摄影测量后方交会法求解外方位元素

摄影测量后方交会求外方位元素 09地信一班 肖明梅 解题思路：定义要用到的变量并初始化，定义一个函数用于求解旋转矩阵R，系数矩阵A,近似坐标矩阵JSZB,常数矩阵L;矩阵的转置，逆，矩阵相乘，相减，求外方位元素的近似值初值以及结果输出都定义为相应的函数。最后定义一个用于循环求解的函数（程序中xhqiujie()）,在该函数中调用之前定义的函数，求出外方位元素近似值初值，改正数Dv[6,1],误差V[8,1]，用do…while语句进行循环，使精度达到20μm,限差低于20μm，然后调用结果输出函数用于输出达到要求的结果。在主函数中创建对象的实例，引用该实例的方法即xhqiujie()函数，就可以求出外方位元素。 代码： using System; using System.Collections.Generic; using System.Linq; using System.Text; namespace 摄影测量后方交会求外方位元素 { class Program { double ψ, ω, κ, Xs, Ys, Zs, m, f, Sx = 0, Sy = 0; double n = 206265 / 3600;//*角元素的单位从m到度的转换系数*// double[,] zuobiao = {{ -86.15, -53.40, -14.78, 10.46 }, {-68.99, 82.21,-76.63,64.43},{36589.41,37631.08,39100.97,40426.54},{ 25273.32,31324.51,24934.98,30319.81 },{ 2195.17,728.69,2386.50,757.31 }}; double[] a = new double[3];//*存储a1,a2.a3*// double[] b = new double[3];//*存储b1,b2,b3*// double[] c = new double[3];//*存储c1,c2,c3*// double[] XX = new double[4]; double[] YY = new double[4]; double[] ZZ = new double[4]; double[,] L = new double[8, 1]; double[,] JSZB = new double[2, 4];//*像点近似坐标*// double[,] A = new double[8, 6];//*系数阵*// double[,] AT = new double[6, 8]; double[,] AB = new double[6, 6]; double[,] AN = new double[6, 6]; double[,] AL = new double[6, 1]; double[,] Dv = new double[6, 1]; double[,] AX = new double[8, 1];//*系数阵与改正数矩阵的乘积*// double[,] V = new double[8, 1];//*中误差矩阵*// private void Qchuzhi() { for (int i = 0; i < 4; i++) { Sx += zuobiao[2, i]; } for (int i = 0; i < 4; i++) { Sy += zuobiao[3, i]; } for (int i = 0; i < 4; i++) { zuobiao[0, i] = zuobiao[0, i] / 1000; zuobiao[1, i] = zuobiao[1, i] / 1000; } //*求外方位元素初始值*// ψ = ω = κ = 0; m = 50000; f = 0.15324; Xs = Sx / 4; Ys = Sy / 4; Zs = m * f; } //*求旋转矩阵R,像点坐标近似值，常数项矩阵L,系数矩阵A*// private void R() { //旋转矩阵R a[0] = Math.Cos(ψ) * Math.Cos(κ) - Math.Sin(ψ) * Math.Sin(ω) * Math.Sin(κ); a[1] = -Math.Cos(ψ) * Math.Sin(κ) - Math.Sin(ψ) * Math.Sin(ω) * Math.Cos(κ); a[2] = -Math.Sin(ψ) * Math.Cos(ω); b[0] = Math.Cos(ω) * Math.Sin(κ); b[1] = Math.Cos(ω) * Math.Cos(κ); b[2] = -Math.Sin(ω); c[0] = Math.Sin(ψ) * Math.Cos(κ) + Math.Cos(ψ) * Math.Sin(ω) * Math.Sin(κ); c[1] = -Math.Sin(ψ) * Math.Sin(κ) + Math.Cos(ψ) * Math.Sin(ω) * Math.Cos(κ); c[2] = Math.Cos(ψ) * Math.Cos(ω); for (int i = 0; i < 4; i++) { XX[i] = a[0] * (zuobiao[2, i] - Xs) + b[0] * (zuobiao[3, i] - Ys) + c[0] * (zuobiao[4, i] - Zs); YY[i] = a[1] * (zuobiao[2, i] - Xs) + b[1] * (zuobiao[3, i] - Ys) + c[1] * (zuobiao[4, i] - Zs); ZZ[i] = a[2] * (zuobiao[2, i] - Xs) + b[2] * (zuobiao[3, i] - Ys) + c[2] * (zuobiao[4, i] - Zs); //由共线条件方程式求得xo,yo的近似值 JSZB[0, i] = -f * (XX[i]) / (ZZ[i]); JSZB[1, i] = -f * (YY[i]) / (ZZ[i]); //常数项矩阵 L[i * 2, 0] = zuobiao[0, i] - JSZB[0, i]; L[i * 2 + 1, 0] = zuobiao[1, i] - JSZB[1, i]; } for (int i = 0; i < 4; i++) { A[2 * i, 0] = (a[0] * f + a[2] * zuobiao[0, i]) / ZZ[i]; A[2 * i, 1] = (b[0] * f + b[2] * zuobiao[0, i]) / ZZ[i]; A[2 * i, 2] = (c[0] * f + c[2] * zuobiao[0, i]) / ZZ[i]; A[2 * i, 3] = zuobiao[1, i] * Math.Sin(ω) - ((zuobiao[0, i] * (zuobiao[0, i] * Math.Cos(κ) - zuobiao[1, i] * Math.Sin(κ)) / f + f * Math.Cos(κ))) * Math.Cos(ω); A[2 * i, 4] = -f * Math.Sin(κ) - zuobiao[0, i] * (zuobiao[0, i] * Math.Sin(κ) + zuobiao[1, i] * Math.Cos(κ)) / f; A[2 * i, 5] = zuobiao[1, i]; A[2 * i + 1, 0] = (a[1] * f + a[2] * zuobiao[1, i]) / ZZ[i]; A[2 * i + 1, 1] = (b[1] * f + b[2] * zuobiao[1, i]) / ZZ[i]; A[2 * i + 1, 2] = (c[1] * f + c[2] * zuobiao[1, i]) / ZZ[i]; A[2 * i + 1, 3] = -zuobiao[0, i] * Math.Sin(ω) - (zuobiao[1, i] * (zuobiao[0, i] * Math.Cos(κ) - zuobiao[1, i] * Math.Sin(κ)) / f - f * Math.Sin(κ)) * Math.Cos(ω); A[2 * i + 1, 4] = -f * Math.Cos(κ) - zuobiao[1, i] * (zuobiao[0, i] * Math.Sin(κ) + zuobiao[1, i] * Math.Cos(κ)) / f; A[2 * i + 1, 5] = -zuobiao[0, i]; } } //*定义一个函数用来求矩阵的转置*// private void T(double[,] A, double[,] B, int a, int b) { for (int i = 0; i < b; i++) { for (int j = 0; j < a; j++) { B[i, j] = A[j, i]; } } } //*定义一个函数用来求矩阵的乘积*// private void Multiply(double[,] A, double[,] B, double[,] C, int a, int b, int c) { for (int i = 0; i < a; i++) { for (int j = 0; j < c; j++) { C[i, j] = 0; for (int m = 0; m < b; m++) { C[i, j] = A[i, m] * B[m, j] + C[i, j]; } } } } private void substract(double[,] A, double[,] B, double[,] C, int a, int b) { for(int i=0;i
