DINGB标准件对照表
中德标准对照表
序号
Item 德国标准
DIN-Standard 中文品名
Description
in Chinese 英文品名
Desciption in English 国际标准
ISO-Standard 中国标准
GB-Standard
1 DIN1 圆锥销 Taper pins ISO2339 GB117
2 DIN7 圆柱销 Parallel pins ISO2339 GB119-86
3 DIN84 开槽圆柱头螺钉 Slotted cheese head
screws ISO1207 GB65-85
4 DIN85 开槽盘头螺钉 Slotted pan head screws ISO1580 GB67-85
5 DIN93 单耳止动垫圈 Tab washers GB854
6 DIN94 开口销 Split cooter pins ISO1234 GB91
7 DIN95 开槽半沉头木螺钉 Slotted raised csk head
wood screws GB101
8 DIN96 开槽半圆头木螺钉 Slotted round head wood
screws GB99
9 DIN97 开槽沉头木螺钉 Slotted countersunk head
wood screws GB100
10 DIN125-A 平垫 Plain washers ISO7089 GB97.1-85
11 DIN125-B 平垫（带倒角） Mediun washers ISO7090 GB97.2-85
12 DIN126 平垫 Plain washers ISO7091
13 DIN127-A 重型弹垫 Spring lock washers,tang
ends GB7244
14 DIN127-B 标准弹垫 Spring lock
washers,square ends GB93-87
15 DIN128-A 鞍形弹垫 Single coil spring lock
washers GB7245-87
16 DIN137-A 弹簧止动垫圈 Curved spring washers
17 DIN137-B 波形弹垫 Wave spring washers GB955
18 DIN186 T型方颈螺栓 T-head blots with square
neck GB37-88
19 DIN188 T型双接头螺T-head bolts with double
栓 nip
20 DIN258 螺纹圆锥销 Taper pins with threaded
end ISO8737
21 DIN261 T型头螺栓 T-head bolts
22 DIN315AF 蝶型螺母（美制） Wing nuts America form
23 DIN315DF 蝶型螺母（德制） Wing nuts germany form GB62-88
24 DIN316AF 蝶型螺母（美制） Wing screws America form
25 DIN317DF 蝶型螺母（德制） Wing screws germany
form
26 DIN319 圆球型盖型螺母 Ball knobs
27 DIN404 开槽带孔球面
圆柱头蚴钉 Slotted capstan screws GB832-88
28 DIN417 开槽长圆柱端
紧定螺钉 Slotted set srews with full
dog point ISO7435 GB75-85
29 DIN427 开槽平端
紧定螺钉（半牙） Slotted set srews with
chamfered end ISO2342 GB73-85
30 DIN431 小六角特薄细牙
螺母 Pip nuts with thread GB808-88
31 DIN432 外舌止动垫圈 External tap GB856-88
32 DIN433 小垫圈
(用于圆柱头螺钉) Washers for cheese head
screws ISO7092 GB848-95
33 DIN434 方斜垫圈（U型） Square taper washers for
U-section GB852-88
34 DIN435 方斜垫圈（I型） Square taper washers for
I-sections GB852-88
35 DIN436 方垫圈 Square washers
36 DIN438 开槽凹端紧定螺钉 Slotted set with cup point ISO7436 GB74-85
37 DIN439 六角薄螺母 Hexagon thin nuts ISO4035 GB6172-86
38 DIN439 细牙六角薄螺母 Hexagon thin nuts ISO8675 GB6173-86
39 DIN440 木螺钉专用垫圈 Rounds washers for wood
constructions ISO7094
40 DIN443 密封帽 Sealing caps,push-in type
41 DIN444 活节螺栓B型 Eye bolts form B GB798-88
42 DIN462 舌止动垫圈 Internal tab washers
43 DIN463 双耳止动垫圈 Washers with two taps GB855-88
44 DIN464 滚花高头螺钉 Knurled thumb screws with
collar GB834-88
45 DIN465 开槽滚花高头螺钉 Slotted knurled thumb
screws with collar
46 DIN466 滚花高螺母 Knurled thumb nuts with
collar GB806-88
47 DIN467 滚花薄螺母 Knurled thumb thin nuts GB807-88
48 DIN470 锁紧垫圈 Sealing washers
49 DIN471 轴用弹性垫圈 Retaining rings for
shafts(external),circlips GB893-86
50 DIN472 孔用弹性垫圈 Retaining rings for
bores(internal),circlips GB893.86
51 DIN478 方头带垫螺栓 Square head bolts with
collar
52 DIN479 方头圆柱底端螺栓 Square head bolts with
half dog point
53 DIN480 方头带垫关圆底端
螺栓 Square head bolts with
collar,half dog point
54 DIN508 T型槽螺母 T-slot nuts ISO299
55 DIN525 单头螺柱 Single end studs
56 DIN529 地脚螺栓 Masonry bolts GB799-88
57 DIN546 带槽圆螺母 Slotted round nuts GB817-76
58 DIN547 端面带孔圆螺母 Round nuts with drilled
holes in one face GB815-88
59 DIN551 开槽平端紧定螺钉 Slotted set screws with flat
point ISO4776 GB73-85
60 DIN553 开槽锥端紧定螺钉 Slotted set screws with
cone point ISO7434 GB71-85
61 DIN555 六角螺母 Hexagon nuts ISO4034
62 DIN557 方螺母-C Square nuts GB39-88
63 DIN558 六角头螺钉 Hexagon screws ISO4018
64 DIN561 六角头圆柱端
紧定螺钉 Hexagon set screws with
full dog point
65 DIN562 薄型方螺母-B Square nuts without bevel
(pressed nuts)
66 DIN571 六角头木螺钉 Hexgon head wood screw
(coach screws) GB102-86
67 DIN580 吊环螺钉 Lifting eye bolts ISO3266 GB825-76
68 DIN582 吊环螺母 Lifting eye nuts
序号
Item 德国标准
DIN-Standard 中文品名
Description in
Chinese 英文品名
Desciption in English 国际标准
ISO-Standard 中国标准
GB-Standard
69 DIN601 六角头螺栓 Hexagon blots ISO4016
70 DIN603 大半圆头方颈Mushroom head square ISO8677 GB14-88
螺栓（马车螺栓） neck bolts(carriage bolts)
71 DIN604 沉头带插销马车
螺栓 Flat countersunk nib bolts
72 DIN605 沉头长方颈马车
螺栓 Flat countersunk long
squareneck bolts
73 DIN607 半圆头带插销马车螺栓 Cup head nib bolts
74 DIN608 沉头短方颈马车
螺栓 Flat countersunk short
square neck bolts
75 DIN609 六角头精配螺栓
（长螺纹） Hexagon fitted bolts,long
thread
76 DIN610 六角头精配螺栓
（短螺栓） Hexagon fitted bolts short
thread
77 DIN653 滚花平头螺钉 Knurled thumb screws thin
type GB835-88
78 DIN660 半圆头铆钉 Round head rivets ISO1051 GB867-86
79 DIN661 沉头铆钉 Contersunk head rivets ISO1051 GB869-86
80 DIN662 半沉头铆钉 Raised contersunk head
rivets ISO1051
81 DIN674 大扁头铆钉 Mushroom head rivets ISO1051
82 DIN703 重型侧面带孔圆螺母 Adjusting rings,heavy
中德标准件对照表
中德标准件对照表序号名称德国标准德国材料德国标号中国标准中国材料
1圆锥销DIN 1StGB 117-8635
2平垫圈DIN 125钢、St50、Nrst、Ms、Al－LegGB 97.1－85140HV/200HV/300HV/A140/A200/A350
4平垫圈DIN 125钢、St51、Nrst、Ms、Al－LegGB 97.2－85140HV/200HV/300HV/A140/A200/A350
6平垫圈－C级DIN 126钢、粗制GB 95－85100HV级
7垫圈DIN 126GB 97.1-85
8锁紧垫圈DIN 12765MnGB 93-8765Mn
9弹簧垫圈DIN 12865MnGB 93-8765Mn
10垫圈DIN 1440StGB 848－85
11垫圈DIN 1441GB 848－85A级代用
12销轴DIN 1443StJB/ZQ4360-86（A型）35
13销轴DIN 1443StJB/ZQ4360-86（B型）35
14销轴DIN 1444StGB 882-86(A型）35
15销轴DIN 1444StGB 882-86(B型）35
16槽销DIN 1471/ISO 8745StGB/T13829.2-92Y15 Y12
17槽销DIN 1473/ISO 8740StGB/T13829.2-92Y15 Y12
18槽销DIN 1476/ISO 8747StGB/T13829.3-92Y12
19槽销DIN 1477/ISO 8746StGB/T13829.3-92Y12
20弹性圆柱销DIN 148155Si7GB 879-8665Mn
21盖形螺母DIN 15876级GB 923－885级
22结构用不锈钢无缝钢管DIN 17458GB/T14975-1994
23输送流体用不锈钢无缝钢管DIN 17458GB/T14976-1994
24锅炉、换热器用不锈钢无缝钢管DIN 17458GB 13296-1991
国内外标准件对照表
COMPARED LIST 序号德国标准中文品名英文品名国际标准中国标准ItemDIN-StandardDescription inChineseDesciption in EnglishISO-StandardGB-Standard1DIN12DIN7圆锥销Taper pinsISO2339GB1173DIN84开槽圆柱头螺钉Slotted cheese head screwsISO1207GB65-854DIN85开槽盘头螺钉Slotted pan head screwsISO1580GB67-855DIN93单耳止动垫圈Tab washersGB8546DIN94开口销Split cooter pinsISO1234GB917DIN95开槽半沉头木螺钉Slotted raised csk headwood screwsGB1018DIN96开槽半圆头木螺钉Slotted round head woodscrewsGB999DIN97开槽沉头木螺钉Slotted countersunk headwood screwsGB10010DIN125-A平垫Plain washersISO7089GB97.1-8511DIN125-B平垫（带倒角）Mediun washersISO7090GB97.2-8512DIN126平垫Plain washersISO709113DIN127-A重型弹垫Spring lock washers,tangendsGB724414DIN127-B标准弹垫Spring lock washers,squareendsGB93-8715DIN128-A鞍形弹垫Single coil spring lockwashersGB7245-8716DIN137-A弹簧止动垫圈Curved spring washers17DIN137-B波形弹垫Wave spring washersGB95518DIN186T型方颈螺栓T-head blots with squareneckGB37-8819DIN188T型双接头螺栓T-head bolts with doublenip20DIN258螺纹圆锥销Taper pins with threadedendISO873721DIN261T型头螺栓T-head bolts22DIN315AF蝶型螺母（美制）Wing nuts America form23DIN315DF蝶型螺母（德制）Wing nuts germany formGB62-8824DIN316AF蝶型螺母（美制）Wing screws America form25DIN317DF蝶型螺母（德制）Wing screws germany form26DIN319圆球型盖型螺母Ball knobs开槽带孔球面圆柱头蚴钉开槽长圆柱端紧定螺钉开槽平端紧定螺钉（半牙）ISO2342GB832-8828DIN417Slotted set srews with fulldog pointISO7435GB75-8527DIN404Slotted capstan screws
标准件中德对照要[1]
![标准件中德对照要[1]](https://360docs-1393072327.cos.ap-beijing.myqcloud.com/f89c0be0f8c75fbfc77db28a.webp)
标准件----中德标准对照
类别 中国标准 德国标准 备注
名称 材料 标准号 名称 标准号
螺栓 螺栓(六角头) 8.8级 GB/T5782-2000 Hexagon cap
screw DIN 931，ISO 4014，
DIN EN24014
螺栓(六角头，全螺纹) 8.8级 GB/T5783-2000 Hexagon head
screw DIN 933，ISO 4017
DIN EN 24017
螺栓(六角头鉸制孔用) 8.8级 GB/T 27-1988 DIN 609
DIN 976
活节螺栓 GB/T 798-1988 DIN 444
钢膨胀螺栓 Holding-down
bolt Hilti HAS-KA
地脚螺栓(弯钩形) 3.6级 GB/T799-1988 DIN 529
螺钉 螺钉(内六角园柱头) 8.8级 GB/T70.1-2000 Socket head screw DIN 912 ,
螺钉(内六角园柱头) 8.8级 GB/T70.1-2000 Hexagon socket
head cap screw DIN 6912，ISO 4762
螺钉(内六角平园头) 8.8级 GB/T70.2-2000 DIN 7984
螺钉(方头长园柱端紧定) 45H GB/T85-1988 Hexagon set screw DIN 561
螺钉(内六角锥端紧定) 45H GB/T78-2000 Grub screw DIN 914
螺钉(开槽园柱头) 4.8级 GB/T 65-2000 Socket head screw DIN 84
螺钉(内六角沉头) 8.8级 GB/T 70.3-2000 Countersunk head DIN 7991
吊环螺钉 25 GB/T 825-1988 Hexagon set screw DIN 580/DIN EN 23266
标准件紧固件对照表
标准件（紧固件）对照表
国标
全称
实物
国标
全称
实物
GB/T70.1 内六角圆柱头螺钉
GB/T6170 粗牙I型六角螺母
GB/T70.2 内六角平圆头螺钉
GB/T6171 细牙I型六角螺母
GB/T818 十字槽盘头螺钉
DIN985 尼龙防松螺母
GB/T819.1 十字槽沉头螺钉
GB/T 802.1 组合式盖形螺母
GB/T77 内六角平端紧定
螺钉 GB/T93 弹簧垫圈
GB/T78 内六角锥端紧定
螺钉 GB/T97.1 平垫圈
GB/T5782 粗牙六角头螺栓
GB/T119.1 圆柱销
GB/T5785 细牙六角头螺栓
GB/T120.1 内螺纹圆柱销
GB/T5783 粗牙全螺纹六角头
螺栓
GB/T879.1 弹性圆柱销
GB/T5784 细牙全螺纹六角头
螺栓
GB/T118 内螺纹圆锥销
GB/T5789 六角法兰面螺栓
GB/T893.1 孔用弹性挡圈-A型
GB/T845 十字槽盘头自攻
螺钉 GB/T894.1 轴用弹性挡圈-A型
GB/T68 开槽沉头螺钉
GB/T896 开口挡圈
ISO7379 轴肩螺钉
GB/T 1096 圆头普通平键
JB/T10582 管状铆钉
六角螺母 尺寸 对比
GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934max3.23.23.24445555.55.55.5min3.043.023.023.843.823.824.844.824.825.345.325.32max1.31.31.31.61.61.62222.42.42.4min1.11.051.051.41.351.351.81.751.752.22.152.15max3.73.413.414.64.324.325.85.455.456.36.016.01min
GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934max77788881010101013141313min6.86.786.787.647.87.787.789.649.89.789.7812.5713.7612.7312.73max3.23.23.25.644.746.455.257.966.86.5min2.962.92.994.43.764.43.74.94.764.94.76.45.766.446.14max8.17.667.669.28.798.7910.8911.511.0511.0514.216.214.3814.38min8.63
GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934GB41-00GB52-76GB6170DIN934max16171617181918192122212224242424min15.5716.7615.7316.7317.5718.7217.7318.6720.1621.7220.6721.6723.1623.7623.6723.67max9.588.4812.21010.81013.91112.81115.91314.813min87.618.047.6410.49.7110.379.6412.110.6512.110.314.112.6514.112.3max17.5919.617.7718.919.8521.920.0321.122.7825.423.3524.4926.1727.726.7526.75min
中德标准件对照表 2
中德标准件对照表序号名称德国标准国际标准德国材料中国标准中国材料备注
1圆锥销DIN1StGB 117-8635A型（Ra0.8） B型（Ra3.2）长度200
2平垫圈DIN125钢、St50、Nrst、Ms、Al－LegGB97.1－85140HV/200HV/300HV/A140/A200/A350对FORMA（不倒角型）
3平垫圈DIN125钢、St50、Nrst、Ms、Al－LegJB/ZQ4335-86A型，100HV对FORMA（不倒角型）范围d39～d160
4平垫圈DIN125钢、St51、Nrst、Ms、Al－LegGB97.2－85140HV/200HV/300HV/A140/A200/A350对FORMB（倒角型）
5平垫圈DIN125钢、St52、Nrst、Ms、Al－LegJB/ZQ4335-86B型，100HV对FORMB（倒角型）范围d39～d160
6平垫圈－C级DIN126钢、粗制GB95－85100HV级范围M36
7平垫圈C级DIN126GB95-85
8垫圈DIN126GB97.1-85
9锁紧垫圈DIN12765MnGB 93-8765Mn
10弹簧垫圈DIN12865MnGB 93-8765Mn
11压杆式油枪DIN1283
12垫圈DIN1440St附图自制
13垫圈DIN1441GB848－85A级代用范围d36，注意：厚度于外径有小差别
14销轴DIN1443StJB/ZQ4360-86（A型）35轴精度分别为a11、c11、f8、h11；带孔
15销轴DIN1443StJB/ZQ4360-86（B型）35轴精度分别为a11、c11、f8、h11；带孔
16销轴DIN1444StGB882-86(A型）35带孔；范围60；精度h11，尺寸系列稍有变化
17销轴DIN1444StGB882-86(B型）35带孔；范围60；精度h11，尺寸系列稍有变化
18槽销DIN1471ISO8745StGB/T13829.2-92Y15 Y12B型（半长锥槽）
德国DIN标准件ISO及国标对照表--标准间对照表
序号德国标准中文品名英文品名国际标准中国标准
ItemDIN-StandardDescription in ChineseDescription in EnglishISO-StandardGB-Standard
1DIN1圆锥销taper pinsISO2339GB/T117-2000
2DIN7圆柱销parallel pinsISO2338GB/T119-2000
3DIN84开槽圆柱头螺钉slotted cheese head screwsISO1207GB/T65-2000
4DIN85开槽盘头螺钉slotted pan head screwsISO1580GB/T67-2000
5DIN93单耳止动垫圈tab washersISO1580GB/T854-1998
6DIN94开口销split cotter pinsISO1234GB/T91-2000
7DIN95开槽半沉头木螺钉slotted raised csk head woodscrewsGB/T101-1986
8DIN96开槽半圆头木螺钉slotted round head wood screwsGB/T99-1986
9DIN97开槽沉头木螺钉slotted countersunk head woodscrewsGB/T100-1986
10DIN125-A平垫plain washersISO7089GB/T97.1-1985
11DIN125-B平垫(带倒角)mediun washersISO7090GB/T97.2-1985
12DIN126平垫plain washersISO7091
13DIN127-A重型弹垫spring lock washers,tang endsGB/T7244-1987
14DIN127-B标准弹垫spring lock washers,square endsGB/T93-1987
15DIN128-A鞍形弹垫single coil spring lock washersGB/T7245-1987
常用标准件规格型号说明
序号德标号国标号名称备注
1DIN 931GB/T 5782-2000六角头螺栓
2DIN 933GB/T 5783-2000六角头螺栓 全螺纹
3DIN 961GB/T 5786-2000六角头螺栓 细牙 全螺纹
4DIN 960GB/T 5785-2000六角头螺栓 细牙
5DIN 6921GB/T 5789-1986六角法兰面螺栓
6DIN 912GB/T 70.1-2000内六角圆柱头螺钉
7GB/T 70.2-2000内六角平圆头螺钉
8DIN 7991GB/T 70.3-2000内六角沉头螺钉
9DIN 84GB/T 65-2000开槽圆柱头螺钉
10DIN 85GB/T 67-2000开槽盘头螺钉
11DIN 963GB/T 68-2000开槽沉头螺钉
12DIN 964GB/T 69-2000开槽半沉头螺钉
13DIN 7985GB/T 818-2000十字槽盘头螺钉
14DIN 965GB/T 819.1-2000十字槽盘头螺钉 第1部分：钢4.8级
15DIN 965GB/T 819.2-1997十字槽沉头螺钉 第2部分：钢8.8、
不锈钢A2-70和有色金属CU2或CU3
16GB/T 15856.1-2002十字槽盘头自钻自攻螺钉
17GB/T 15856.2-2002十字槽沉头自钻自攻螺钉
18GB/T 15856.3-2002十字槽半沉头自钻自攻螺钉
19DIN 913GB/T 77-2000内六角平端紧定螺钉
20DIN 914GB/T 78-2000内六角锥端紧定螺钉
21GB/T 845-1985十字槽盘头自攻螺钉
22DIN 125GB/T 97.2-2002平垫圈 倒角型 A级
23DIN 127GB/T 93-1987标准弹簧垫圈
24DIN 9021GB/T 96.1-2002大垫圈 A级
25WS 999901鞍形自锁垫圈M型
26WS 9250鞍形双面自锁垫圈S型
27WS 999903大齿面鞍形自锁垫圈B型
(整理)螺丝的国际标准
精品文档
精品文档 螺丝的国际标准
J-日规（JIS） D-欧规（DIN） A-美规（AISI） G-国标（GB）
B-英规（BSW） S-国际标准（ISO） T-特殊标准
规格标准——GB标准
十字槽盘头自攻螺钉 GB 845-85
十字槽沉头自攻螺钉 GB 846-85
十字槽半沉头自攻螺钉 GB 847-85
开槽盘头自攻螺钉 GB 5282-85
开槽沉头自攻螺钉 GB 5283-85
开槽半沉头自攻螺钉 GB 5284-85
六角头自攻螺钉 GB 5285-85
十字槽盘头自攻锁紧螺钉 GB 6560-86
十字槽沉头自攻锁紧螺钉 GB 6561-86
十字槽半沉头自攻锁紧螺钉 GB 6562-86
六角头自攻锁紧螺钉 GB 6563-86
内六角花形圆柱头自攻锁紧螺钉 GB 6564-86
十字槽头凹穴六角头自攻螺钉 GB 9456-88
精密机械用紧固件十字槽自攻螺钉 刮削端 GB /T 13806.2-92
墙板自攻螺钉 GB /T 14210-93
十字槽盘头自钻自攻螺钉 GB /T 15856.1-2002
十字槽沉头自钻自攻螺钉 GB /T 15856.2-2002
十字槽半沉头自钻自攻螺钉 GB /T 15856.3-2002
六角法兰面自钻自攻螺钉 GB /T 15856.4-2002
六角凸缘自钻自攻螺钉 GB /T 15856.5-2002
六角凸缘自攻螺钉 GB /T 16824.1-1997
六角法兰面自攻螺钉 GB /T 16824.2-1997
规格标准——GB标准
十字槽盘头自攻螺钉 GB 845-85
十字槽沉头自攻螺钉 GB 846-85
十字槽半沉头自攻螺钉 GB 847-85
开槽盘头自攻螺钉 GB 5282-85
开槽沉头自攻螺钉 GB 5283-85
开槽半沉头自攻螺钉 GB 5284-85
德国DIN标准件ISO及国标对照表
序号德国标准中文品名英文品名国际标准中国标准ItemDIN-StandardDescription in ChineseDescription in EnglishISO-StandardGB-Standard1DIN1圆锥销taper pinsISO2339GB/T117-20002DIN7圆柱销parallel pinsISO2338GB/T119-20003DIN84开槽圆柱头螺钉slotted cheese head screwsISO1207GB/T65-20004DIN85开槽盘头螺钉slotted pan head screwsISO1580GB/T67-20005DIN93单耳止动垫圈tab washersISO1580GB/T854-19986DIN94开口销split cotter pinsISO1234GB/T91-20007DIN95开槽半沉头木螺钉slotted raised csk head woodscrewsGB/T101-19868DIN96开槽半圆头木螺钉slotted round head wood screwsGB/T99-19869DIN97开槽沉头木螺钉slotted countersunk head woodscrewsGB/T100-198610DIN125-A平垫plain washersISO7089GB/T97.1-198511DIN125-B平垫(带倒角)mediun washersISO7090GB/T97.2-198512DIN126平垫plain washersISO709113DIN127-A重型弹垫spring lock washers,tang endsGB/T7244-198714DIN127-B标准弹垫spring lock washers,squareendsGB/T93-198715DIN128-A鞍形弹垫single coil spring lockwashersGB/T7245-198716DIN137-A弹簧止动垫圈curved spring washers17DIN137-B波形弹垫wave spring washersGB/T955-198718DIN186T型方颈螺栓T-head bolts with square neckGB/T37-198819DIN188T型双接头螺栓T-head bolts with double nip20DIN258螺纹圆锥销taper pins with threaded endISO873721DIN261T型头螺栓T-head bolts22DIN315AF蝶型螺母(美制)wing nuts amercia form23DIN315DF蝶型螺母(德制)wing nuts germany formGB/T62-198824DIN316AF蝶型螺钉(美制)wing screws amercia form25DIN317DF蝶型螺钉(德制)wing screws germany form26DIN319圆球型盖型螺母ball knobs27DIN404开槽带孔球面圆柱头螺钉slotted capstan screwsGB/T832-198828DIN417开槽长圆柱端紧定螺钉slotted set srews with fulldog pointISO7435GB/T75-198529DIN427开槽平端紧定螺钉(半牙)slotted set srews withchamfered endISO2342GB/T73-198530DIN431小六角特薄细牙螺母pipe nuts with threadGB/T808-198831DIN432外舌止动垫圈external tapGB/T856-198832DIN433小垫圈(用于圆柱头螺钉)washers for cheese head screwsISO7092GB/T848-1985德国标准和国际标准、中国标准中英文对照表序号德国标准中文品名英文品名国际标准中国标准ItemDIN-StandardDescription in ChineseDescription in EnglishISO-StandardGB-Standard德国标准和国际标准、中国标准中英文对照表33DIN434方斜垫圈(U型)square taper washers for U-sectionGB/T852-198834DIN435方斜垫圈(I型)square taper washers for I-sectionsGB/T852-198835DIN436方垫圈square washers36DIN438开槽凹端紧定螺钉slotted set with cup pointISO7436GB/T74-198537DIN439六角薄螺母hexagon thin nutsISO4035GB/T6172-200038DIN439细牙六角薄螺母hexagon thin nutsISO8675GB/T6173-200039DIN440木螺钉专用垫圈rounds washers for woodconstructionsISO709440DIN443密封帽sealing caps,push-in type41DIN444活节螺栓B 型eye bolts form BGB/T798-198842DIN462内舌止动垫圈internal tab washers43DIN463双耳止动垫圈washers with two tapsGB/T855-198844DIN464滚花高头螺钉knurled thumb screws withcollarGB/T834-198845DIN465开槽滚花高头螺钉slotted knurled thumb screwswith collar46DIN466滚花高螺母knurled thumb nuts with collarGB/T806-198847DIN467滚花薄螺母knurled thumb thin nutsGB/T807-198848DIN470锁紧垫圈sealing washers49DIN471轴用弹性挡圈retaining rings forshafts(external),circlipsGB/T894.1-198650DIN472孔用弹性挡圈retaining rings forbores(internal),circlipsGB/T893.1-198651DIN478方头带垫螺栓square head bolts with collar52DIN479方头圆柱底端螺栓square head bolts with halfdog point53DIN480方头带垫半圆底端螺栓square head bolts withcollar,half dog point and54DIN508T型槽螺母T-slot nutsISO29955DIN525单头螺柱single end studs56DIN529地脚螺栓masonry boltsGB/T799-198857DIN546带槽圆螺母slotted round nutsGB/T817-198858DIN547端面带孔圆螺母round nuts with drilled holesin one faceGB/T815-198859DIN551开槽平端紧定螺钉slotted sit screws with flatpointISO4776GB/T73-198560DIN553开槽锥端紧定螺钉slotted set screws with conepointISO7434GB/T71-198561DIN555六角螺母hexagon nutsISO403462DIN557方螺母-Csquare nutsGB/T39-198863DIN558六角头螺钉hexagon screwsISO4018序号德国标准中文品名英文品名国际标准中国标准ItemDIN-StandardDescription in ChineseDescription in EnglishISO-StandardGB-Standard德国标准和国际标准、中国标准中英文对照表64DIN561六角头圆柱端紧定螺钉hexagon set screws with fulldog point65DIN562薄型方螺母-Bsquare nuts withoutbevel(pressed nuts)66DIN571六角头木螺钉hexagon head wood screws(coach screws)GB/T102-198667DIN580吊环螺钉lifting eye boltsISO3266GB/T825-198868DIN582吊环螺母lifting eye nuts69DIN601六角头螺栓hexagon boltsISO401670DIN603大半圆头方颈螺栓(马车螺栓)mushroom head square neckbolts (carriage bolts)ISO8677GB/T14-198871DIN604沉头带插销马车螺栓flat countersunk nib bolts72DIN605沉头长方颈马车螺栓flat countersunk long squareneck bolts73DIN607半圆头带插销马车螺栓cup head nib bolts74DIN608沉头短方颈马车螺栓flat countersunk short squareneck bolts75DIN609六角头精配螺栓（长螺纹）hexagon fitted bolts,longthread76DIN610六角头精配螺栓（短螺纹）hexagon fitted bolts,shortthread77DIN653滚花平头螺钉knurled thumb screws thin typeGB/T835-198878DIN660半圆头铆钉round head rivetsISO1051GB/T867-198679DIN661沉头铆钉contersunk head rivetsISO1051GB/T869-198680DIN662半沉头铆钉raised contersunk head rivetsISO105181DIN674大扁头铆钉mushroom head rivetsISO105182DIN703重型侧面带孔圆螺母adjusting rings,heavy range(shafting collars)83DIN705侧面带孔圆螺母adjusting rings,light range(shafting collars)GB/T816-198884DIN741卡头wire rope clips85DIN787T型槽螺钉T-slot screwsISO29986DIN835双头螺柱（牙长=2D）studs-metal (end=2d)GB/T900-198887DIN906内六角锥型闭锁螺钉hexagon socket pipeplugs,conical thread88DIN908内六角直型闭锁螺钉hexagon socket screwplugs,cyl. thread89DIN909外六角锥型闭锁螺钉hexagon head pipeplugs,conical thread90DIN910外六角直型闭锁螺钉hexagon head screwplugs,cyl.thread91DIN911内六角扳手socket wrenchesISO293692DIN912内六角圆柱头螺钉hexagon socket cap screwsISO4762GB/T70-200093DIN913内六角平端紧定螺钉hexagon socket set screws withflat pointISO4026GB/T77-200094DIN914内六角尖端紧定螺钉hexagon socket set screws withcone pointISO4027GB/T78-2000
