《计算机网络应用》技能大赛模拟题及答案

《计算机网络应用》技能大赛模拟题
拓扑编址:
设备名称接口地址PC1 IP 192.168.10.100/24 PC2 IP 192.168.20.100/24 PC3 IP 192.168.30.100/24 PC4 IP 10.11.12.100/24
S3760 VLAN10 192.168.10.1/24
S3760 VLAN20 192.168.20.1/24
S3760 VLAN30 192.168.30.1/24
S3760 F0/24 192.168.2.1/24
R1762A F1/1 192.168.2.2/24
R1762A S1/2 200.1.1.1/30
R1762B S1/2 200.1.1.2/30
R1762B F1/0 10.11.12.1/24
SERVER1 IP 192.168.30.252/24 SERVER2 IP 192.168.30.253/24 SERVER1和2物理主机IP 192.168.30.254/24 SERVER3 IP 10.11.12.100/24
实验题目
1、在S3760与S2126上划分VLAN，将PC机与服务器加入到相应的VLAN 中。

S2126A划分VLAN、端口
S2126B划分VLAN、端口
S3760B划分VLAN
2、服务器直接连接在核心交换机SW3760的Fa0/1上，需要在两个端口上限制接入服务器的数量，F0/1限制为4台，超过后将关闭该端口。

3、为S3760上的VLAN接口、R1762A和R1762B上的以太网接口配置IP地址。

S3760上的VLAN配置
R1762A以太网接口配置
R1762B以太网接口配置
4、在S3760A使用具有三层特性的物理端口实现RIP路由与R1762A实现内网的互联。

5、R1762A和R1762B之间运行静态路由协议，提供园区内部网络的连通性。

6、在R1762A和R1762B之间建立PPP链路，并对PPP进行CHAP验证。

（分）
7、在一台SERVER2上配置FTP服务器，使VLAN 10中的PC能够进行文件的上传和下载。

8、在R1762A上使用网络地址转换技术，使VLAN 10内使用私有地址的主机能够访问Internet中的资源。

9、在一台SERVER3上配置Web服务器，使VLAN 10中的PC1能够进行Web 网页的浏览。

存。

*****************************************CISCO****************** ***************
hostname r1762a
username r1762b password 0 cisco
interface FastEthernet0/1
ip address 192.168.2.2 255.255.255.0
ip access-group 100 in
ip nat inside
interface Serial0/2/0
ip address 200.1.1.1 255.255.255.252
ip access-group 100 out
ip nat outside
ip virtual-reassembly
encapsulation ppp
ppp authentication chap
router rip
version 2
network 192.168.2.0
no auto-summary
ip route 201.102.192.0 255.255.255.0 200.1.1.2
ip route 202.102.192.0 255.255.255.0 200.1.1.2
ip nat inside source list 10 interface Serial0/2/0 overload
access-list 10 permit 192.168.10.0 0.0.0.255
access-list 100 permit ip host 192.168.10.101 host 202.102.192.68
access-list 100 permit tcp host 192.168.10.100 host 201.102.192.68 eq www access-list 100 deny tcp any any
access-list 100 permit ip any any
================================================= hostname r1762b
username r1762a password 0 cisco
interface Loopback0
ip address 202.102.192.68 255.255.255.0
interface Loopback1
ip address 201.102.192.68 255.255.255.0
interface FastEthernet0/1
ip address 10.11.12.1 255.255.255.0
interface Serial0/3/0
ip address 200.1.1.2 255.255.255.252
encapsulation ppp
clock rate 64000
ppp authentication chap
ip route 0.0.0.0 0.0.0.0 Serial0/3/0
================================================= s2126a
hostname s2126a
interface FastEthernet0/1
switchport access vlan 10
switchport mode access
interface FastEthernet0/24
switchport trunk encapsulation dot1q
switchport mode trunk
interface Vlan10
ip address 192.168.10.254 255.255.255.0
================================================= s3760a
hostname s3760a
errdisable recovery cause psecure-violation
errdisable recovery interval 30
vlan 10
vlan 20
vlan 30
interface FastEthernet0/1
switchport access vlan 30 switchport mode access
switchport port-security maximum 4 switchport port-security
spanning-tree portfast
interface FastEthernet0/3
switchport access vlan 10 switchport trunk encapsulation dot1q switchport mode trunk
spanning-tree portfast
interface FastEthernet0/4
switchport access vlan 20 switchport mode access
spanning-tree portfast
interface FastEthernet0/24
no switchport
ip address 192.168.2.1 255.255.255.0
interface Vlan10
ip address 192.168.10.1 255.255.255.0 !
interface Vlan20
ip address 192.168.20.1 255.255.255.0 !
interface Vlan30
ip address 192.168.30.1 255.255.255.0
router rip
version 2
network 192.168.2.0
network 192.168.10.0
network 192.168.20.0
network 192.168.30.0
no auto-summary
ip route 0.0.0.0 0.0.0.0 FastEthernet0/24
==================================================
*************************************H3C************************ *********
sys-view
sysname s2126b
vlan 20
int f0/24
port link-type trunk
quit
int f0/4
port link-type access
port access vlan 20
quit
int vlan 20
ip address 192.168.20.254 255.255.255.0 undo shutdown
quit
save。
