纽威硬密封球阀
2017年阀门行业纽威阀门分析报告
(此文档为word格式，可任意修改编辑！）正文目录1、阀门龙头，质地优秀 (6)1.1、公司是国内领先的中高端工业阀门供应商 (6)1.2、注重研发、制造、管理、销售等核心能力 (13)1.3、高管增持彰显信心，股价安全边际较高 (19)2、阀门行业：关注国内集中度提升机遇 (20)2.1、全球市场：应用广泛，增长平稳 (20)2.2、国内市场：中低端竞争激烈，行业面临整合 (23)3、上行周期叠加，业绩重启增长 (25)3.1、油气阀门：受益产业上游复苏及中下游高景气 (25)3.1.1、上游环节投资复苏提振开采设备及海工阀门业务 (26)3.1.2、中游环节管线及LNG阀门受益“十三五”油气管网建设 (31)3.1.3、下游环节新增设备投资需求驱动炼化阀门销售增长 (34)3.2、化工阀门：重点开拓煤化工市场及优质客户 (36)3.3、核电阀门：厚积薄发，深耕国内及欧洲市场 (39)4、立足主业，打造全球工业阀门领导者 (43)5、盈利预测 (43)6、估值水平与投资评级 (45)7、风险分析 (46)图目录图1：公司营业收入远超同行竞争对手 (6)图2：公司利润总额领先同行竞争对手 (7)图3：公司阀门产品分为10个系列 (8)图4：下游面向油气、化工、电力（含核电）、采矿、船舶、水处理及一般工业领域 (8)图5：上市公司股东结构及下属子公司 (9)图6：单季度收入与布油价格变化趋势 (10)图7：单季度收入变化趋势滞后布油价格约1年 (10)图8：营业收入变化 (11)图9：归母净利润变化 (11)图10：毛利率、净利率基本平稳 (12)图11：期间费用率总体平稳 (12)图12：公司研发费用明显高于同行 (13)图13：公司取得阀门行业国际权威认证 (14)图14：公司产能情况 (15)图15：IPO募投项目在建产能 (15)图16：单位固定资产收入贡献比较 (16)图17：部分高管平均薪酬比较 (16)图18：期间费用率比较 (17)图19：海外销售收入占比提升 (17)图20：分地区收入占比（2016H1） (18)图21：油气、化工、核电领域全球优质客户资源 (18)图22：毛利率比较 (19)图23：全球工业阀门市场平稳增长 (20)图24：全球工业阀门分地区占比（2012年） (21)图25：全球工业阀门下游占比（2012年） (21)图26：全球工业阀门分类型占比（2012年） (22)图27：全球主要阀门企业市场份额（2011年） (22)图28：全球主要阀门企业阀门业务收入变化 (23)图29：国内工业阀门市场平稳增长 (23)图30：国内工业阀门下游占比（2012年） (24)图31：国内TOP20阀门企业产值（2014年） (25)图32：公司油气阀门产品应用于产业链上、中、下游各环节 (26)图33：国际原油现货价格企稳回升 (27)图34：陆上钻机数量回暖，海上钻机数量企稳 (27)图35：全球在运钻井平台数量接近2006年水平 (28)图36：7家油气企业资本开支拐点出现在2016Q4 (28)图37：7家油气企业资本开支滞后国际油价约半年 (29)图38：海洋油气开发装备与开采工艺 (29)图39：油气开发环节及海工装备领域的主要客户 (30)图40：阀门产品应用于各类海洋油气开发装备 (31)图41：深海水下阀门交付海油工程文昌气田群项目 (31)图42：公司参与的油气管线项目分布 (32)图43：公司参与的部分重大油气管线工程 (32)图44：LNG接收站工艺流程 (33)图45：公司参与的部分LNG接收站项目 (33)图46：“十三五”国内油气管道建设目标 (34)图47：全球炼油厂开工率保持较高水平 (35)图48：9家美股油气炼化企业资本开支保持平稳 (35)图49：杜邦、陶氏单季度资本开支 (37)图50：5家国际化工企业资本开支逐季增长 (37)图51：煤化工阀门产品1 (38)图52：煤化工阀门产品2 (38)图53：煤化工行业十三五规划产能 (39)图54：并网、在建及计划新增核电机组装机容量 (40)图55：阿海珐EPR第三代技术核电站项目 (42)图56：欧洲地区计划新增核电装机容量达2049万千瓦 (42)表目录表1. 公司取得的阀门行业国内外产品权威认证与生产资质 (14)表2. 实际控制人、部分高管及员工持股计划增持情况 (19)表3. 纽威阀门产品供应国内众多管线及LNG项目 (33)表4. “十三五”7大炼化一体化基地 (36)表5. 公司供应阀门产品的煤化工项目 (39)表6. 中广核防城港项目3-4号机组（采用第三代核电技术国产“华龙一号”）阀门中标情况汇总 (41)表7. 公司及子公司中标的核电阀门项目 (41)表8. 公司分项收入预测 (44)表9. 可比公司的PE比较 (45)1、阀门龙头，质地优秀1.1、公司是国内领先的中高端工业阀门供应商苏州纽威阀门成立于2002年，2014年完成上市。
纽威阀门样本 Neway Valves
Cat.no.:E-BFVCat.no.:E-PVCat.no.:E-CSV Cat.no.:E-PS Cat.no.:E-FSVCat.no.:E-PLVNo.999 Xiangjiang Road, Suzhou New District,P .R. China Post Code:215129Tel: 86-512-666-51365Fax: 86-512-666-51360E-Mail: neway@ C a t .n o .:E -P V -2005-U S12315 Parc Crest Drive Suite 190Stafford, T exas 77477Phone: 281-933-5775Fax: 281-933-5779JAG Flocomponents USA, Ltd.U.S. Sole Distributor:Manufacturer:Cat.no.:E-MVN the safety and protection ofe w a y r e c o g n i z e s t h eimportance of valve quality for personnel health and property. It is our quality commitment to focus our resources to provide our customers with first class products at a competitive price, that are designed, manufactured, inspected and tested in accordance with our customers, specifications and that comply with all international standards.With respect to the facts that the current industrial standards do not always take into consideration the likelihood and consequences of possible deterioration in service, related to specific service fluids or the external environment in which they operate. Our customers are requested to keep an open line of communication withNEWAY technical research center utilizes the most advanced computertechnology to improve the existing products and develop the new lines, this includes a highly educated and trained engineering team and a comprehensive internal computer network which links the entire operations of design, manufacturing and administration.NEWAY design philosophy is to develop a safety and cost-efficient valve, we introduced the latest AUTO CAD and I-DEAS software for all our new product design research which include the advanced finite element analysis to virtually verify the new design prior to production, this has resulted in dramatically reducing the new product design time and ensure a safety and cost efficient final product.NEWAY technical personnel are always ready to offer on line or on site technical training and support for all of its distributors, agents and end users.Fire safe is standard design of all NEWAY ball valve.Technical InnovationAPI 6D API 607API 6FA BS 5351BS 6755ANSI B16.34ANSI B16.10ANSI B16.5MSS SP-25MSS SP-55 NACE Std MR0175SHELL MESCAPI 598 Fire Safe Test CertificateTest FacilityTest ChartCNC LatheThe latest computer technology are also widely applied in NEWAY for valve manufacturing, this include a large number of numeric control machines (Machining center, CNC horizontal and vertical lathe, CNC drilling machine) and ERP management system which significantly improve our machining quality and process control. NEWAY also employes a number of conventional lathe with capacity up to machine 48ball valve.NEWAY manufacturing philosophy is to ensure stable quality and just in time delivery.4.2M Lathe CNC Lathe Automatic welding MachineMachining CenterCNC DrillingNEWAY developed an extensive and advanced inspection and test facilities to control the quality from rough castings or forgings to final products. These facilities enable us to do Radio graphic test, Ultra-sonic test, Dye-penetrate test, Magnetic test, Positive Material Identifier (PMI), Impact test, T ensile test, Hardness test, Fire safe test, Cryogenic test, Vacuum test, Low fugitive emission test and Hydro-static test.NEWAY Quality Assurance is dedicated to the pursuit of a zero defect valve, and this has resulted in the company having more quality qualifications and end user approval than most of our competitors. NEWAY is certified by ISO 9001 (certificate under DNV) and API 6D (registered no. 6D-0285) and our off-shore platform valves are type approved by ABS. Moreover, NEWAY is the first valve manufacturer in China to be certified to CE/PED (category IV, mode B+D, certificate under B.V.), All of NEWAY soft seated ball valves are fire safe tested and certified by Lloyd s Register.Part number identificationControlled Stem & Stuffing Box FinishFor the elimination of air pollution, it is essential to control the fugitive emissions leakage of various chemicals from valves in your chemical plant. NEWAY low emissions ball valves installed with our emissions defense packing have been designed and tested to m e e t t h e 100 P P M m a x i m u m e m i s s i o n l e v e l (acceptance test per Shell SPE 77/312). This is NEWAYstandard specification for all series BA, B and BB flanged floating ball valve.The stem surface finish is controlled between Weather proofbelleville-spring washerLow Emission packingFire Safe Seat SealingAdditionally, the fire safe metal seat can prevent the line pressure erosion on soft seat and minimize soft seat creep deformation. All NEWAY floating valves fire safe is designed and test certified in accordance with API 607.When static are generated and concentrated on the ball, the spring-loaded pins installed on ball, stem are provided to ensure electrical continuity throughout the valve.Anti-Static DeviceStem lower end is integral T shaped designed to be blow-out proof. It is internally inserted and functions as the backseat for assured stem sealing at all pressuresBlow-out Proof StemBefore FireBodyStemPacking ClosureBall StemPackingBallSeatBodyPackingStemAnti-Static DeviceClosureBodyBallGasketClosureWhen non-metal sealing material are decomposed or deteriorated by a plant fire, the upstream line pressure pull the ball into contact with the metal seat lip beneath the soft seat to shut off the line fluid to minimize the internal leakage.Design Feature:Live Loaded Gland FlangeLow Emission PackingLive loading is designed to provide gland load retention, compensating for expected in-service consolidation of the packing. A set of Belleville-Spring Washers are used on each gland stud to help exert a continuous compressive force on the gland follower flange and therefore reduce fugitive emissions from the stem packing. NEWAY standard Belleville-Spring Washers are protected by a weatherproof cap to keep them free from environmental contamination, resulting in a longstable life.The packing set is a combination of parallel and vertical layer sealing elements, which are made of expanding graphite in die-formed rings and have features of heat resistance, less stress relaxation and low creep. With this special structure, it allows for a low-friction on rotary & rising stem valves, therefore providing the stabilized seal performance for long cycle life.For medium and low temperature service, the standard V shape PTFE packing rings are installed for lowemission control.Floating Ball Valve Design FeatureLow Emission Control2963161861171514128137541110Series FE1 Ball ValveRegular port, uni-body, end entry designBlow-out Proof StemInternally inserted and functions as the backseat for assured stem sealing at all pressuresMetal-to-Metal Sealing When non-meatl sealing is deteriorated by fire,ball floats to shut off the line fruidEmission-free Graphite primary gasketIndex noPart123456789Index no PartBody Closure BallGland Flange Lever Seat Ring Stem Gland Gasket101112131415161718Grounding Washer Packing Set Stop Plate Thrust Washer Retainer Washer Bolt Rotaining SpringSeries FE1 Ball ValveSeries FE1 Ball ValveRegular port,uni-body,cast steel,end entry designClass 150LBWeight KgW mmH mmL mmD mmd mmSizeinDimensionsWW DLdHWDLddHGear Operator1 / 22 3101 / 23 / 411-1/222-1/23468101 / 23 / 49.512.71930385164761141441879.512.712.71925.43851647610215220325412.719108117127165178191203229267292330140152545964901021121211662082463035459120140140160265265265300400 300 * 400 *120140 1.72.72.985.008.7112.416.6624.38541011502.83.61638111071817962416135151412Series FB2 Ball Valveavailable in size from to 12 full port or witnessed and certified by Lloyd s Register.Double "D" Stem HeadProvides mounting of the lever handle alwaysin parallel to the flow passage Blow-out Proof Stem Internally inserted and functions as the backseat for assured stem sealing at all pressuresEmission-free Graphite primary gasket Metal-to-Metal SealingWhen non-meatl sealing isdeteriorated by fire,ball floats to shut off the line fruid easily for installation of gear, motor or pneumatic actuator 123456789Body Closure Ball Yoke Gland Flange Seat Ring Stem Gland Gasket 101112131415161718Grounding Washer Packing Set Thrust Washer Stud Nut Bolt Bolt Spring Steel BallSeries FB2 material specifications Series FB2 Ball Valve Two-piece,split body,cast steel,side entry design Full Port Size in D mm L mm H mm W mm Weight Kg Reduced Port Size in D mm L mm H mm W mm Weight Kg d mm 150L B Gear Operator Dimensions W H D L Full Port WH d D L Reduced Port W 123456789101112131415161718No. Part Standard Stainless Steel Sour Service Low TemperatureServiceASTM A352-LCB ASTM A352-LCB ASTM A182-F316ASTM A216-WCB ASTM A216-WCB PTFE ASTM A182-F316ASTM A182-F316316SS + Graphite Graphite PTFE PTFE ASTM A320-L7M ASTM A194-7M ASTM A320-L7M ASTM A320-L7M S.S.S.S.ASTM A216-WCB ASTM A216-WCB ASTM A105/ENP ASTM A216-WCB ASTM A216-WCB PTFE ASTM A182-F6a ASTM A276-420316SS + Graphite Graphite PTFE PTFE ASTM A193-B7M ASTM A194-2HM ASTM A193-B7M ASTM A193-B7M S.S.S.S.ASTM A351-CF8M ASTM A351-CF8M ASTM A182-F316ASTM A351-CF8M ASTM A351-CF8M PTFE ASTM A182-F316ASTM A182-F316316SS + Graphite Graphite PTFE PTFE ASTM A193-B8ASTM A194-8ASTM A193-B8ASTM A193-B8S.S.S.S.ASTM A216-WCB ASTM A216-WCB ASTM A105/ENP ASTM A216-WCB ASTM A216-WCB PTFE ASTM A182-F6a ASTM A276-420316SS + Graphite Graphite PTFE PTFE ASTM A193-B7ASTM A194-2H ASTM A193-B7ASTM A193-B7S.S.S.S.Body Closure Ball Yoke Gland Flange Seat Ring Stem Gland Gasket Grounding Washer Packing Set Thrust Washer Stud Nut Bolt Bolt Spring Steel Ball 1 / 23 / 411-1/222-1/23456810121 / 2131925385164761021251522032543051310811712716517819120322935639445753361014059637697107142152178252272342345479591301301602302304004007001100 300 * 300 * 400 * 600 *1303/4*1/2*3/43/4*1/2*3/41*3/4*11-1/2*1-1/22*1-1/2*22-1/2*2*2-1/23*2-1/2*34*3*46*4*68*6*810*8*1012*10*121.782.003.517.2311.0515.022.036.058.0110.0195.0309.0346.02.29131925385164761021522032541319253851647610215220325430519117127165178190203229394457530610152828510011512015316219129034044282130130160230230400400460 300 * 300 * 400 *130 3.04.57.09.515.016.029.548.0123.0212.0230.03.5Series FB2 Ball Valve122019178111354197161021181631415296Blow-out Proof Stem Internally insertedand functions as the backseat for assured stem sealing at all pressuresSeries FB2 Ball Valve Two-piece, split body, forged steel, side entry design This series ball valves are featured with two-piece bolted with flanged end body and floating ball. Body and closure are fully forged steel made which eliminate the inevitable casting defects and is ideal for high pressure service. FB2 series ball valves are available in size from 1 /2 to 4 and offers ANSI class rating 600 to 2500, all meet the fire safe requirements of BS 6755 and API 607. Blowout-proof stem, anti-static device and locking device are standard design, low emission packing with live loaded gland flange design can be available upon request. Manual handle operation is basic standard, but fully machined mounting pad can also easily install with gear, motor or pneumatic operator.ANSI Class 150 to 300 and Three-piece design can be supplied upon request.Double "D" Stem HeadProvides mounting of the lever handle always in parallel to the flow passageSecure LIne Flow Equipped with an integral locking device to secure the line flow Spring-loaded pins installed on ball, stem is provided to ensure electrical continuity throughout the valve Bolted Body/AdapterFlanged body and flanged adapter secured with cap screws to maintain seal integrity Metal-to-Metal SealingWhen non-meatl sealing is deteriorated by fire,ball floats to shut off the line fruid Index no Part 1234567891011Body Closure Ball Lever Lever Sleeve Seat Ring Stem Gland Gasket Steel Ball Packing Set Index no Part 12131415161718192021Stop Plate Thrust Washer Stud NutSpringSpring Washer Stop Pin Nut WasherLocking Plate Series FB2 Ball ValveThis is a typical Series FB2 floating ball valve illustrated cross-section drawing which is only fordemonstrating of basic design features. The actual product design may be slightly different from this sample drawing due to its size and pressure class.Series FB2 material specifications Series FB2 Ball Valve 123456789101112131415161718192021No. Part Standard Stainless Steel Sour Service Low TemperatureServiceBody Closure Ball Lever Lever Sleeve Seat Ring Stem Gland Gasket Steel Ball Packing Set Stop Plate Thrust Washer Stud Nut Spring Spring Washer Stop Pin Nut Washer Locking Plate ASTM A105ASTM A105ASTM A105/ENP Carbon Steel Polyethylene PTFE ASTM A182-F6a ASTM A276-420Graphite S.S.PTFE Carbon Steel PTFE ASTM A193-B7M ASTM A194-2HM S.S.Alloy Steel Carbon Steel Carbon Steel Carbon Steel Carbon Steel ASTM A350-LF2ASTM A350-LF2ASTM A182-F316Carbon Steel Polyethylene PTFE ASTM A182-F316ASTM A182-F316316 + Graphite S.S.PTFE S.S.PTFE ASTM A320-L7M ASTM A194-7M S.S.Alloy Steel S.S.S.S.S.S.S.S.ASTM A182-F316ASTM A182-F316ASTM A182-F316Carbon Steel Polyethylene PTFE ASTM A182-F316ASTM A182-F316Graphite S.S.PTFE S.S.PTFE ASTM A193-B8ASTM A194-8S.S.Alloy Steel S.S.S.S.S.S.S.S.ASTM A105ASTM A105ASTM A105/ENP Carbon Steel Polyethylene PTFE ASTM A182-F6a ASTM A276-420Graphite S.S.PTFE Carbon Steel PTFE ASTM A193-B7ASTM A194-2H S.S.Alloy Steel Carbon Steel Carbon Steel Carbon Steel Carbon Steel Two-piece,split body,forged steel,side entry design L W H D H Dd WL Dimensions Full Port Size in D mm L mm H mm W mm Weight Kg Reduced Port Size in D mm L mm H mm W mm Weight Kg d mm 600L B B Full Port Reduced Port 3/4*1/2*3/4713131921622970831401707.510.01/2*1/4*1/21 / 23 / 41319216229831121701708.511.01 / 23 / 411-1/2234131925385176102165191216241292356432668890120135180224160170170280300450500 3.55.16.513.229.034.0135.53/4*1/2*3/41*3/4*11-1/2*1*1-1/22*1-1/2*23*2*3713192538517613192538517610216519121624129235643243668890120135180130160170170280300450 2.93.85.310.61342.081.51/2*1/4*1/24*3*4Series FB2 Ball ValveSeries FB2 Ball Valve Series BC Ball Valve Two-piece,split body,forged steel,side entry designL W HD WLHDd DimensionsFull Port Size in D mm L mm H mm W mm Weight Kg Reduced PortSizein D mm L mm H mm W mm WeightKgd mm150LBFull Port Reduced Port1 / 23 / 411-1/22313192538517621622925430536847083112123143177200230230300400450700 6.811.016.032.664.090.0713264751708.01/2*1/4*1/21 / 213264882309.03/4*1/2*3/41*3/4*11-1/2*1*1-1/22*1-1/2*23*2*37131925385113192538517621622925430536847070831121231431771702302303004004507.510.015.028.041.082.01/2*1/4*1/2NEWAY trunnion mounted ball valve contains 3 main series: TB2 series for cast steel two-piece design, TB3 series for forged steel three-piece design and TTE series for top entry uni-body design, all designed conform to API 6D and fire safe test are satisfied to BS 6755 and API 6FA. They are available in size from 2to 48Wide range of body and trim material is available for service00temperature from -46C to 200C and pressure rating from ANSI class 150 to 1500 or for sour service to NACE Mr0175.For 6 inch and larger NEWAY Trunnion mounted ball valveswill be installed with a sealant injection fittings on both stemand seats. When the sealing materials (seat sealing or stemo-ring) are damaged or decomposed by fire or otheraccidental causes, leakage from the seat and stem can beprevented by injection of sealant into these fittings. Fitting isalso internally installed a second check valve to providesbackup sealing. Emergency sealant injection system Cavity Pressure ReliefEach ball seats shut off the line fluid independently on the upstream and downstream side, allowing double block o p e r a t i o n. W h e n t h e p r e s s u r e i s simultaneously applied to both sides of the ball in closed position, the valve bore and the body cavity will be isolated from each other, and the residue within the body cavity can be released through the drain plug.Double block and bleed Top flange Injection Closure Gland Body Ball SeatThe stem is made separately from the ball; The lover end of the stem is designed with an integral collar to be blowout-proof.Antistatic device is a standard feature of NEWAY ball valve . A spring-loaded pin assures the electrical continuity, between ball ,stem and body, so as to avoid sparks during turning of the stem to open and close the valve, which could be dangerous in caseof hazardous area installation.Super Fire safe designExternal leakage preventionLeakage from the valve stem area isprevented by double sealing with 2 O-rings and gland gasket. Leakagethrough the valve body joint is alsoblocked by double sealing with O-ringand body gasket. After a fire hasdeteriorated O-rings, gland gasket,body gasket and stem firesafe packingare the measure that prevents externalfluid leakage. When non-metal materials such as O-ring, seat insert and spacer aredecomposed or deteriorated by fire, theedge of the metal seat preloaded by theBall to shut off the line fluid to minimize internal leakage through the valve bore. Also the fire safe flexible graphite seat packing will be compressed by the seat spring to prevent fluid leakage Internal leakage preventionAnti Blow-out Stem Anti-static Device Top Flange Stem Stem fire safe packingGland O-ring Gland gasket Body Ball Anti-static spring Grounding plunger Drain plug Body Upstream seat Body cavity Closed ball Vent valve Downstream seat Body cavity Total spring force (Fs)Cavity pressure (Pc)Fig b. P*D1>FsP=Pc-Pl Cavity pressure (Pc)Total spring force (Fs)Fig a. P*D1<Fs P=Pc-Pl Stem Top Flange Gland Body Closure O-ring Ball Gland gasket Body gasket Stem firesafe packing Trunnion Mounted Ball ValveDesign FeatureTrunnion Mounted Ball Valve Design FeatureH L Dd W H L D d d mm L mm H mm W mm D mm L mm H mm W mm d mm 517610215220325430533738743843848976102152203254305337387438489540591203229394457533610686762864914101610671651932313293933934414815986436437082304004004601000*500*500*500*500*500*500*500304790161268467560766902113013001520234681012141618202224517610215220325430533738743848954059125121616523018178203229394457533610686762864914101610671651932313293934014414815986437087988632304004601000*500*500*500*500*500*500*500*500*500173350931662734755707789351190134615795176283165230383*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2022*20*2224*20*243*2*3WD mm L mm H mm W mm D mm L mm H mm W mm d mm 51761021522032543053373874384897610215220325430533738743848959135643255966078783888999110921194139717624727636336342654859864874081040075010001500*500*500*500*500*500*500*5004170122255440662010601440186024003240 600L B 234681012141618202451761021522032543053373874384895912351763683811922794601000529729235643559660787838889991109211941397217624727636336342654859864874081092040075010001500*500*500*500*500*500*500*500*500275080251.835060082011301550210028003626517676102381457192279460100083103--------------3*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2024*20*243*2*34*3*4W HL D d L H D d WTwo-piece,split body,cast steel,side entry design Full PortSizeinWeight Kg Reduced Port Size in Weight Kg DimensionsGear Operator Series TB2 Ball Valve Series TB2 Ball ValveTow-piece,split body,cast steel,side entry design Gear OperatorFull Port Size in Weight Kg Reduced Port Size in Weight Kg Dimensions 150L BWDdHWDdHLL22328201315652919810383733341426161127918363538724251221173231302230311Series TB3 Ball ValveIndex noPart12345678910111213141516171819Body Closure BallSeat Assembly( )Seat Insert Seat Ring StemTrunnion Alignment Pin ShimTrunnion Support Gasket Body Gasket Spacer GasketFiresafe Gasket Gland Cap Top Flange Thrust Washer BearingIndex noPartSeat Follower Vent Valve Drain Seat Spring Grounding Spring Grounding Plunger O-Ring O-Ring O-Ring Series TB3 Ball ValveD mmL mmH1mm2346810121416182022242651761021522032543053373884384895405916351782032293944575346106867628649149911067114320030031533540542746550662266673083389590011012616516520022026229334192435480518535265285285*300*300*300*500*600*600*600*600*600*800*80021.1132.0992190345495577859114414401918235228033200W mmH2mmSize inD mmL mmH1mmW mm3*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2022*18*2224*20*2426*22*2628*24*28d mm517610215220325430533738743843848954059176102152203254305337387438489540591635686203229394457534610686762864914991106711431245200300315335405427465506622666666730833895110126165170200220262293341392392435480518265285285*300*300*300*500*600*600*600*600*600*600*80026.4540102225373509730790109511522343206022152700H2mmWH 1H 2DdWLSeries TB3 Ball ValveSeries TB3 material specifications 123456789101112131415161718192021222324252627No. Part Standard Stainless Steel Sour Service Body Closure BallSeat Assembly Seat Insert Seat Ring Stem Trunnion Alignment Pin ShimTrunnion Support Gasket Body Gasket Spacer Gasket Firesafe Gasket Gland Cap Top Flange Thrust Washer Bearing Seat Follower Vent Valve Drain Seat Spring Grounding Spring Grounding Plunger O-Ring O-Ring ASTM A105ASTM A105ASTM A105/ENPAssembled By No.5&625% Glass-filled PTFE ASTM A105/ENP ASTM A105/ENP ASTM A182-F316ASTM A182-F316ASTM A216-WCB/ENP 316SS + Graphite 316SS + Graphite PTFE316SS + Graphite 316SS + Graphite ASTM A105ASTM A105316 + PTFE + MoS2316 + PTFE + MoS2ASTM A105/ENP Assembly S.S.Inconel X-750S.S.ASTM A182-F316NBR NBR ASTM A182-F316ASTM A182-F316ASTM A182-F316Assembled By No.5&625% Glass-filled PTFE ASTM A182-F316ASTM A182-F316ASTM A182-F316ASTM A182-F316ASTM A351-CF8M 316SS + Graphite 316SS + Graphite PTFE316SS + Graphite 316SS + Graphite ASTM A182-F316ASTM A182-F316316 + PTFE + MoS2316 + PTFE + MoS2ASTM A182-F316Assembly S.S.Inconel X-750S.S.ASTM A182-F316NBR NBR ASTM A105ASTM A105ASTM A105/ENPAssembled By No.5&625% Glass-filled PTFE ASTM A105/ENP ASTM A105/ENP ASTM A182-F316ASTM A182-F316ASTM A216-WCB/ENP 316SS + Graphite 316SS + Graphite PTFE316SS + Graphite 316SS + Graphite ASTM A105ASTM A105316 + PTFE + MoS2316 + PTFE + MoS2ASTM A105/ENP Assembly S.S.Inconel X-750S.S.ASTM A182-F316NBR NBR ASTM A350-LF2ASTM A350-LF2ASTM A350-LF2/ENPAssembled By No.5&625% Glass-filled PTFE ASTM A350-LF2/ENPASTM A350-LF2/ENP ASTM A182-F316ASTM A182-F316ASTM A352-LCB/ENP316SS + Graphite 316SS + Graphite PTFE316SS + Graphite 316SS + Graphite ASTM A350-LF2ASTM A350-LF2316 + PTFE + MoS2316 + PTFE + MoS2ASTM A350-LF2/ENP Assembly S.S.Inconel X-750S.S.ASTM A182-F316NBR NBR Low TemperatureServiceDimensionsClass 150LB Full PortSize inWeight KgClass 150LB Reduced portWeight KgGear OperatorThree-piece,split body,forged steel,side entry designD mmL mmH1mm234681012141618202224285176102152203254305337388438489540591686292356432559660787838889991109211941295139715492063153303454154274655196386837488549179581131291691481852262693003504024464925315564007501000*300*300*500*600*600*600*600*600*800*800*8003363.5117273.54527366251230153521352640337049206060W mmH2mmD mmL mmH1mmW mm3*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2022*18*2224*20*2428*24*3030*24*28d mm5176102152203254305337387438438489591591761021522032543053373874384895405916867373564325596607878388899911092119412951397164916512063153303454154274655196386836837489179171131291691481852262693003504024021165315314007501000*300*300*500*600*800*800*600*600*600*600*60046.59917630453690210901310164022702430344042504730H2mmH 1H 2LH 1H 2LD dWKgD mmL mmH1mm2346810121416182022242851761021522032543053373884384895405916862162833054045025696487628399169911093 11431347206315330345415427465519638683748854917958113129169148185226269300350402446492531556265400750*300*300*400*500*600*600*600*600*600*800*800311121137651775890013501715209022202890457545.68W mmH2mmD mmL mmH1mmW mm3*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2022*18*2224*20*2428*24*2830*24*30d mm5176102152203254305337387438438489591591761021522032543053373874384895405916867372833054045025696487628399199911093114313471397206315330345415427465519638683683748917917113129169148185226269300350402402446531531265400750*300*300*500*600*600*600*600*600*600*800*8003655103222381619830970153018302010222032003200H2mmWH 1H 2DdWLH 1H 2Series TB3 Ball ValveDimensionsClass 300LB Full PortSize inWeight KgClass 300LB Reduced PortSize inWeight Kg Gear OperatorDimensionsClass 600LB Full PortSize inWeight KgClass 600 LB Reduced PortSize inGear OperatorThree-piece,split body,forged steel,side entry designThree-piece,split body,forged steel,side entry design Series TB3 Ball ValveWLH 1H 2DdH 1H 2LDdW337302332322330174140826273181665562573325371412213813212810223534362843299391525Series TTE Ball Valve Series TTE Ball ValveWH 1H 2LDd H 1H 2DmmL mm2346810121416182024385176102152203254305337388438489591H2mmW mm701101101751952802853203404104455106404004007501000*300*300*500*600*600*600*600*600*600303880150248438601625123015352135264039602412923564325596607878388899911092119413971-1/2209195240280305400435440505590700775840H1mmD mmL mm2*1-1/2*23*2*34*3*46*4*68*6*810*8*1012*10*1214*12*1416*14*1618*16*1820*18*2024*20*24d mm3851761021522032543053373874384895176102152203254305337387438489591292356432559660787838889991109211941397H2mmW mm701101101751952802853203404104455104004007501000*300*300*500*600*600*600*600*60040549921230451090210901310164024303440209195240280305400435440505590700775H1mm12345678910111213141516171819202122232425262728293031No. Part Standard Stainless Steel Sour Service Body Closure BallSeat Assembly Seat Insert Seat Ring Spring Seat Stem Shim Gasket Gasket Gasket Gland Cap Top Flange Thrust Washer Shim Bearing Bearing Vent V alve DrainRetainer Ring Retainer Ring Retainer Ring Retainer Ring Seat Spring Grounding Spring Grounding Plunger O-Ring O-Ring O-Ring O-Ring ASTM A216-WCB ASTM A105ASTM A105/ENPAssembled By No.5&6Nylon 1010 + 5% MoS2ASTM A105/ENP ASTM A105/ENP ASTM A105/ENP ASTM A182-F316316SS + Graphite 316SS + Graphite 316SS + Graphite ASTM A105ASTM A105316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2Assembly S.S.PTFE PTFE PTFE PTFEInconel X-750S.S.ASTM A182-F316NBR NBR NBR NBR ASTM A351-CF8M ASTM A182-F316ASTM A182-F316Assembled By No.5&6Nylon 1010 + 5% MoS2ASTM A182-F316ASTM A182-F316ASTM A182-F316ASTM A182-F316316SS + Graphite 316SS + Graphite 316SS + Graphite ASTM A182-F316ASTM A182-F316316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2Assembly S.S.PTFE PTFE PTFE PTFEInconel X-750S.S.ASTM A182-F316NBR NBR NBR NBR ASTM A216-WCB ASTM A105ASTM A105/ENPAssembled By No.5&6Nylon 1010 + 5% MoS2ASTM A105/ENP ASTM A105/ENP ASTM A105/ENP ASTM A182-F316316SS + Graphite 316SS + Graphite 316SS + Graphite ASTM A105ASTM A105316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2Assembly S.S.PTFE PTFE PTFE PTFEInconel X-750S.S.ASTM A182-F316NBR NBR NBR NBR ASTM A352-LCB ASTM A350-LF2ASTM A350-LF2/ENPAssembled By No.5&6Nylon 1010 + 5% MoS2ASTM A350-LF2/ENP ASTM A350-LF2/ENP ASTM A350-LF2/ENP ASTM A182-F316316SS + Graphite 316SS + Graphite 316SS + Graphite ASTM A350-LF2ASTM A350-LF2316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2316 + PTFE + MoS2Assembly S.S.PTFE PTFE PTFE PTFEInconel X-750S.S.ASTM A182-F316NBR NBR NBR NBR Low TemperatureServiceSeries TTE material specifications Top entry, trun nion mounted designDimensionsGear OperatorClass 600LB Full PortSize inWeight KgClass 600LB Reduced PortSize inWeight KgSeries TTE Ball ValveSeries TTE Ball Valve。
硬密封球阀项目建议书(总投资6000万元)(29亩)
硬密封球阀项目建议书规划设计 / 投资分析摘要说明—该硬密封球阀项目计划总投资5856.20万元，其中：固定资产投资5108.13万元，占项目总投资的87.23%；流动资金748.07万元，占项目总投资的12.77%。
达产年营业收入5845.00万元，总成本费用4395.78万元，税金及附加100.48万元，利润总额1449.22万元，利税总额1749.59万元，税后净利润1086.91万元，达产年纳税总额662.68万元；达产年投资利润率24.75%，投资利税率29.88%，投资回报率18.56%，全部投资回收期6.89年，提供就业职位86个。
严格遵守国家产业发展政策和地方产业发展规划的原则。
项目一定要遵循国家有关相关产业政策，深入进行市场调查，紧密跟踪项目产品市场走势，确保项目具有良好的经济效益和发展前景。
项目建设必须依法遵循国家的各项政策、法规和法令，必须完全符合国家产业发展政策、相关行业投资方向及发展规划的具体要求。
项目总论、项目建设背景及必要性分析、产业研究分析、项目投资建设方案、项目选址分析、项目工程设计、工艺概述、环境保护概况、项目安全保护、项目风险评估、项目节能概况、项目实施安排方案、投资方案说明、盈利能力分析、项目评价结论等。
第一章项目建设背景及必要性分析一、项目建设背景1、中国制造2025，是中国政府实施制造强国战略第一个十年的行动纲领。
《中国制造2025》提出，坚持“创新驱动、质量为先、绿色发展、结构优化、人才为本”的基本方针，坚持“市场主导、政府引导，立足当前、着眼长远，整体推进、重点突破，自主发展、开放合作”的基本原则，通过“三步走”实现制造强国的战略目标：第一步，到2025年迈入制造强国行列；第二步，到2035年中国制造业整体达到世界制造强国阵营中等水平；第三步，到新中国成立一百年时，综合实力进入世界制造强国前列。
“中国制造2025”要顺应“互联网+”的发展趋势，以信息化与工业化深度融合为主线。
进口阀门十大品牌
进口阀门品牌有哪些? 进口阀门十大品牌告诉您进口阀门品牌有哪些?相对于国内，进口阀门品牌的技术更加成熟，也更加受消费者的信赖，但同时价格也偏高。
下面，世界工厂泵阀网为大家详细介绍进口阀门十大品牌，以供选择采购。
进口阀门品牌之所以价格高，主要是由于采用了上等原材料，比小计厂家贵出数倍。
1、FISHER 费希尔费希尔阀门根据不同要求分别采用美国ANSI/API、英国BS、日本JIS、德国DIN、国标GB等标准进行设计、制造与检验。
主要产品有纯碱专用阀、陶瓷球阀、胶泥阀、氧气专用阀、气动/电动调节阀、自力式调节阀、金属硬密封球阀、高温蝶阀、空分系统蝶阀、盘阀、金属硬密封蝶阀、浓硝酸专用阀、球阀、截止阀、止回阀、平板闸阀、电站阀以及非标特殊阀门。
2、Masoneilan 梅索尼兰在阀门控制领域，梅索尼兰公司创下了多项第一：最先开发了大大简化了阀门口径的设计概念; 最先开发了控制阀顶部导向和底部导向技术; 最先研制了第一台通用控制阀(Camflex); 最先发明了用于控制阀口径计算和设计过程中能可靠地预测其噪音的方法。
3、日本kitz北泽进口阀门日本kitz北泽阀门创业于1951年，至今已成为世界屈指可数的综合阀门厂之一。
公司不仅生产一般设备用阀门以及各种工业成套设备阀门，还生产各种自动操作、测试设备用阀门。
在北泽，从铸造、锻造加工到组装，都是在严格的质量管理下进行系列化的生产。
此外，在出厂时，产品均根据公司制定的“质量保证条例”进行严格检查，因此得到世界各地用户的好评。
4、德国HANK汉克进口阀德国HANK汉克阀门于1852年创建于门兴格拉德巴赫,汉克阀门是以生产高品质、先进的阀门、测量及控制系统而享誉全球的跨国性生产企业。
在全球几十个国家拥有子公司及分支机构。
主要产品有气动阀门、给排水阀门、液压球阀、低温阀门、高温高压阀门、进口蝶阀、进口旋塞阀、进口截止阀、液压球阀、进口针型阀、进口球阀等。
5、法国OTTO阀门法国OTTO奥托阀门是欧洲地区流体控制领域的主要生产和供应商之一，公司总部位于法国拉罗，公司致力于科研开发流体控制阀门，生产流体控制设备系统，在许多个国家均有生产阀门基地。
不锈钢耐高温球阀型号参数
不锈钢耐高温球阀型号参数
不锈钢耐高温球阀是一种可以承受高温介质的阀门，常用于石化、化工、冶金等行业。
以下是一些常见的不锈钢耐高温球阀型号参数：
1. 型号：Q347F
公称压力（PN）：1.6-4.0MPa
公称通径（DN）：15-300mm
适用介质：水、蒸汽、油品、酸碱等
适用温度：-29℃～500℃
2. 型号：J41H
公称压力（PN）：1.6-6.4MPa
公称通径（DN）：15-200mm
适用介质：水、油、酸碱等
适用温度：-40℃～450℃
3. 型号：Q641F
公称压力（PN）：1.6-6.4MPa
公称通径（DN）：15-300mm
适用介质：水、蒸汽、油品、酸碱等
适用温度：-40℃～450℃
4. 型号：J61Y
公称压力（PN）：4.0-32.0MPa
公称通径（DN）：15-50mm
适用介质：水、油、酸碱、高温气体等
适用温度：-29℃～570℃
注意：以上信息仅供参考，实际使用请根据具体情况选型。
GRV硬密封球阀样本
3. Flow direction for floating mounted type is uni-directional. Trunnion mounted type is fully bi-directional with double-block-and-bleed c a p a b i l i t y.
H
153 195 213 265 153 195 213 265 168 208.5 244 275 167 208 244 275
单位Unit: mm
H1
165 204 217 235 165 204 217 235 141 167 203 242 141 167 202.5 226
Weight Kg 28 54 84 183 30 60 100 204 32 64 122 267 55 97 162 390
金属 密 封球 阀Metal Seated Ball Valves
固 定 球 阀Trunnion Type
16 填料PACKING
FLEXIBLE GRAPHITE
17 填料 压环GLAND RING A182 F304
18 填料 压盖GALND
A182 F304
材料 MATERAL
A182 F316 INCONEL X-750 A182 F316+STL A182 F316+SFNi A182 F316+STL A182 F304+GRAPHITE FLEXIBLE GRAPHITE A194 2H A193 B7 A182 F316 JIS SUS329J1 FLEXIBLE GRAPHITE A182 F316 A182 F304+GRAPHITE A182 F304 FLEXIBLE GRAPHITE A182 F304 A182 F304
纽威硬密封球阀
纽威以客户的要求为生产指导原则、以“提供 工业阀门全套解决方案”为宗旨，最终服务客户、 满足客户！
Completed Solution for Engineering Valves
谢 谢！
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
弹簧防尘保护结构：
弹簧防尘保护设计
弹簧防尘保护结构能有效地防止固体颗粒物质进入弹簧孔影响弹簧预紧功能。 固定球阀弹簧防尘保护设计
浮动球阀弹簧防尘保护设计
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
球体、阀座密封面材料、硬化方式可选
金属硬密封球阀-Lip Seal球阀
Completed Solution for Engineering Valves
NEWAY VALVE (SUZHOU) CO.,LTD.
金属硬密封球阀-Lip Seal球阀
Completed Solution for Engineering Valves
结束语 公司从设计、生产到检验均有足够的实力保证
纽威硬密封球阀的生产保证及质量控制 加工控制
数控设备一角
普通设备一角
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制 球体制造
球体的加工流程为：
•球体基体的加工 • 球体的喷涂 • 喷涂后球体的粗磨 • 喷涂后球体的精磨 • 装配前和阀座的配磨。
小于ra02球体数控磨床数控磨床控制面板completedsolutionforengineeringvalves纽威硬密封球阀的生产保证及质量控制密封面研磨球体阀座装配前密封面之间的精密配磨装配前球体和阀座在专用设备上的对磨completedsolutionforengineeringvalves纽威硬密封球阀的生产保证及质量控制球体检测高精度三坐标检测仪对球体的检验三坐标测试仪正在检验球体的圆度completedsolutionforengineeringvalves纽威硬密封球阀的生产保证及质量控制无损检测
球阀压力等级jis标准和型号
球阀压力等级JIS标准和型号
一、JIS 10K球阀
JIS 10K球阀是一种常见的球阀，其压力等级为10K，适用于各种流体管道系统。
以下是JIS 10K球阀的主要特点和型号：
1.主要特点
（1）结构简单：JIS 10K球阀的球体和阀座之间没有复杂的机械结构，使得其结构简单，易于维护和更换。
（2）密封性好：JIS 10K球阀采用金属材料制成，具有良好的密封性能，能够有效地防止流体泄漏。
（3）流量控制精确：球体的转动角度可以精确控制，从而实现对流量的精确调节。
（4）适用范围广：适用于各种流体管道系统，如气体、液体、蒸汽等。
2.型号说明
JIS 10K球阀的型号通常由以下几个部分组成：
（1）阀门类型代号：通常为“Q”表示球阀。
（2）连接形式代号：通常为“J”表示对接焊连接。
（3）压力等级代号：10K表示压力等级为10K。
（4）球体形式代号：通常为“D”表示浮动球体。
（5）阀座密封面材料代号：金属密封面用“H”表示。
二、JIS 20K球阀
JIS 20K球阀是一种高压球阀，其压力等级为20K，适用于高压流体管道系统。
以下是JIS 20K球阀的主要特点和型号：
3.主要特点
（1）耐高压性能好：由于JIS 20K球阀采用高强度材料制造，具有良好的耐高压性能，能够承受高压流体对阀门造成的冲击和压力。
（2）防爆性能强：由于其具有较好的密封性能和耐高压性能，因此可以有效地防止流体泄漏和爆炸事故的发生。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
纽威硬密封球阀的生产保证及质量控制 加工控制
数控设备一角
普通设备一角
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制 球体制造
球体的加工流程为：
•球体基体的加工 • 球体的喷涂 • 喷涂后球体的粗磨 • 喷涂后球体的精磨 • 装配前和阀座的配磨。
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制 材料控制
铸件100% 由NEWAY铸造厂提供 浇铸前化学分析、浇铸后毛坯热处理 PMI成分检测 拉伸、弯曲等机械性能试验 硬度检测、冲击测试 金相检测
Completed Solution for Engineering Valves
耐磨阀门 之 纽威金属硬密封球阀
Date:May. 10th 2007 Rev:02
Completed Solution for Engineering Valves
金属硬密封球阀概述
金属硬密封球阀适用于工况比较恶劣的情 况，它可满足于高温、高压、强腐蚀性及 含有颗粒性介质等恶劣工况；在工作状态 下，其密封安全可靠，使用寿命长，操作 方便，压力损失比较小。 由于硬密封球阀的以上诸多优点，因此， 它在管线上的应用日益广泛，也越来越受 到用户及阀门生产厂家的重视。
固定球阀
Completed Solution for Engineering Valves
纽威金属硬密封球阀结构特点
• 阀门整机采用两片式设计 • 填料采用压板压紧结构
蝶簧压紧
压板压紧
• 蝶簧压紧提供预紧比压结构
• 球体、阀座密封面硬化处理
• 阀座密封面附近弹性槽结构
浮动球阀
两片式设计
放置颗粒介质进入
密封表面处理
1）渗氮 硬度：65HRC
硬化层厚度：0.16～0.5mm
2）HVOF超音速喷涂（WC，Cr3C2）
硬度： 68~75HRC
硬化层厚度：0.2～0.25mm
3）喷焊（镍基合金、硬质合金）
硬度：53～57HRC
硬化层厚度：0.8～1.0mm
4） 堆焊（硬质合金） 硬度：38～45HRC
硬化层厚度：≥1.6mm
浮动球阀
Completed Solution for Engineering Valves
纽威金属硬密封球阀的生产范围
设计、制造：BS5351及API6D 检查、试验：API6D 温度范围：-196~600 ℃
产品范围:
尺寸 ： 压力等级： 主体材料: 内件材料: 连接形式:
2”~24” (DN50~DN600) 150LB ~ 2500LB (PN20~PN420) 锻造碳钢，不锈钢 A105+ENP, Cr13, F304, F316 手柄，齿轮，电动，气动装置
多结构解决方案
O形圈结构
填料结构
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
阀座密封面处弹性槽结构：
弹性槽设计
球体受力、受热变形，弹性槽结构能使密封面更好的贴合保证密封效果
弹性槽独特设计
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
弹簧防尘保护结构：
弹簧防尘保护设计
弹簧防尘保护结构能有效地防止固体颗粒物质进入弹簧孔影响弹簧预紧功能。 固定球阀弹簧防尘保护设计
浮动球阀弹簧防尘保护设计
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
球体、阀座密封面材料、硬化方式可选
Completed Solution for Engineering Valves
纽威金属硬密封球阀的生产范围
设计、制造：BS5351及API6D 检查、试验：API598 温度范围：-196~600℃
产品范围:
尺寸 ： 压力等级： 主体材料: 内件材料: 连接形式:
1/2”~4” (DN15~DN100) 150LB ~ 2500LB (PN20~PN420) 锻造碳钢，不锈钢 A105+ENP, Cr13, F304, F3床
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制 喷涂过程控制
密封表面的HVOF超音速喷涂处理
喷涂气源与送粉
喷涂控制
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制
纽威硬密封球阀的生产保证及质量控制 材料控制
Completed Solution for Engineering Valves
纽威硬密封球阀的生产保证及质量控制 加工控制
公司拥有加工中心、数控机床、普通机床数台，可以确保各种高精密零件 快速、有效的加工。
加工中心
Completed Solution for Engineering Valves
Completed Solution for Engineering Valves
固定球阀
三片式设计
表面硬化 弹性槽设计
阀门设计生产过程中的技术应用
- 3-维实心成型及设计 有限单元分析技术
- 机械强度分析 - 应力分析
Completed Solution for Engineering Valves
弹性槽设计
表面硬化
Completed Solution for Engineering Valves
纽威金属硬密封球阀结构特点
压板压紧
静电导出结构
• 阀门整机采用三片式锻造设计 • 可选填料密封或O-RING密封 • 防静电、防火功能 • 球体、阀座密封面超硬处理 • 阀座密封面附近弹性槽结构
放置颗粒介质进入
纽威金属硬密封球阀的技术亮点 有限元球体分析
先进的FEA保障: 通过有限元分析控制重要零件的应力及变形处于安全界限以内
球体模型
应力分布图
球体变形分布图
Completed Solution for Engineering Valves
纽威金属硬密封球阀的技术亮点
常温、高温不同结构设计 1）常温& 中温：O形圈结构 2）高温：石墨填料结构
