电磁换向阀SV10-P22A英文.pdf
电磁阀换向阀DNDYS英文.pdf
2-position, 6-way, soft shift, solenoid-operated directional spool valve Capacity:5 gpm (20 L/min.)Functional Group:Products : Cartridges : Directional : 6 Way : 2 Position, 6 Way Spool, Soft Shift, Solenoid OperatedModel: DNDYSProduct DescriptionThis solenoid-operated 6-way, 2-position cartridge is a direct-acting, balanced spool valve with a soft shift feature. The soft shift feature greatly reduces system shock due to valve actuation. The typical use for this valve is to select between two separate circuits. The de-energized condition connects P and T to the first circuit and when energized connects P and T to the second circuit.Technical FeaturesThe soft shift cartridge is interchangeable with the standard cartridge, however, the performance limits are lower. This valve is direct actuated and requires no minimum hydraulic pressure for operation.The soft shift feature can greatly reduce shock due to valve actuation but should not be counted upon in applications where timing is critical. If you need accurate ramping or timing control, consider Sun's electro-proportional valves. This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.The soft shift feature results in significant increase in response time over Sun's standard solenoid. Response time is dependant on flow, pressure, coil voltage, oil viscosity and ambient temperature. Typical response time ranges from 150 ms to 300 ms. The solenoid's unique magnetic design results in a high efficiency solenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.For consistent soft shift performance, port 1 should be at a positive pressure. Coils are interchangeable with other Sun Series 1 solenoid products and can be mounted on the tube in either direction.This valve includes a push-type manual override control. Other manual control options such as T or D, cannot be ordered with the soft shift control but can be installed easily in the field. See Twist/Lock Manual Override link above for details. Please note: Manual override functionality is not compatible with weatherized coils. Coil connector options offer ratings up to IP69K. See individual coil product pages for details. Additional weatherized coils and kits are available for more complete environmental protection.The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service. Incorporates the Sun floating style construction to minimize the possibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.Special NotesPlease verify cartridge clearance when choosing a Sun manifold. Different valve controls and coils require different clearances.DownloadDNDY-SXN-*** $184.40Recommended List PriceSpool ConfigurationSeal MaterialCoilStandard OptionsX-+0.00Standard OptionsN Buna-N +0.00VViton+6.00*** See Coil Options Below Standard Coil Options (View All )DIN 43650 3 pin (Hirschman) SAE J858AAMP Junior TimerTwin LeadMetri-PackDeutsch DT04-2P*** no coil528 SAE J858A, 28 VDC, +25.30 814 Metri-Pack, 14 VDC, +27.70211DIN 43650 3 pin(Hirschman), 115 VAC, +36.40 536SAE J858A, 36 VDC, +22.50 814N Metri-Pack, 14 VDC, notransient voltagesuppression (TVS) diodes+27.20212DIN 43650 3 pin(Hirschman), 12 VDC,+20.40 612AMP Junior Timer, 12 VDC, +19.90 824Metri-Pack, 24 VDC, +24.90212N DIN 43650 3 pin(Hirschman), 12 VDC, notransient voltagesuppression (TVS) diodes +19.90 612N AMP Junior Timer, 12 VDC,no transient voltagesuppression (TVS) diodes+19.40 828Metri-Pack, 28 VDC, +27.70214DIN 43650 3 pin(Hirschman), 14 VDC,+23.20 614AMP Junior Timer, 14 VDC, +22.60 836Metri-Pack, 36 VDC, +27.70214N DIN 43650 3 pin(Hirschman), 14 VDC, notransient voltagesuppression (TVS) diodes+22.70 624AMP Junior Timer, 24 VDC, +19.90 848Metri-Pack, 48 VDC, +27.70223DIN 43650 3 pin(Hirschman), 230 VAC, +36.40 624N AMP Junior Timer, 24 VDC,no transient voltagesuppression (TVS) diodes+19.40 912Deutsch DT04-2P, 12 VDC, +26.20224DIN 43650 3 pin(Hirschman), 24 VDC, +20.40 628AMP Junior Timer, 28 VDC, +22.60 912N Deutsch DT04-2P, 12 VDC,no transient voltagesuppression (TVS) diodes+25.70224N DIN 43650 3 pin(Hirschman), 24 VDC, notransient voltagesuppression (TVS) diodes+19.90 636AMP Junior Timer, 36 VDC, +22.60 914Deutsch DT04-2P, 14 VDC, +29.10228DIN 43650 3 pin(Hirschman), 28 VDC, +23.20 712Twin Lead, 12 VDC, +22.50 914N Deutsch DT04-2P, 14 VDC,no transient voltagesuppression (TVS) diodes+28.60236DIN 43650 3 pin(Hirschman), 36 VDC, +23.20 712N Twin Lead, 12 VDC, notransient voltagesuppression (TVS) diodes+22.00 924Deutsch DT04-2P, 24 VDC, +26.20248DIN 43650 3 pin(Hirschman), 48 VDC, +23.20 724Twin Lead, 24 VDC, +22.50 924N Deutsch DT04-2P, 24 VDC,no transient voltagesuppression (TVS) diodes+25.70297DIN 43650 3 pin(Hirschman), 24 VAC, +48.80 724N Twin Lead, 24 VDC, notransient voltagesuppression (TVS) diodes+22.00 928Deutsch DT04-2P, 28 VDC, +29.10298DIN 43650 3 pin(Hirschman), 220 VDC,+48.80 728Twin Lead, 28 VDC, +25.30 936Deutsch DT04-2P, 36 VDC, +29.10299DIN 43650 3 pin(Hirschman), 127 VDC,+48.80 736Twin Lead, 36 VDC, +25.30 948Deutsch DT04-2P, 48 VDC, +29.10514SAE J858A, 14 VDC, +25.30 812Metri-Pack, 12 VDC, +24.90 HN24AA Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead,ATEX Certification Ex mb IICT3 Gb.+852.00524SAE J858A, 24 VDC, +22.50 812N Metri-Pack, 12 VDC, notransient voltagesuppression (TVS) diodes +24.40 HN24AB Hazardous environmentduty, 1/2 inch MPTmechanical conduit, 24VDC, 10 feet twin lead, CSACertification+852.00Embedded Coil Options (Click Here)2E12V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,12 VDC, 0-10V +172.90 4E12V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 12 VDC, 0-10V+161.10 4E24V Deutsch DT04-6P,programmable via IR linkcoil/power saver, 24 VDC, 0-10V+161.102E24V DIN 43650 3 pin(Hirschman), programmablevia IR link coil/power saver,24 VDC, 0-10V+172.90 Additional Options (Click Here)Additional Coils512SAE J858A, 12 VDC, +22.50 71219Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length, 12 VDC, +33.40 72419Twin Lead, to DelphiWeather-Pack Connector, 9inch lead length 24 VDC,+33.40548SAE J858A, 48 VDC, +22.50 71299Twin Lead, to Deutschconnector, 9 inch leadlength, +34.70 72499Twin Lead, to Deutschconnector, 9 inch leadlength,+34.70648AMP Junior Timer, 48 VDC, +22.60 714Twin Lead, 14 VDC, +25.30 748Twin Lead, 48 VDC, +25.30 Stainless options not available for this modelRelated ModelsDNDYCopyright © 2002-2013 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。
电磁换向阀SV08-21中文.pdf
➥◥ げण
USASI: ISO:
Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ Ⴠ 欬着兎皽釭⚗扭兼ぴ⇫ᇭ 梏矒兞䫻德⮓䚕᧨功䞷₣苀秼䆞ᇭ ♾折兎皽䟄☚✛兗簖ᇭ 舊磧䄎㆞嫣材兢㨓ᇭ 㙡ↅ䟄☚♾疸㗱ᇭ 㠃⇢㲰枇⨚兎皽幍帰ᇭ ㄣ㊴㓚虱折ↅᇭ ♾折,3.腋㻃(⨚兎皽ᇭ ぴ₩抩䞷梏ⷣᇭ 兢㨓侶①ᇭ
ᕓ㘩ప᧤⅔㖖㙡ↅ᧥
Ƙ ࡵ Ɨ ࣥ࢟ —— Ɨ ࡵ Ƙ ᄰ࢟ - - - 40°C ဟ 32 cSt/150 ssu ࡼᎉጘ
➥ᕓ
҈ࢷ߇喝EDU SVL ≭䛻喝莋屐㊶賍⦍ ڱ䘔⇰喝⦷EDU SVL 㢅᧨蜙⮶秧◖⒕朮᧤穚⒕朮᧥ ⍕Ꮢ㠯ఠ喝綍ഒ᧨㪖瘮ₐ受蟇厅蓒⺐ ㏫ఴ䷉䉋䒩喝♾⦷綍䤓欬着䟄☚喒⦃茫扭兼ぴ⇫ ৹Ꮐᬢ䬠喝䟄☚᧨税摞欬着⋋䤓㢅᧨氥㶰㖖䯉䕅㊐♧荩䤓㢅梃᧶ 抩䟄᧶秧諗᧷蛦䟄᧶秧諗ᇭ 20č ᬢ⮰㏫ఴ݉⩡≭喝㪖瘮兎皽᧶9'&㢅眸᧨9$&᧤⏷㽱㠃 税᧥㢅眸ᇭ(⨚兎皽᧶9'&㢅眸᧷9'&㢅眸 ᰬᄻ।ऴ⩡ࢷ喝EDU SVL 㢅欬着⋋䤓 䓳␐喝莋屐 Ϸ䉔喝伧矑⅚ℝᨺF6W᧤ᨺVVX᧥䤓䪎䓸㽈㒥牑㦘䀵袛⇫䞷䤓⚗㒟㽈Ⴕ 㷱喝蠼㦘腏Ⓟ᧨莋屐 䬬ႀ喝9&᧷莋屐 䬬ႀڣܬಷण喝&7;;᧷莋屐 ჲᄭ㏰Тಷण喝6.;7᧷莋屐 ㏫ఴ㳦喝肺ↅ莓᧷⺈ℝ㦗㡴ⓜ䞮ℶ䤓(⨚兎皽᧨庆莋 屐簛欄䤓兎皽绬租痥㋾ᇭ
1.50 38.1 2.00 50.8*
0.61 15.2
英寸 毫米
0.13 3.3
1.62 41.1
0.28 7.1
ᱼ᫅
Т喝摜摞᧶◒⏚᧤箬᧥᧷朱 Ⓟ᧨ぴ⇫槱兞䫻德⮓䚕ᇭ盶缂 槱柏枛᧷ₐ受蟇厅2⨚皽✛㖰 皽᧤㪖瘮⨚᧥ᇭ ᴳ ۲ 䬬 ಃ 喝 摜 摞 ᧶ ◒ ⏚ ᧤箬᧥᧷棂㨐㺶荩舊薦矑 杬⚗摠᧨珩莓7᧨欬着 ☚┪才EDU SVL ᧷莋屐 ᇭ㙟∪䚒犐枇材✛朱Ⓟ 梏⧦᧷⻉⺇♾賍㦘硵ₜ⚛᧨庆 莧幱ぴ☑ᇭ ᴳ ۲ ㏫ ఴ 喝 摜 摞 ᧶ ◒ ⏚ ᧤箬᧥᧷兮䍼⫠⺐遙᧷ + 儶功舊䂸䆕癕兎᧷莋屐 ᇭ E ಷ ㏫ ఴ 喝 摜 摞 ᧶ ◒ ⏚ ᧤箬᧥᧷⧩⦉摠⻭盶⮂⏷⺐ 遙᧨䶵⚗,3.腋㔳㪖瘮᧨揜 㦘鍻㒟扭碟犀᧷ ∔喝ᰵ ڟE ಷ㏫ఴ⮰ᝬᰵᏀ ⩔喏䄣࣮㻭 3.400.1ᇭ
电磁换向阀SV10-28中文.pdf
ᴳ ۲ ㏫ ఴ 喝 摜 摞 ᧶ ◒ ⏚ ᧤ 箬᧥᧷兮䍼⫠⺐ 遙᧷+ 儶功舊䂸箫兎᧷莋屐 ᇭ
ₐ受㳰厅᧤㪖⨚᧥ N
㺮㳰厅 V
ᴳ۲㏫ఴ㏴〛 (VDC)
ᴳ۲㏫ఴ⩡ࢷ DS ♛㓐ㇱ㘴⯃
0 㡯兎⦗
DG ',1
10 9'&†
DL ⺋兎
12 9'&
DL/W ⺋兎᧨サ:HDWKHUSDN®
24 9'&
E ಷ ㏫ ఴ 喝 摜 摞 ᧶ ◒ ⏚ ᧤ 詊⚇᧥᧷⧩⦉摠⻭盶 ⮂⏷⺐遙᧷䶵⚗,3.腋㔳 㪖瘮᧨揜㦘鍻㒟扭碟犀᧷ ∔喝ᰵ ڟE ಷ㏫ఴ⮰ᝬᰵ Ꮐ⩔喏䄣࣮㻭 3.400.1ᇭ
䃎䉙ಷण SV10-28 __ - __ __ __ - __ - __ __ __ __ __
2
1
ᕓ㘩ప᧤⅔㖖㙡ↅ᧥
① 到② ——；② 到① - - - 40°C 时 32 cSt/150 ssu 的油液
17.2/250
13.8/200
10.3/150
6.9/100
3.4/50
压降 (bar/psi)
15.1 30.3 45.4 60.6 75.7
4
8
12
16 20
流量 (lpm/gpm)
➥◥
Ⴠ 欬着兎皽釭⚗扭兼ぴ⇫ᇭ Ⴠ ♾折兎皽䟄☚✛兗簖ᇭ Ⴠ 㙡ↅ䟄☚♾疸㗱ᇭ Ⴠ ♾折,3.腋㻃(⨚兎皽ᇭ Ⴠ 梏矒兞䫻德⮓䚕᧨功䞷₣苀秼䆞ᇭ Ⴠ ㄣ㊴㓚虱折ↅᇭ Ⴠ ぴ₩抩䞷梏ⷣᇭ
电磁换向阀SV10-23英文.pdf
Return to Table of ContentsDESCRIPTIONA solenoid-operated, two-way, poppet-type, normally open, screw-in, hydraulic cartridge valve.OPERATIONWhen de-energized, the SV10-23 allows bidirectional flow from 2 to 1. With the sensor option, the neutral sensor will signal OFF or LOW.When energized, the valve’s poppet closes to block flow from 2 to 1. In this mode, the cartridge allows free reverse flow from 1 to 2 after overcoming the solenoid force (requires 3.4 to 10.3 bar / 50 to 150 psi). With the sensor option, the neutral sensor will signal ON or HIGH.Operation of Manual Override Option: To override, push and hold override button.FEATURES• Continuous-duty rated solenoid. • Manual override option.• Hardened seat for long life and low leakage. • Unitized, molded coil design.• Optional coil voltages and terminations. • Industry common cavity.• Efficient wet-armature construction.• Cartridges are voltage interchangeable.• Optional waterproof E-Coils rated up to IP69K.RATINGSOperating Pressure: 207 bar (3000 psi)Proof Pressure: 345 bar (5000 psi)Flow: See Performance ChartInternal Leakage: 0.15 cc/minute (3 drops/minute) max. at 207 bar (3000 psi)Temperature: with standard Buna N seals: -40 to 100°C (-40° to 212°F);with Fluorocarbon seals: -26 to 204°C (-15°F to 400°F);Sensor Option: -40°C to 110°C (-40°F to 230°F)Coil Duty Rating: Continuous from 85% to 115% of nominal voltageResponse Time: First indication of change of state with 100% voltage supplied at 80% of nominal flow rating: Energized: 80 msec.; De-energized: 30 msec.Response Time with Sensor: 158 ms pull-in, 57 ms drop-outInitial Coil Current Draw at 20°C: Standard Coil: 1.67 amps at 12 VDC; 0.18 amps at 115 VAC (full wave rectified).E-Coil: 1.7 amps at 12 VDC; 0.85 amps at 24 VDCMinimum Pull-in Voltage: 85% of nominal at 207 bar (3000 psi)Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC10-2; See page 9.110.1; Cavity Tool: CT10-2XX; See page 8.600.1Seal Kit: SK10-2X-T; See page 8.650.1Coil Nut: Part No. 7004420ISO:with Sensor:PERFORMANCE (Cartridge Only)SYMBOLS1.053.18.6/1256.9/1005.2/753.4/501.7/2511.4322.7634.1956.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i45.41268.118 Port 2 to 1 De-energized ——Port 1 to 2 Energized - - - -32 cSt/150 sus oil at 40°CSOLENOID VALVES34.5/50027.6/40020.7/30013.8/2006.9/100FLOW lpm/gpmP R E S S U R E D R O P b a r /p s iSV10-23 with SensorPort 2 to 1 Energized - - - - -Port 1 to 2 Energized — - —Port 1 to 2 De-energized ——32 cSt/150 sus oil at 40°C11.4322.7634.1956.81545.41268.118VALVE SHIFT %F L O W VccS E N S O R O U T P U TTypical Sensor Output vs. Valve Shift0.3 lpm 0.08 gpm68.1 lpm18 gpm Hatched Area: Overlapping Stroke, Leakage FlowH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.053.2Dimensions will differ significantly with Sensor Option; see page 3.010.1.TO ORDERSV10-(P )23(A )__ - __ __ __ - __ - __ __ __ __ __ - __ __OptionNone (Blank) 152μ Screen S Manual Override P Manual Override KFor Manual Override options see page 1.001.1Cartridge: Weight: 0.16 kg. (0.35 lbs.); Weight with Sen-sor option: 0.45 kg. (1.0 lbs.); Steel with hardened worksurfaces. Zinc-plated exposed surfaces. Buna N O-rings and polyester elastomer back-up standard.Standard Ported Body:Weight: 0.16 kg. (0.35 lbs.); Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.010.1.D-Coil: Weight: 0.27 kg. (0.60 lbs.); Unitized thermo-plastic encapsulated, Class H high temperature magnetwire. See page 3.200.1.E-Coil: Weight: 0.41 kg.(0.9 lbs.); Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.PortingCartridge Only 0SAE 6 6TSAE 8 8T 1/4 in. BSP* 2B 3/8 in. BSP* 3B1/2 in. BSP* 4B*BSP Body; U.K. Mfr. OnlyWith sensor option, use model code SV10-P23A . . .See page 3.010.1Without sensor option, use model code SV10-23 . . .Voltage Std. Coil 0 Less Coil** 10 10 VDC † 12 12 VDC 24 24 VDC 36 36 VDC 48 48 VDC 24 24 VAC 115 115 VAC 230 230 VAC**Includes D-Coil Nut†DS, DW or DLterminations onlyE-Coils: 10,12,20 or 24 VDC only.MATERIALSFor Coils with Zener Diode, add “/Z ” to option code. For example: “ER/Z ”. Not available on all models. See coil option info. on pages 3.200.1 & 3.400.1Coil Termination E-Coil D-Coil Deutsch DT04-2P ER (IP69K) DR (IP65)Metri-Pack ® 150 EY (IP69K) DY (IP65)Dual Lead Wires EL (IP69K) DL (IP65)Amp Jr. Timer EJ (IP67) —DIN 43650 EG (IP65) DG (IP65)Dual Spades — DS (IP65)Sensor Type 3 Dual Output, N.C./N.O.SealsN Buna N (Std.) V Fluorocarbon Sensor Option: See page 3.010.1Sensor/Connector N Neutral Sense/DT04-4P M Neutral Sense/M12-4P Mating Connectors :DT06-4S: Part No. 4001953M12-4S: available at or H YDRA F ORCEH YDRA F ORCE .com。
电磁阀换向阀DLDAZ英文.pdf
2-way, solenoid-operated directional spool valve with position switchCapacity:12 gpm (45 L/min.)Functional Group:Products : Cartridges : Solenoid Operated : 2-Way : Spool with Position Indicating SwitchModel: DLDAZProduct DescriptionThis solenoid-operated 2-way, 2-position cartridge is a direct-acting, balanced spool directional valve. The valve is available in either a normally open or normally closed configuration.The position switch provides confirmation that the valve is in the spring biased position.Technical FeaturesA coil must be ordered with this cartridge. This cartridge is supplied as a sealed, factory set unit and is not field serviceable. If the assembly requires changes or service it needs to be returned to the factory.Any tampering will violate the product warranty. This valve utilizes a wet armature design. This means that the working fluid surrounds the armature and is exposed to the heat generated by the coil. This can be a factor if the coil is energized for long periods of time. Some fluids, notably water/glycol mixtures, break down at these temperatures over time and form varnishes that will affect the function of the cartridge.Position switch is CE approved.A wide variety of coil termination and voltage options are available. When torquing this cartridge into its cavity, a crow's foot wrench or similar will be required since the position switch precludes the use of a deep socket wrench.The solenoid's unique magnetic design results in a high efficiencysolenoid, yielding high spool actuating force per Watt expended, leading to reliable valve shifting.The solenoid tube assembly is fatigue rated for 5000 psi (350 bar) service.Incorporates the Sun floating style construction to minimize thepossibility of internal parts binding due to excessive installation torque and/or cavity/cartridge machining variations.This valve is direct actuated and requires no minimum hydraulic pressure for operation.C-Spool DownloadH-Spool DownloadDLDA-ZCN-224 $575.00Recommended List PriceSpool ConfigurationSeal MaterialCoilStandard Options C Normally Closed +0.00HNormally Open+0.00Standard OptionsN Buna-N +0.00VViton+3.50*** See Coil Options Below Standard Coil Options (View All )DIN 43650 3 pin (Hirschman)AMP Junior TimerTwin LeadMetri-PackDeutsch DT04-2P211DIN 43650 3 pin(Hirschman) 115 VAC +36.40 612 AMP Junior Timer 12 VDC +19.90 812NMetri-Pack 12 VDC no transient voltagesuppression (TVS) diodes +24.40212 DIN 43650 3 pin+20.40 612NAMP Junior Timer 12 VDC no+19.40 824Metri-Pack 24 VDC+24.90(Hirschman) 12 VDC transient voltagesuppression (TVS) diodes212N DIN 43650 3 pin(Hirschman) 12 VDC notransient voltagesuppression (TVS) diodes+19.90 624AMP Junior Timer 24 VDC +19.90 912Deutsch DT04-2P 12 VDC +26.20214N DIN 43650 3 pin(Hirschman) 14 VDC notransient voltagesuppression (TVS) diodes +22.70 624N AMP Junior Timer 24 VDC notransient voltagesuppression (TVS) diodes+19.40 912N Deutsch DT04-2P 12 VDC notransient voltagesuppression (TVS) diodes+25.70223DIN 43650 3 pin(Hirschman) 230 VAC +36.40 724N Twin Lead 24 VDC notransient voltagesuppression (TVS) diodes+22.00 924Deutsch DT04-2P 24 VDC +26.20224DIN 43650 3 pin(Hirschman) 24 VDC +20.40 812Metri-Pack 12 VDC +24.90 924N Deutsch DT04-2P 24 VDC notransient voltagesuppression (TVS) diodes+25.70224N DIN 43650 3 pin(Hirschman) 24 VDC notransient voltagesuppression (TVS) diodes+19.90Stainless options not available for this modelRelated ModelsDLDA DLDASCopyright © 2002-2013 Sun Hydraulics Corporation. All rights reserved.Terms and Conditions - ISO Certification - Statement of Privacy。
电磁换向阀SV98-T40英文.pdf
Return to Table of ContentsDESCRIPTIONdirectional control valve. It is well suited for use in specialized low-pressure pilot systems or power shift transmission control.OPERATIONWhen de-energized, the SV98-T40 allows flow from 3 to 2 and from 4 to 1. When energized, the cartridge’s spool shifts to allow flow from 2 to 1 and from 3 to 4. Pressure at 1 (tank) should not exceed 3.4 bar (50 psi).The coil is an integral part of the valve and is not serviceable.FEATURES• Economical drop-in style.• Integral waterproof coil standard.See page 3.400.1 for a description of tests conducted to verify coil waterproofing.• 12 or 24 VDC coils.• Several push-on termination options.RATINGSOperating Pressure: up to 30 bar (435 psi)Flow: 30 lpm (8 gpm)Internal Leakage: 70 ml/minute (4.3 cu. in./minute) maximum from inlet to tank at 30 bar (435 psi)Temperature: -40 to 120°CCoil Duty Rating: Continuous from 85% to 115% of nominal voltage Response Time: First indication of change of state with 100% voltage and flow rating: Pull-in: 50 ms; Drop-out: 30 ms.Initial Coil Current Draw at 20°C: 1.68 amps at 12 VDCMinimum Pull-in Voltage: 85% of nominal at 30 bar (435 psi)Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: Flange MountFlange Mounting Screws: M5 x 8; Part No. 4000039 (not provided with valve)Cavity: VC-T004; See page 9.111.1Cavity Tool: CT-T004R0-x-G; See page 8.600.1Seal Kit:SK98-T4N-000; See page 8.650.1SYMBOLSUSASI/ISO:PERFORMANCE (Cartridge Only)1.704.1SOLENOID VALVES8.3/1209.7/14011.0/1606.9/1005.5/804.1/602.8/40P R E S S U R E D R O P b a r /p s iPressure Drop vs. Flow 32 cSt/150 sus oil at 40q C213FLOW lpm/gpm457681.4/20H YDRA F ORCE .comDIMENSIONS1.704.2OptionNone(Blank)233μ screen Son inlet portMATERIALSCartridge including Coil: Weight:0.26 kg. (0.57 lbs.) Steel withhardened work surfaces. Zinc-Nickel plated exposed surfaces.HNBR O-rings standard. Coil isencapsulated, class H high-temperature magnetwire, withzinc-nickel plated shell.Standard Ported Test Body:Weight: 0.11 kg. (0.25 lbs.)Anodized high-strength 6061 T6aluminum alloy, rated to 207 bar(3000 psi). See page 8.010.1.Mounting Screws: Must be orderedseparately: Part No. 4001015SV98-T40 __ - __ __ - __ __ - __ __TO ORDERVoltage12 12 VDC24 24 VDCTerminationDJ Amp Junior TimerY2A Metri-Pack® 150.2ADR Deutsch DT04-2PPortingC artridge Only 0SAE66TCoils with internaldiode are available.Consult factory.1.1629.5H YDRA F ORCEH YDRA F Return to Table of Contents。
10电磁换向阀
4
3
2
B
P
A
© 2009 Sun Hydraulics Corporation
18
Products/Company Introduction Seminar Solenoid Operated Cartridge Valves
系列 1 特殊扭动/锁紧人工控制形式
L Twist/Lock (锁销) Manual Override T Twist (瞬时的) Manual Override D Twist/Lock (两种) Manual Override
.25 gpm (1 L/min.)
.25 gpm (1 L/min.) 12 gpm (45 L/min.) .25 gpm (1 L/min.) 10 gpm (40 L/min.) 5 gpm (20 L/min.)
DAAC
DBA* DMDA DBAC DNDA DNDC
T-8A / P
T-9A / P T-11A / 1 T-9A / P T-31A / 1 T-31A / 1
Solenoid Valves - Coil Connector / Voltage Options
For Sun Series 1 Solenoid Valves (DAAL, DTDA, DLDA, DMDA, DNDA)
© 2009 Sun Hydraulics Corporation
21
Products/Company Introduction Seminar Solenoid Operated Cartridge Valves
© 2009 Sun Hydraulics Corporation
2
Products/Company Introduction Seminar Solenoid Operated Cartridge Valves
电磁换向阀SV12-31英文.pdf
Return to Table of ContentsDESCRIPTIONvalve.OPERATIONat 3. When energized, the spool shifts to allow flow between 1 and 3 while blocking flow at 2.While port 1 may be fully pressurized, it is not intended to be used as the inlet.FEATURES• Continuous-duty rated solenoid.• Hardened spool and cage for long life.• Optional coil voltages and terminations.• All ports may be fully pressurized.• Heavy-duty waterproof E-Coils rated up to IP69K.RATINGSOperating Pressure: 240 bar (3500 psi) max.Flow: See Performance ChartLeakage: 410 cc/minute (25 cu. in./minute) at 240 bar (3500 psi)Temperature: -40 to 120°C with Buna N seals Coil Duty Rating: See ChartResponse Time: Pull-In: 100 msec; Drop-Out: 100 msec Initial Coil Current Draw at 20°C: 2.8 amps at 12 VDC Filtration: See page 9.010.1Fluids: Mineral-based or synthetics with lubricating properties at viscosities of7.4 to 420 cSt (50 to 2000 sus); See Temperature and Oil Viscosity, page 9.060.1Installation: No restrictions; See page 9.020.1Cavity: VC12-3; See page 9.112.1Cavity Tool: CT12-3XX; See page 8.600.1Seal Kit: SK12-3X-MM; See page 8.650.1E-Coil Nut: Part No. 7085180USASI/ISO:PERFORMANCE (Cartridge Only)SYMBOLS1.369.113.8/20010.3/1506.9/1003.4/5037.91018.9556.815FLOW lpm/gpmP R E S S U R E D R O P b a r /p s i3 to 1 —— ; 2 to 1 - - - -32 cSt/150 sus oil at 40q C37.91018.9556.81575.820FLOW lpm/gpmP R E S S U R E b a r /p s iOPERATING LIMITSPull-In Current 85% of Nominal Drop-Out Current 5% of Nominal Inlet at 1: hatched; Inlet at 3: shaded32 cSt/150 sus oil at 40q C110120607050403020100-20-10-30-401008090706050% O F R A T E D V O L T A G EAMBIENT TEMPERATURE (q C)CONTINUOUS DUTY OPERATING RANGE Minimum Voltage at the Coil Required for Pull-In32 cSt/150 sus oil at 40q CSOLENOID VALVESH YDRA F ORCE .comReturn to Table of ContentsDIMENSIONS1.369.2Cartridge: Weight: 0.29 kg. (0.65 lbs.) Steel with hardened work surfaces. Zinc-plated exposed surfaces. Buna N O-rings and TFE back-ups standard.Standard Ported Body: Weight: 0.98 kg. (2.15 lbs.) Anodized high-strength 6061 T6 aluminum alloy, rated to 207 bar (3000 psi). Ductile iron bodies available; dimensions may differ. See page 8.012.1. E-Coil: Weight: 1.36 kg. (3.0 lbs.) Fully encapsulated with rugged external metal shell. Rated up to IP69K with integral connectors. See page 3.400.1.TO ORDERSV12-31 __ __ __ - __ - __ __ __ __ __Porting Cartridge Only 0 SAE 8 8T SAE 10 10T SAE 12 12T 1/2 in. BSP* 4B 3/4 in. BSP* 6B*BSP Body; U.K. Mfr. OnlySealsBuna N (Std.) N Fluorocarbon VVoltage 0 Less Coil 12 12 VDC 24 24 VDC 36 36 VDC 4848 VDCTerminations (VDC)EL Leadwires (2), IP65 Rated ES Dual Spades, IP65 Rated EG DIN 43650, IP65 Rated EW Leads w/Weather-Pack ® Connector, IP65 RatedEY Metri-Pack ® 150 Connector, IP69K RatedCoils with internal diode are available. Consult factory.Other coil voltages may be availablefor OEM applications. Consult factory.MATERIALSH YDRA F ORCEH YDRA F ORCE .com。
