斯凯孚正时皮带修理包使用指南
斯凯孚正时皮带修理包使用指南作者：来源：《汽车与驾驶维修》2012年第04期随着汽车技术的不断发展，对汽车发动机也提出了更高的要求。
汽车发动机既需要有更快的转速以获得更大的输出功率，又需要驱动越来越多的辅助设备，同时还需要满足发动机轻量化、小体积的发展趋势。
作为汽车发动机重要组成部分的正时系统，在这其中起到了非常关键的作用。
为了使汽车发动机获得最佳的动力性和更高的安全性，斯凯孚公司(SKF)和许多汽车制造厂商共同建议车主在更换正时系统或辅助系统的时候，应同时更换皮带、张紧轮和惰轮。
因为，无论是由于超过规定值的张力、振动以及高温等原因造成的正时系统部件损坏，都会影响到正时系统内的其他部件。
如果不将它们同时更换，就会导致正时系统内的其他部件陆续损坏。
更为严重的后果，会导致发动机零部件的损坏，带来不必要的经济损失。
正时皮带修理包的主要组成部分(视使用情况配置有所不同)1.正时皮带(图1)正时皮带的齿形是八字形曲形或梯形断面。
正时皮带内部是玻璃纤维或是钢板材质，外部是人造橡胶或是氯丁橡胶材质。
2.正时皮带张紧轮(图2)正时皮带张紧轮通过设置适当的正时皮带张力，为正时皮带提供导向。
在安装过程中，张紧力的调节是由挡板上的弹簧通过推动张紧轮偏心来实现的。
在发动机运转时，带有弹簧和摩擦系统的正时皮带张紧轮能使正时皮带处于一个恒定的张力状态中。
3.辅助皮带(图3)辅助皮带比普通V形带更宽、更薄，而且通常有3—6根加强筋。
4.辅助皮带张紧轮(图4)当辅助皮带驱动几个部件时，辅助皮带张紧轮是用来引导辅助皮带，在整个皮带上保持合适的张力。
辅助皮带张紧轮的侧面通常有1根或多根加强筋。
5.惰轮(图5)惰轮是固定不动的，可使皮带正确地安装在从动件上。
正时皮带修理包常见问题解答1.张紧轮和惰轮有时看上去是一样的，能否互换?需要按照指定的零件号进行安装。
每一台车用发动机都有自己的性能特性，也就是说张紧轮和滑轮都是为每种新发动机量身设计和测试的。
