysis for second-order agents under directed and switching topology and with communication delay. With this background, this paper investigates two kinds of second-order consensus problems for agents under directed and switching topology. For the case without communication delay, we perform the consensus analysis by employing a new graph theoretical method. This is different from most of the existing literature which heavily relies on analyzing the eigenvalues of the transformed system matrix. Moreover, the least convergence rate for all the agents to reach consensus can also be specified, which, to the best of our knowledge, has not been investigated
