投影机控制代码大全
BE EF 03 19 00 B4 91 01 B5 02 CC CC 00 00 00 00 00 00 00 00 CC CC CC CC CC CC CC CC CC CC CC CC
波特率：19200
丽讯(美国)
vitek
D820MS
开机
7E 50 4E 0D
关机
7E 50 46 0D
视频
49 56 45 44 20 20 20 31 0D
电脑
49 52 47 42 20 20 20 31 0D
波特率：9600
晨星
CX856
开机
7E 50 4E 0D
关机
7E 50 46 0D
视频
7E 53 56 0D
电脑
7E 53 52 0D(波特率：9600)
晨星
CX615P
开机
BE EF 03 19 00 8E 85 01 01 02 CC CC FF FF FF FF 00 00 00 00 CC CC CC CC CC CC CC CC CC CC CC CC
普乐士(日本)
PLUS
U5系列
开机
23 50 31 0D0A
关机
23 50 30 0D0A
视频
23 53 56 0D0A
电脑
23 53 52 0D0A
115200,N,8,1;2RXD,5GND
此系列投影机支持两种波特率：19200.115200
普乐士
PLUS
开机
23 50 31 43 524C46
电脑
434620494E50555420310D0A
EIKI
LC-XNB4M&S
LC-XNB4&S,LC-NB4&SLC-XNB3&W&S&NB3W&E&E
开机
43 30 30 0D0A
关机
43 30 320D0A
视频
43 30 36 0D0A
电脑
43 30 35 0D0A
波特率19200
EIKI
LC-X4&L & LC-SX4L
S视频
534F555243452034320D
DVI
534F555243452031320D(波特率9600)
Epson
82
开机
50 57 52 204F4E 0D0A
关机
50 57 52 204F46 46 0D0A
视频
534F55 52 43 45 20 34 31 0D0A
电脑
534F55 52 43 45 20 31 31 0D0A
关机
BE EF 04 0700 F0 29 01 20 00 CC CC CC CC
视频
BE EF 03 19 00 24 50 01 B5 02 CC CC 00 00 00 00 01 00 00 00 CC CC CC CC CC CC CC CC CC CC CC CC
电脑
BE EF 03 19 00 B4 91 01 B5 02 CC CC 00 00 00 00 00 00 00 00 CC CC CC CC CC CC CC CC CC CC CC CC
投影机代码大全(仅供参考)
松下(日本)
panisonic
开机
02 504F4E 03
关机
02 504F46 03
视频
02 49 49 533A56 49 44 03
电脑
02 49 49 533A52 47 31 03
9600,N,8,1;3RXD,4GND
索尼(日本)
SONY
PX11/PX45
TX120/CX80
ASKC20,C60,C85,C95C100,C105,C200,C300
开机
BE EF 80 06 00 00 00 01 00 01 00 01 00
关机
BE EF 80 06 00 00 00 01 00 01 00 00 00
视频
BE EF 80 06 00 00 00 01 00 32 00 03 00
波特率：9600控制线23反接5接5
Epson
5300
开机
1B 07 01 00 0301 F4
关机
1B 07 01 00 0300 F5
视频
1B 07 01 01 00 20 D7
电脑
1B 07 01 01 00 10 E7(波特率9600)
夏普(日本)
Sharp
开机
504F57 52 20 20 20 310D
43 30 36 0D0A
电脑
43 30 380D0A(波特率19200)
澳视(asee)
3380
开机
BE EF 02 06 00 9D C6 C4 00 00 00 00 00
关机
BE EF 02 06 00 9D C6 C4 00 00 00 00 00
视频
BE EF 02 06 00 E0 C0 E9 00 00 00 00 00
关机
504F57 52 20 20 20 300D
视频
49 56 45 44 20 20 20 310D(后两位或32 0D)
电脑
49 52 47 42 20 20 20 310D(后两位或32 0D)
波特率：9600
明基(台湾)
BENQ
8225/8235/8125
开机
BE EF 02 06 00 13 CE AA 00 00 00 00 00
视频
A9 00 01 00 00 00 019A
电脑
A9 00 01 00 00 02 039A(波特率:38400)
SONY
PX35/FX51
开机
A9 01 02 00 00 03 039A
关机
A9 01 02 00 00 00 039A
视频
A9 00 01 00 00 02 039A
电脑
A9 00 01 00 00 01 019A(波特率:38400)
关机
06 14 00 03 00 34 11 01 5D
视频
06 14 00 04 00 34 13 01 04 64
电脑
06 14 00 04 00 34 13 01 00 60
波特率：115200
BENQ
650/660
开机
BE EF 02 06 00 13 CE AA 00 00 00 00 00
关机
23 50 30 43 524C46
视频
23 53 56 43 524C46
电脑
23 50 52 43 524C46
爱其(日本)
EIKI
LC-XT5
开机
43 30 30 0D0A
关机
43 30 31 0D0A
视频
43 30 36 0D0A
电脑
43 30 35 0D0A
波特率：19200
EIKI
SD10
电脑
BE EF 02 06 00 D3 C0 EA 00 00 00 00 00
波特率：19200
日电(日本)
NEC
开机
02 00 00 00 00 02
关机
02 01 00 00 00 03
视频
02 03 00 00 02 01 06 0E
电脑
02 03 00 00 02 01 01 09
波特率：38400
SONY
FX40
开机
3A00 08 00 08 45 08 0D A9 17 2E 00 00 003F9A
关机
3A00 08 00 08 45 08 0D A9 172F00 00 003F9A
视频
3A00 08 00 08 45 08 0D A9 172A00 00 003F9A
VGA1
3A00 08 00 08 45 08 0D A9 17 2B 00 00 003F9A
开机
A9 17 2E 00 00 003F9A
关机
A9 172F00 00 003F9A
视频
A9 172A00 00 003F9A
电脑
A9 17 2B 00 00 003F9A
38400 8 1 E（偶校验）投影机2脚接收
SONY
PX40
开机
A9 17 2E 00 00 003F9A
关机
A9 172F00 00 003F9A
开机
4330300D0A
关机
4330310D0A
视频
4333330D0A
电脑
4330350D0A
(波特率19200)
EIKI
LC-X999/984/990/983/980U
980E/982U/870U
970U/970E/860/XC1/XM2/
SM3/NB1/NB2/XM1
XNB1/XNB2/LC-SM1/SM2
电脑
BE EF 80 06 00 00 00 01 00 32 00 00 00
波特率9600
ASK
C212/C214/C216
开机
28 50 57 52 31 29
关机
28 50 57 52 30 29
视频
28 53 52 43 32 29
电脑
28 53 52 43 30 29(波特率115200)
视频
7E 53 56 0D
RGB1
7E 53 52 0D
RGB2
7E 53 47 0D
波特率：9600
DIGITEL
(ALL)
宏控 投影机 RS-232 控制代码 说明书
Serial Multimedia Control System
投影机 RS-232 控制代码
用户手册
在使用本系统前，请详细阅读本说明书
配套使用
宏控中控配套-投影机 RS-232 控制代码
3M ................................................................................................................................3 ASK ..............................................................................................................................4 BARCO ..........................................................................................................................6 BOXLIGHT................................................................................................................7 CHRISTIE ....................................................................................................................8 DIGITEL ......................................................................................................................9 EIKI ............................................................................................................................9 INFOCUS ....................................................................................................................13 LENOVO ......................................................................................................................18 LUMENS ......................................................................................................................19 NEC ............................................................................................................................20 OPTOMA ......................................................................................................................21 PLUS ..........................................................................................................................22 POLAROID ..................................................................................................................23 PROJECTIONDESIGN ..................................................................................................23 PROXIMA ....................................................................................................................23 VIEWSONIC ................................................................................................................27 爱普生 ......................................................................................................................27 奥视 ..........................................................................................................................31 东芝 ..........................................................................................................................32 飞浰普 ......................................................................................................................35 富士通 ......................................................................................................................36 惠普 ..........................................................................................................................36 佳能 ..........................................................................................................................37 明基 ..........................................................................................................................38 日立 ..........................................................................................................................40 三洋 ..........................................................................................................................42 胜利 ..........................................................................................................................45 松下 ..........................................................................................................................47 索尼 ..........................................................................................................................48 夏普 ..........................................................................................................................49
各品牌投影仪控制码对照表
序号型号波特率校验控制码（16进制）0 自定义自定义自定义用户输入1 丽讯9600 无开机：7E 50 4E 0D关机：7E 50 46 0D2 中光学优派雅图DS310/320雅图FD200FS 19200 无开机：BE EF 10 05 00 C6 FF 11 11 01 00 01 00关机：BE EF 03 06 00 DC DB 69 00 00 00 00 003 三洋雅图LX610LX620/LX630 19200 无开机：43 30 30 0D关机：43 30 31 0D4 奥图码鸿合9600 无开机：7E 30 30 30 30 20 31 0D关机：7E 30 30 30 30 20 30 0D5 ASK/索拓雅图LX640雅图LX650/660雅图LX8000 19200 无开机：41 30 30 0D关机：41 30 31 0D6 雅图DX110/120雅图DX221 115200 无开机：FF 00 50 00 58 FF关机：FF 00 50 00 57 FF7 雅图DX216 115200 无开机：30关机：FF 00 50 00 57 FF8 日立19200 无开机：BE EF 03 06 00 BA D2 01 00 00 60 01 00关机：BE EF 03 06 00 2A D3 01 00 00 60 00 009 索尼38400 偶开机：A9 17 2E 00 00 00 3F 9A关机：A9 17 2F 00 00 00 3F 9A10 宏基115200 无开机：2A 20 30 20 49 52 20 30 30 31 0D关机：2A 20 30 20 49 52 20 30 30 32 0D11 爱普生X300 9600 无开机：50 57 52 20 4F 4E 0D关机：50 57 52 20 4F 46 46 0D12 联想9600 无开机：50 4F 57 52 20 20 20 31 0D关机：50 4F 57 52 20 20 20 30 0D13 NEC 38400 无开机：02 00 00 00 00 02关机：02 01 00 00 00 0314 松下19200 无开机：02 50 4F 4E 03关机：02 50 4F 46 0315 明基115200 无开机：0D 2A 70 6F 77 3D 6F 5E 23 0D关机：0D 2A 70 6F 77 3D 6F 56 66 23 0D16 富可视9600 无开机：28 50 57 52 31 29关机：28 50 57 52 30 2917 夏普9600 无开机：50 4F 57 52 20 20 20 31 0D关机：50 4F 57 52 20 20 20 30 0D18 三菱9600 无开机：30 30 21 0D关机：30 30 22 0D19 丽讯0855ST 9600 无开机：56 39 39 53 30 30 30 31 0D关机：56 39 39 53 30 30 30 32 0D20 优派6383S 115200 无开机：06 14 00 04 00 34 11 00 00 5D关机：06 14 00 04 00 34 11 01 00 5E以上为投影仪控制码对照表，现与投影仪配套使用的点圆互动多媒体壁挂一体机，是目前最新的多媒体教室解决方案，详情请联系我们，应用图示请看下图：。
投影机RS232控制代码
代码写入到中控中 ⑧ 如果厂家提供的是ASAII码，需要先作ASAII������ 16进
制码的转换，方法是，将ASAII码输入到【VGA、VIDEO、 POWER ON、POWER OFF】四个代码窗口中，按一下 【ASAII������ 16进制】按钮，原来输入的四个窗口中的代 码就转换成16进制码，根据厂家提供的代码要求，可能需 要加上象起始码、确认码之类的代码（不同厂家不一定一 样），再进行保存、发送等步骤直至控制码录入完成。
当所有控制命令全部写入后，关闭写码程 序。
二、投影机RS232控制代码的录入
数据库中没有您需要的投影机RS232控制代 码时，您需要在投影机使用手册中或向投 影机厂家索取相关代码，按以下方法输入 到以下窗口中：
① 先点击【添加型号命令】按钮，出现以上窗口 ② 输入投影机的品牌和型号 ③ 在【波特率选择】下拉窗口中选择控制代码的波特率 ④ 在【校验类型】中选择厂家提供的校验类型 ⑤ 再输入提供的【VGA、VIDEO、POWER ON、
RS232控制线连接
将后面板上投影机控制口的P 5（数据地）、P 2 （控制时为发送数据），分别与投影机PC控制口 （投影机上标有RS232C、CONTROL或PC CONTROL，有方型串口或圆型串口）中定义的 数据地和数据接收脚相连即可（注：投影机定义 的数据发送脚不要连接）。
单击【查找】按钮，出现以下窗口：
在查找关键词中输入您的投影机的品牌型 号，如上图所示。如果数据库中有您的品 牌型号投影机，那么在【选择投影机型号】 窗口中就出现该型号，或在【选择投影机 型号】下拉菜单中选择您需要的型号，如 下图：
投影机RS232控制代码
投影机 RS232 控制代码
广州宏控电子科技有限公司
更多内容请浏览
http://www.
1
020-85260060
广州宏控电子科技有限公司(中控系统/矩阵切换器生产厂家)
3M ......................................................................................................................................................... 3 ASK ......................................................................................................................................................4 BARCO.................................................................................................................................................. 6 BOXLIGHT .....................................................................................................................................7 CHRISTIE........................................................................................................................................... 8 DIGITEL ............................................................................................................................................. 9 EIKI ....................................................................................................................................................9 INFOCUS ........................................................................................................................................... 13 LENOVO .............................................................................................................................................18 LUMENS .............................................................................................................................................19 NEC ....................................................................................................................................................20 OPTOMA .............................................................................................................................................21 PLUS ..................................................................................................................................................22 POLAROID......................................................................................................................................... 23 PROJECTIONDESIGN .....................................................................................................................23 PROXIMA ........................................................................................................................................... 23 VIEWSONIC ......................................................................................................................................27 爱普生 .............................................................................................................................................27 奥视 ..................................................................................................................................................31 东芝 ..................................................................................................................................................32 飞浰普 .............................................................................................................................................35 富士通 .............................................................................................................................................36 惠普 ..................................................................................................................................................36 佳能 ..................................................................................................................................................37 明基 ..................................................................................................................................................38 日立 ..................................................................................................................................................40 三洋 ..................................................................................................................................................42 胜利 ..................................................................................................................................................45 松下 ..................................................................................................................................................47 索尼 ..................................................................................................................................................48 夏普 ..................................................................................................................................................49
明基(BenQ)投影仪通用中控代码
3. Command Table
Note: The available features are different by model. (eg. source, audio settings, aspect ratio..etc.), please refer to the user manual for the further information. Function Power Type Write Write Read Write Write Write Write Write Write Source Selection Write Write Write Write Write Write Read Write Write Audio Control Read Write Write Operation Power On Power off Power Status COMPUTER/YPbPr COMPUTER 2/YPbPr2 Component DVI-A DVI-D HDMI HDMI 2 Composite S-Video Network USB Display USB Reader Current source Mute On Mute Off Mute Status Volume + Volume 3
Read Write Write Read Write Write Write Audio source Write select Write Write Write Read Write Write Write Write Write Picture Mode Write Write Write Write Write Write Read Write Write Read Write Write Picture Setting Read Write Write Read Write Write Read
松下投影索尼投影爱普生投影明基投影串口指令大全
三洋Sanyo投影机EF10/EF12/XF10/XF12控制代码波特率：19200数据位：8停止位：1奇偶校验：投影机开：4330300D投影机关：4330310D电脑：4330350D视频：4330370DS视频：4330380DD V I：4330350D松下780NTU/750U/759VU/759XU/6500U/6600U/X100控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S视频：024949533A53564403D V I：024949533A44564903松下711/701/511/501/711U/701U/501U/520/720/7500/7600控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S视频：024949533A53564403松下Panasonic投影机7500U/7600U/595U/592U/390U/U1X90/U1S90控制代码波特率：9600数据位：停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S视频：024949533A53564403松下76U/56U/75U/55U/797U/797PXU/797VXU/797PWU/797VU/597U/795U/730NTU控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S视频：024949533A53564403明基8225/8235/8125投影机控制代码波特率：19200数据位：8停止位：1奇偶校验：投影机开：BEEF02060013CEAA0000000000投影机关：BEEF0206003EC4D70000000000电脑：BEEF020600AEC6C70000000000视频：BEEF02060051C6C80000000000S视频：BEEF02060080C7C90000000000索尼Sony投影机PX35/PX40/FX51控制代码波特率：38400数据位：8停止位：1奇偶校验：2投影机开：A90102000003039A 投影机关：A90102000000039A电脑：A90001000002039A视频：A90001000000019AA90001000001019AEpson爱普生投影机EMP-7700/7600/5600控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：1D00090101000301F1 投影机关：1D00090101000300F2电脑：1D00090101010010E41D00090101010021D3S视频：1D00090101010022D2D V I：1D00090101010050A4Epson爱普生投影机810/800/600/TS10控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452032310D视频：534F555243452034310DS视频：534F555243452034320DD V I：534F555243452031320DEpson爱普生投影机720/730/520/30/52/73/53/S1控制代码波特率：9600数据位：81奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452031310D视频：534F555243452034310DS视频：534F555243452034320DEpson爱普生投影机735控制代码波特率：96008停止位：1奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452031310D视频：534F555243452034310DS视频：534F555243452034320D三洋Sanyo投影机EF10/EF12/XF10/XF12控制代码波特率：19200 数据位：8停止位：1奇偶校验：投影机开：4330300D 投影机关：4330310D 电脑：4330350D 视频：4330370D S 视频：4330380DD V I：4330350D松下780NTU/750U/759VU/759XU/6500U/6600U/X100控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S 视频：024949533A53564403D V I：024949533A44564903松下711/701/511/501/711U/701U/501U/520/720/7500/7600控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S 视频：024949533A53564403松下Panasonic投影机7500U/7600U/595U/592U/390U/U1X90/U1S90控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S 视频：024949533A53564403松下76U/56U/75U/55U/797U/797PXU/797VXU/797PWU/797VU/597U/795U/730NTU控制代码波特率：9600数据位：停止位：1奇偶校验：投影机开：02504F4E03投影机关：02504F4603电脑：024949533A52473103视频：024949533A56494403S 视频：024949533A53564403明基8225/8235/8125投影机控制代码波特率：19200数据位：8停止位：1奇偶校验：投影机开：BEEF02060013CEAA0000000000投影机关：BEEF0206003EC4D70000000000电脑：BEEF020600AEC6C70000000000视频：BEEF02060051C6C80000000000S 视频：BEEF02060080C7C90000000000索尼Sony投影机PX35/PX40/FX51控制代码波特率：38400数据位：8停止位：1奇偶校验：2投影机开：A90102000003039A 投影机关：A90102000000039A电脑：A90001000002039A视频：A90001000000019AS 视频：A90001000001019AEpson爱普生投影机EMP-7700/7600/5600控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：1D00090101000301F1 投影机关：1D00090101000300F2电脑：1D00090101010010E4视频：1D00090101010021D3S 视频：1D00090101010022D2D V I：1D00090101010050A4Epson爱普生投影机810/800/600/TS10控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452032310D视频：534F555243452034310DS 视频：534F555243452034320DD V I：534F555243452031320DEpson爱普生投影机720/730/520/30/52/73/53/S1控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452031310D视频：534F555243452034310DS 视频：534F555243452034320DEpson爱普生投影机735控制代码波特率：9600数据位：8停止位：1奇偶校验：投影机开：505752204F4E0D投影机关：505752204F46460D电脑：534F555243452031310D视频：534F555243452034310DS 视频：534F555243452034320D。
明基(BenQ)投影仪通用中控代码
Color Temperature-Cool <CR>*ct=cool#<CR> <CR>*ct=cooler#<CR> <CR>*ct=?#<CR> <CR>*asp=4:3#<CR> <CR>*asp=16:9#<CR> <CR>*asp=16:10#<CR> <CR>*asp=AUTO#<CR> <CR>*asp=REAL#<CR> <CR>*asp=LBOX#<CR> <CR>*asp=WIDE#<CR> <CR>*asp=ANAM#<CR> <CR>*asp=?#<CR> <CR>*zoomI#<CR> <CR>*zoomO#<CR> <CR>*auto#<CR> <CR>*BC=on#<CR> <CR>*BC=off#<CR> <CR>*BC=?#<CR> <CR>*pp=FT#<CR> <CR>*pp=RE#<CR> <CR>*pp=RC#<CR> <CR>*pp=FC#<CR> <CR>*QAS=on#<CR> <CR>*QAS=off#<CR>
Read Write Write Read Write Write Write Audio source Write select Write Write Write Read Write Write Write Write Write Picture Mode Write Write Write Write Write Write Read Write Write Read Write Write Picture Setting Read Write Write Read Write Write Read
常用投影机rs232控制码
厂商型号串口参数连接ON OFF PC1 VIDEO1 PC2 VIDEO2 核预关机3M MP7640 19200,n,8,1 3,5 $be,$ef,3,6,0,$ba,$d2,1,0,0 $be,$ef,3,6,0,$2a,$d3,1,0,0,$be,$ef,3,6,0,$fe,$d2,1,0,0,$be,$ef,3,6,0,$6e,$d3,1,0,0, None$be,$ef,3,6,0,$9e,$d3,1,0,0,$20,2,05 60MP8650/8660/8780 9600,n,8,1 'D00W00',13 'D00W01',13 'D02W01',13 'D02W11',13 'D02W02',13 'D02W12',13 5 90 MP8670 9600,n,8,1* 3,5 $31,$11,$3f $31,$11,$3e $31,$21,$21 $31,$21,$11 $31,$21,$22 $31,$21,$12 Y 5 60 MP8745 9600,n,8,1* 3,5 $31,$11,$3f $31,$11,$3e $31,$21,$21 $31,$21,$11 $31,$21,$22 None 5 60MP8746/8747 19200,n,8,1 3,5 $be,$ef,3,6,0,$ba,$d2,1,0,0, $be,$ef,3,6,0,$2a,$d3,1,0,0,$be,$ef,3,6,0,$fe,$d2,1,0,0,$be,$ef,3,6,0,$6e,$d3,1,0,0,$be,$ef,3,6,0,$3e,$d0,1,0,0,$be,$ef,3,6,0,$9e,$d3,1,0,05 60MP8725/8730/8740 9600,n,8,1* 3,5 $31,$11,$1f $31,$11,$1e $31,$21,$21 $31,$21,$11 $31,$21,$22 $31,$21,$12 5 60 Acer 7753CASK A2-A10/A8+/A9+/A10+ 1200,n,7,1 13 ,'PWR;1',13 13 ,'PWR;0',13 13 ,'SRC;0',13 13 ,'SRC;2',13 13 ,'SRC;3',13 13 ,'SRC;5',13 Y 5C80/90/100 9600,n,8,1* $be,$ef,$80,6,0,0,0,1,0,1,0,1,0,1,0 $be,$ef,$80,6,0,0,0,1,0,1,0,1,0,0,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,0,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,3,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,4,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,2,0Y 5BARCO 2100LC 9600,n,8,1* $fe ,1,$65,$66, $ff $fe,1,$66,$67,$ff $fe,$01,$31,$0, ,$36,$ff $fe,$01,$31,$01,$33,$ff $fe,$01,$31,$05,$37,$ff $fe,$01,$31,$02,$34,$ff 5Canon LV-serial 19200,n,8,1 3,5 ‘C00’,13,10 ‘C01’,13,10 ‘C05’,13,10 ‘C07’,13,10 ‘C06’,13,10 ‘C08’,13,10 Y 5CTX 702EIKI LC-870 3,5LC-X2U/X984 19200,n,8,1 3,5 ‘C00’,13,10 ‘C01’,13,10 ‘C05’,13,10 ‘C07’,13,10 ‘C06’,13,10 ‘C08’,13,10 Y 5 EPSON EMP50/70 9600,n,8,1 3,4,5 $1b,7,1,0,3,1,$f4 $1b,7,1,0,3,0,$f5 $1b,7,1,1,0,$10,$e7 $1b,7,1,1,0,$21,$d6 None $1b,7,1,1,0,$22,$d5 Y 5 120 EMP800/810 9600,n,8,1 3,5 ‘PWR ON’,13 ‘PWR OFF’,13 ‘SOURCE 11’,13 ‘SOURCE 41’,13 ‘SOURCE 21’,13 ‘SOURCR 42’,13 Y 5EMP5300/5500/7300/7500 9600,n,8,1 3,4,5 $1b,7,1,0,3,1,$f4 $1b,7,1,0,3,0,$f5 $1b,7,1,1,0,$10,$e7 $1b,7,1,1,0,$20,$d7 Bugexist None Y 5 90 EMP5350/5600/7250/7350/7600/7700/8000/8100/90009600,n,8,1 3,4,5 $1b,7,1,0,3,1,$f4 $1b,7,1,0,3,0,$f5 $1b,7,1,1,0,$10,$e7 $1b,7,1,1,0,$21,$d6 $1b,7,1,1,0,$11,$e6 $1b,7,1,1,0,$22,$d5 Y 5 60 HITACHI CP-S860/X960/X970 9600,n,8,1 $31,$11,$3f $31,$11,$3e $31,$21,$21 $31,$21,$11 $31,$21,$22 None Y 5 90CP-X980/X985 19200,n,8,1 $be,$ef,3,6,0,$ba,$d2,1,0,0, $be,$ef,3,6,0,$2a,$d3,1,0,0,$be,$ef,3,6,0,$fe,$d2,1,0,0,$be,$ef,3,6,0,$6e,$d3,1,0,0,$be,$ef,3,6,0,$3e,$d0,1,0,0,$be,$ef,3,6,0,$9e,$d3,1,0,0,$20,2,05 90Infocus LP400/425z/435z/755 19200,n,8,1 T,G ‘(PWR1)’,13 ‘(PWR0)’,13 ‘(SRC0)’,13 ‘(SRC2)’,13 ‘(SRC3)’,13 None 5 180 LP500/530 19200,n,8,1 T,G ‘(PWR1)’,13 ‘(PWR0)’,13 ‘(SRC0)’,13 ‘(SRC2)’,13 ‘(SRC3)’,13 ‘(SRC5)’,13 5 180 LP770 9600,n,8,1 T,G ’00!’,13 ’00”’,13 ‘00_r1’,13 ‘00_v1’,13 ‘00_r2’,13 ‘00_v2’,13 5 1801Kocak DP900/1100 19200,n,8,1 ‘(PWR0)’,13 ‘(PWR1)’,13 ‘(SRC0)’,13 None ‘(SRC1)’None 5厂商型号串口参数联结ON OFF PC1 VIDEO1 PC2 VIDEO2 开关机Mitsubishi LVP-X70U/X50U/S50U/S250/SA51U9600,n,8,1 3,5 ’00!’,13 ‘00”’,13 ‘00_r1’,13 ‘00_v1’,13 None None 5LVP-X390/X400 9600,n,8,1 3,5 ’00!’,13 ‘00”’,13 ‘00_r1’,13 ‘00_v1’,13 ‘00_r2’,13 ‘00_v2’,13 5 Panasonic PT-L557/757/759/797/6500 9600,n,8,1 3,5 2,‘PON’,3 2,‘POF’,3 2,‘IIS:RG1’,3 2,‘IIS:VID’,3 2,‘IIS:RG2,3 None Y 5Paloroid CP-XL8810/8840/SL8850 9600,n,8,1 $be,$ef,$80,6,0,0,0,1,0,1,0,1,0,1,0 $be,$ef,$80,6,0,0,0,1,0,1,0,1,0,0,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,0,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,3,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,4,0$be,$ef,$80,6,0,0,0,1,0,1,0,$32,0,2,05CP-X1800 1200,n,7,1 13,'PWR;1',13 13,'PWR;0',13 13,'SRC;0',13 13,'SRC;2',13 13,'SRC;3',13 13,'SRC;5',13 Y 5 Proxima LS1/LS2/LX2/RX7000/DP9300/9400/5900/5950/9250/9250+19200,n,8,1 3,5 ‘C00’,13,10 ‘C01’,13,10 ‘C05’,13,10 ‘C07’,13,10 ‘C06’,13,10 ‘C08’,13,10 Y 5 DP9310 19200,n,8,1 3,5 ‘C00’,13 ‘C01’,13 ‘C05’,13 ‘C07’,13 ‘C06’,13 ‘C08’,13 Y 5DP6150 9600,n,8,1 $be,$ef,$80,6,0,1,0,1,0,1,0 $be,$ef,$80,6,0,1,0,1,0,0,0$be,$ef,$80,6,0,1,0,$32,0,0,0$be,$ef,$80,6,0,1,0,$32,0,3,0$be,$ef,$80,6,0,1,0,$32,0,4,0$be,$ef,$80,6,0,1,0,$32,0,2,05DP5800/6800 1200,n,7,1 $31,$11,$1f $31,$11,$1e $31,$21,$21 $31,$21,$11 $31,$21,$22 $31,$21,$12 5S520 19200,n,8,1 $be,$ef,3,6,0,$ba,$d2,1,0,0,$60,1,0 $be,$ef,3,6,0,$2a,$d3,1,0,0,$60,0,0$be,$ef,3,6,0,$fe,$d2,1,0,0,$20,0,0$be,$ef,3,6,0,$6e,$d3,1,0,0,$20,1,0None $be,$ef,3,6,0,$9e,$d3,1,0,0,$20,2,05DP6850+/6860 19200,n,8,1 $be,$ef,3,6,0,$ba,$d2,1,0,0,$60,1,0 $be,$ef,3,6,0,$2a,$d3,1,0,0,$60,0,0$be,$ef,3,6,0,$ fe,$d2,1,0,0,$20,0,0$be,$ef,3,6,0,$6e,$d3,1,0,0,$20,1,0$be,$ef,3,6,0,$3e,$d0,1,0,0,$20,4,0$be,$ef,3,6,0,$9e,$d3,1,0,0,$20,2,05NEC MT850/1050/1055MT840/1040/104538400,n,8,1 2,0,0,0,0,2 2,1,0,0,0,3 2,3,0 ,0,2,1,1,9 2,3,0,0,2,1,6,14 2,3,0,0,2,1,2,10 2,3,0,0,2,1,11,19 5 MT840E/1040E/1045ELT84/85/140/150/154/155VT440/54038400,n,8,1 2,0,0,0,0,2 2,1,0,0,0,3 2,3,0,0,2,1,1,9 2,3,0,0,2,1,6,14 None 2,3,0,0,2,1,11,19 5LT156/XT5000 38400,n,8,1 2,0,0,0,0,2 2,1,0,0,0,3 2,3,0,0,2,1,1,9 2,3,0,0,2,1,6,14 2,3,0,0,2,1,26,34 2,3,0,0,2,1,11,19 5 SANYO All 19200,n,8,1 3,5 ‘C00’,13 ‘C01’,13 ‘C05’,13 ‘C07’,13 ‘C06’,13 ‘C08’,13 Y 5 180SHARP XG-NV6/7/P10/V10/C30 9600,n,8,1 3,5 ‘POWR’,32,32,32,’1’,13 ‘POWR’,32,32,32,’1’,13‘IRGB’,32,32,32,’1’,13‘IVED’,32,32,32,’1’,13‘IRGB’,32,32,32,’2’,13None 5 902SONY VPL-PXx0/PXx1 38400,n,8,1 3,5TOSHIBA TLP-670 9600,n,8,1 3,5 2,‘PON’,3 2,‘POF’,3 2,‘IN1’,3 2,‘IN2’,3 None None 5 180 3。
三菱投影机RS232控制码V201009-新版.xls.deflate
三菱电机投影机PC控制代码使用方法《简易指南》2010年8月RS232控制代码 （ A ）[通讯设置]PROTOCOL RS-232CBAUD RATE 9600 [bps]DATA LENGTH 8 [bits]PARITY BIT NONESTOP BIT 1 [bit]FLOW CONTROL NONE[命令输入]控制项目ASCII HEXPOWER ON00! <CR>30h 30h 21h 0DhPOWER OFF00" <CR>30h 30h 22h 0DhINPUT COMPUTER 100_r1 <CR>30h 30h 5Fh 72h 31h 0DhINPUT COMPUTER 200_r2 <CR>30h 30h 5Fh 72h 32h 0DhINPUT VIDOE00_v1 <CR>30h 30h 5Fh 76h 31h 0DhINPUT S-VIDOE00_v2 <CR>30h 30h 5Fh 76h 32h 0DhINPUT DVI/HDMI 100_d1 <CR>30h 30h 5Fh 64h 31h 0DhINPUT DVI/HDMI 200_d2 <CR>30h 30h 5Fh 64h 32h 0DhINPUT COMPONENT00_c1 <CR>30h 30h 5Fh 63h 31h 0Dh[说明：]2) 大部分中控器字符之间不空格适用三菱投影机型号 - 2010年8月25日止DLP投影机LCD投影机家用投影机DX-540/545/548LX-390HC6050DX-320/DS-327LX-510/610/5120/6150HC77-10SPF-15S<R>/X<R>LX-5280/6280HC77-20SPM-332X/343X/330X LW-600/6100/6200/7700HC77-60DMD-350X/353X LX-7300/7800/7350/7850MD-300S/300X LF-8300MD-150S/307S/307XMD-311X/315SMD-549X/565X/580X/640XMD-7200/7500MD-530X/536XMD-360X/363X/550X/553XGS-312/316GX-318/318(PA)/385/570GW-365/760/6800GX-6400GX-320/325/540/545 GX-320ST/740/745 GF-780年8月版备注如无此输入通道则空置如无此输入通道则空置如无此输入通道则空置如无此输入通道则空置如无此输入通道则空置。
控制系统中投影机RS232串口代码
视频：02H49H4EH33H03H
S-VIDEO：02H49H4EH34H03H
CAMERA：02H49H4EH36H03H
东芝
DIN-8P
RD：1
TD：7
GND：4
新的机型
9600bps
220型
开机：02H50H4FH4EH03H
关机：02H50H4FH46H03H（有确认信息）
关机：BEHEFH80H06H00H00H00H01H00H01H00H00H00H
VGA1：BEHEFH80H06H00H00H00H01H00H32H00H00H00H
DVI1：BEHEFH80H06H00H00H00H01H00H32H00H01H00H
S1：BEHEFH80H06H00H00H00H01H00H32H00H02H00H
INPUTA(computer) : A5H 01H 00H 01H 00H 01H 03H 00H 01H 00H 01H 17H 00H 80H 08H 00H 06H 40H 54H 2BH 00H 00H 00H A4H 5AH
VIDEO : A5H 01H 00H 01H 00H 01H 03H 00H 01H 00H 01H 17H 00H 80H 08H 00H 06H 40H 54H 2AH 00H 00H 00H A5H 5AH
视频：49H 56H 3BH 44H 20H 20H 20H 31H 0DH
普乐士(PLUS)
U2 850W
19200 bps
DB9：
RD：3
GND：5
TD：2
开机：23H 50H 31H 0DH 0AH
关机：23H 50H 30H 0DH 0AH
