MACSV.HLP.语音报警配置说明（续）
MACSV.HLP.语音报警配置说明（续）
语音报警配置说明（续）
操作员站如果找不到如《语音报警配置说明》中说明的和点名相对应的语言文件时，会继续寻找MACSV操作员站\\start\\alarmwave.txt中的配置项，并根据改文档中的说明设置语音文件。
如果没有点名语音文件和此文件，则报警不发声。
具体配置如下：
[COUNT]
NUM=3 表示报警发声条件的条数，可以设成任意数字，这里设成3，则操作
员会找从[ALARM1]到[ALARM3]这三个子项中的配置条件。
[ALARM1] 标题由ALARM+数字组成，数字表示报警发声条件的第几个，这里
表示第一个。
WAV=ALARM.WAV WAV=后面的名称表示语音文件的名称。
这里是ALARM.WAV
STATION=10 STATION=后面的数字表示使用上面语音文件的站。
TAGNAME=AI10 TAGNAME=后面的字符表示使用上面语音文件的点名，这里的点名
可以只是点名开头的几个字母，此时系统会将所有以这几个字母开头的报警发声点使用上述文件。
TAGTYPE=AI TAGTYPE=后面的字符表示使用上述语音文件的点的类型，只能是
AI,AM,DI,DM,PI,VI中的一种
[ALARM2]
WAV=ALARM2.WAV
STATION=10
TAGNAME=AM10
TAGTYPE=AM
[ALARM3]。
工程可以根据站号，点名和点类型灵活配置报警声音。
