SY-2000S荧光硫说明书(英文版)
SY—2000S荧光定硫仪

SY—2000S荧光定硫仪使用说明书(V2.0)目录1.前言…………………………………………………………………………2.基本原理……………………………………………………………………3.系统工作条件要求…………………………………………………………3.1 环境要求………………………………………………………………3.2 电力要求………………………………………………………………3.3 气源要求………………………………………………………………4.仪器组成及安装……………………………………………………………4.1 开箱检查………………………………………………………………4.2 系统组成………………………………………………………………4.2.1 主机…………………………………………………………………4.2.2 计算机系统组成……………………………………………………4.2.3 进样器部分…………………………………………………………4.2.4 气路连接……………………………………………………………4.2.5 电路连接……………………………………………………………5.软件安装及操作说明……………………………………………………5.1 安装SY—2000S程序………………………………………………5.2 卸载SY—2000S程序………………………………………………6. 启动和退出SY—2000S程序……………………………………………6.1 概述……………………………………………………………………6.2 启动……………………………………………………………………6.3退出…………………………………………………………………7.开机………………………………………………………………………8.样品分析……………………………………………………………………9.关机……………………………………………………………………10.反应室清洗………………………………………………………………11.仪器维护…………………………………………………………………12.故障维修指南……………………………………………………………1前言:SY —2000S 紫外荧光定硫仪是根据紫外荧光原理与计算机技术相结合开发的新一代精密实验仪器。
ty2000硫分析仪操作规程汇编(4篇范文)

ty2000硫分析仪操作规程汇编(4篇范文)第1篇 ty2000硫分析仪操作规程一.关闭电源以后重新开机:面板上四个电源开关全关(向下)。
松开氮气减压阀;开氮气瓶总阀,钢瓶压力应大于1mpa;然后开氮气减压阀使输出压力为0.2~0.25mpa,面板上氮气压力表指针应在规定位置(见第6条)。
打开放大器、柱温、检测室三个电源开关(向上);色谱柱选择旋钮置tcp位置,进样阀置取样位置。
等待30分钟以后,状态页柱温显示应接近给定值;并确认加热块外壳己经发烫;但注意不要长时间触摸,以免烫伤。
按步骤2开氮气的要求分别开氧气和氢气;等几分钟让氢气充满气路管线后就可以点火。
必须注意在气路调整好后,n2、h2、o2、压力必须记录在案(备查)不得随意变动。
开机或进样前都要观查面板三个压力表表压是否正确,否则要将压力表指针调整到位。
若长期不用后开机,要重新检查气路各接头有无泄漏(用毛笔沾洗涤液试漏)特别是危险性大的氢气管线。
点火前必须先确认高压开关在向下位置(关闭);用镊子揭盖点火,有一下爆鸣声响;盖上盖子后再开高压开关;观察状态页上输入信号数值应有几个mv的增大,否则火没有点燃;再关高压开关,重新揭盖点火。
以后如果要检查是否熄火,或判断检测器是否正常都通过开和关高压开关并观察输入信号的变化来进行。
慢慢调细调电位器旋钮,分几次把输入信号数值调到到0.3mv 左右。
按基线键显示信号曲线,待基线稳定后就可以进样分析。
二.关机如果只是暂时不进样,只关高压开关(向下)并把色谱柱选择在tcp位置,进样阀置取样位置。
其它的特别是三只压力旋钮不要随意改变。
长时间不用停机:a、先关高压开关,再关柱温和放大器开关,色谱柱选择在tcp 位置,进样阀置取样位置。
b、关氢气瓶总阀,松开氢气瓶减压阀。
c、关氧气瓶总阀,松开氧气瓶减压阀。
d、等待面板氢气和氧气压力表指示为零(即燃烧室已经熄火)后,关检测室开关。
e、关氮气瓶总阀,松开氮气瓶减压阀。
自-YHCL-2000自-动测硫仪说明书(又购)

YHCL-2000自动测硫仪说明书目录一、概述 (1)二、特点 (2)三、主要技术指标 (3)四、分析原理 (4)五、结构介绍 (4)六、键盘操作说明及使用方法 (6)七、安装 (12)八、使用方法 (13)九、常见故障 (16)十、仪器成套及技术文件……………………………………20 一、概述本公司生产的全自动测硫仪,主要用于测定石油、煤炭、钢铁和各种矿中的全硫含量,是煤炭、电力、化工、建材、冶金、地质勘探、商检、环保检测等部门实验室的优选必备仪器。
该仪器是依据GB/T387中库仑滴定法而设计的,是在MTCL系列、以及现有国内其他测硫仪的基础之上改进研发而成的。
改善了原有线性不好,零点漂移,需手动控制电解开关,手动调节炉流等不足之处。
该仪器的全部测定过程采用微处理器智能控制,新增加了如:自动控制电解开关、PID模式控制炉流等诸多智能控制功能;并由微处理器对测试数据进行多种校正和处理,使得测定数据稳定,平行样好,结果的准确度和精确度优于国标GB/T387 要求,且大屏幕汉字显示,人机界面友好,键盘操作简单易学好用,自动化智能控制程度较高,体积小巧等诸多优点,故是目前实验室较理想的测硫仪。
二、特点本仪器较同类测硫仪相比,具有如下特点:【1】人机界面友好,键盘操作简单易学好用。
【2】炉温采取PID模式控制炉流,控温精度高,可有效保护硅碳管,延长使用寿命。
【3】设定炉温,修正等可直接通过键盘输入改变。
【4】智能控制电解开关的开与关,不会因开关机的顺序而产生过电解现象。
【5】做煤样时可以随时查看炉温、炉流、指示电压、进程时间及含硫量,试验过程一目了然。
【6】自动判断滴定终点,缩短实验时间,提高工作效率。
【7】若输入了水分值,则计算、打印干剂硫和水分值。
【8】本仪器可以掉电记忆最新的10个历史记录,并可随时打印历史记录。
三、主要技术指标【1】硫的测量范围:0-100%【2】试样燃烧分析时间3--5分钟,,智能判断滴定终点返回。
X荧光仪英译汉说明书

MXF-2400型多通道X-射线荧光分析仪使用说明书岛津公司分析测量分部本说明书中讲述了仪器的详细构造和工作原理,并且介绍了大量我们在仪器设计方面的技术秘密,以便用户更加充分的了解和使用仪器。
我们敬请广大用户不要把本说明书送给或借给他人;也不要向他人描述本说明书中的内容。
安全使用仪器内部会产生对人体有害的X-射线和高压。
为了安全使用仪器要注意下面的内容。
关于X-射线疾病预防1、本仪器属于“X-射线设备”。
它符合“电磁辐射疾病1、原理和构造测量原理当X-射线管产生的X-射线(以下叫做初始X-射线)照射到被测样品时,组成样品的每一种元素都会反射出具有特殊波长的X射线(以下叫做特征X-射线或荧光X-射线)。
由于样品是由多种成分组成的,所以该荧光X-射线是由各种特征X-射线混合而成的。
每一个量角仪都是根据每种特征X-射线的波长设置的。
因此,如果该混合荧光被反射到某一个量角仪上,那么只有相应组分发出的特征X-射线才会被量角仪中的晶体有选择性地反射到探测器上。
探测器也安装于量角仪上。
被检测到的X-射线的强度同相应组分的含量成比例。
因此,通过测量一定时间内检测到的X-射线的总量就可以得到相应组分的含量。
本仪器可以同时检测、测量并记录下各种元素所发出的X-射线。
X-射线管X-射线管直立于主机的中心部位。
它是由美国VARIAN公司制造的.激发灯丝所产生热电子通过高压被加速。
当这些被加速的热电子撞击到靶金属(以下叫做靶)时,靶会产生连续波长的X射线(以下叫做连续X-射线)和靶金属的特征X-射线。
这两种射线混合后组成的光束即初始X-射线。
初始X射线通过一个位于X-射线管底部的厚的铍窗照射到被测样品上。
X-射线管的靶金属是铑,所以初始X射线就是由X-射线和和靶金属的特征X射线混合而成的。
(RHK,RHL)。
RH-K线和RH-L线有助于X-射线分别激发样品中的重元素和轻元素。
当热电子光束撞击靶时,超过99%的动能转化成热能,在转化中靶会被加热。
(整理)硫含量测定仪技术应用说明书

SY—2000S荧光定硫仪使用说明书(V2.0)泰州市奥普特分析仪器有限公司目录1.前言…………………………………………………………………………2.基本原理……………………………………………………………………3.系统工作条件要求…………………………………………………………3.1 环境要求………………………………………………………………3.2 电力要求………………………………………………………………3.3 气源要求………………………………………………………………4.仪器组成及安装……………………………………………………………4.1 开箱检查………………………………………………………………4.2 系统组成………………………………………………………………4.2.1 主机…………………………………………………………………4.2.2 计算机系统组成……………………………………………………4.2.3 进样器部分…………………………………………………………4.2.4 气路连接……………………………………………………………4.2.5 电路连接……………………………………………………………5.软件安装及操作说明……………………………………………………5.1 安装SY-2000S程序………………………………………………5.2 卸载SY-2000S程序………………………………………………6. 启动和退出SY-2000S程序……………………………………………6.1 概述……………………………………………………………………6.2 启动……………………………………………………………………6.3退出…………………………………………………………………7.开机………………………………………………………………………8.样品分析……………………………………………………………………9.关机……………………………………………………………………10.反应室清洗………………………………………………………………11.仪器维护…………………………………………………………………12.故障维修指南……………………………………………………………1前言:SY-2000S 紫外荧光定硫仪是根据紫外荧光原理与计算机技术相结合开发的新一代精密实验仪器。
THA-2000S操作步骤

THA-2000S型紫外荧光定硫仪操作步骤1.开机:打开氧气和氩气阀,将分压调到0.2MP左右,再顺序打开温控开关,放大开关,风扇开关,进样器开关,电脑开关,待温度升到设定值后准备分析。
2.打开电脑中THA-2000S主程序,点击”联机”,正常后打开点击紫外灯开关,紫外灯电源指示灯亮。
(紫外灯打开后仪器基线
会有个上飘过程。
)将仪器的工作参数和状态调整到合适范围。
3.建立或调用标样曲线:
a.调出原有标样曲线用其中某点的标样进行校正,做2到
3个平行样后取其平均值,点击校正系数根据提示输入
标样的实际值和测量值算出校正系数后即可进行样品
分析。
b.取能涵括样品含量的2到3种标样,分别进行分析,保
存并建立出标样曲线后进行样品分析。
4.样品分析
在与标样相同的工作参数下把工作内容选到样品分析。
连续有2到3个样品重复性较好即可保存数据。
5. 关机:
完成分析后首先关闭紫外灯开关,然后关闭氧气和氩气钢瓶。
然后依次关闭温控,放大,风扇,进样器,最后关闭电脑。
6. 注意:关闭仪器后不要关闭外接电源,仪器风扇会自动打开,直到仪器内部温度降下来!。
总硫含量测定法(紫外荧光法)SH0689-2000
轻质烃及发动机燃料和其他油品的总硫含量测定法(紫外荧光法)SH/T0689—20001 范围1.1本标准适用于测定沸点范围约25一400℃,室温下粘度范围约0.2一I0mm2/s之间的液态烃中总硫含量。
本标准适用于总硫含量在1.0一8000mg/kg的石脑油、馏分油、发动机燃料和其他油品。
1.2本标准适用于测定卤素含量低于0.35%(m/m)的液态烃中的总硫含量。
1.3以SI(国际单位制)作为标准计量单位。
1.4本标准涉及某些有危险性的材料、操作和设备,但是无意对与有关的所有安全问题都提出建议。
因此,用户在使用本标准之前应建立适当的安全和防护措施并确定有适用性的管理制度。
2引用标准下列标准包括的条文,通过引用而构成为本标准的一部分,除非在标准中另有明确规定,下述引用标准应是现行有效标准。
GB/T4756石油液体手工取样法3方法概要将烃类试样直接注人裂解管或进样舟中,由进样器将试样送至高温燃烧管,在富氧条件中,硫被氧化成二氧化硫(SO2);试样燃烧生成的气体在除去水后被紫外光照射,二氧化硫吸收紫外光的能量转变为激发态的二氧化硫(SO2),当激发态的二氧化硫返回到稳定态的二氧化硫时发射荧光,并由光电倍增管检测,由所得信号值计算出试样的硫含量。
警告:接触过量的紫外光有害健康,试验者必须避免直接照射的紫外光以及次级或散射的辐射光对身体各部位、尤其是眼睛的危害。
4意义和应用石油化工厂加工的原料中含有痕量硫化合物会引起催化剂中毒。
本标准可用于测定加工原料中的硫含量,也可用于控制产品中的硫含量。
5仪器5.1燃烧炉:电加热,温度能达到1100℃,此温度足以使试样受热裂解,并将其中的硫氧化成二氧化硫。
5.2燃烧管:石英制成,有两种类型。
用于直接进样系统的可使试样直接进人高温氧化区。
用于舟进样系统的人口端应能使进样舟进人。
燃烧管必须有引人氧气和载气的支管,氧化区应足够大, 确保试样的完全燃烧。
5.3流量控制:仪器必须配备有流量控制器,以确保氧气和载气的稳定供应。
BF-3000S紫外荧光定硫仪说明书
BF-3000S紫外荧光定硫仪使用说明书大连北方分析仪器有限公司目录一、前言 (1)二、工作原理及结构 (1)三、仪器技术参数及主要特点 (2)四、系统工作条件要求 (3)五、仪器组成及安装 (3)六、开机及样品分析操作 (7)七、软件操作步骤 (8)八、标准曲线制作和样品分析 (14)九、仪器操作注意事项 (22)十、仪器维护及常见故障的排除 (22)十一、仪器配置清单 (25)十二、产品使用信息反馈单 (26)十三、保修卡 (29)使用本仪器之前,应仔细阅读说明书中的所有内容,熟悉仪器的各个组成部分,避免因误操作损坏仪器,给您的工作带来不便,谢谢合作!一、前 言欢迎使用我公司开发研制的BF-3000S 紫外荧光定硫仪,为了确保您对该仪器能够正确使用和维护,请详细阅读该使用说明。
该说明详细介绍了仪器的工作原理、仪器构造、故障处理、软件应用及一些操作技巧和使用时应注意事项等内容。
若在使用过程中存在疑问,请即时与我公司联系,我们会及时给您更详细的解答。
二、基本原理BF-3000S 紫外荧光定硫仪采用紫外荧光法测定总硫含量,该方法为当前成品油中硫含量的推荐方法标准之一,也是测定石油及其化工产品中硫含量的最好方法之一。
该仪器关键部件均采用进口器件,大大提高了仪器的精度和稳定性。
该仪器广泛应用于测定成品油、原油、馏分油、石油气、塑料、石油化工产品等产品中总硫含量。
BF-3000S 紫外荧光定硫仪气路流程图如下:BF-3000S 紫外荧光定硫仪基本原理:如上图所示,样品被微量注射器(或气体进样器)送入石英裂解管后,在1000℃左右的高温裂解炉的作用下,样品被全部气化由载气(氩气AR )带入裂解区和燃烧氧发生氧化裂解反应,反应生成物包括SO 2,CO 2,H 2O ,*NO ,以及其它氧化产物(以下用MO X 表示)。
样品中的氮化物定量地转化为²NO ,硫化物定量地转化为SO 2 。
反应气随载气和过量的氧气,通过膜式干燥器脱去反应过程中产生的水分子,进入反应室。
SY-2000S荧光硫测定仪技术规格书
SY-2000S荧光硫测定仪技术规格书
1 工作环境条件
1.1 电源:220V,50Hz
1.2 温度:操作环境10˚C~35˚C
1.3 湿度:20~90%
2 配置
2.1 仪器及相关配件:主机1台,裂解炉1台,进样器1台,石英管1支,标样2盒,计算机1套,进样针2支,连接线1套,保险丝2只,操作说明书及合格证各1份。
2.2 工作站软件,可以控制仪器操作、数据处理及方法数据管理。
3 性能指标及技术要求
1.技术参数:测量范围:0.2mg/L~10000mg/L ~百分含量
温度范围:室温~1100℃控温精度:±1%
重复性误差:0.2mg/L≤X≤1.0mg/L,≤±0.1mg/L
1.0mg/L<X≤10mg/L,Cv≤±10%
10mg/L<X Cv≤±5%
2.性能特点:Windows操作平台,人机对话,操作便捷。
微电流检测采用国内首创硫检测器,使仪器具有灵敏度高、噪声低、线性范围宽、抗干扰能力强等优点。
适用范围:适用于测定原油、馏分油、液化石油气、塑料、石油化工产品、食物等中总硫含量。
3.符合标准:符合ASTM D5453、SH/T 0689-2000等标准。
ZDS荧光硫测定仪说明书
一、概述ZDS-2000型荧光硫测定仪是采用紫外荧光法原理与计算机控制技术相结合研制开发的新一代测定液体、固体、气体物料中硫元素含量的分析系统。
仪器由新型电子元件设计的微电流放大器和微机控制数据采集与处理及紫外荧光分析系统构成。
该仪器具有灵敏度高,噪音低,线性范围宽、抗干扰能力强以及操作简便、性能稳定等优点,广泛应用于石油、化工、电力、环保及其它相关领域的科研单位和生产单位,是目前国内最先进的紫外荧光定硫分析系统。
仪器主要由主机(数据采集、控制系统)、裂解炉、自动进样器、计算机(含操作软件)、打印机等部件组成,其结构示意图如图1.1所示:图1.1二、工作原理ZDS-2000型荧光硫测定仪采用紫外荧光法测定原理。
试样直接进入裂解管或进样舟中,由进样器将试样送至高温燃烧管,在富氧条件中,硫被氧化成二氧化硫(SO2);试样燃烧生成的气体在除去水后被紫外光照射,二氧化硫吸收紫外光的能量转变为激发态的二氧化硫(SO2*),当激发态的二氧化硫返回到稳定态的二氧化硫时发射荧光,并由光电倍增管按特定波长检测接收,发射的荧光对于硫来讲完全是特定的并且与原样品中的硫含量成正比。
再经微电流放大器放大,计算和数据处理,即可转换为与光强度成正比的电信号。
使用该仪器对样品进行分析时,首先用硫的标准样品作出相应的标准曲线,调用相应的标准曲线进行样品分析,就可测出未知样品中的硫含量。
警告:接触过量的紫外光有害健康,试验者必须避免直接照射紫外光以及次级或散射的辐射光对身体各部位,尤其是眼睛的危害。
ZDS-2000型荧光硫测定仪的工作原理及气路流向如图2.1:图2.1 ZDS-2000型荧光硫测定仪框图三、技术参数3.1、测试方法:紫外荧光法3.2、可测样品状态:固体、液体、气体3.3、测量范围:1.0mg/L~10000mg/L (液体)3.4、温度范围及控温精度:室温~1200℃ 0.5%±1℃3.5、PMT高压范围:DC400V~700V,根据测量试样浓度的高低,通过操作系统设置所需值。
- 1、下载文档前请自行甄别文档内容的完整性,平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益,请联系客服反馈,我们会尽快为您处理(人工客服工作时间:9:00-18:30)。
SY—2000N Chemiluminescentnitrogen detectorInstructions for use(V2.0)泰州市奥普特分析仪器有限公司TaiZhou City AoPuTe Analysis Instruments Co. Ltd.Recording1Foreword:SY-2000N Chemiluminescent nitrogen detector based on principle of chemiluminescence method combined with computer technology to develop next-generation precision laboratory instruments. Wide linear range, strong anti-jamming ability, simple, stable and reliable results, and highlight the advantages, which can be widely applied in petroleum, chemical industry, electric power, coal, food, environmental protection and other areas, is now more advanced sulfur analysis instrument.2The basic principle:SY-2000N Chemiluminescent nitrogen detector works as follows:1 : SY-2000N Chemiluminescent nitrogen detector block diagramInstrument by the injector, cracking, ozone generators, reactor micro-current amplifier and, photoelectric conversion device, data processing system consists of several parts. When the sample is introduced after high temperature pyrolysis reactor, mixed with oxygen combustion and quantification of nitrogen compounds into NO, dehydration and carried by carrier gas dryer into the reaction Chamber, from ozone O3reaction excited NO2cm,Dang NO2﹡When you return to the ground state, issue a photon, the light received by a photomultiplier tube and consists of micro-current amplifier, data processing systems convert the displayed a luminous intensity is proportional to the signal, by measurement of chemiluminescence intensity to derive the total nitrogen content of the sample.The entire reaction can be represented as follows:High-temperatureR—N+O2N O+NO2+CO2+H2ON O+O3 N O2*+O2N O2*N O2+hγ'3Detailed technical parameters1Technical parameters:1.1Power supply voltage:AC220 v±10%1.2Power of the whole machine≤2200 W1.3Measuring range:0.1ppm—1%1.4Detection limit: 2 NG1.5Repeatability:Content of 0.1 ppm--1.0ppm Shi ±0.1ppmContents 1 ppm--10ppm Shi <10%Content >10 ppm Shi <5%1.6Baseline drift using : < 2uV/72h1.7Temperature range : room temperature ~1150 ° c1.8Temperature control accuracy: better than ±3° c1.9Cooling way: air cooler4Performance introduction4.1Wide range of application,Applies to total stability of light hydrocarbon gas, light oil or heavy oil Sulfur Determination of the content of.4.2Introduction of computer control and data processing.4.3Equipped with a printer directly prints analysis, analysis maps.4.4Instrument Dual CPU architecture functional,Performance and stability、Measuring accuracy of the results.4.5Combination of single-point calibration and multi-point calibration, automatically generated, save the calibration curve.4.6High measuring range (third gear attenuation).4.7High sensitivity (gain four).4.8Instrument software is simple, convenient, and easy to learn。
5System requirements5.1Environmental requirements:To ensure that the instruments can work properly, need to have the following environment conditions:1.Ambient temperature constant and cannot be above30degrees centigrade. 2.Must not contain corrosive gases in ambient air and dust, so as to avoid corrosion of parts, wiring short circuit.3.Spacious, airy instrumentation requirements, avoid direct exposure to sunlight.5.2Power requirements:1.Power supply voltage220V±5%/50HZ .2.Supply current is greater than15A.3.Have a good ground, resistance to ground is not more than3ω.5.3Air source:1.High purity oxygen:purity ≥99.9%2.High-purity argon gas: purity ≥99.9%6Equipment composition andinstallation6.1Opening inspection:After receiving the instrument user, against the packing list should be examined case-by-case, see if there are parts shortagesor damage occured, if there is a shortage or damage, should get in touch with the company.Note: before using this instrument, carefully read the instructions for all content, are familiar with the various components of the instrument, in order to avoid accidental operation damage the instrument, if service is required, it shall promptly notify the company.6.2System composition:6.2.1Hosts:1, response splitting part:Reaction. By two-stage Complete sample sulphide is converted S O2furnace computer control and display of temperature and the ambient temperature within the host, temperature control accuracy ±1%, flow control unit can control three way adjustment range is as follows: (cracked)50 ~ 500 ml/minO2(gas)30 ~ 300 ml/minO2(Carrier gas)30 ~ 300 mL/minArPart 2, detectorComplete the detection of fluorescence signals, amplification, and accept the computer control, to send the signal to the computer.6.2.2Computer system comprisingComputer systems including the host, monitor, printer, keyboard, mouse, and the corresponding computer software, dedicated data acquisition and control system. Complete temperature control, signal processing and control, intermediate and final results of the sample analysis.6.2.3Injector partsTo ensure constant speed sampling, the user can0.3 ul/sec≈1.2ul/sec Based on an analysis of requirements within the scope of selected sampling speed.6.2.4Pneumatic connectionsSystem air flow chart:5: System air flow chartNote: the instrument before use, clean all gas lines and fittings require.1.Flow control valve clockwise, will all flow to a minimum.Note: do not close the flow control valve, you should gently go can feel when there is resistance to, too much force can damage the valve.2. Inner diameter of3mm of stainless steel pipes, copper pipes or Teflon pipe imports argon argon gas source and host connected to source of oxygen and oxygen linked to imports.Note: requires source of oxygen with oxygen inlet connection between gas dryers (5A Molecular sieve).3.quartz cracked pipe installation(1)Host activities on both sides of the bezel is removed.(2)Saturate a cotton small amounts of solvent such as alcohol or acetone will wipe clean the tube wall, to remove the dirt and fingerprints.(3)Carefully place the Lysis tubes in cracking furnaces, the injector at the right side of the stove.(4)Splitting oxygen pipeline connected to the Lysis tube cracking oxygen imported, gas pipeline connected to the Lysis tube containing gas imports.(5)With four semi-circular ring of insulating ceramic (Lysis tube clips) to the Lysis tube and left end fixed.Note: you should enable the Lysis tube coaxial with the cracking furnace inside as much as possible, to ensure that pipe heat evenly.(6)Crystal cracked fitting the Lysis tube trailer, and connected to the equipment of the gas export and fitting clamp fitting and the Lysis tube end clamp.Note: to ensure the Lysis tube type ball grinding and not leak between the connector, you need to use sealing washers (silicone rubber).(7)Will host activities on both sides of the bezel installed.3.PTFE back panel of the pipeline will be connected to the gas-exportingand gas dryers, dryer with the host at the other end connected to the rear panel above the gas imports.More than pneumatic connection when the operation is complete, it is necessary to complete gas tightness check, to ensure that the gas leak, air flow has not stopped up, all gases from the exhaust only export outflows.6.2.5Electrical connection:1.In the back panel of the instrument's good ground earth terminal access. 2.Plug the supplied power cord into the power socket on the rear panel corresponds to.3.Connect the computer power cable in accordance with the operating instructions connect a computer system.Note: ensure all wiring connections and reliable, no loose.7Software installation and operating instructions7.1Install SY-2000N ProgramInstalling for the first time, follow these steps∶1. Power boot a computer into windowsXP operating systems2. The CD Setup and installation considerations for copying to your hard drive c:\SY in a subdirectory3.left mouse button double-click CD SETUP. EXEinto SY-2000N Setup.4.Follow the instructions in Setup, each click (Next) button, and thenclicking (Finish) button to complete the installation.Or basis directly from the CD Installation Notes install program. Note: the instrument is to give users in all application software is already installed, if the user is in use for some other reason you need to reinstall the SY-2000N program, you should uninstall the SY-2000N Setup andinstall SY-2000N Setup. How to uninstall please refer touninstalling SY-2000N Setup.7.2Uninstall SY-2000N SetupUninstall the SY-2000N Installer, follow these steps:1Open the WindowsXP [ Control Panel ], double-click [ add/territory remove programs ] icon, the system opens (adds HK remove programs) the dialog box.2In the dialog box list, select the "SY-2000N chemiluminescent nitrogen detector", and then click (add/territory remove) button, prompt box appears, select the "Yes" button to start thedelete SY-2000N chemiluminescent nitrogen detector program, then press OK button to complete the uninstall.8Start and quit SY-2000N programsOverviewInstall SY-2000N programUninstall SY-2000N programStart SY-2000N programsQuit SY-2000N programsSY-3000N Window and basic operation8.1OverviewThis chapter describes how to install the SY-2000N chemiluminescent nitrogen detector program. Prior please make sure Microsoft Windows XP or later is installed. If you do not use Windows menus, edit boxes, scroll bars, or dialog boxes you have questions, please refer to Windows XP operating system user's manual.Note:SY-2000N Installer Before installation, please keep it safe backup just in case.If you receive an upgraded version of the program, uninstall the original program, And then install the upgraded version of the program(See Uninstall SY-2000N programs).8.2StartYou can select the method to enter:1, Double-click windowsXP desktop SY-2000N shortcut icon chemiluminescent nitrogen detector:2、Click the windowsXP began , and then move the mouse pointer to pointto the program SY-2000N chemiluminescent nitrogen detector and its parent menu item under SY-2000N chemiluminescence nitrogen, and click the left mouse button on the menu.8.3ExitYou can select the method exit1. Select from the file menu (exit).2. Quick on the button bar, click the close button.9Power on:In accordance with the instructions for use keep full equipment electricity, gas, ground connection is good, check for leakage, or leakage, make sure that is correct, and then follow these steps to power on the system.(1)Gas purging:To ensure the instrument often work under, power should be gas before blowing to remove water vapour and other impurities in the gas. This is a new instrument and the instrument is not used for a long time is particularly important.Gas purging method: flow control valve counterclockwise, moved three meters are to15Notches, purging10Minutes or so.(2)Power upOpen the power distribution box, or total power supply distribution Board, reopening the entire instrument, instrument power up, boot the computer, enter the Windows The operating system.Note:Enter SY-2000N Program cannot run other applications, has exited other applications should be running and shuts down. Windows window then click on Start, and settings , and Control Panel , and powermanagement ,power schemes , and waiting for the State of the system , and turn off the monitor , And turn off hard disks , these four sets for the never option. Otherwise, the SY-2000N program may not run correctly to avoid damage to the instrument, such as over-temperature of cracking furnace, electric wire burned.(3)Gas flow selection①Cracking O2Airflow:This road O2Gas flow rate directly affects the size of the sampleconversion of oxidative pyrolysis, effects samples into sulphide in SO2rates. Analysis when making cracking o2gas in excess, to ensure full combustion of samples, Lysis tube does not generate carbon, while traffic also should not be too large, otherwise not conducive to theresponses, sample fluorescence transformation of sulfides as SO2intensity is reduced.General analysis of condition, can be cracked O2Air flow adjustmentto150~500ml/min Within the scope of.②Ar Airflow:Ar As the carrier gas, the volatile samples carry into the cracked pipe of high temperature parts, oxidative pyrolysis of samples. General requirements for Ar gas flow in the60~400ml/min range, users can high and low sulfur content of samples, sample size and cracking of o2gas flow, such as the size of the selection of suitable Ar gas flows.③O2Airborne gas flow:General analysis of liquid samples of relatively light distillate, gas can be without this road. When the samples are less volatile,and Ar gas by adding a certain amount of o2gas together as the carrier gas, can promote the gasification of the samples.(4)SY-2000N Program startsAs mentioned earlier, run SY-2000N Program, enter the standard sample, sample analysis.10Sample analysis:Analysis of liquid samples, for example the following describes the basic operation of samples and some problems should be noticed.1. Sample preparation:Analysis unknown samples by fluorescence analysis of sulfur method, first get the response value of an unknown sample, namely integration area and sulfur content of unknown sample results are based on the same points of reference materials in the condition area, reference materials and sample weight of unknown, unknown score calculated data such as size of the sample. Therefore, prior to the analysis of unknown samples, to pre-select a number of different concentration of standard samples, sample selection should pay attention to the following several points:(1)With suitable sulfur compounds as solute:(2)With the appropriate solvent, samples, and unknown samples in the sample matrix as close as possible.(3)Use within the warranty period of the standard sample, sample shelf life is one year, so that samples need to be kept. Solutes andsolvents are volatile substances the samples should be kept inrefrigerated containers, to prolong its service life.2. Sample analysisAs mentioned before sample analysis, first select the appropriate sample, sample curve, the concentration of the samples in the standard curve, to ensure sample analysis data is accurate and reliable, if the concentration of the samples in the standard curve in addition to and exceed the minimum sample concentration10%~20%, Or micro-current amplifier saturation (peak shape for flat peak, need to replace the quantum), asked to reselect the sample making standard curves.11Shutdown:Subject to the instrument after use, shut down by doing the following:1. Turn off the UV lamp power supply, cooling by temperature controller button, turn off the furnace power.2. Power down the host, injector, for a few minutes and pneumatic clean after, turn off the gas.3. For two hours, after the temperature dropped off fan switch.4. By balloon tips quit SY-2000N programs into Windows exit window, power off the computer, monitor, printer.5. Distribution box, or power Board total power is off.12Reaction chamber-cleaningBecause the instrument used for a long time. Reaction indoor residue deposits, resulting in a lower sensitivity, analysis results are not repeated, so users should be based on the use of regular cleaning Chamber. The sediment may be powdered or likely to be oily, its color may be yellow, Brown or black, which mainly depends on the type and operating conditions of the analysis sample, such as material feed speed too high, lack of oxygen, the oven temperature is too low.Cleaning process is as follows:1. Turn off all power switches.2. Open the cover, unplug the darkroom high voltage power and signal plugs, disconnected lines.3. Release the dark base and back panel screws, take out the darkroom later, release the dark end cap fixing screws. (Air road pipelines of end caps).Note: photomultiplier tube-side window shows up, the needs in-side window with a piece of black cloth to block the light.4. Remove Chamber cover screws, carefully removing the gland, filters, Quartz. If the "o"-ring broken, replace it with new.5. Cleaned the mirrors of wadded paper with high silica film and filters, wipe with clean soft cloth with no hair reaction indoor wall, if necessary, get scrubbed clean with acetone or ethanol, and oxygen blow dry.6. Reaction chamber-cleaning is complete, again in order to install.Note: when fixed optical filters, quartz, and action should be smooth, degree of tightening to ensure airtight, beware of filters, quartz plate rupture. Filters, quartz plate location do not install anti-, quartz reaction indoor wall that protects the filter.7. Fixed to the Chamber after Chamber, anechoic chamber attached to the detector, and connect all cables and gas pipelines to avoid leaks, leakage phenomenon.8. Cover the cover.13Instrument maintenance1. Long-term use of the system, pneumatic joints leakage may occur, users response to the gas as a whole do not regularly checked.2. Users should always check after cracking tube outlet port and with and without the carbon in the gas circuit. If cracking tubes of carbon deposition in, you can access oxygen combustion in high temperature conditions clear. If carbon deposits in the pipeline. The timely replacement of new line.3. Users should be required to replace the oxygen desiccant, to ensure that the system is functioning properly.Note:1. Air drier stuffing (5A molecular sieve ) Processing method : 500 Temperatures, activation of 4 Hours.4. Check the use of cracked pipes on a regular basis, if the cracked pipe wall becomes white and rough, instructions for quartz tube lifetime had to, it should be replaced immediately. Analysis of low concentration samples usually, demanding to the Lysis tube, cracked pipe inner wall roughness can lead to drop in its signal strength decreases, lower sensitivity, resolution, Lysis tube on low concentration sample analysis does not apply may also apply to the analysis of high content of samples. 5. Periodic cleaning Chamber, cleaning methods, see the fifth chapter. 6. Injector regularly driven screw Guide bar and add lubricant to reduce wear and noise.Workstation main interface:Workstation's main operations Description:1、Control keysA、Start: the instrument starts automatically sentenced peak, the measurementsignal points.B、End: end the analysis of standard samples, or samples, calculation of theaverage results, starting the next sample or specimen analysis.C、Save curve: saves the current curve curve data in the list.D、Exit: exits the application.2、Gas flow setting interface:Airflow can be adjusted for tuning key can also be entered in the edit box.OK Key to confirm.3、The amplification of the signal processing:The amplification of the signal is divided into two levels, first level: micro-current amplifier; second level: normal voltage amplifier. Magnification levels are available through the interface of the radio button selected.4、Temperature setting:Temperature can be adjusted for tuning key can also be entered in the edit box.OK Key to confirm.5、Toolbar buttons:Analysis is often used toolbar buttons are buttonsA、New construction: new analysis.B、Open: open curves that already exists, and call it.C、Save: save analysis results.D、Preview: print preview.E、Online: Instrumentation and computer communication.F、Status: setting the instrument's working state.G、Unit: mg/L PPm Unit conversion.H、Gain: instrumental measurement signal amplification and processing.I、Air flow: setting the airflow.J、Heating: heated up.K、Temperature: instrument stopped heating up.L、Ozone: ozone generator on and off.M、Exit: exits the application.。
