第一章 HP34401A数字多用表HP34401A 数字多用表是具有 6 1/2数字显示、高性能的数字式万用表。
它将台式仪器的整体性能融为一体,为我们进行电量测量提供多种不同的测试方案，使我们获得满意的测量结果.构制高精度的测量●测量直流电压、直流电流、电阻：设置6位的数字分辨率（使用6位数字慢模式可进一步减小测量燥声）。
对于100mA， 1V,和10V量程，设置输入阻抗大于10 GΩ,可获得最好的直流测量精度.使用4线电阻测量可获得最高的电阻测量精度。
使用数学归零测量2线导线电阻,在直流电压测量时，并可消除互连偏置的影响。
●测量交流电压、交流：设置6位的数字分辨率选择低通交流滤波器（1 Hz to 300 kHz)●测量频率和周期：设置6位的数字分辨率方便的台式仪器特性●清晰的真空荧光显示器●内设数学运算功能●连续测试及二极管测量功能●无需手动、读数保留特性●可携带、无台架的厚实外壳灵活的系统特性●HP—IB (IEEE—488) 接口标准配制●RS—323 接口标准配制●标准程控语言包括: SCPI, HP34578A， and FLUKE 8840.●读取速率高达1000 个/每秒●存储量可达512个读数●极限测试，并有 pass/fail 信号第一节技术指标一．万用表的技术指标说明在这一节中，我们将介绍技术指标中的部分术语,以便对数字多用表的技术指标能更好的理解。
HP34401A数字多用表
HP34401A数字多⽤表第⼀章 HP34401A数字多⽤表HP34401A 数字多⽤表是具有6 1/2数字显⽰、⾼性能的数字式万⽤表。
它将台式仪器的整体性能融为⼀体，为我们进⾏电量测量提供多种不同的测试⽅案，使我们获得满意的测量结果。
构制⾼精度的测量●测量直流电压、直流电流、电阻：设置6位的数字分辨率（使⽤6位数字慢模式可进⼀步减⼩测量燥声）。
对于100mA, 1V,和10V量程，设置输⼊阻抗⼤于10 GΩ，可获得最好的直流测量精度。
使⽤4线电阻测量可获得最⾼的电阻测量精度。
使⽤数学归零测量2线导线电阻，在直流电压测量时，并可消除互连偏置的影响。
●测量交流电压、交流:设置6位的数字分辨率选择低通交流滤波器 (1 Hz to 300 kHz)●测量频率和周期:设置6位的数字分辨率⽅便的台式仪器特性●清晰的真空荧光显⽰器●内设数学运算功能●连续测试及⼆极管测量功能●⽆需⼿动、读数保留特性●可携带、⽆台架的厚实外壳灵活的系统特性●HP-IB (IEEE-488) 接⼝标准配制●RS-323 接⼝标准配制●标准程控语⾔包括: SCPI, HP34578A, and FLUKE 8840.●读取速率⾼达1000 个/每秒●存储量可达512个读数●极限测试，并有 pass/fail 信号第⼀节技术指标⼀．万⽤表的技术指标说明在这⼀节中，我们将介绍技术指标中的部分术语，以便对数字多⽤表的技术指标能更好的理解。
位数及超量程位数指标是数字多⽤表最基本的、⽽有时也是最容易混淆的特性。
位数等于数字多⽤表可以测量或显⽰出“9”的最⼤数量，这表⽰完整的位数数量。
但是，⼤多数多⽤表可以测量超量程的量值，即可再加上部分或“1/2”个位数。
例如，HP 34401A 设置在10V量程范围时，测量到 9.99999 VDC，这表⽰分辨率为6个完整的数位。
但是，该表也可以测量超过10V量程的范围，最⼤可以测量到12.00000 VDC. 这就是所谓超过20%的测量范围能⼒和6 1/2 位数的测量。
