ABAQUS用连续介质的方法建立描述混凝土模型不采用宏观离散裂纹的方法描述裂纹的水平的在每一个积分点上单独计算其中。
低压力混凝土的本构关系包括：
Con crete Smeared cracki ng model (ABAQUS/Sta ndard)
Concrete Brittle cracki ng model (ABAQUS/Explicit)
Con crete Damage plasticity model
高压力混凝土的本构关系：
Cap model
1、ABAQUS/Standard 中的弥散裂缝模型Concrete Smeared cracking model (ABAQUS/Standard):
只能用于ABAQUS/Standard 中
裂纹是影响材料行为的最关键因素，它将导致开裂以及开裂后的材料的各向异性
用于描述：单调应变、在材料中表现出拉伸裂纹或者压缩时破碎的行为
在进行参数定义式的Keywords:
*CONCRETE
*TENSION STIFFENING
*SHEAR RETENTION
*FAILURE RATIOS
2、ABAQUS/Explicit 中脆性破裂模型Concrete Brittle cracking model (ABAQUS/Explicit): 适用于拉伸裂纹控制材料行为的应用或压缩失效不重要，此模型考虑了由于裂纹引起的材料
各向异性性质，材料压缩的行为假定为线弹性，脆性断裂准则可以使得材料在拉伸应力过大
时失效。
在进行参数定义式的Keywords
*BRITTLE CRACKING,
*BRITTLE FAILURE,
*BRITTLE SHEAR
3、塑性损伤模型Concrete Damage plasticity model :
适用于混凝土的各种荷载分析，单调应变，循环荷载，动力载荷，包含拉伸开裂(cracking)和压缩破碎(crushing)，此模型可以模拟硬度退化机制以及反向加载刚度恢复的混凝土力学特性
在进行参数定义式的Keywords:
*CONCRETE DAMAGED PLASTICITY
*CONCRETE TENSION STIFFENING
*CONCRETE COMPRESSION HARDENING
*CONCRETE TENSION DAMAGE
*CONCRETE COMPRESSION DAMAGE。
