【TCCN-3.3.5-Trinity8400单机&外网架设心得】
本帖最后由 harklewis 于 2011-4-2 01:46 编辑
本教程是小弟我钻研了几天总结的
首先给大家说说小弟我对服务器的概念:
我只是个小白而已只是个人理解
你创建服务器就好像你建一个房子
IP就好像是这个房子的编号
端口就是这个房子的几个门
别人要去你房子必须知道你的编号
然而进房子的时候要进的去门才行
你的门上写着4就只能让有4这个钥匙的人进了
【方便大家学习我就不设置回复可见了回帖是美德】
一.服务端安装
大家都下载好了TCCN-3.3.5-Trinity8400服务端了吗？下载好了就开始安装
安装路径里面不能有中文字符最好直接安装到磁盘目录
X:\TCCN-3.3.5-Trinity8400
二.启动WEB_server
运行一键启动WEB服务器.exe 看是否存在无法启动apache等问题
这是运行成功的web
【问题2.1】
启动一键启动web服务器.exe 后不能在浏览器打开注册页面,请右键单击一键启动web服务器状态栏图标如果出现:单独启动Apache 说明Apache未成功启动
解决办法:
1.
首先检查wow_server文件夹所在目录中是否有中文,如果有中文,请把wow_server无中文的路径中,推荐放到磁盘根目录.
2.
如果没有1里的情况,可能是端口冲突引起,请用记事本打开X:\TCCN-3.3.5-Trinity8400\web_server\etc\httpd.conf.template
滚动条拉到最下面找到:
Listen 80
NameVirtualHost *:80
<VirtualHost *:80>
ServerName
DocumentRoot %APMXE%/htdocs/reg
</VirtualHost>
Listen 8081
NameVirtualHost *:8081
<VirtualHost *:8081>
ServerName
DocumentRoot %APMXE%/htdocs/reg
</VirtualHost>
删掉其中的:
Listen 80
NameVirtualHost *:80
<VirtualHost *:80>
ServerName
DocumentRoot %APMXE%/htdocs/reg
</VirtualHost>
保存此文件,重启web_server服务器
3.
apache 启动不了解决方法：
网络连接 - 本地连接 - 右键 - 属性 - internet 协议(TCP/ip) - 属性 - 常规选项卡 - 高级 - WINS选项卡 - LMHOSTS 查询如果LMHOSTS 查询前面有勾，就去掉那个勾，没勾就勾上
然后确定确定关闭
MYSQL启动不了
服务端安装目录\web_server\mysql5\bin 找到mysqld-nt.exe 双击打开
三、设置N a v i c a t 8
确定web服务器启动成功之后
运行 x:\TCCN-3.3.5-Trinity8400\tools\navicat 里面的 navicat.exe
程序运行后点左上角的"连接" 在密码那一栏输入2009 点击确定
双击"localhost"连接到localhost
双击"localhost"连接下的"realmd" 再双击右边的"realmlist"
address 这一栏填服务器IP 如果自己玩就填127.0.0.1或者本机IP
想要架设外网的朋友就填自己的外网IP 最好用花生壳注册一个免费静态域名填上去【问题3.1 进了游戏显示连接断开或者进去了没有服务器】
原因一：
gamebuild 必须改成和客户端版本号一样的
现在最新的是3.3.5 13685版本所以填上13685
原因二：
没有覆盖原来的TrinityRealm.exe
（TrinityRealm.rar附件有下载）
（由于以前写的不是很显眼导致这个问题大家没有重视）
【问题3.2 更改账号G M等级】
双击 realmd 连接中的 account 表这里可以看你的账号ID 记住你想改为G M账号的ID
双击 account_access 表ID栏写上你想改为GM账号的ID gmlevel 是GM等级最后一栏写1
【问题3.3 想改成官方出生数据的】
双击 locallhost 连接下的 world 找到 playercreateinfo_item这个表选中他按F6 把文件官方出生数据.txt复制然后粘贴到弹出来的窗口按回车
等他加载完成就ok啦
【问题3.4 想人物出生不带全部技能经验倍数怪物血量等设置】
在X:\TCCN-3.3.5-Trinity8400\wow_server\TrinityCore.conf 相关设置
四、启动wow_server
由于wow更新了一次所以要把TrinityRealm.rar
解压到服务端wow_server覆盖原来的TrinityRealm.exe（TrinityRealm.rar附件有下载）
启动一键启动wow服务器.exe 等待那个2个小框框加载完毕bi一声就完成了
【问题4.1】
如果启动一键启动web服务器.exe 正常, 一键启动WOW服务器.exe 启动后不出现mangos和reamld控制台或提示配置错误
需要下载.NET Framework 3.5
【.NET Framework 3.5】
下载地址为：
ttp:///downloads/zh-cn/details.aspx?displaylang=zh-cn&FamilyID=ab99342f-5d1a-413d-8319-81da479ab0d
以上步骤完成就能自己玩了至于这些问题遇到了按着解决方法试试没遇到最好
下面是架设外网教程
五、外网架设
准备工作：
大芒果的3.3.5的客户端
花生壳免费域名解析服务的服务端
Navicat软件（大芒果单机tools文件夹里有）
1.
访问花生壳的网站：/peanuthull/
然后点击免费注册
接着注册账号信息
注册成功后，下载花生壳软件
登录护照然后看自己的免费域名
2.
打开大芒果WEB服务器确保你的数据库正常开启确保能打开注册账号的网页
3.
打开navicat (大芒果单机里tools文件夹有前面用了多次了)
找到我们第一次修改版本号的那个地方
就是 locallhost 连接里 realmd 下面的 realmlist 这个表
找到 address 栏在里面填写你刚刚花生壳登录里面的免费域名
4.创建一个登陆器给你朋友登录你的wow服务器
echo y | rd /s "Cache"
echo SET realmlist "address栏中的IP" > Data\zhTW\realmlist.wtf
echo SET realmlist "address栏中的IP" > Data\enTW\realmlist.wtf
echo SET realmlist "address栏中的IP" > Data\zhCN\realmlist.wtf
echo SET realmlist "address栏中的IP" > Data\enCN\realmlist.wtf
echo SET realmlist "address栏中的IP" > Data\enUS\realmlist.wtf
echo SET realmlist "address栏中的IP" > realmlist.wtf
start wow.exe
goto end
创建一个.txt文档把这一段代码复制到里面再保存
把后缀改为.bat
5.访问你花生壳域名的网页(注意用你注册的域名访问)看看是否可以访问
6.可以访问的话就开启wow_server 如果出错参考上面启动wowserver
7.等待wow服务器读取完毕，外网就开启成功了，你可以让你的朋友访问你域名的地址，注册账号后
教程到此结束了欢迎大家加我Q794259385 一起交流探讨
本教程原创转贴请带上本贴地址谢谢看帖不回帖木有小JJ （女的木有小咪咪）
