CARMES五性一体化分析软件-模板
五性一体化协同设计平台五性工具与数据集成环境五性工程软件CARMES6工业和信息化部电子第五研究所数据中心协同一致的五性工作平台，全面到位的五性解决方案CARMES 6突破五性（指可靠性、维修性、保障性、测试性和安全性，即RMS ）工具集的定位，从型号五性一体化设计和全寿命、全过程、全特性管理需求出发，统一筹划，构建企业级五性协同工作环境和平台，强化五性项目、任务、流程、状态和数据的管理监控，功能更加强大实用，可有效辅助企业全方位实现型号五性工作的顶层管理、过程协同和数据共享，提供五性工程一体化解决方案。
1. 全面覆盖，全局掌控2. 综合集成，工程实用CARMES 6集成了型号五性工作所需的22个功能模块和丰富的基础数据库，覆盖30多个RMS 工作项目，形成工程实用的先进RMS 平台和解决方案。
发展历程五性工程软件CARMES自2001年推出以来，历经10多年的工程磨砺，持续创新，集科研成果和工程经验于一体，已成为集成化的五性工程领域专业软件平台。
CARMES 6是在系统总结型号五性工程发展需求和吸取广大用户多年应用经验及反馈意见基础上的一次重大升级，是CARMES发展历程的一个重要里程碑。
CARMES 6充分体现了装备RMS全寿命周期、全系统、全过程、全特性管理的需求，在寿命周期RMS任务、过程和状态集成管理，五性协同设计，功能与数据的一体化集成共享等方面取得突破，在五性系统性、集成化、规范化、自动化和易用性方面取得重要进展。
工程应用CARMES全面融合我国国防工程所需的五性技术和标准，立足国际前沿，密切结合型号工程实际，以贴身服务五性工程为出发点，在RMS工程领域得到广泛应用并取得显著实效，已成功应用于神舟飞船总体及分系统，以及卫星、导弹、核装备、飞机、电子对抗、雷达、C4I、舰船、兵器等系统的500多家用户。
CARMES项目获国防科学技术进步奖，并因成功应用于我国载人航天工程而荣获中国载人航天办公室嘉奖。
CARMES 6新特性1.五性综合管理协同设计平台CARMES 6强化了型号五性综合管理和监控功能，从五性系统工程角度对装备全寿命、全过程的RMS工作实施有效的监管。
通过增加五性管理层，实现型号寿命周期五性工作项目、任务、过程和数据的集成管理。
型号总师、项目负责人、设计师和任务委托方等不同类型用户通过这一管理层次，借助相应的五性工具，实现全局掌控、任务分配与监管、设计分析和监督考核等功能，形成高度一致的五性协同工作环境和集成平台。
2.丰富实用的五性基础数据库CARMES 6从工程应用实际出发，从多年的型号五性工作和实践中积累了大量的五性基础数据，建立起丰富实用的五性基础库。
CARMES 6的五性基础数据库覆盖了航天、航空、电子、船舶、兵器、工程物理等领域主要型号用国产和进口元器件可靠性预计参数库、模块失效率数据，以及机械、机电产品可靠性数据。
依托这些丰富的可靠性预计参数库，可快速便捷的实现可靠性预计的自动化。
CARMES 6包含大量的传感器和敏感元件的性能和可靠性参数，为测试系统的设计提供重要技术支持。
此外，还积累了大量的产品故障模式库、型号元器件适用信息库、保障资源库、危险源信息库等。
CARMES 6提供按用户型号需求定制五性参数库服务，满足用户个性需求。
3.有机融合型号元器件优选和进口元器件风险管理功能型号元器件优选、国产化和进口电子元器件风险管理是当前型号管理的重要工作，与型号五性工作存在紧密联系。
CARMES 6通过下列手段将型号元器件优选管理与可靠性工作有机融合在一起：✧针对型号元器件优选目录中的元器件清单建立通用产品库、可靠性预计参数库和故障模式库等。
✧结合元器件国产化工作，建立进口电子元器件风险信息库，实施进口元器件风险控制，依据国产化前后电子元器件的可靠性水平差异对设备或模块的可靠性进行对比分析，从使用风险、可靠性和费用等方面权衡各种国产替代方案，辅助国产化决策。
4.一体化建模CARMES 6从五性系统工程角度设计出一体化可靠性综合建模方法，一次建模即可完成系统基本可靠性、任务可靠性和可靠性评估等多个五性工作项目的模型构建、数据录入和分析评估工作。
系统树模块增加了节点逻辑关系定义功能，建立系统树时可直接定义节点间的可靠性逻辑关系（如串联、并联、表决、储备等），据此自动生成可靠性框图（RBD）和可靠性评估需要的可靠性树。
建立系统树时可录入节点的逻辑结构、分布类型、失效率、试验数据等信息，选定相应的节点后，即可生成RBD图和可靠性评估逻辑树，点击RBD计算或可靠性评估计算按钮，就可计算生成RBD的任务可靠度和可靠性评估的可靠度置信下限等计算结果报表。
同理，依据FMECA结果可自动生成相应的故障树。
CARMES 6充分利用五性工程的内在联系，高度融合集成各工作项目所需的功能和数据，形成高效的五性设计分析和评估集成环境。
✧工作状态可靠性预计/非工作状态可靠性预计/降额设计集成在一个页面表格中进行，元器件类型、结构参数、复杂度、应力等参数集中录入，一次完成，避免重复录入和不一致问题。
✧可靠性预计得到的失效率数据，在RBD、可靠性评估、FMECA、故障树分析（FTA）、以可靠性为中心的维修分析（RCMA）等模块中可直接自动引用，不需要用户额外操作按钮再获取。
✧可靠性预计模块中用户设定了预计依据、环境、温度和降额准则等应用模版的缺省值后，按[保存]按钮，依托CARMES 6强大的预计参数库，系统即可自动完成可靠性参数查找和失效率计算功能，极大提高可靠性预计效率。
✧可靠性预计模块得到的失效率数据、FMECA模块的故障模式及其频数比数据可直接用于测试性建模分析和RCMA模块的逻辑决断分析。
5.高效的五性工作导航CARMES 6用工作导航图的方式，依据顶层国军标要求给出了产品寿命周期各阶段的五性工作流程和主要项目，为用户在产品寿命周期的不同阶段开展五性相应工作项目提供导航式的指引，用户双击相关工作项目框即可进入相应的工作项目。
CARMES 6中各模块都有清晰的帮助向导，用户双击相应的流程框即可激活所需的工作窗口，快速地协助用户完成工作。
6.符合RMS标准，满足工程要求CARMES 6支持国内外RMS标准规范，符合国内工程标准和管理要求，其算法与报表完全满足国家军用标准要求。
☆GJB 450A《装备可靠性工作通用要求》☆GJB 368B《装备维修性通用大纲》☆GJB 2547 《装备测试性大纲》☆GJB 1371《装备保障性分析》☆GJB 900《系统安全性分析大纲》☆GJB/Z 299C《电子设备可靠性预计手册》☆GJB/Z 108A《电子设备非工作期可靠性预计手册》☆MIL-HDBK-217F《电子设备可靠性预计》☆MIL-HDBK-217F NOTICEⅡ☆电信、电力等行业预计方法☆GJB 1378 《装备预防性维修大纲的制订要求与方法》☆GJB/Z 57《维修性分配与预计手册》☆GJB 2961 《修理级别分析》☆GJB 4355 《备件供应规划要求》☆GJB/Z 35《元器件降额准则》☆GJB/Z 841《故障报告、分析和纠正措施系统》☆GJB/Z 1391《故障模式、影响及危害性分析指南》☆GJB/Z 768A 《故障树分析指南》☆GJB 899A 《可靠性鉴定和验收试验》☆GJB 1407 《可靠性增长试验》☆GJB/Z 20517 《武器装备寿命周期费用分析估算》☆……7.一流的技术支持服务工业和信息化部电子第五研究所作为国内唯一的可靠性专业研究机构，是国军标GJB/Z 299C《电子设备可靠性预计手册》、GJB/Z 108A《电子设备非工作状态可靠性预计手册》的编制单位，是国产军用电子元器件产品手册编制单位和信息中心，具有雄厚的技术实力，能够提供及时、到位的本地化技术和数据支持。
能够以工程和用户需求为牵引不断对软件创新和持续稳定升级。
CARMES拥有强大的软件研发和技术服务团队，提供源代码级技术支持，可及时增加新型元器件的预计模型和参数，动态跟踪国内外元器件最新产品，定期更新扩充元器件库。
CARMES可开发用户EDA电路设计软件接口，可按工程及用户要求编制报表。
惟有CARMES能够郑重承诺：根据用户提供的元器件清单完成可靠性预计参数等数据的收集、分析与整理，建立用户自己的、针对用户型号工程常用元器件的预计参数库、优选信息库和故障模式库等基础数据库。
可以根据用户的不同需要，协助用户做好可靠性预计、分析和设计，生成用户需要的可靠性设计报告。
8.高度的数据安全性CARMES 6可按系统树节点设定五性各工作项目的权限，实现任何级别产品的安全管理要求，可定义三员管理，完全符合国防军工保密要求。
并能根据系统日志实现关键数据的恢复，即使在突然宕机、退出CARMES的情况下，仍然可恢复系统树及相关五性分析的关键数据。
9.架构先进，支持跨平台，多样化呈现CARMES 6充分利用程序设计技术发展的最新成果，采用先进的三层架构，支持跨平台、跨数据库应用和分布式部署，具有良好的可扩展性和按模块独立升级能力。
CARMES 6采用WPF（Windows Presentation Foundation）用户界面框架，支持多窗口、多线程、多属性并行操作，功能和界面设计更加合理易用，呈现方式更加丰富多彩、规范明晰。
例如，系统树用树形表格呈现，用户可在系统树中获取更多的信息，诸如节点名称、型号规格、产品层次、功能等，输出形式更加多样化。
CARMES 6功能模块RMS任务及信息综合管理RMSMIS通过实施RMS工作项目管理、任务分配、流程指引、参数管理、状态监控及报表归档等综合管理手段，构造企业级五性协同工作环境，实现RMS一体化管理。
主要功能包括：✧依据GJB 450A《装备可靠性工作通用要求》、GJB 3872《装备综合保障通用要求》等五性顶层标准和五性大纲要求，结合本单位型号特点，柔性设定五性工作项目、规划和分配五性工作任务，检查五性任务和报告提交状况，监控任务进度和五性状态。
✧检查五性任务和报告提交状况，监控任务进度和五性状态。
✧依据研制合同要求，确定和集中管理工程项目各层次产品的五性参数（目标值/规定值、门限值/最低可接受值、预计值、评估值、验证值等），能直接从提交的五性报告摘要中提取五性参数值。
✧根据产品层次（系统树）对生成的各种五性设计分析报告进行集中管理，并具备报告提交、审核和归档功能。
✧具有根据五性工作流程导航功能，能够根据导航引导开展相应的五性工作。
可靠性建模RBD可靠性建模RBD能完成系统任务可靠性建模及可靠度计算功能。
具有可靠性一体化建模功能，能够在一个统一的程序界面中实现可靠性一体化建模，包括其结构和逻辑关系、分布参数、试验数据等方面的定义和数据录入，实现系统树、可靠性预计、可靠性框图和可靠性评估等工作项目一体化建模和综合分析计算。
