is deﬁned by
͸ϱ
q(r, ␪) = q¯m(r)sin ␮␪
ห้องสมุดไป่ตู้
(1)
m =1
where ␮ = m␲/␣.
Kirchhoff Plate Theory
First consider the bending problem of the aforementioned sectorial plate under the loading deﬁned in (1), based on the Kirchhoff plate theory. The equilibrium equations of the plate problem at hand are given by Timoshenko and WoinowskyKrieger (1959):
INTRODUCTION
A plate is typically considered to be thin when the ratio of its thickness to a representative lateral dimension is less than 1/20. Using the Kirchhoff (or classical thin) plate theory, the bending solutions may be determined with good accuracy. However, if the aforementioned ratio is greater than 1/20, the bending solutions will not be accurate. For example, the deﬂections will be underpredicted from neglecting the effect of transverse shear deformation. These inaccuracies may be largely eliminated by using the Mindlin plate theory, which takes into consideration the ﬂexibility of the plate due to the transverse shear deformation.
clamped or free. The ﬂexural rigidity of the isotropic plate is given by D = Eh3/[12(1 Ϫ ␯2)], where E is the Young’s modulus and ␯ Poisson’s ratio. The shear modulus of the plate is G = E/[2(1 ϩ ␯)]. For analysis, it is expedient to adopt the polar coordinates system for such a plate shape, with the origin
BENDING SOLUTIONS OF SECTORIAL MINDLIN PLATES FROM KIRCHHOFF PLATES
By C. M. Wang,1 Member, ASCE, and G. T. Lim2
ABSTRACT: This study presents exact relationships between the bending solutions of sectorial plates based on the Kirchhoff (or classical thin) plate theory and the Mindlin plate theory. While the former plate theory neglects the effect of transverse shear deformation, the latter theory allows for this effect, which becomes signiﬁcant when dealing with thick plates and sandwich plates. The considered sectorial plates have simply supported radial edges, while the circular curved edge may be either simply supported, or clamped or free. The availability of such relationships allow easy conversion of the existing Kirchhoff sectorial plate solutions into the corresponding Mindlin solutions, thus bypassing the need to solve the more complicated bending equations of the Mindlin plates. The use of the relationships is illustrated using some sectorial plate examples, and sample solutions obtained were checked with previous researchers’ results and those computed from the software ABAQUS.
1Assoc. Prof., Dept. of Civ. Engrg., National Univ. of Singapore Kent Ridge, Singapore 119260. E-mail: cvewcm@.sg
2Grad. Student, Dept. of Civ. Engrg., National Univ. of Singapore, Kent Ridge, Singapore.
Wang and his coworkers embarked on a research project to develop relationships between the solutions of classical and higher-order plate theories. So far, the research has yielded very interesting bending relationships that are exact and yet simple to use, but they can only be applied to certain classes of plate shapes, boundary, and loading conditions. For instance, exact deﬂection relationships were found for (1) simply supported polygonal plates under arbitrary loading conditions (Wang and Alwis 1995), (2) axisymmetric bending of circular and annular plates (Wang and Lee 1996; Wang 1997), and (3) the bending of Levy plates (Wang et al. 1999). As a continuation of this project, this paper focuses on the elastic bending problem of sectorial plates with simply supported radial edges while the circular edge may be either simply supported, or clamped or free. The relationships between the bending solutions for such plates are derived herein. On the basis of existing exact Kirchhoff solutions for these plates [see books by Timoshenko and Woinowsky-Krieger (1959) and Mansﬁeld (1989)], the relationships enable the easy deduction of the corresponding exact Mindlin plate solutions. These new sectorial Mindlin plate solutions (and thus the relationships) are veriﬁed by comparison studies with previous researchers’ results [e.g., those given by Cheung and Chan (1981)] wherever possible. For some cases, the writers used the software ABAQUS to provide independent checks to ensure the correctness of the results.
Note. Associate Editor: Roberto Ballarini. Discussion open until September 1, 2000. To extend the closing date one month, a written request must be ﬁled with the ASCE Manager of Journals. The manuscript for this paper was submitted for review and possible publication on January 26, 1999. This paper is part of the Journal of Engineering Mechanics, Vol. 126, No. 4, April, 2000. ᭧ASCE, ISSN 0733-9399/00/0004-0367– 0372/$8.00 ϩ $.50 per page. Paper No. 20139.
