Using the Brittle Cracking Material Model in Abaqus/ExplicitThe brittle cracking constitutive model in Abaqus/Explicit is applicable to all brittle materials, not just concrete. This model can be expected to yield more accurate and realistic results than the tensile failure criterion (*TENSILE FAILURE), which is also applicable to brittle materials. In addition, the brittle cracking model allows more detailed modeling of post-cracking response than the simple tensile failure model.Capability summaryThe brittle cracking model in Abaqus/Explicit:•Is applicable to brittle materials whose compressive and pre-cracking tensile behavior can be represented through linear elasticity•Does not track individual macro-cracks, but captures the effect of cracking and damage on stresses and stiffness through constitutive calculations•Accounts for crack-induced anisotropy•Is conceptually compatible with the ideas of the Abaqus progressive damage framework (i.e.“damage initiation” and “damage evolution”), even though the user interface is different •Can be viewed as complementary to the ductile damage capability in Abaqus/Explicit•Accomplishes the same end-result effect as the Abaqus/Standard XFEM approach (i.e. through jumps in displacements) though the two modeling approaches are quite differentCrack initiation• A simple Rankine criterion used:•Crack initiates when the maximum principal stress exceeds the material tensile strength •Multiple cracks (as many as the number of direct stress components) can initiate at a point, in orthogonal directions•The crack orientations are governed by the principal stress directions •Post-cracking tensile (Mode I) and shear (Mode II) behavior can be independently controlled •Conceptually similar to “damage initiation & evolution” (i.e. material stiffness degradation is specified with a post-initiation “damage evolution” behavior)Post-cracking behavior•Mode I (i.e. normal, tensile) response specified by maximum strain, maximum displacement or Mode I fracture energy•Strain-based definition can introduce mesh sensitivity (due to the same arguments as for ductile damage)•Not recommended except for reinforced concrete•Displacement- or energy-based specification of post-cracking Mode I response is recommended (one can be derived from the other )•Element characteristic length may be used to convert strain-type data to displacement (or energy-based) definition (again, this is similar to ductile damage modeling)•Mode II (shear) response is specified by providing shear stiffness as a function of opening strain across the crack•Direct tabular entries (fraction of initial stiffness vs. crack opening strain) or analytical form (power law) can be usedElement deletion option•Elements may be removed from the model once the failure strain (or displacement) is reached •Allows specification of number of cracks at a material point that should fail before complete failure of the material occurs•Useful in overcoming possible excessive element distortion issues when the material point fails in tension•Exercise caution when using element removal option, since it precludes availability of the element to resist compression and hence may not be realistic for all brittle damage applications! Required input parametersFigure 1 shows a schematic of the material parameters and properties that are applicable when using the brittle cracking model:Figure 1: Required input parameters for the Abaqus/Explicit brittle cracking modelExample 1 - Crack propagation in a plate with a holeThis is the model in Abaqus Benchmark problem 1.19.2 (Release 6.9); there, it is solved in Abaqus/Standard using XFEM. The half-symmetric model is shown in Figure 2. Equal and opposite displacements are prescribed at the two ends of the plate.Fracture parameters used:-Max principal stress: 22.0E6 Pa-Fracture toughness (Modes I & II): 2.87E3 N/m (BK-type mode-dependence is used for damage evolution in the XFEM version of the model)-Linear shear stiffness degradation over a crack opening strain of 0.001 used in the brittle cracking model, along with element deletion (using “brittle failure” option)Figure 2: Half-symmetry model of a plate with a holeFigure 3 presents the predicted load-displacement histories from both the brittle cracking and XFEM approaches – a good agreement is observed.Figure 3: Comparison of load-displacement responses from brittle cracking and XFEM approaches The following points should be noted:•CPE4R elements with enhanced hourglass control were used in the Explicit analysis (XFEM model used fully integrated element)-Default hourglass control predicts lower peak load, with a somewhat larger deviation from the XFEM result•No significant sensitivity to load amplitude type (smooth step vs. ramp vs. constant velocity) observed in the quasi-static, Explicit result (all results not shown here)•Lack of crack orientation output and crack status output to the output database (ODB) prevents a direct comparison of brittle cracking result with the analytical applied stress vs. variation of crack length•Rough comparison using element status can still be made (not presented here)Example 2 – Brazilian Fracture TestIn the so-called Brazilian test for brittle fracture, a cylinder is compressed between two rigid platens ( Figure 4).Figure 4: Cylinder compressed between two rigid platensThe peak load is given by the theoretical expression:F max= π R f toWhere R = radius of the cylinder and f t0 = tensile strength of the material.Fracture parameters & dimensions used-Radius of cylinder: 150 mm-Max principal stress: 2.0 MPa-Fracture toughness: 0.055 N/mm-Linear shear stiffness degradation over a crack opening strain of ~0.008 was used in the brittle cracking model, along with element deletion (with the “brittle failure” option).Note that the actual damage evolution data and specification of element removal are not strictly necessary here, since we are mainly interested in predicting the peak load and comparing with the theoretical value. The use of element deletion is also optional, except to visualize the blunt cracks resulting from deleted elements (an approximate workaround for not being able to visualize the actual crack orientations and crack status in Abaqus/Viewer).Figure 5: Comparison of predicted peak load with theoretical valueFigure 5 shows that the brittle cracking model predicts a peak load that is consistent with the theoretically computed value. Note that enhanced hourglass control was used in this simulation.Limitations•Crack visualization is not possible the with the brittle cracking model, except through element deletion which, if used, can be misleading•Compressive and pre-cracking tensile behavior is limited to linear elasticity•No damage is possible in compression. Note however, that there are other models in Abaqus/Explicit, such as concrete damaged plasticity, that can represent brittle damage inelasto-plastic materials。
