Analysis of Transient Resistance Characteristics for Resistive Type High Temperature Superconducting Fault Current Limiter
2018 年 5 月 第 33 卷第 9 期
电工技术学报
TRANSACTIONS OF CHINA ELECTROTECHNICAL SOCIETY
DOI：10.19595/j.cnki.1000-6753.tces.170310
Vol.33 No. 9 May 2018
电阻型高温超导限流器暂态电阻特性分析
Gong Jun1 Zhu Jiahui2 Fang Jin1 Chen Panpan2 Qiu Ming2 （1. School of Electrical Engineering Beijing Jiaotong University Beijing 100044 China
2. China Electric Power Research Institute Beijing 100192 China）
Abstract Providing an effective guarantee for power transmission quality and stability in power system, high temperature superconducting fault current limiter (SFCL) is an effective device to solve the problem of short circuit fault in power girds, due to the superior properties of self-triggered, high current limiting ability and low normal operation loss. In this paper, a mathematical model for the dependence of transient resistance of resistive type superconducting current limiting unit (SCLU) on its transport current and ambient temperature is built, by analyzing the electrical and thermal properties of YBCO superconductor. In order to investigate the law of the current limiting ability of SFCL with suffering fault current in the power grid, PSCAD/EMTDC and Matlab have been combined to simulate this behavior. PSCAD/EMTDC is used for line modeling and short circuit fault operation simulation and Matlab is used to build the superconducting equivalent mathematic model. According to the analysis of numerical transient simulation, current-limiting ratio in high temperature SFCL, resistance variation characteristic in SCLU and temperature variation characteristic in SCLU are obtained, under the condition of single-phase shortcircuit fault and three-phase short-circuit fault , respectively. Moreover, for verifying the law of resistance variation, the superconducting tape is subjected to the impact current test. Calculation and analysis results
