汽车零部件查询系统设计说明书

交通与汽车工程学院课程设计说明书课程名称: 计算机应用基础课程设计课程代码: 6011339题目: 汽车零部件查询系统设计年级/专业/班:学生姓名:学号:开始时间: 2012 年 4 月 1 日完成时间:2012 年 4 月12 日课程设计成绩：学习态度及平时成绩（30）技术水平与实际能力（20）创新（5）说明书（计算书、图纸、分析报告）撰写质量（45）总分（100）指导教师签名：年月日目录摘要 (1)1 引言…………………………………………………………………………………………2 方案设计…………………………………………………………………………………2.汽车零部件查询模拟系统方案设计 (5)2.1.1系统功能描述 (5)2.1.2系统结构分析 (5)2.1.3系统流程分析 (5)2.2程序界面和代码设计 (6)2.2.1系统工程设计框架 (6)2.2.2系统各界面设计及代码设计 (8)3 结果分析 (33)结论 (45)致 (46)参考文献 (47)摘要随着计算机的普及,计算机高级语言已经运用到生活中的各个方面，本次课程设计使用VB语言作为开发工具，进行了汽车零部件查询系统的程序设计，该程序能实现汽车零部件查询模拟功能，进行汽车零部件的查询，修改，添加等操作，查询结果简便明了，运行界面清晰实用，操作方便，易于实际处理。

关键词：网络化计算机对策VB语言汽车零部件查询程序1 引言1.1 问题的提出随着计算机的普及，网络进入大众的家庭。

VB一种可视化的、面向对象和采用事件驱动方式的高级程序设计语言，可用于开发Windows环境下的各类应用程序。

本次课程设计主要容就是使用VB编制简单、实用的小程序，以巩固我们所学的计算机VB语言知识，提高分析问题和解决问题的能力，锻炼我们独立动手的能力。

1.2任务与分析本课题主要的目的是为了检测步进电机步距角误差，并把误差进行分析计算，最终得到一份误差数据，用误差曲线的方式在坐标上面把误差和步数结果表现出来，方便日后对误差的分析、误差的减少讨论出相应的方案…2 设计方案首先根据题目要求设计合理界面，确定哪些控件会用到，要考虑到操作的方便性和美观性。

再按题目的功能要求编写对象的事件代码，并其逐一进行调试和修改。

…2.1系统总体方案的设计2.1.1系统的驱动控制方案设计根据设计要求，程序要达到的功能如下：（1）、用随机文件建立汽车零部件和管理员的信息档案；（2）、读出汽车零部件的信息，显示在列表框中；（3）、能实现汽车零部件及管理员的信息的查询，修改，添加，删除等操作；（4）、对汽车零部件搜索。

2.1.2系统结构分析根据上面对系统功能的描述，构建出系统的总体功能结构图，如图1所示图1 系统的总体功能结构图2.1.3系统流程分析本系统运行后从欢迎（登录）界面进入主界面。

程序的主要工作流程图如图2所示。

图2系统主要流程图2.2程序界面和代码设计2.2.1系统工程设计框架在设计程序之前，应先布局整个工程。

本系统可设立一个工程文件，取名汽车零部件查询系统.vbp，该工程中包括1个模块文件，11个窗体文件，如图3所示。

图3工程容模块代码如下：Dim hType qichepj As String * 10 ljxh As String * 10 sych As String * 10 jg As String * 10fb As String * 10 rq As String * 10 dw As String * 10 End TypeDim cars As qiche Type managerbh As String * 10xb As Variantxm As Variantmm As String * 10End TypeDim pers As managerSub save()Kill App.Path + "\mag.dat"Open App.Path + "\mag.dat" For Random As #1 For i = 0 To Form4.List1.ListCount - 1pers.bh = Form4.List1.List(i)pers.xb = Form4.List2.List(i)pers.xm = Form4.List3.List(i)pers.mm = Form4.List4.List(i)Put #1, i + 1, persNext iCloseEnd SubSub xishi(p)Form10.Text5(0) = ""Form10.Text5(1) = ""Form10.Text5(2) = ""Form10.Text5(3) = ""Form10.Text5(4) = ""Form10.Text5(5) = ""Form10.Text5(0) = Form12.List1(0).List(p)Form10.Text5(1) = Form12.List1(1).List(p)Form10.Text5(2) = Form12.List1(2).List(p)Form10.Text5(3) = Form12.List1(3).List(p)Form10.Text5(4) = Form12.List1(4).List(p)Form10.Text5(5) = Form12.List1(5).List(p)End Sub2.2.2 系统各界面设计根据功能不同，在本系统中设计了11个窗体。

（1）欢迎界面欢迎界面的主要功能是让用户了解程序软件的用途（2）用户登录界面用户登录界面的功能是让管理员进入系统，防止非工作人员进入。

用户登录主界面如图5所示图5登录界面登录页面主要代码如下：Dim pers As managerPrivate Sub Command1_Click() '登录系统按钮Static t As Integerf = FalseIf Text2.Text = "" Or Text1 = "" ThenMsgBox "请填写完整的个人信息"End IfIf Text2.Text <> "" ThenOpen App.Path + "\mag.dat" For Random As #1 n = LOF(1) / Len(pers)Do While Not EOF(1)Get #1, , persIf Trim(Text2.Text) = Trim(pers.bh) Thenf = TrueForm3.ShowUnload Form2Exit DoEnd IfLoopCloseIf f = False Thent = t + 1If t < 3 ThenMsgBox "用户不存在,请重新输入！", vbOKOnly + vbInformation, "用户名错误"ElseMsgBox "重试次数已到，即将退出本系统!", vbOKOnly + vbExclamation, "用户名错误"EndExit SubEnd IfEnd IfEnd IfEnd SubPrivate Sub Command2_Click() '结束按钮EndEnd Sub（3）主界面一如图6所示主界面的功能是展示出系统软件的功能，使用户一目了然。

图6 主界面主要代码如下：Dim cars As qiche ’通用定义代码Dim a(5)Private Sub Form_Load()Frame1.Visible = FalseList2.Visible = FalseEnd SubPrivate Sub bz_Click() ’查看系统帮助Form9.ShowEnd SubPrivate Sub ss_Click() ‘搜索零件List2.Visible = TrueFrame1.Visible = TrueList2.Visible = Not List2.VisibleList2.ClearEnd SubPrivate Sub Command1_Click() ’依照零件信息对零件搜索For i = 0 To 4If Combo1(i).Text = "" ThenFor j = 0 To Form12.List1(i).ListCount - 1List3(i).AddItem Form12.List1(i).List(j)Next jElset = iCall hunt(t)End IfNext iIf Text1 <> "" And Text2 <> "" ThenCall hunt2ElseIf Text1 = "" And Text2 <> "" Then Text1 = 0: Call hunt2 ElseIf Text1 <> "" And Text2 = "" Then Text2 = 10 ^ 10: Call hunt2 ElseFor j = 0 To Form12.List1(5).ListCount - 1List3(5).AddItem Form12.List1(5).List(j)Next jEnd IfFor k = 0 To 5m = List3(k).ListCountFor j = 0 To mIf List3(k).List(j) <> "" Thena(k) = a(k) + 1End IfNext jNext kMax = a(0)For i = 1 To 5If a(i) > Max ThenMax = a(i)End IfNext iFor k = 0 To Val(Max)If List3(0).List(k) <> "" And List3(1).List(k) <> "" And List3(2).List(k) <> "" And List3(3).List(k) <> "" And List3(4).List(k) <> "" And List3(5).List(k) <> "" Then List2.AddItem List3(0).List(k) & List3(1).List(k) & List3(2).List(k) & List3(3).List(k) & List3(4).List(k) & List3(5).List(k)End IfNext kFrame1.Visible = FalseList2.Visible = TrueEnd SubSub hunt(t)For i = 0 To Form12.List1(t).ListCount - 1If Trim(Combo1(t).Text) = Trim(Form12.List1(t).List(i)) ThenList3(t).AddItem Form12.List1(t).List(i), iElseList3(t).AddItem "", iEnd IfNext iEnd SubSub hunt2()For i = 0 To List1(5).ListCount - 1If Val(Text1) < Val(List1(5).List(i)) And Val(Text2) > Val(List1(5).List(i)) Then List3(5).AddItem List1(5).List(i), iElseList3(5).AddItem "", iEnd IfNext iEnd SubPrivate Sub Command2_Click() ‘退出搜索零部件Frame1.Visible = FalseEnd SubPrivate Sub glsj_Click() ‘打开管理员数据管理功能Form4.ShowEnd SubPrivate Sub bk_Click() ‘表框式查询零部件Form10.ShowForm10.Frame1.Visible = TrueEnd SubPrivate Sub kp_Click() ‘卡片式查询零部件Form10.ShowForm10.Frame2.Visible = TrueEnd SubPrivate Sub ljgl_Click() ‘打开零部件数据管理功能Form12.ShowEnd SubPrivate Sub tc_Click() ‘退出系统EndEnd Sub（4）主界面二如图7所示图7 主界面主要代码如下：1．卡片式零件查询：Dim q（1).查看上一个零件的代码如下:Private Sub Command1_Click()Static q As IntegerIf q = -1 Then q = List2.ListCount - 1p = Val(List2.List(q))Call xishi(p)q = q - 1End Sub（2）查看下一个零件代码如下：Private Sub Command2_Click()Static q As IntegerIf q > List2.ListCount - 1 Then q = 0p = Val(List2.List(q))Call xishi(p)q = q + 1Command1.Enabled = TrueEnd Sub（3）退出卡片式查询代码如下：Private Sub Command3_Click()Form3.ShowUnload MeEnd Sub（4）查看第一个零件代码如下：Private Sub Command4_Click()p = Val(List2.List(0))Call xishi(p)End Sub（5）查看最后一个零件代码如下：Private Sub Command5_Click()p = Val(List2.List(List2.ListCount - 1)) Call xishi(p)End Sub（6）卡片式配件框发生改变代码如下：Private Sub Text3_Change()List2.ClearFor i = 0 To Form12.List1(0).ListCount - 1If Text3 <> "" And Text4 = "" ThenIf Trim(Text3) = Trim(Form12.List1(0).List(i)) ThenList2.AddItem iEnd IfEnd IfIf Text3 <> "" And Text4 <> "" ThenIf Trim(Form12.List1(0).List(i)) = Trim(Text3) And Trim(Form12.List1(1).List(i)) = Trim(Text4) ThenList2.AddItem iEnd IfEnd IfNext iIf List2.ListCount > 0 ThenList2.ListIndex = 0p = Val(List2.Text)Call xishi(p)ElseText5(0) = ""Text5(1) = ""Text5(2) = ""Text5(3) = ""Text5(4) = ""Text5(5) = ""End IfIf List2.ListCount > 1 Then Command2.Enabled = TrueEnd Sub（7）卡片式零件型号框发生改变代码如下：Private Sub Text4_Change()List2.ClearFor i = 0 To Form12.List1(0).ListCount - 1If Text4 <> "" And Text3 = "" ThenIf Trim(Text4) = Trim(Form12.List1(1).List(i)) ThenList2.AddItem iEnd IfEnd IfIf Text3 <> "" And Text4 <> "" ThenIf Trim(Form12.List1(0).List(i)) = Trim(Text3) And Trim(Form12.List1(1).List(i)) = Trim(Text4) ThenList2.AddItem iEnd IfEnd IfNext iIf List2.ListCount > 0 ThenList2.ListIndex = 0p = Val(List2.Text)Call xishi(p)ElseText5(0) = ""Text5(1) = ""Text5(2) = ""Text5(3) = ""Text5(4) = ""Text5(5) = ""End IfIf List2.ListCount > 1 Then Command2.Enabled = TrueEnd Sub2.列表框式零件查询：（1）列表框式配件框发生改变代码如下：Private Sub Text1_Change()List1.ClearList1.AddItem "配件" & " " & " " & "零件型号" & " " & " " & "适用车型" & " " & " " & " " & " " & "发布日期" & " " & " " & " " & "单位" & " " & " " & " " & " " & " " & "价格"For i = 0 To Form12.List1(0).ListCount - 1If Text1 <> "" And Text2 = "" ThenIf Trim(Form12.List1(0).List(i)) = Trim(Text1) ThenList1.AddItem Form12.List1(0).List(i) & Form12.List1(1).List(i) & Form12.List1(2).List(i) & Form12.List1(3).List(i) & Form12.List1(4).List(i) & Form12.List1(5).List(i)End IfEnd IfIf Text1 <> "" And Text2 <> "" ThenIf Trim(Form12.List1(0).List(i)) = Trim(Text1) And Trim(Form12.List1(1).List(i)) = Trim(Text2) ThenList1.AddItem Form12.List1(0).List(i) & Form12.List1(1).List(i) & Form12.List1(2).List(i) & Form12.List1(3).List(i) & Form12.List1(4).List(i) & Form12.List1(5).List(i)End IfEnd IfNext iEnd Sub（2）列表框式零件型号框发生改变代码如下：Private Sub Text2_Change()List1.ClearList1.AddItem "配件" & " " & " " & "零件型号" & " " & " " & "适用车型" & " " & " " & " " & " " & "发布日期" & " " & " " & " " & "单位" & " " & " " & " " & " " & " " & "价格"For i = 0 To Form12.List1(0).ListCount - 1If Text1 = "" And Text2 <> "" ThenIf Trim(Form12.List1(1).List(i)) = Trim(Text2) ThenList1.AddItem Form12.List1(0).List(i) & Form12.List1(1).List(i) & Form12.List1(2).List(i) & Form12.List1(3).List(i) & Form12.List1(4).List(i) & Form12.List1(5).List(i)End IfEnd IfIf Text1 <> "" And Text2 <> "" ThenIf Trim(Form12.List1(0).List(i)) = Trim(Text1) And Trim(Form12.List1(1).List(i)) = Trim(Text2) ThenList1.AddItem Form12.List1(0).List(i) & Form12.List1(1).List(i) & Form12.List1(2).List(i) & Form12.List1(3).List(i) & Form12.List1(4).List(i) & Form12.List1(5).List(i)End IfEnd IfNext iEnd Sub（5）主界面三如图8所示图8 主界面主要代码如下:Dim cars As qiche ‘通用代码Dim a(5)（1）修改零件代码如下：Private Sub Command1_Click()If List1(0).Text = "" ThenMsgBox "请选择要修改的零件"ElseForm7.ShowForm7.Text1 = List1(0).TextForm7.Text2 = List1(1).TextForm7.Text3 = List1(2).TextForm7.Text4 = List1(3).TextForm7.Text5 = List1(4).TextForm7.Text6 = List1(5).TextList1(0).RemoveItem List1(0).ListIndexList1(1).RemoveItem List1(1).ListIndexList1(2).RemoveItem List1(2).ListIndexList1(3).RemoveItem List1(3).ListIndexList1(4).RemoveItem List1(4).ListIndexList1(5).RemoveItem List1(5).ListIndexEnd IfEnd Sub（2）添加零部件代码如下：Private Sub Command2_Click()Form8.ShowEnd Sub（3）删除零部件代码如下：Private Sub Command3_Click()List1(0).RemoveItem List1(0).ListIndexList1(1).RemoveItem List1(1).ListIndexList1(2).RemoveItem List1(2).ListIndexList1(3).RemoveItem List1(3).ListIndexList1(4).RemoveItem List1(4).ListIndexList1(5).RemoveItem List1(5).ListIndexEnd Sub（3）退出零部件查询系统代码如下：Private Sub Command4_Click()Form3.ShowUnload MeEnd Sub（4）打开窗体运行代码如下：Private Sub Form_Load()Open App.Path + "\car.dat" For Random As #2 Do While Not EOF(2)i = i + 1Get #2, i, carsList1(0).AddItem cars.pjList1(1).AddItem cars.ljxhList1(2).AddItem cars.sychList1(3).AddItem cars.fbList1(4).AddItem cars.dwList1(5).AddItem cars.jgLoopCloseEnd SubPrivate Sub List1_Click(Index As Integer) ‘点击零部件显示属性Select Case IndexCase 0List1(5).ListIndex = List1(0).ListIndexList1(4).ListIndex = List1(0).ListIndexList1(3).ListIndex = List1(0).ListIndexList1(2).ListIndex = List1(0).ListIndexList1(1).ListIndex = List1(0).ListIndexCase 1List1(5).ListIndex = List1(1).ListIndexList1(4).ListIndex = List1(1).ListIndexList1(3).ListIndex = List1(1).ListIndexList1(2).ListIndex = List1(1).ListIndexList1(0).ListIndex = List1(1).ListIndexCase 2List1(5).ListIndex = List1(2).ListIndexList1(4).ListIndex = List1(2).ListIndexList1(3).ListIndex = List1(2).ListIndexList1(0).ListIndex = List1(2).ListIndexList1(1).ListIndex = List1(2).ListIndexCase 3List1(5).ListIndex = List1(3).ListIndexList1(4).ListIndex = List1(3).ListIndexList1(0).ListIndex = List1(3).ListIndexList1(2).ListIndex = List1(3).ListIndexList1(1).ListIndex = List1(3).ListIndexCase 4List1(5).ListIndex = List1(4).ListIndexList1(0).ListIndex = List1(4).ListIndexList1(3).ListIndex = List1(4).ListIndexList1(2).ListIndex = List1(4).ListIndexList1(1).ListIndex = List1(4).ListIndexCase 5List1(0).ListIndex = List1(5).ListIndexList1(4).ListIndex = List1(5).ListIndexList1(3).ListIndex = List1(5).ListIndexList1(2).ListIndex = List1(5).ListIndexList1(1).ListIndex = List1(5).ListIndexEnd SelectEnd Sub（6）主界面四如图9所示图9 主界面主要代码如下：（1）添加零部件代码如下：Private Sub Command1_Click()If Combo1(0).Text <> "" And Combo1(1).Text <> "" And Combo1(2).Text <> "" And Combo1(3).Text <> "" And Combo1(4).Text <> "" And Text1 <> "" Then Form3.List1(0).AddItem Combo1(0).TextForm3.List1(1).AddItem Combo1(1).TextForm3.List1(2).AddItem Combo1(2).TextForm3.List1(3).AddItem Combo1(3).TextForm3.List1(4).AddItem Combo1(4).TextForm3.List1(5).AddItem Text1Call save2Form3.ShowUnload MeElseMsgBox "请写入完整的信息！"End IfEnd Sub（2）退出添加零部件页面代码如下：Private Sub Command2_Click()Form3.ShowUnload MeEnd Sub（7）主界面五如图10所示图10 主界面主要代码如下：（1）添加个人信息代码如下：Private Sub Command1_Click()Form5.ShowEnd Sub（2）删除个人信息代码如下：Private Sub Command2_Click()List1.RemoveItem List1.ListIndex List2.RemoveItem List2.ListIndex List3.RemoveItem List3.ListIndex List4.RemoveItem List4.ListIndex Call saveEnd Sub（1）修改个人信息代码如下：Private Sub Command3_Click()If List1.Text = "" ThenMsgBox "请选择修改对象"ElseForm6.ShowForm6.Text1 = List1.TextForm6.Text2 = List3.Textbo1.Text = List2.Text List1.RemoveItem List1.ListIndexList2.RemoveItem List2.ListIndexList3.RemoveItem List3.ListIndexList4.RemoveItem List4.ListIndexEnd IfEnd Sub（4）退出个人信息窗口代码如下：Private Sub Command4_Click()Form3.ShowUnload MeEnd Sub（5）打开个人信息窗口运行代码如下：Private Sub Form_Load()i = 0Open App.Path + "\mag.dat" For Random As #1 Do While Not EOF(1)i = i + 1Get #1, i, persList1.AddItem pers.bh, i - 1List2.AddItem pers.xb, i - 1List3.AddItem pers.xm, i - 1List4.AddItem pers.mm, i - 1LoopCloseEnd SubPrivate Sub List1_Click()List2.ListIndex = List1.ListIndex List3.ListIndex = List1.ListIndex List4.ListIndex = List1.ListIndex End SubPrivate Sub List2_Click()List1.ListIndex = List2.ListIndex List3.ListIndex = List2.ListIndex List4.ListIndex = List2.ListIndex End SubPrivate Sub List3_Click()List1.ListIndex = List3.ListIndex List2.ListIndex = List3.ListIndex List4.ListIndex = List3.ListIndex End SubPrivate Sub List4_Click()List1.ListIndex = List4.ListIndex List2.ListIndex = List4.ListIndexList3.ListIndex = List4.ListIndexEnd Sub（8）主界面六如图11所示图11 主界面主要代码如下：Dim pers As managerPrivate Sub Form_Load()Text3 = ""End SubPrivate Sub Command1_Click() ‘确定添加按钮If Text1 = "" Or Text2 = "" Or Text3 = "" Or Combo1.Text = "" Then MsgBox "请输入完整的信息"Text1.SetFocusExit SubEnd IfIf Text1 <> "" And Text2 <> "" And Text3 <> "" And Combo1.Text <> "" Then Form4.List1.AddItem Text1Form4.List2.AddItem Combo1.TextForm4.List3.AddItem Text2Form4.List4.AddItem Text3Call saveEnd IfForm4.ShowUnload MeEnd SubPrivate Sub Command2_Click() ‘退出按钮Form4.ShowUnload MeEnd Sub（9）主界面七如图12所示图12 主界面3 结果分析单击“确定”按钮，运行结果见图1所示图1用户登录单击“搜索”按钮，运行结果见图2所示。
