nagios监控mysql详细配置

Nagios监控mysql
工作原理
利用特定的用户定期访问指定的mysql数据库。

当不能访问或连不通时则报警。

配置过程如下
1、在生产库上安装nagios插件，
以nagios-plugins-1.4.15为例来讲述整个配置过程
进入nagios-plugins-1.4.15 目录
./configure 编译
然后是编译完显示一定要有mysql支持，不然没有check_mysql这个插件
config.status: creating po/Makefile
--with-apt-get-command:
--with-ping6-command: /bin/ping6 -n -U -w %d -c %d %s
--with-ping-command: /bin/ping -n -U -w %d -c %d %s
--with-ipv6: yes
--with-mysql: /usr/bin/mysql_config
--with-openssl: yes
--with-gnutls: no
--enable-extra-opts: no
--with-perl: /usr/bin/perl
--enable-perl-modules: no
--with-cgiurl: /nagios/cgi-bin
--with-trusted-path: /bin:/sbin:/usr/bin:/usr/sbin
--enable-libtap: no
Make all&&make install
插件安装完毕
再安装nrpe 安装过程略同时是编译安装三步曲：./configure make make install
2、配置mysql
mysql> create database nagios; //建立nagios专用数据
Query OK, 1 row affected (0.00 sec)
mysql> grant select on nagios.* to nagios@'%' identified by '######'; //建立nagios专用用户权限只给select就OK，给多了不安全。

###是密码
Query OK, 0 rows affected (0.00 sec)
mysql> flush privileges; //刷新权限让数据库接受新的配置
Query OK, 0 rows affected (0.00 sec)
mysql> select User,Password,Host from user;//查询一下
+--------+-----------------------------------------------------------------------+------------------------------------+
| User | Password | Host |
+--------+-----------------------------------------------------------------------+------------------------------------+
| root | *FD571203974BA9AFE270FE62151AE967ECA5E0AA | localhost |
| root | | localhost.localdomain |
| root | | 127.0.0.1 |
| | | localhost |
| | | localhost.localdomain |
| nagios | *34194D8AE12BBBCB89E1755EF0337452C18FF325 | % |
+-----------+-----------------------------------------------------------------------+--------------------------------+
6 rows in set (0.00 sec)
用以下命令来验证一下，
[root@localhost /]# /usr/local/nagios/libexec/check_mysql -H 192.168.12.88 -u nagios -d nagios -p
3j5Power
Uptime: 3552 Threads: 1 Questions: 56 Slow queries: 0 Opens: 30 Flush tables: 1 Open tables: 23 Queries per second avg: 0.15
[root@localhost /]#
3、配置nrpe.cfg
[root@localhost /]# vim /usr/local/nagios/etc/nrpe.cfg，加入下面一行
command[check_mysql]=/usr/local/nagios/libexec/check_mysql -H 192.168.12.88 -u nagios -d nagios -p ###### //后面的###代表你设的密码
4、配置nagios服务端
[root@station1 /]# vim /usr/local/nagios/etc/objects/192.168.12.88.cfg //加入如下内容
define service{
use generic-service
host_name LDS
service_description check_mysql
check_command check_nrpe!check_mysql
action_url /pnp4nagios/index.php/graph?host=$HOSTNAME$&srv=$SERVICEDESC$' class='tips' rel='/pnp4nagios/index.php/popup?host=$HOSTNAME$&srv=$SERVICEDESC$
}
//标蓝的部分是加了图形显示的设置，要是你没配置pnp4nagios这行可注掉重起nrpe 和服务端的nagios就可以了。
