海宝HP260讲解

System Layout
标准系统元件
9
手动气体控制器 • 进气连接. • 等离子气/保护气的预流/切割 流. • 压力传感器检测背压
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
系统说明
说明 (HPR130 and HPR260*) • 30, 45, 80 and 130, 200* and 260* A切割电流 • HyDefinition® 干式等离子 • LongLife® 氧气等离子 • 碳钢, 不修钢 和铝的切割工艺 • 100% 占载率贯穿整个切割范围
材料 碳钢 不锈钢 铝
What’s new?
System Layout
标准系统元件
10
自动气体控制器
选择气体控制器
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
What’s new?
System Layout
标准系统元件
6
HPR 割枪 • 水冷. • 260 A 能力. • O2/Air, O2/O2,N2/N2, H35/N2, 和 F5/N2 切割工艺. • HyDefinition® 部件. • 划线和切割可用同一套易损件.
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
2
生产性的切割范围 HPR 130 - (.8 to 19 mm) *HPR 260 - (.8 to 32 mm) (.8 to 32 mm) (1.2 to 25 mm)
What’s new?
LongLife 长寿命技术
3
Hypertherm 通过控制电流 和气体的渐升和渐降来改 善电极的寿命. LongLife® 长寿命技术减少 了铪芯在每一次的起弧和 断弧中的损耗.
HyPerformance™ Plasma
系统概述
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
流量控制器
What’s new?
System Layout
标准系统元件
8
手动气体控制器和用户操作界面 • • • • 系统电源开关. 出错灯和代码. 气体选择和流量设定. 切割电流设定.
ቤተ መጻሕፍቲ ባይዱ
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
System Layout
标准系统元件
7
开关阀组件 • 控制等离子气/保护气 的预流/切割流. • 同气体控制器相连. • 设置在离割枪(1.8 M) 之内.
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
标准系统元件
5
等离子电源 HPR260 等离子电源带有二个 130 A, 19.5 kW 的斩波器,用来产 生恒定的直流输出, 其范围从15 A 到260 A.
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
标准系统元件
4
等离子电源 HPR130 等离子电源带有一个 130 A, 19.5 kW 的斩波器,用来产 生恒定的直流输出, 其范围从15 A 到130 A.
HPR130 System Overview Rev. 0 Copyright, 2004 Hypertherm, Inc. These materials cannot be reproduced in any form without the permission of Hypertherm, Inc.
