ANADIGICS为三星Galaxy S 4G和Galaxy SII X智能手机提供功率放大器
ANADIGICS为三星Galaxy S 4G和Galaxy SII X智能手机提供功率放大器
ANADIGICS, Inc. (Nasdaq：ANAD) 是全球首屈一指的射频 (RF) 解决方案供应商。该公
司今日宣布开始为三星电子的新型Galaxy S 4G和Galaxy SII X智能手机批量供应AWT6622
和AWT6624第四代低功耗高效率 (HELP4™) 功率放大器 (PA)。三星Galaxy S 4G智能
手机将由T-Mobile独家销售，配备一块4英寸的显示屏、500万像素摄像头，带LED闪光灯，
采用1 GHz处理器和Android 2.2 Froyo操作系统。而三星Galaxy SII X智能手机将由Telus
独家销售，配备1.5 GHz双核处理器、一块4.5英寸显示屏、800万像素摄像头，带LED闪
光灯，采用Android 2.3 Gingerbread操作系统。 ANADIGICS全球销售高级副总裁
Michael Canonico表示：“三星新型Galaxy S 4G和Galaxy SII X智能手机采用先进
的HSPA+连接技术，配备超大屏幕和强大处理器，必将给用户带来出色的多媒体体验。
ANADIGICS的HELP4功率放大器系列可以显著延长高耗电的多媒体智能手机的电池续航时间，
已然成为效率和性能方面的行业标准。我们很高兴继续与三星电子密切合作，把移动用户体
验推上新的台阶。” ANADIGICS行业领先的HELP4™产品系列采用该公司专
有的InGaP-Plus™技术，可在整个中低输出功率水平下实现最佳效率，而且其静态电
流也是业内最低。凭借业界领先的HSPA+能效表现，AWT6622和AWT6624功率放大器可以显著
延长4G手机、智能手机、平板电脑、上网本和笔记本的电池寿命。 ANADIGICS
HELP4™功率放大器系列的重要信息和特征： •世界一流的性能 o 平均
功耗比上一代功率放大器低30% o 三种模式状态，可在中低输出功率水平实现高效率
o 行业最低静态电流 o 最大输出功率下可实现同类最佳线性度 •业界领先的
集成设计 o 面积仅为3 mm × 3 mm o 集成电压调节 o 集成“
可级连”的定向射频耦合器，具有20dB定向性 ANADIGICS HELP4™功率放
大器系列的重要技术规格：
零件编号
频带
效率
静态电流
AWT6622
1850 MHz至1910 MHz
(频带2)
40% @ +28.6 dBm
34% @ +17 dBm
24% @ +8 dBm
2 mA
AWT6624
1710 MHz至1785 MHz
(频带3、4、9 & 10)
39% @ +28.3 dBm
36% @ +17 dBm
26% @ +8 dBm
2 mA
如需了解有关ANADIGICS的产品和多媒体内容的更多信息，请参阅以下资源：
•ANADIGICS LinkedIn：/company/anadigics •ANADIGICS Facebook：
/anadigics •ANADIGICS Twitter：/anadigics •ANADIGICS照片：
/anadigics •ANADIGICS视频：/anadigics
