欧规插脚尺寸
欧洲插头插座标准)1
前言欧共体和欧洲自由联盟技术标准协调局已颁布法令:决定在1994年内设计出欧洲通用的电源插头和插座.以取代目前二十多种不统一的电源接插件;同时与国际电气化标准委员会(正C)的标准接轨。
新的电源插头和插座将以IEc906~l为基础。
官方预计,这个标准的转换过程将需10年.同时告知：凡向欧洲出口的电源插头插座,必需服从新标准的实施。
总的出自CEE7，欧盟EN50075《插头插脚尺寸标准，类似于中国插头插座型式尺寸标准》，各个国家都有自己标准编号，例法国NF C61-304,NF C61-303,NF C61-316;德国DIN49441,DIN49406,DIN49446,DIN VDE0620;荷兰NEN1020;葡萄牙NP1260等等一般欧式插头首先做VDE认证，并且采用法德两用插头，中间孔为法式插座使用，两边铜极为德式插座使用，故认证采用德国标准，然后法标，可以一次申请，多国认证，这样其它认证只做差异部分，这是三芯单相两极带双接地插头，二芯就比较简单，欧盟国家基本相同。
欧洲插头有几种模式,我记得大概有以下几种模式:双脚圆型\双脚圆型\双脚圆型+接地孔对应的标准我只知道一个是EN50075,其他两个是多少,请高手指点!DIN VDE 0620或者IEC 60884欧式插头（两圆）说明:欧标插头（两圆）的制造标准按CE标准执行。
欧标插头在德国、奥地利、荷兰、瑞典、挪威、芬兰、俄罗斯等大部分欧洲国家使用，由于这个标准在整个欧洲普遍使用，我们把它称为是“欧洲大陆”的标准。
插头是两个圆柱，跨距为19mm,接地级是通过两侧插头接地完成的。
中欧和东欧CEE7 / 7欧式插头有嵌入式插脚，法国和比利时插座与之相似。
在欧洲标准插座电气参数是10A-16A 230ACV交流电源。
欧标插座是世界上最安全的插座，接地最特殊主要是考虑人得安全。
因此也是世界上使用最广泛的插头标准。
注：意大利标插头是三圆柱一条线，丹麦标和瑞士标插头是三圆柱成三角形状，都是有直接接地级插脚。
各国插脚标准
Measured (mm)
澳规插脚尺寸要求之一
澳规插脚尺寸要求之二
阿规插脚尺寸要求之一
阿规插脚尺寸要求之二
Symbol
Requirement (mm)
A
8.0 min.
B
7.92
C
7.92
D
6.86
E
6.86
F
60
G
60
Measured (mm)
Symbol H I J K L M N
Requirement (mm) 1205 13.72 6.25 6.25
美规/墨西哥规插脚尺寸要求之一
尺寸没有标明公差的数字以±0.005为公差,所有单位均为inch; 标注角度的地方没有注明公差的以±1度为公差;
美规/墨西哥规插脚尺寸要求之二
尺寸没有标明公差的数字以±0.005为公差,所有单位均为inch; 标注角度的地方没有注明公差的以±1度为公差;
韩规插脚尺寸要求之一
课堂公约
请将手机调整至静音状态 积极回应、大胆参与
我们将要掌握的内容
一般常用有哪些插脚方式 各种插脚方式的尺寸要求如何
我们将要掌握的内容
一般插脚方式
欧规、英规、美规、韩规、日规、中 规、澳规、阿规共八种
欧规插脚尺寸要求之一
欧规插脚尺寸要求之二
英规插脚尺寸要求之一
英规插脚尺寸要求之二
韩规插脚尺寸要求之二
日规插脚尺寸要求之一
日规插脚尺寸要求之二
日规插脚尺寸要求之三
日规插脚尺寸要求之四
中规插脚尺寸要求之一
中规插脚尺寸要求之二
Symbol
A B C D
Requirement (mm)
1.4 ~ 1.5 6.18 ~ 6.4 12.565 ~ 12.835 15.65 ~ 16.35
2020最新世界各国安规插头尺寸标准(WORD版)
Appendix 1HGIJError! Reference source not found. page 1 of 1(澳规)Australia integrated plug according to AS/NZS 3112:2000 for AU type2.8 TABLE: Australia plug dimension according to AS 3112 figure 2.1 C & E P Part No.DimensionsLimit MeasuredPass/FailDistance from projection part edge to L and N pins9mm min. A Width of live pin6.35 ± 0.15mm CThick of live pin metal part 1.58 to 1.78mm Thick of live pin insulated part1.58 to 1.78mm D Pin center to plug center 7.92mm F Length of live pin17.06 ± 0.4mm F Length of live pin insulated part 8.7 ± 0.5mm G Length of plug base >27.0mm or <21.9mm H Length of plug base >27.0mm or <21.9mm ILength of plug base>27.0mm or <21.9mmAppendix 1Error! Reference sourcepage 2 of 2not found.(澳规)Australia integrated plug according to AS/NZS 3112:2000 for AU typeAppendix 2Error! Reference sourcepage 1 of 1not found.(英规)British integrated plug according to BS 1363 for UK type12. TABLE: BSI plug dimension according to BS 1363 figure 4 PDimensions Limit Measured Pass/Fail PartNo.R9.5mm min.Distance from projection part edge to L and NpinsA Width of live pin 6.22 to 6.48mmB Width of ground pin 7.8 to 8.05mmC Length of live pin 17.2 to 18.2mmD Length of ground pin 22.23 to23.23mmE Thickness of live pin 3.9 to 4.05mmAppendix 2Error! Reference sourcepage 2 of 2not found.(英规)British integrated plug according to BS 1363 for UK typeAppendix 3Error! Reference sourcepage 1 of 1not found.(欧规)European integrated plug according to EN 50075 for EU type7 DimensionsPlugs shall comply with Standard Sheet 1Between two pins (pin base) 18.0-19.2mmBetween two pins (pin top) 17.0-18.0mmDiameter of pin (metallic part) 4±0.06mmDiameter of pin (pin base) max. 4.0mmDiameter of pin (middle part) max. 3.8mmPin length 19±0.5mmLength of pin except metal part 10+ 1.0mmAppendix 3Error! Reference sourcepage 2 of 2not found.(欧规)European integrated plug according to EN 50075 for EU typeAppendix 4page 1 of 1(中国规)China integrated plug according to GB-1002 for CN type3 TABLE: China plug dimension according to GB1002 figure 1 PDimensions Limit Measured Pass/Fail PartNo.Distance from projection part edge to L and N pins 6.5mm min.b Width of live pin 6.4-0.22 mmt Thickness of live pin 1.5-0.15 mme1 Length of live pin 16 ±0.35mmPin center to pin center 12.7±0.135mmNote:*1) the detachable integrated plug is installed in the AC/DC adapter during the measurement.Appendix 5page 1 of 1Argentina integrated plug according to IRAM 2063 for AR type Pin dimension and marking requirements:Appendix 5page 2 of 2Argentina integrated plug according to IRAM 2063 for AR typeAppendix 6EADCKG HF J IBpage 1 of 1Korea integrated plug according to KSC 8305 for KR typeTABLE: Korea plug dimension according to KSC8305 A RadiusR5+1mm D Between two pins19±0.2mm H Diameter of pin (metallic part) 4.8±0.06mmF Diameter of pin (pin base) 4.6±0.2mmG Diameter of pin (middle part) 4.3mm I Pin length19± 0.5mm J Length of pin except metal part 10+ 1.0mmShape of pin topChamfered or roundRound shapePAppendix 6page 2 of 2Korea integrated plug according to KSC 8305 for KR typeAppendix 7page 1 of 1(美规)North American integrated plug according to NEMA 1-15 P for US type1.5.2 TABLE: US plug dimension according to NEMA 1-15P (non polarity) P PartDimensions Limit (mm) Measured (mm) Pass/Fail No.A Thickness of live pin 1.40-1.65B Width of live pin 6.10-6.60C Distance between two live pins (centre) 12.70±0.127D Distance between hole and plug face (if13.77±0.127hole used)E Outer diameter of hole (if hole used) 3.96±0.127F Inner diameter of hole (if hole used) 3.18±0.127H Length of live pins 15.88-18.24。
各国插脚标准
Appendix 1Error! Reference source not found.page 1 of 1(澳规)Australia integrated plug according to AS/NZS 3112:2000 for AU type2.8 TABLE: Australia plug dimension according to AS 3112 figure 2.1 C & E P Part No.DimensionsLimit MeasuredPass/FailDistance from projection part edge to L and N pins9mm min. A Width of live pin6.35 ± 0.15mm Thick of live pin metal part 1.58 to 1.78mm CThick of live pin insulated part1.58 to 1.78mm D Pin center to plug center 7.92mm F Length of live pin17.06 ± 0.4mm F Length of live pin insulated part 8.7 ± 0.5mm G Length of plug base >27.0mm or <21.9mm H Length of plug base >27.0mm or <21.9mm ILength of plug base>27.0mm or <21.9mmGHI JAppendix 1Error! Reference source not found.page 2 of 2(澳规)Australia integrated plug according to AS/NZS 3112:2000 for AU type J Length of plug base >27.0mm or<21.9mmRadial of plug projection part R 21mm max.Height of plug projection part 8.6mm min.Note:*1) the detachable integrated plug is installed in the AC/DC adapter during the measurement.Appendix 2Error! Reference source not found.page 1 of 1(英规)British integrated plug according to BS 1363 for UK type12. TABLE: BSI plug dimension according to BS 1363 figure 4 P PartNo.Dimensions Limit Measured Pass/FailDistance from projection part edge to L and NpinsR9.5mm min.A Width of live pin 6.22 to 6.48mmB Width of ground pin 7.8 to 8.05mmC Length of live pin 17.2 to 18.2mmD Length of ground pin 22.23 to23.23mmE Thickness of live pin 3.9 to 4.05mmAppendix 2Error! Reference source not found.page 2 of 2(英规)British integrated plug according to BS 1363 for UK typeF Thickness of ground pin 3.9 to 4.05mmG Length of live pin except metal part 9.5mm max.H Length of live pin except insulated part9.2mm maxI Width of pin end chamfer 1.2 to 2.0mmJ Length of pin end chamfer 1.35 to 1.85mmK Length between live pin to ground pin 22.1 to 22.36mmL Length between live pin to ground pin 11.05 to11.18mmM Length of plug base 25.37mm max.N Length of plug base edge to live pin 34.6mm max.O Height of plug base 6.35mm min.Appendix 3Error! Reference source not found.page 1 of 1(欧规)European integrated plug according to EN 50075 for EU type7 DimensionsPlugs shall comply with Standard Sheet 1Between two pins (pin base) 18.0-19.2mmBetween two pins (pin top) 17.0-18.0mmDiameter of pin (metallic part) 4± 0.06mmDiameter of pin (pin base) max. 4.0mmDiameter of pin (middle part) max. 3.8mmPinlength 19± 0.5mm Length of pin except metal part 10+ 1.0mmAppendix 3Error! Reference source not found.page 2 of 2(欧规)European integrated plug according to EN 50075 for EU typeShape of pin top Chamfered orroundRound shape P Length of plug base 35.3± 0.7mm Width of plug base 13.7± 0.7mm Diagonal dimension of plug base26.1± 0.5mm Height of plug projection part 18-0.0mmAppendix 4page 1 of 1(中国规)China integrated plug according to GB-1002 for CN type3TABLE: China plug dimension according to GB1002 figure 1 P Part No.DimensionsLimit MeasuredPass/FailDistance from projection part edge to L and N pins6.5mm min. b Width of live pin 6.4-0.22 mm t Thickness of live pin 1.5-0.15 mm e1 Length of live pin 16 ± 0.35mm Pin center to pin center12.7± 0.135mmNote:*1) the detachable integrated plug is installed in the AC/DC adapter during the measurement.Appendix 5page 1 of 1Argentina integrated plug according to IRAM 2063 for AR typePin dimension and marking requirements:LocationRequirementMeasuredVerdictMarking of neutral with NNDistance from edge to L and N pins min. 8 mmmmDistance between pin center 13.72±0.1mm mmpage 2 of 2Argentina integrated plug according to IRAM 2063 for AR typePin length 18.2±0.2 mm mm Pin width 6.25±0.1 mm mm Pin thickness 1.55±0.07 mm mm Pin center to plug center 7.92±0.1 mm mm One half distance of pin center to pin6.86±0.1 mm mm centerPin angle 120°±5´Ending of the contact pins be rounded Fig. 1a or 1bAppendix 6page 1 of 1Korea integrated plug according to KSC 8305 for KR typeTABLE: Korea plug dimension according to KSC8305A Radius R5+1mm D Between two pins 19±0.2mm H Diameter of pin (metallic part) 4.8± 0.06mmF Diameter of pin (pin base) 4.6±0.2mmG Diameter of pin (middle part) 4.3mmI Pinlength 19± 0.5mm J Length of pin except metal part 10+ 1.0mmShape of pin top Chamfered orround Round shape PABC DEFG HIJKpage 2 of 2Korea integrated plug according to KSC 8305 for KR typeC Length of plug base 35.3± 0.7mm E Width of plug base 13.7± 0.7mm B Diagonal dimension of plug base26.1± 0.5mmK Height of plug projection part 4mm min.Appendix 7page 1 of 1(美规)North American integrated plug according to NEMA 1-15 P for US type1.5.2 TABLE: US plug dimension according to NEMA 1-15P (non polarity) PDimensions Limit (mm) Measured (mm) Pass/Fail PartNo.A Thickness of live pin 1.40-1.65B Width of live pin 6.10-6.60C Distance between two live pins (centre) 12.70±0.127D Distance between hole and plug face (if13.77±0.127hole used)E Outer diameter of hole (if hole used) 3.96±0.127F Inner diameter of hole (if hole used) 3.18±0.127H Length of live pins 15.88-18.24。
各国插脚标准
D
15.65 ~ 16.35
澳规插脚尺寸要求之一
澳规插脚尺寸要求之二
阿规插脚尺寸要求之一
阿规插脚尺寸要求之二
Symbol Requirement (mm) Measured (mm) Symbol Requirement (mm) Measured (mm) A 8.0 min. H 1205
欧规插脚尺寸要求之一
欧规插脚尺寸要之二
美规/墨西哥规插脚尺寸要求之一
尺寸没有标明公差的数字以±0.005为公差,所有单位均为inch; 标注角度的地方没有注明公差的以± 1度为公差;
美规/墨西哥规插脚尺寸要求之二
尺寸没有标明公差的数字以±0.005为公差,所有单位均为inch; 标注角度的地方没有注明公差的以± 1度为公差;
韩规插脚尺寸要求之一
韩规插脚尺寸要求之二
日规插脚尺寸要求之一
日规插脚尺寸要求之二
日规插脚尺寸要求之三
日规插脚尺寸要求之四
中规插脚尺寸要求之一
中规插脚尺寸要求之二
Symbol Requirement (mm) Measured (mm)
A
1.4 ~ 1.5
B
6.18 ~ 6.4
C
12.565 ~ 12.835
安规插脚尺寸要求
安规插脚尺寸要求介绍
讲 解 人：pingping.Guo 2009年8月
课堂公约
请将手机调整至静音状态 积极回应、大胆参与
我们将要掌握的内容
一般常用有哪些插脚方式 各种插脚方式的尺寸要求如何
我们将要掌握的内容
一般插脚方式
欧规、英规、美规、韩规、日规、中 规、澳规、阿规共八种
B
7.92
I
欧规插头标准
欧规插头标准欧规插头标准，即欧洲规定的插头和插座的标准，是欧洲国家用于家用电器、工业设备等电气设备的标准规定。
欧规插头标准的制定，旨在保障电器设备的安全性、互换性和可靠性，为用户提供安全可靠的电气使用环境。
欧规插头标准的内容主要包括插头和插座的设计、尺寸、材料、接线方法、绝缘等方面的规定。
在欧规插头标准中，对于不同类型的插头和插座，有着详细的规定和要求，以确保各种类型的电器设备都能够安全地使用。
在欧规插头标准中，最常见的是欧洲标准C型插头和F型插头。
C型插头是欧洲最常见的两脚圆形插头，适用于欧洲大部分国家；F型插头是带有接地针的两脚插头，适用于德国、奥地利、荷兰、瑞典等国家。
这两种插头都符合欧规插头标准的要求，保证了插头和插座的互换性和安全性。
欧规插头标准的制定不仅对欧洲国家内部的电器设备有着重要意义，同时也对国际间的贸易和合作有着积极的影响。
由于欧规插头标准的统一，各国的电器设备可以在欧洲范围内自由流通和使用，为国际贸易和合作提供了便利条件。
在实际生活中，我们经常会遇到使用欧规插头标准的电器设备。
因此，了解欧规插头标准对于我们正确选择和使用电器设备至关重要。
在购买电器设备时，我们应该注意选择符合欧规插头标准的产品，以确保其安全性和可靠性。
此外，对于需要在欧洲国家使用电器设备的人员来说，了解欧规插头标准也是非常必要的。
在使用电器设备时，我们应该按照标准规定正确插拔插头，保证电器设备的安全使用。
总之，欧规插头标准对于保障电器设备的安全性和可靠性起着至关重要的作用。
作为消费者和用户，我们应该了解并遵守欧规插头标准，选择和使用符合标准要求的电器设备，以确保我们的生活和工作环境的安全和可靠。
同时，欧规插头标准的统一也为国际贸易和合作提供了便利条件，促进了各国之间的交流与合作。
希望本文对大家对欧规插头标准有所了解，谢谢阅读。
各国插脚安规尺寸标准
目录1、VDE欧规胶壳插脚：标准-EN50075/IEC600832、BS英规胶壳插脚：标准-BS13633、SAA澳规胶壳插脚：标准-AS/NZS31124、UL美规胶壳插脚：标准-ANSI-NEMA WD65、CCC中国规胶壳插脚：标准-GB1002-20086、Korea韩国胶壳插脚：标准-KSC83057、Brasil巴西规胶壳插脚：NBR141368、India印度胶壳插脚：标准IS12939、Argentina阿根廷胶壳插脚：IRAM206310、SASO沙特胶壳插脚：SASO-220311、JAPAN日本胶壳插脚：JISC830312、小南非规胶壳插脚：SABS164-1修订记录2013-10-15修改：1、GB1002-2008版CCC插脚（厚1.4-1.5mm）增加插头插销离边沿的距离不小于6.5mm。
2、增加日规插脚安规尺寸图表，日规插脚（厚1.4-1.6mm）备注“L"的尺寸要求不大于0.9mm，及插头插销离边沿的距离不小于5.1mm。
3、修改美规插脚安规尺寸，美规插脚（厚1.40-1.65mm），备注插头插销离边沿的距离不小于5.1mm.。
4、插脚图示缩小2PIN欧洲插脚Two-pin plugs f(Up to2.5A rating)EN50075/IEC60083-C5/CEE7/DIN49464P≥4.0,Q≥18.0,I：金属下部结合部分边缘应光滑钝化,不得尖锐刺手.此插脚适应国家包括:德国,俄罗斯,以色列英国插脚UK Plug Checking Form according to Figure 4of BS1363BS-3Symbol Requirement(mm)Symbol Requirement (mm)Symbol Requirement(mm)Symbol Requirement(mm)A 25.37max.I 22.10-22.36Q 17.2-18.2Y 1.2-2.0B25.37max.J 22.23-23.23R 6.22-6.48Z R 0.1-1.0C34.6max.K 1.35-1.85S 3.90-4.05a 58︒-62︒D11.05-11.18L 7.80-8.05T 6.22-6.48b 1.35-1.85E11.05-11.18M 58︒-62︒U 6.35min.c 58︒-62︒FR 15min.N 3.90-4.05V 60︒-80︒d 1.35-1.85GR 9.5min.O 9.2max.W 1.35-1.85e 0.2max.H R 9.5min.P 9.5max.X 3.90-4.05f 1.35-1.85此插脚适应国家包括:英国、新加坡、马来西亚Grounding pin澳规插脚AS/NZS3112Standard sheet Figure 2.1(a1)or 2.1(c)Standard sheet Figure 2.1(e)and fig 2.4PositionRequired (mm)By Measurement (mm)By the gauges in Figure A1A6.35±0.15-B6.35±0.15C+0.150.051.63--D7.92--E10.31--F17.06±0.4-G19.94±0.81、2、3、421.9max.or 27.0min.-5、660︒--78.6min.-821.0max.-920.0±1.0-101.0max -118.7±0.5-Distance fromprojection part edge toL and N pins 9mm min.美国插脚UL插脚：According toUL1310/UL498/UL817/UL1659/ANSI-NEMA WD6-2002Figure1-15备注：关于电源插墙式插脚（UL1310)中7.16条款要求：起始于金属插脚的任意一点，与金属插脚的托台圆周边之间的距离不得小于5.1mm。
2013.10.OK-各国插脚安规尺寸标准
Symbol I J K L M N O P
Requirement (mm) 22.10-22.36 22.23-23.23 1.35-1.85 7.80-8.05 58-62 3.90-4.05 9.2 max. 9.5 max.
Symbol Q R S T U V W X
Requirement (mm) 17.2-18.2 6.22-6.48 3.90-4.05 6.22-6.48 6.35 min. 60-80 1.35-1.85 3.90-4.05
小南非插脚
Symbol
Requirement (mm)
Measured (mm)
Symbol
Requirement (mm)
Measured (mm)
B C D E F G ① ② ③
25.5 - 26.5 90 - 92 R 5.0 – 6.0 35.0 – 36.0 13.0 – 14.4 18.8 – 19.2 > 14 mm See above See above
Symbol Y Z a b c d e f
Requirement (mm) 1.2-2.0 R 0.1-1.0 58-62 1.35-1.85 58-62 1.35-1.85 0.2 max. 1.35-1.85
此插脚适应国家包括:英国、新加坡、马来西亚
澳规插脚 AS/NZS3112
Standard sheet Figure 2.1 (a1) or 2.1(c)
22.22±0.15 19.1±0.15 7.010-7.085 5.030-5.105 15.77-16.94 20.47-21.64 ≥7.94
28.6±0.15 25.4±0.15 8.660-8.735 7.010-7.085 20ห้องสมุดไป่ตู้47-21.64 28.47-29.64 ≥9.52
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
Locations Size (mm) Tolerance
(mm)
a 45°--
b 26,1 ±0,5
c 5,0 +1
d 35,3 ±0,7
e 13,7 ±0,7
f 18 – 19,2 --
g 17 – 18 --
h Ø4,0 ±0,06
i Ø3,8 max.
k Ø4,0 max.
l 19,0 ±0,5
m 10,0 +1
n 0 – 4,0 --
o 18,0 min.
Locations Size (mm) Tolerance
Measured (for both L and N pins, if applicable) (mm)
(mm) Sample No.: Sample No.: Sample No.: a1 25.37 max.
a2 25.37 max.
b1 11.05 – 11.18
b2 11.05 – 11.18
c 34.6 max.
d R 15 min.
e 9.5 min.
f 17.7 ±0.5 / / /
g 1.6 ±0.25
h 22.73 ±0.5
i 22.23 ±0.13
j 9.5 max. / / / k 9.2 max. / / / l (7.75 for ISOD) 7.80 – 8.05
m 3.90 – 4.05 / / / n 3.90 – 4.05
o1 6.35 ±0.13
o2 6.35 ±0.13
p 3.90 – 4.05
q 1.2 – 2.0
r 1.6 ±0.25
s R 0.1 – 1.0
u 60° – 80°
t 60°±2°
(I) Permitted additional chamfers on L and N pins used? (Yes/No)
Locations Size (mm) Tolerance
Measured (for both L and N pins, if applicable) (mm)
(mm) Sample No.: Sample No.: Sample No.:
A 60°±2°
B 1.6 ±0.25
(II) Alt. method of forming 58o to 60o included chamfer on pin ends used? (Yes/No)
C 60°±2°
D 1.6 ±0.25
(III) Alt. method of forming main chamfer on pin ends used? (Yes/No)
E 0.2 max.
F 1.6 ±0.25
(IV) Concave shrinkage allowance for solid ISOD?
G 7.75 – 8.05
H 3.90 – 4.05
I1 0.15 max.
I2 0.15 max.
I3 0.15 max.
I4 0.15 max.
(V) Concave shrinkage allowance for castellated ISOD?
J1 7.75 – 8.05
J2 0.13J1 min.
J3 0.13J1 min.
K 3.90 – 4.05
L1 0.15 max.
L2 0.15 max.
L3 0.15 max.
L4 0.15 max.
The outline of the plug does not exceed the dimensions shown above for a distance ___________mm (required: min. 6.35mm) from the engagement surface.
Au plug of pin
Locations
Size (mm) Tolerance (mm) R 0.35 ±0.05 S 0.9 ±0.1 T ≥0.60 -- V
6
--
Locations Size (mm) Tolerance (mm)
A 6.35 ±0.15
C (both pins) 1.63 ±0.15
D (nominal) 7.92 --
F 17.06 ±0.4
1 21.9 max. or 27.0 min. --
2 21.9 max. or 27.0 min. --
3 21.9 max. or 27.0 min. --
4 21.9 max. or 27.0 min. --
5 60°--
6 60°--
7 > 8.6 --
8 < 21.0 --
9 20.0 ±1.0
10 <1.0 --
11 8.7 ±0.5
US plug Dimension
Locations Size (mm)
1 1.65
1.40
2 1.65
1.40
3 6.60
6.10
4 13.77
5 18.24
15.88
6 3.96
7 3.18
From live pins to the edge
China plug Dimension
Dimensions Size (mm) Tolerance (mm)
A 1.5 -0.1
B 6.4 -0.22
C 12.7 ±0.135
D 16 ±0.35
From live pins to the edge > 6.5。
