法兰尼净水器新品FLN-100G-08：“非常6+1”更有实力
520，在这特殊的日子，法兰尼给您一个特殊的惊喜——FLN-100G-08温情上
市，论创新、论技术、论体验等，绝对无可挑剔！依托顶尖技术支撑，专注实力
打造，用实验数据说话，旨在提升用户体验。
法兰尼超强阻垢大流量双出水净水机FLN-100G-08，外观独特，优点众多，
实用性强……绝对的实力派，请看小编为您一一道来！
一、外观参数
1.外观展示
FLN-100G-08外观别具一格，打破传统，给人眼前一亮之感。
2.产品参数
1.机器运作的基本所在，正确使用一款产品，从了解它的具体参数开始。
产品型号：FLN-100G-08
产品尺寸：335×185×415mm
额定电压：AC 220V 50Hz
额定功率：35W
额定总净水量：2.5m³
净水流量：0.26L/min
进水压力：0.1-0.35Mpa
工作压力：0.4-0.6Mpa
执行标准：QB/T4144-2010
注意事项：定期清洗和更换滤芯
适用温度：4℃-38℃
适用水源：市政自来水，符合GB5749-2006指标
卫生许可批准文号：粤卫水字【2015】第S2102号
出水水质：符合《生活饮用水水质处理器卫生安全与功能评价规范-反渗透
处理装置》（2001）的要求
二、技术透析
1.阻垢炭膜技术
法兰尼新兴的阻垢炭膜技术，即使用的是一种具有阻垢功效的水处理改性炭
膜，针对水垢形成的基本原理，阻垢炭膜可有效过滤水中胶体、细菌，吸附有机
物等水垢生长协助因子，同时能够对活性炭进行改性，使其具有催化功效，增高
水垢形成的活性能，长效抑制水垢形成，是一种世界领先的技术。
法兰尼阻垢专利技术，拥有6大特效——①高效阻垢；②缓释持久；③安全
可靠；④使用便捷；⑤经济实用；⑥绿色环保。
2.RO反渗透技术
法兰尼RO反渗透技术，采用高精度纯物理过滤，在自然渗透中，水是从低
浓度向高浓度液扩散，最终达到浓度平衡，反渗透是利用外力（克服渗透压）使
水由高浓度向低浓度流动，一般通过高压水泵来提供外力。
过滤精度高：法国航天反渗透技术，过滤精度达到0.0001微米，能过滤水
中的有害物质。
脱盐率高：反渗透脱盐率为95%-98%，过滤出的净水中含有对人体有益的微
量元素。
三、8大特点合集
1.非常“6+1”，多级高精度过滤。
FLN-100G-08，采用“6+1”级高精度过滤，分别为“外置5微米PP棉+精密
5微米PP棉+致密1微米PP棉+烧结炭滤芯+阻垢炭滤芯+100G RO膜滤芯+后置
载银活性炭（MTF9）”，高效去除杂质，饮水绝对无忧！
2.首次并联水路设计，强效净化。
FLN-100G-08本机采用双纤维PP棉芯+双炭棒滤芯组合，为法兰尼首款并联
水路设计的净水产品，制水量大，过滤效果强。
并联水路滤芯配置（从左往右）
并联水路设计，滤芯从左至右的顺序为：致密1微米PP棉滤芯+烧结炭滤芯、
阻垢炭滤芯+精密5微米PP棉。
双纤维PP棉滤芯
双纤维PP棉芯即：精密5μmPP棉+致密1μmPP棉，极大提升预处理纳污
量，解决原水浊度高，避免滤芯易污堵、换芯过于频繁的问题。
双炭棒滤芯
双炭棒滤芯即：烧结炭滤芯+阻垢炭滤芯，均采用优质椰壳活性炭经过特殊
工艺加工而成，兼具流量大、过滤精度高、高效吸附等诸多优点，外加法兰尼专
利阻垢炭技术，强效去垢更彻底。
3.大流量RO膜，100G更比150G强！
FLN-100G-08采用大泵大膜，制水快，大膜配小罐（3.2G），提升造水速度。
既能保证每日用水量，又可更新存水，使水质保持新鲜。另外配置的100G RO
膜，造水速度可提升50%，在达到理想进水水量、水压等条件下，最高流量甚至
可达150G的产水标准。
4.阻垢炭专利技术，超强阻垢！
法兰尼专利阻垢炭技术，能够很好的去除水中胶体成分，又能极大提升硬度
离子的能量值（活性），达到强效阻垢的作用。
5.自动排污，1:1超低废水比。
FLN-100G-08自带全自动排污功能，结合法兰尼长达一年的实验数据分析，
实现1:1超低废水排放。
6.滤芯智能提醒，饮水更安全。
整机拥有滤芯寿命提示、智能滤芯更换提醒，实时保障饮水安全，通过对滤
芯使用实时监控，到期提醒用户及时更换滤芯，保障用水安全。
7.双出水设计，一机两用。
FLN-100G-08采用双出水设计，双重水质满足您饮用水的各种需求。生活水
——适合洗菜、做饭、煲汤。纯净水——去除水中杂质、重金属、水垢等，健康
直饮。
8.全食品级选材。
FLN-100G-08所有涉水部件均采用食品级PP材质，可远离塑化剂及重金属污
染，消费者可放心饮用，杜绝一切污染源！
以上是FLN-100G-08的相关介绍，有没有被吸引到？FLN-100G-08：“非常6+1”
•有实力，无所畏惧！现FLN-100G-08接受首批预定中，数量有限，先到先得，
赶紧行动起来吧！预订渠道：
