At IEEE Communication Networks and Services Research (CNSR 2005), Halifax, Canada.
Shortest-hop Based Reliableຫໍສະໝຸດ Network Multicast
†
K.L. Eddie Law†, Daniel Siu‡ Ryerson University, Toronto, Canada. Email: eddie@ee.ryerson.ca ‡ IBM Canada, Toronto, Canada. Email: siud@sympatico.ca Abstract
Although many multicast communication protocols have been recommended at IETF, reliable multicast communications currently rely on programs built at the application layer, e.g., multicast overlay. This is because there is a lack of reliable multicast protocols. This is even harder for the multicast capable routers to offer transparent reliable multicast services if receivers are on paths with drastically different path characteristics. In this paper, concept of multicast reliability integrated within routing algorithm is discussed. It is important to map reliability from transport layer to network layer, and subsequently from network layer to data link layer. The novelty of the proposed design is to offer packet recovery mechanisms between every two intelligent routers. The resulting shortest-hop based reliability eliminates the retransmission request implosion problem and shortens the error recovery session time along any multicast tree. Consequently, the proposed design offers high goodput performance for multicasting important information in wired and wireless networks.
end-to-end packet recovery techniques. In Section 3, the design details on integrating both positive acknowledgment (ACK) and negative acknowledgment (NACK) techniques in a multicast tree infrastructure are discussed. Packet loss rate is analyzed to determine the operating choice of NACK and ACK mechanisms. Each router has a soft-store for calculating packet loss rate between next intelligent multicast routers and storing temporary packets. In the design, the numbers of retransmission requests between leaves and root are reduced which improve the bandwidth utilization. In Section 4, goodput per link is measured to compare different reliable multicast scheme. In Section 5, extensive experiments have been done in a prototype testbed. Performance results are discussed. Section 6 concludes the paper.
