高速背板互连解决方案-TEConnectivity.pptx
3M TE Connectivity 3200 系列连接器使用说明书
Using the Right Combination of Application T ooling and T erminalsis Critical for Maintaining Product Warranties and Protecting Y our InvestmentTOOLING AND WARRANTY-ULBUSINESS CHALLENGECustomers jeopardize reliability, safety and their product warranties if they do not use the Original Equipment Manufacturer (OEM) tooling and terminals which have been designed and qualified together in the proper application and adhere to UL specifications.There are several common instances where a customer risks losing the warranty for their specific application when using industry standard products:• If the product and/or its components have been modified or improperlyhandled, used or installed.• If the OEM tooling is used with any product other than the OEM approvedproduct for which the tooling wasdesigned to operate.• If the wire termination is accomplished using equipment other than thespecified OEM application tooling. Anon-OEM crimp press can be used butthe applicator or touch tooling thatforms the terminal around the wiremust use OEM tooling.Customers also need to take intoconsideration the UL designation forterminal and connector products. MostOEM terminals and connectors are ULrecognized and approved for use inan end product that complies with ULrequirements. However, it is differentwith closed barrel terminals like rings,spades, splices and quick connects. Thecombination of OEM specified tooling andthese closed barrel terminals earns a ULListing, which demands that the OEMproduct itself comply with UL requirementsand be subjected to UL testing andinspections. Should customers use anincorrect combination of terminal andtooling, or use the terminal in an applicationexceeding the defined product parametersor UL standard, they not only void theirwarranty and UL Listing but exposethemselves to product liability issues.SOLUTIONBy using the completeMolex Interconnect System – including the correct combination of Molex terminals and specified tooling – customers receive a reliable solution each and every time while maintaining their product warranty and meeting different industry standards like the UL Listing requirements.Molex understands that identifying the right tooling equipment to use witha specific connector system can be challenging. T o simplify the process,the company provides a search feature on that allows users toinput the terminal part number and retrieve exact tooling options and work instructions. Details include the tooling part information; instruction manual; andApplication T ooling Specification sheet,which provides critical specifications tohelp ensure the proper products and toolsare being used to achieve compliance andmaintain product warranties. There is alsoa search feature that allows customersto identify previously available tooling tohelp reduce costs to the customers.Molex offers free educational materialsabout crimping through its commercialcrimp book. Additionally, its Crimp QualityPosters, which are 25” x 38” in size andfeature either closed barrel or open barrelterminals, are available in 15 differentlanguages including English and Spanish.Finally, Molex technical experts are alwaysavailable to answer questions about Molexconnector products, tooling equipmentand overall crimp quality.APPLICATION BRIEFT o learn more visit /ab/solderlessterminals.html /ab/applicationtooling.htmlBENEFITS AND ROIThanks to rigorous testing and validation procedures, Molex stands behind its solutions with warranties that ensure its products will deliver unmatched performance in any customer application within the designed product specification of the system.©2015 Molex Order No. 987651-3233Printed in USA/GF/2015.08。
TE CONNECTIVITY 照明连接方案速查手册说明书
照明产品目录照明连接方案速查手册1-11773931-1 (1)模组化可退线POKE-IN插入式连接器1-1773872-8 (8)POKE-IN插入式纤薄导线连接器1-1773909-3 (10)SLIM线到板连接器 POKE-IN 1-1773870-4 (12)模组化免螺丝端子台1-1773872-7 (14)COOLSPLICE系列连接器1-1773891-8 (16)COOLSPLICE系列连接器-大线径1-1773884-7 (18)微型SLIMSEAL防水连接器系列1-1773896-3 (20)SLIMSEAL圆形防水连接器系列1-1773883-9 (23)推紧式导线连接器1-1773884-2 (25)旋转接头导线连接器1-1773884-6 (27)2P免压接线到线连接器1-1773870-5 (29)2位LIGHT-N-LOK模组化带锁扣连接器1-1773886-4 (31)3位LIGHT-N-LOK模组化带锁扣连接器1-1773886-5 (33)调光光控器底座和上盖1-1773879-1 (35)LUMAWISE ENDURANCE S模块1-1773915-3 (37)ANSI_C136 41_可旋转调光插座1-1773278-9 (41)LUMAWISE LED底座8-1773700-9 (43)LUMAWISE LED免焊接底座1-1773869-1 (49)LUMAWISE Z32 LED免焊接底座1-1773700-1 (51)LUMAWISE Z35 LED免焊接底座1-1773882-6 (53)LUMAWISE调光光控器底座、套筒和上盖1-1773879-1 (55)接地线夹组件1-1773919-9 (57)NECTOR M密封防水PCB面板安装连接器1-1773923-3 (61)照明连接方案速查手册街道照明户外照明TE Connectivity特色产品照明子系统解决方案•天线•屏蔽罩(BLS)•EMI 滤波器•继电器和开关•精密电阻器•太阳能接线盒•电动汽车充电线束请访问我们的网站：LUMAWISE 调光插座、底座和上盖型号2213362-22213627-22213730-12213748-1产品信息1-1773728-91-1773872-81-1773879-1LUMAWISE Endurance S模块型号2213858-12213837-12213795-1产品信息1-1773915-3SLIMSEAL 圆形连接器系列型号9-2834004-19-2834005-1产品信息1-1773883-9NECTOR M电缆组件型号2829460-12829488-1产品信息5-1773465-6COOLSPLICE 系列连接器型号2213800-22213800-42213600-12213600-22213600-3适用线径18 AWG 0.75mm 220-22 AWG 0.52-0.34mm 212/14-14/16 AWG 4.0/2.5-2.5/1.5mm 212/14-16/18 AWG 4.0/2.5-1.5/0.75mm 214/16-16/18 AWG 2.5/1.5-1.5/0.75mm 2产品信息1-1773891-81-1773884-7模组化可释放的插入式连接器型号2834006-11-2834006-05-2834006-3适用线径18-22 AWG (Solid & Stranded)产品信息1-1773872-8型号1-2834074-21-2834075-22-2834074-32-2834075-3适用线径18-22 AWG Max2.0mm 绝缘外径产品信息1-1773896-3SLIMSEAL 微型IP67防水线到线连接器系列型号2834048-22834049-22834054-12834055-1适用线径16-22 AWG (Solid & Stranded)产品信息1-1773886-41-1773886-5LIGHT-N-LOK 带锁扣的模组化连接器灯具电源和控制室内照明TE Connectivity照明子系统Array解决方案•天线•屏蔽罩(BLS)•EMI 滤波器•继电器和开关•精密电阻器•传感器•端子和连接头请访问我们的网站：户外照明——街道照明模组化 可释放的插入式连接器型号2834006-11-2834006-05-2834006-3适用线径18-22 AWG (Solid & Stranded)产品信息1-1773872-8型号1-2834074-21-2834075-22-2834074-32-2834075-3适用线径18-22 AWG Max2.0mm 绝缘外径产品信息1-1773896-3SLIMSEAL 微型IP67防水线到线连接器系列LUMAWISE LED底座型号2213678-32213407-12213407-22213480-1产品信息8-1773700-9型号2834048-22834049-22834054-12834055-1适用线径16-22 AWG (Solid & Stranded)产品信息1-1773886-41-1773886-5LIGHT-N-LOK 带锁扣的模组化连接器免剥线压入式连接器型号2106431-22106003-2适用线径贯穿式 18AWG封闭式 18AWG产品信息5-1773455-12P 免压接线到线连接器型号2271180-12271183-1适用线径18-22AWG18-22AWG产品信息1-1773863-8紧凑型线到板Poke-In 连接器型号2834172-32834171-32834167-32834012-32834010-3适用线径与2834167-3互配20-24AWG 18-22AWG16-20AWG20-24AWG产品信息1-1773909-31-1773869-6型号2299514-12299515-12299518-1适用线径22-12AWG22-12AWG 22-12AWG产品信息1-1773884-2推紧式导线连接器TE Connectivity 和 TE connectivity (logo) 均为商标。
线卡和背板上高速带宽传输的匹配端接通孔根(STUB)技术
线卡和背板上高速带宽传输的匹配端接通孔根(STUB)技术吴小龙;吴梅珠【摘要】线卡和底板中的通孔支线(短截线)固有阻抗不匹配问题对于要获得更高传输带宽来说是一个很大的阻碍.本篇论文对高层数PCB短的和长的通孔支线进行了研究.数据分析表明:长支线会产生更大的反射损失和S21特性的侵蚀.短支线会产生预期外的相位变化,并带来更大的谐波侵蚀脉冲波形和闭合眼图.通过使用顺序层压和背钻方法可以使这些阻碍得到解决,但会导致更高的产品成本.对于线卡,更密集通孔和隔离盘尺寸使背钻困难异常且难以操作.就高成本的根部背钻方面来说,已发表的匹配端接通孔支线的MTSviaTM技术可作为一种替代方法,并可应用到线卡和底板之上.制作埋入式端接电阻用于去除接地层反射并降低串扰和额外的损失.3D电磁场模拟被用于计算S11,S21参数,特性阻抗和眼图.制作参考底板是当前用于确认时间和频率范围内的测量的模拟结果.【期刊名称】《印制电路信息》【年(卷),期】2011(000)006【总页数】7页(P22-27,40)【关键词】通孔;支线(短截线);模拟;MTS电阻设计【作者】吴小龙;吴梅珠【作者单位】江南计算技术研究所,江苏无锡214083;江南计算技术研究所,江苏无锡214083【正文语种】中文【中图分类】TN411 TEM（横向电磁波）在过孔带状线系统中的传输为支持带状线系统中过孔“TEM”为“横向电磁波（型）[Transverse Electromagnetic (mode)]”的传输，必须满足TEM在电介质（受电流运载路径限制）中传输这个强制性条件。
在带状线过孔系统情况下，这种需求就转变成孔道结构。
图1给出了一个简单的电路图，这里孔道由上部带状线发射点-1，信号孔-2，参考孔-3，底部带状线-5的接收部分，和包围整个通孔结构的介质层-4组成。
在连接器区域和进行探针测试情况下，可以忽略上部带状线，电磁波将通过上部过孔焊盘发出。
在这种情况下，图1简化成到图2。
OSFP连接器笼和电缆组件-TEConnectivity
OSFP连接器、笼和电缆组件TE Connectivity（TE）的八信道小规格可插拔(OSFP）连接器、笼和电缆组件支持总体数据传输率200Gbps，最高可达400Gbps，可满足下一代数据中心需求。
这些产品设计用于28G NRZ和56G PAM-4协议，并且在未来系统升级后可用于112G PAM-4。
OSFP产品通过在插头中采用整合散热器技术，提供卓越散热性能，并可提供支持400G数据速率所需的信号完整性。
OSFP产品提供高端口密度，可在1RU交换机的8通道接口中配置多达36个端口，从而满足当前和下一代硅产品路线图。
应用• 交换机• 服务器• 路由器• 存储设备主要特点• 专为支持28G NRZ和56G PAM-4协议设计• 设计用于高达15W热负载，低气流场合•能够在1RU交换机中提供36个端口主要优势• 支持数据传输率200Gbps，最高可达400Gbps• 卓越散热性能和信号完整性•高端口密度OSFP连接器和笼电缆组件• 1 x 1和1 x 4笼，支持多端口和单端口应用• 低成本、气流通风优化型不锈钢笼确保模块冷却和最佳系统气流• 挡板和端口开口处采用传统EMI封闭• 平块压接PCB组装连接器• 8通道高密度连接器、封装和互配接口符合OSFP MSA规范• 久经验证的0.6mm间距，共60个端子• 简单的低成本对夹型设计，带有2排端子• 可通过共地对齐实现Belly-to-belly安装，PCB成本和噪声低• 现已支持56G PAM-4，未来可升级至112G PAM-41x1 OSFP笼组件1x4 OSFP笼组件，带导光管描述TE产品料号1x1 OSFP笼组件2317416-11x4 OSFP笼组件2338495-1OSFP SMT，PDNI连接器组件2324869-1OSFP SMT，带压紧板，PDNI连接器组件2324869-21x4 OSFP笼，后侧开口2338495-31x4 OSFP笼，带栅格，每个端口1个导光管1-2338495-11x4 OSFP笼，后侧开口，每个端口1个导光管1-2338495-31x4 OSFP笼，带栅格，每个端口2个导光管2-2338495-11x4 OSFP笼，后侧开口，每个端口2个导光管2-2338495-31x4 OSFP笼，带栅格，每个端口4个导光管4-2338495-11x4 OSFP笼，后侧开口，每个端口4个导光管4-2338495-31x4光导管组件，每个端口4个导光管2325080-41x4光导管组件，每个端口2个导光管2325080-51x4光导管组件，每个端口1个导光管2325080-61x4笼子带导光管笼2338495-51x4 OSFP笼，带栅格，无EMI弹簧2315853-21x4 OSFP笼，后侧开口，无EMI弹簧2315853-4EMI/防尘插头2317857-2防尘插头2324698-1产品料号信息OSFP SMT连接器OSFP电缆组件电缆组件• 模块适用于MSA规范阻抗范围• 气流可经过模块壳，从而冷却前向后气流系统中的下游电子元件，或者实现后向前气流排气产品供应• OSFP至OSFP直连电缆• OSFP至2或4个QSFP56分支电缆• OSFP至8根SFP56分支电缆• 将考虑其他自定义电缆配置• OSFP支持高达26 AWG规格• 最大3米电缆覆盖范围满足IEEE 802.3cd SDD21要求 - 13.28 GHz下17.16 dB描述TE产品料号OSFP - OSFP，1米，30AWG 2821906-5OSFP - OSFP，2米，30AWG 2821906-7OSFP - OSFP，3米，26AWG 2336065-3OSFP - 2 QSFP，1米，30AWG 2324441-2OSFP - 2 QSFP，2米，30AWG 2324441-4OSFP - 2 QSFP，3米，26AWG 2335033-3OSFP - 4 QSFP，1米，30AWG 2324442-2OSFP - 4 QSFP，2米，30AWG 2324442-4OSFP - 4 QSFP，3米，26AWG 2336063-3OSFP - 8 SFP，1米，30AWG 2324443-2OSFP - 8 SFP，2米，30AWG 2324443-4OSFP - 8 SFP，3米，26AWG2336064-3产品料号信息OSFP至OSFPOSFP至2 QSFPOSFP至4 QSFPOSFP至8 SFPOSFP连接器、笼和电缆组件TE Connectivity、TE、TE connectivity（标识）以及Every Connection Counts均为商标。
TE传感器解决方案
发动机，涡轮及辅助动力装置
•• 热电偶线束用于废气温度测量 •• LVDT用于推力反向器位置监控 •• Pt200空气温度传感器 •• 多级排放阀LVDT位置传感器 •• 叶轮轨迹和平衡加速度传感器 •• 健康和使用监测系统(HUMS)加速度传
感器 •• 燃料箱液位和流量传感器
军用(导弹，陆地车辆，航海， 无人机)
家用烤箱
•• 温度传感器用于烹饪温度监控 •• 温度传感器用于热解清洁和门锁控制
微波炉
•• 湿度传感器用于烹饪时的食物湿度测量 •• 红外温度传感器用于非接触式食物温度
测量 •• 力传感器测量放入食物的重量
冰箱
•• 温度传感器用于冷藏室和冷冻室的温度 监控
•• 湿度传感器监控制冰抽屉和冰箱隔层湿 度
应用解决方案
干衣机
•• 湿度传感器用于干衣过程中的湿度监 控，当衣物干燥时以及时关闭电源
•• 红外温度传感器测量衣服温度，防止过 热损坏衣物
•• 力传感器用于测量放入的衣物重量
灶具
•• 温度传感器用于电磁炉或灶具的玻璃陶 瓷烹饪面板的温度控制
洗碗机
•• 磁阻传感器用于洗涤喷射臂位置检测 •• 温度传感器用于水温测量和加热控制 •• 液位传感器监控水位和洗涤剂剂量
TE Connectivity SPE T1工业连接器IP20 产品说明书
INTRODUCTION SPE T1 INDUSTRIAL CONNECTORS IP20INTRODUCTION SPE T1 INDUSTRIAL CONNECTORS IP20Summary•New communication standard for factory, process and building automation •Communication infrastructure for the Industrial Internet of Things•IP communication down to the lowest automation level, offering full transparency from sensor/actuator to the cloud.•Substitution of legacy fieldbus systems•Wide area of applications, incl. sensor/actuator connectivity, I/O modules, robotics & machinery, elevators and buildingsTechnology•IEEE 802.3 standards from 10 Mbps to 1 Gbps•Connector standard series IEC 63171Benefits•Small diameter, more flexible and less heavy cables enable the application to move faster and use less energy•Small connector formfactor allows miniaturization in next generationapplications •Easy and quick cable connector assembly reduces installation cost•Reflow solderable SPE board connector supports latest Industrial assembly processes •Cable connector uses high reliable crimp contacts, reducing downtimeApplications• Sensors • Actuators • Switches • Machinery • RoboticsSPE T1 INDUSTRIAL CONNECTORS IP20•Standardized in IEC 63171-6•Enables powering of cascaded devices •THR solder (board) and crimp contact (cable)•Operating temperature range: -40°C -+85°C •Conductor cross section: AWG 26-22switch switch PoDLSeparate Power+ Lower cable weight + Smaller and cost-effective cable-Point-to-point only-Low noise limits for power signal-Special circuitry required+ Higher currents / power + Support of multiple topologies -Higher cable weight -Cable costs PoDL vs. separate PowerEthernet Use Cases at the Edge of theAutomation PyramidSPE Implementation ScenariosMigrationAdditionIntegrationSPE Control SystemEngineering Workstation Asset Management Station Public/Private Cloud SPE Adoption TimelineIndustrial Ethernet TCP/IP & EthernetIIoT Services (Monitoring & Optimization)SPE SPE SPE SPESPE Industrial EthernetPotential Use CaseSubstitution of legacy fieldbusEthernet down to the sensor levelPoint-to-Point, up to 1 kmMultidrop, up to 25 m / > 20 nodes ** tested & simulated by TE Source: // Simatic documentationEthernet Switch with Media ConversionMultidrop Point-to-Point& MultidropIndustrial SPE Network OptionsMultidropPoint-to-pointDeviceDeviceconnector connector connector connector patch cord patch cordcabling cabling cabling conn.conn.2m STP of max 36 m, typ. AWG 22Up to 4 in-line connectors and 2 device connectors STP of max 996 m, typ. AWG 18Up to 10 in-line connectors and 2 device connectors 2m1000BASE-T110BASE-T1L Unshielded wire of max 25 m Up to (>)8 in-line connectors/devices 10BASE-T1SDeviceconnector connector connector connector cabling cabling cabling impedance termination impedance terminationcablingcabling Device Device Device Stub length max 10cmStar topology (distribution)Line topology (daisy-chaining)Point-to-pointSPE Architectures Node 2Node 1PSESPE PD SPE PSE SPE PD SPE PSEPDSPE Power Source Equipment Powered device Single Pair Ethernet PHY Single Pair Ethernet Power line …LegendPower Cascaded PDs powered by one PSE Data Multiple SPE nodes in series either through1.Integrated switches per node2.MultidropPower One PD powered by one PSE (PoDL)Data Point-to-point Power •Downstream PDs powered by switch Data •Downstream SPE nodes connected to switch /multiple PHYs。
TE Connectivity 混合电动汽车解决方案产品概述说明书
Hybrid & Electric Mobility SolutionsPUT THE POWER ON THE ROADTE Connectivity (TE) provides a complete line of connectors, relays, harnesses, contactors and disconnects to safely connect and protect the flow of data and power around your hybrid or electric vehicle.TE‘s automotive products have been proven in light and heavy-duty vehicles and our technologies leverage decades of experience with high-voltage generation, transmission and distribution. So you can depend on them to be safe and reliable in your application.capabilities.Our technologies leverage decades of experience with high-voltage generation, transmission and distribution and you can depend on them to be safe and reliable in your application.Mobility simplified. One charge at a time. TE is helping enable electric mobility by creating safe, high-quality components for every part of the charging station – and making them affordable. Our experience with high-voltage energy distribution and Smart-Grid technology gives us insight into the needs of this important market segment. More than a complete charging solution.A smart one. Smart charging solutions enable customers to meter their EV’s electricity consumption, and communicate data via innovative smart charging cords and inlets. You supply the shell, we’ll supply everything else. TE has everything it takes to create your charging solution, except the box it goes in. From cables to contactors, meters to card readers, screens to sockets, we’ve already solved how it all goes together.CHARGING SOLUTIONSAMP+ line of cables, connectors, harnesses and terminals safely and reliably channel high- and low-voltage power in and around the battery and vehicle, to help you put the power to the road.Completing the connections that power it all. More than 50 years of experience with high-voltage electricity separates us from automotive engineering companies in the hybrid and EV industry.We’re using that knowledge to help create smarter, better, easier ways to connect the grid to drivers – and give them the mobility they need. Before everyone can embrace driving hybrid and electric vehicles, we need a safe, reliable way to get the power from the grid to the chargers, and into the batteries.TE’s broad array of energy and industrial technologies have seen decades of real-world use connecting and protecting the flow of power around the world. So you can depend on them to be safe and reliable in your application, too. INFRASTRUCTURE SOLUTIONSCatalog 1654294-4 Publishxed xx-2017Catalog 1654294-4 Publishxed xx-2017Catalog 1654294-4Publishxed xx-2017At TE Connectivity, we support your RoHS requirements. We’ve assessed more than 1.5 million end items/components for RoHS compliance, and issued new part numbers where any change was required to eliminate the restricted materials. Part numbers in this catalog are identified as:RoHS CompliantPart numbers in this catalog are RoHS Compliant, unless marked otherwise. These products comply with European Union Directive 2002/95/EC as amended 1 January 2006 that restricts the use of lead, mercury, cadmium, hexavalent chromium, PBB, and PBDE in certain electrical and electronic products sold into the EU as of 1 July 2006.Note: For purposes of this Catalog, included within the definition of RoHS Compliant are products that are clearly “Out of Scope” of the RoHS Directive such as hand tools and other non-electrical accessories. Non-RoHS CompliantThese part numbers are identified with a “t” symbol. These products do not comply with the material restrictions of the European Union Directive 2002/95/EC.5 of6 CompliantA “l” symbol identifies these part numbers. These products do not fully comply with the European Union Directive 2002/95/EC because they contain lead in solderable interfaces (they do not contain any of the other five restricted substances above allowable limits). However, these products may be suitable for use in RoHS applications where there is an application-based exception for lead in solders, such as the server, storage, or networking infrastructure exemption. Note: Information regarding RoHS compliance is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge based on the information provided by our suppliers. This information is subject to change. For latest compliance status, refer to our website referenced below. So whatever your questions when it comes to RoHS, we’ve got the answers at / customersupport/rohssupportcenter/Catalog 1654294-4Publishxed xx-2017Remark: Starting from 0.03 mm2 (AWG 32) a wire can be crimped.Most of the wire size ranges are mentioned in mm 2, as well as the insulation diameters which are in many cases only in mm’s We therefore included the con-version tables on page X and page XI. Please note that wire and insulation sizes are for guidance only. Consult the customer drawing for precise detail.FLK and FLR stand for German DIN (72551) abbreviations. FLK means: In German: • Fahrzeug-Leitung Kunststoff In English: • Vehicle Cable Plastic FLR means: In German: • Fahrzeug-Leitung reduziert In English:• Thin Walled Cable (reduced insulation thickness)P a g eP o w e r t r a i n S y s t e m sS a f e t y &S e c u r i t y S y s t e m sC o n v e n i e n c eD r i v e r I n f o r m a t i o nB o d y &C h a s s i s S y s t e msCatalog 1654294-4Publishxed xx-2017P a g eP o w e r t r a i n S y s t e m sS a f e t y &S e c u r i t y S y s t e m sC o n v e n i e n c eD r i v e r I n f o r m a t i o nB o d y &C h a s s i s S y s t e m sCatalog 1654294-4Publishxed xx-2017P a g eP o w e r t r a i n S y s t e m sS a f e t y &S e c u r i t y S y s t e m sC o n v e n i e n c eD r i v e r I n f o r m a t i o nB o d y &C h a s s i s S y s t e msCatalog 1654294-4Published 04-201744AMP+ IPTConnector for powertrain applications in high vibrationenvironment, up to 300A (depending on wire crosssection) at 105°. Used e.g. to connect inverter toe-machine and charging applications.IP Rating: IP6k9kHVIL:noCPA:noFire Classification:HBVibration Level:4Application Specification: 114-94133Product Specification: 108-94293Interface Drawing:114-94132-1AMP IPT 1pxiVersion(Cable Dimension)Coding Order Information25 / 35 / 50 mm²(acc. LV216-2)releasedATo be Orderedsee drawing!BCDEF16 mm²in planningDrawing 114-94131-1 *IP Rating: IP6k9kHVIL:noCPA:noFire Classification:HBVibration Level:4Application Specification: 114-94133Product Specification: 108-94293Interface Drawing:114-94132-2AMP IPT 2pxiVersion(Cable Dimension)Coding Order Information25 / 35 / 50 mm²released ATo be Orderedsee drawing!16 mm²in planningDrawing 114-94131-2 *IP Rating: IP6k9kHVIL:noCPA:NoFire Classification:HBVibration Level:4Application Specification: 114-94133Product Specification: 108-94293Interface Drawing:114-94132-3AMP IPT 3pxiVersion(Cable Dimension)Coding Order Information25 / 35 / 50 mm²released ATo be Orderedsee drawing!16 mm²in planningDrawing 114-94131-3 *white papers and other technical information. To download our literature visit/automotiveliterature.htmlor document questions. To contact a PIC representative, visit /support-centerCatalog 1654294-4Publishxed 04-2017DISCLAIMERWhile TE Connectivity (TE) has made every reasonable effort to ensure the accuracy of the information in this catalog, TE does not guarantee that it is error-free, nor does TE make any other representation, warranty or guarantee that the informati-on is accurate, correct, reliable or current. TE reserves the right to make any adjustments to the information contained herein at any time without notice.TE expressly disclaims all implied warranties regarding the information contained herein, including, but not limited to, any implied warranties of merchantability or fitness for a particular purpose. The dimensions in this catalog are for reference pur-poses only and are subject to change without notice. Specifications are subject to change without notice. Consult TE for the latest dimensions and design specifications.TRADEMARKSAMP+, AMP MCP, MCON, MQS, EVC, TE, TE Connectivity, TE Tyco Electronics (logo), TE (logo) and TE connectivity (logo) are trademarks.Other product names, logos, and company names mentioned herein may be trademarks of their respective CAR is a trademark.COPYRIGHT© 2017 TE Connectivity All rights reserved.TE Connectivity Germany GmbH certified acc. ISO 14001 and ISO/TS 16949:2002TE Connectivity Germany GmbHAmpèrestrasse 12–14 | 64625 Bensheim | Germany Phone: +49 (0)6251 133-0 Product Information Center EMEAPhone: +800 0440-5100 (toll-free)United States – Harrisburg Product Information Center: Phone: +1 800-522-6752 Fax: +1 717-986-7575South AmericaPhone: +54 11-4733-2015 Fax: +54 11-4733-2083South Africa – Port ElizabethPhone: +27 41-503-4500 Fax: +27 41-581-0440EUROPEUNITED STATESSOUTH AMERICAAFRICAAustralia – SydneyProduct Information Center: Phone: +61 2-9840-8200 Fax: +61 2-9634-6188People’s Republic of China Hong KongPhone: +852 2738-8731 Fax: +852 2735-0243People’s Republic of China ShanghaiPhone: +86 21-3398-0000 Fax: +86 21-3398-1999Korea – SeoulPhone: +82 2-3415-4500 Fax: +82 2-3486-3810ASIA / PACIFIC1654294-4 | P u b l i s h e d 04-2017。
TE Connectivity Eurocard 连接器快速参考指南说明书
EUROCARD CONNECTORS PER DIN 41612 ANDIEC 60603-2Quick Reference GuideTE Connectivity’s (TE) Eurocard two piece connectors offer a reliable, cost effective solution enabling communication across protocols in industrial automation anddata applications. By meeting DIN 41612 and IEC 60603-2 specifications, our Eurocard connectors are proven to provide reliable signal integrity (SI) and electrical performance in demanding applications. With a broad portfolio, it is easy to find the right connector type and style to fit your application. Common Bus Systems include STE Bus, CIMBUS, FUTUREBUS, VMEBus, MULTIBUS (II), NUBUS, VXi Bus andVME 64X.KEY FEATURES • Meets DIN 41612 and IEC 60603-2 • Two-piece reliability • Polarized housings • Flame retardant• Types B, C, D, F, M, Q and R • Standard DIN sizes as well as half,third, and expanded sizes •Various solder post lengths and ACTION PIN and eye-of-needle contact tails•Selective contact loadingThe Eurocard line is available in board-to-board, wire-to-board, ribbon cable-to-board and high current connectors.APPLICATIONS• Data centers• Storage• Servers• Base stations• T elecommunications equipment• Backplane and motherboard assemblies • Switching systems•Modular rack systems STANDARD BUSSES• CIMBUS Type B, 64 Position • FUTUREBUS Type C, 96 Position • MULTIBUS (II) Type C, 96 Position • NUBUS Type C, 96 Position • STE Bus Type B, 64 Position • VME 64X Type C, 96 Position • VMEbus Type C, 96 Position •VXI Bus Type C, 96 PositionPRODUCT SPECIFICATIONS• DIN 41612 Two-Part Connectors for Printed Circuit Boards • IEC 60603-2 C onnectors for Frequencies below 3 MHzfor Printed Circuit BoardsAPPLICATION SPECIFICATIONS• 114-9014 Eurocard Connector Types B, C, M and R (Board-to-Board Application)• 114-19004 Eurocard Connector, Type F Receptacle • 114-12026 Type M Coax Contacts • 114-10014Size VIII Power Contacts• Power automation • Distributed control systems in industrial control • Programmable logic controllers (PLC)• Robotics • T est and lab equipment• Energy distribution • Monitoring equipment32 / 32A, B Posted.104——5536053-564 / 64A, BACTION PIN———5650865-532 / 32A, BPosted.130——5536446-5 ACTION PIN———5650864-520 / 20A, B Posted.114——7-1393640-278 / 78 2 / 0Posted.1181-1393645-760 / 60 4 / 0Posted.104148412-542 / 42 6 / 0Solder.104148413-524 / 248 / 7ACTION PIN.236148497-5*78 / 78 2 / 0 ACTION PIN.1905148417-560 / 60 4 / 0ACTION PIN.1905148420-542 / 42 6 / 0ACTION PIN.1465-1393637-7*Connectors for CompactPCI applications10 A PCB—Vert PlugNo3-1393589-1 Wire16–18Cable Recpt No1-1393589-120 A Wire12–14Cable Plug No1393589-3 Cable Recpt No1393589-925 A PCB—R/A PlugNo1-1393589-8Yes1-1393589-7 R/A RecptNo2-1393589-9Yes2-1393589-740 A PCB—Vert Recpt No148375-1 Wire8Cable Plug No1393589-1Cable Recept No1393589-7PCBVert Recpt1-1393662-0RG-179 Cable Cable Plug3-1393668-4 Cable Plug3-1393668-0RG-316 CableCable Plug1392020-1 Cable Recpt1392019-1 R/A Cable Recpt1393668-4DIN 41612 TYPE M: POWER AND COAXF826198-1D 7-826199-0F8-826199-0B, C, D, F, R Receptacle926495-2C .012 x .012Flat Rock Flat RockC (Half Size).025 x .025432582-1—.012 x .012Flat Rock Flat RockC (128 position).025 x .025432584-1—C (160 position).025 x .025432585-1—F .025 x .025Flat Rock Flat Rock .039 x .039Flat RockFlat Rock M.025 x .025—148454-1M Crimp PowerContacts—Daniels crimping tool M 300-BT—Mating / Unmating Force (96 pos)90.7 N (20.4 lb) Max.90.7 N (20.4 lb) Max.90.7 N (20.4 lb) Max.Solderability Yes Yes Yes Dielectric Strength 1000 V 1000 V —Vibration 10-2000 Hz, 20G 10-500 Hz, 6G—Shock 490 m/s 2(50G)——Acceleration980 m/s 2——Rapid Temperature Change -55°C, +125°C -55°C, +125°C —Insulation Resistance 1 E 12 ohms 1 E 12 ohms —Dielectric Strength 1000 V 1000 V —Visual ExaminationYesYesYesDIN 41612 ACCESSORIESDIN 41612 PERFORMANCE LEVELSDIN 41612 PERFORMANCE LEVELS, continuedContact Mount in Use10 N (2.25 lb)10 N (2.25 lb)10 N (2.25 lb) Growth of Mold Yes——Visual Examination Yes——Combustibility10 sec burning——ACTION PIN, TE Connectivity, TE Connectivity (logo) and Every Connection Counts are trademarks. All other logos, products and/or company names referred to herein might be trademarks of their respective owners.The information given herein, including drawings, illustrations and schematics which are intended for illustration purposes only, is believed to be reliable. However, TEConnectivity makes no warranties as to its accuracy or completeness and disclaims any liability in connection with its use. TE Connectivity‘s obligations shall only be as set forth in TE Connectivity‘s Standard T erms and Conditions of Sale for this product and in no case will TE Connectivity be liable for any incidental, indirect or consequential damages arising out of the sale, resale, use or misuse of the product. Users of TE Connectivity products should make their own evaluation to determine the suitability of each such product for the specific application.*as defined /leadfree© 2018 TE Connectivity Ltd. family of companies All Rights Reserved.1-1773725-1 04/18 DNDTE TECHNICAL SUPPORT CENTERUSA +1 (800) 522-6752Canada +1 (905) 475-6222Mexico+52 (0) 55-1106-0800Latin/S. America +54 (0) 11-4733-2200Germany +49 (0) 6251-133-1999UK +44 (0) 800-267666France+33 (0) 1-3420-8686Netherlands +31 (0) 73-6246-999China+86 (0) 400-820-6015Part numbers in this brochure are RoHS Compliant*, unless marked otherwise.。
一种高速背板用高密度数据传输连接器设计
一种高速背板用高密度数据传输连接器设计邵建兴;张杰【摘要】从理论设计、仿真分析和产品测试3个方面对一种高速背板用高密度数据传输连接器进行了分析设计。
通过对差分信号的特征阻抗、串扰、插入损耗等参数的分析，对连接器的插针接触件、PCB传输线和介质体进行了设计。
采用电磁场与电路联合仿真的分析方法，从时域、频域和数据域3个方面对所设计的连接器进行了仿真分析。
最后，通过对连接器的信号完整性测试结果表明：连接器的高速性能满足12.5 Gbit/s的高速背板传输性能要求。
%A high density connector for high-speed backplane is designed and analyzed from theory,simulation and test. By analyzing the characteristic impedance,crosstalk and insert loss,the insert contact,PCB transmission line, substrate of the connector are designed. The connector simulation is performed from time-domain,frequency-domain and data-domain by using electromagnetic field and circuit combined simulation method. Finally,the signal integrity of the connector is tested,which shows that the connector can be used in 12.5 Gbit/s high speed backplane systems.【期刊名称】《电子器件》【年(卷),期】2016(039)002【总页数】7页(P291-297)【关键词】高密度;数据传输;连接器;高速背板;信号完整性【作者】邵建兴;张杰【作者单位】上海航天科工电器研究院有限公司，上海200331;上海航天科工电器研究院有限公司，上海200331【正文语种】中文【中图分类】TN602随着通信系统中电子设备越来越多，且设备越来越复杂，数据总线、时钟及链路速度均在不断攀升，以满足高速数据互连传输的需要。
TE Connectivity Universal MATE-N-LOK 产品规格说明书
110-2023, Rev. 3© 2014 Tyco Electronics Corporation,a TE Connectivity Ltd. company.Catalog and product specification according to IEC 61810-1 and to be used only together with the ‘Definitions’ section.Catalog and product data is subject to the terms of the disclaimer and all chapters of the ‘Definitions’ section, available at /definitionsCatalog product data, ‘Definitions’ section, application notes and all specifications aresubject to change.n2 pole 8A, 2 form C (CO) contactsn Polarized bistable version with 1 or 2 coils n 5kV/10mm coil-contactnReinforced insulationTypical applicationsBattery powered equipment or applications with “memory function”.ApprovalsVDE Cert. No. 40007571, UL E214025, cCSAus 1142018 CQC 180********Technical data of approved types on request.Contact DataContact arrangement 2 form C (CO)Rated voltage 250VAC Max. switching voltage 400VAC Rated current 8A, UL: 10A Limiting continuous current 8A, UL: 10A Limiting making current, max. 4s, duty factor 10% 15A Breaking capacity max. 2000VA Contact material AgNi 90/10Frequency of operation, with/without load 900/72000h -1Operate/Reset time max. 10/5ms Bounce time max., form A/form B 4/9msContact ratings Type Contact Load Cycles IEC 61810RT444 A (NO) 8A, 250VAC resistive, 85°C 100x103 RT424 C (CO) 8A, 250VAC resistive, 85°C 30x103UL 61810-1 (former UL 508)RT424 A/B (NO/NC) 10A, 250VAC, general purpose, 85°C 20x103 RT424 A/B (NO/NC) 1/2hp, 240VAC ,85°C 1x103 RT424 A/B (NO/NC) Pilot duty, B300, R300, 85°C 6x103 RT4/E A/B (NO/NC) 10A/24VDC, general purpose, 85°C 5x10³EN60947-5-1RT424 A/B (NO/NC) AC-15, 250VAC, 3A 6.050Mechanical endurance >2x106 operationsPower PCB Relay RT2 bistableZ b210-2023, Rev. 3© 2014 Tyco Electronics Corporation,a TE Connectivity Ltd. company.Catalog and product specification accordingto IEC 61810-1 and to be used only togetherwith the ‘Definitions’ section.Catalog and product data is subject to theterms of the disclaimer and all chapters ofthe ‘Definitions’ section, available at/definitionsCatalog product data, ‘Definitions’ section,application notes and all specifications aresubject to change.Product code Version Contacts ContactmaterialCoil version Coil Part numberRT424A058A, 2 form C (CO)AgNi 90/10Bistable 1coil5VDC4-1393243-4RT424A12pinning 5mm,contacts12VDC4-1393243-6RT424F05flux proof Bistable 2 coils5VDC5-1393243-2RT424F1212VDC5-1393243-4RT424F2424VDC5-1393243-6RT424F4848VDC5-1393243-7 RTE24F248A 24VDC8-1415541-7 RTE24F06pinning 5mm6VDC1-1415020-1 RTE24F12wash tight12VDC7-1415072-1Power PCB Relay RT2 bistable (Continued)Other Data (continued)Terminal type PCB-THT, plug-in1)Weight 13gResistance to soldering heat THTIEC 60068-2-20 270°C/10sPackaging/unit tube/20 pcs., box/500 pcs.1) socket available for 1 coil version only, see Accessories.AccessoriesFor 1 coil version,details see datasheet A ccessories Industrial Power Relay RTNOTE: indicated contact ratings and electrical endurance data for directwiring of relays (according IEC 61810-1); for relays mounted on socketsderatings may apply.Insulation DataInitial dielectric strengthbetween open contacts 1000Vrmsbetween contact and coil 5000Vrmsbetween adjacent contacts 2500VrmsClearance/creepagebetween contact and coil ≥10/10mmbetween adjacent contacts ≥ 3/4mmMaterial group of insulation parts IIIaTracking index of relay base PTI 250VOther DataMaterial compliance: EU RoHS/ELV, China RoHS, REACH, Halogen contentrefer to the Product Compliance Support Center at/customersupport/rohssupportcenterAmbient temperaturebistable 1 coil -10 to 85°Cbistable 2 coils -40 to 85°CCategory of environmental protectionIEC 61810 RTII - flux proofRTIII - wash tigthVibration/shock resistance (functional),opening B contact 3/5gopening closed A contact 6/15gShock resistance (destructive) 100gPCB layout / terminal assignmentBottom view on solder pins8 A,2 form C (CO) contactsm m to 2.54 m m cana)Dimensionsa) Indicated contactposition while or after coilenergization with resetvoltage.b) for 2 coil version onlyProduct code structure Typical product code RT 4 2 4 F24TypeRT Power PCB Relay RT2 bistableVersion4 8A, pinning 5mm, flux proof E8A, pinning 5mm, wash tightContact configuration2 2 form C (CO) contactsContact material4 AgNi 90/10CoilCoil code: please refer to coil versions tableThis list represents the most common types and does not show all variants covered by this datasheet. Other types on requestOther types on request.。
