ShortCommunicationAtmosphericemissionsestimationofHg,As,andSefromcoal-firedpowerplantsinChina,2007
HezhongTiana,⁎,YanWanga,ZhigangXueb,YipingQua,FaheChaib,JimingHaocaStateKeyJointLaboratoryofEnvironmentalSimulation&PollutionControl,SchoolofEnvironment,BeijingNormalUniversity,Beijing100875,China
bChineseResearchAcademyofEnvironmentalSciences,Beijing100012,China
cDepartmentofEnvironmentalScienceandEngineering,TsinghuaUniversity,Beijing100084,China
abstractarticleinfoArticlehistory:Received30August2010Receivedinrevisedform18April2011Accepted21April2011Availableonline31May2011
Keywords:EmissionHgAsSeEmissionfactorCoal-firedpowerplants
OverhalfofcoalinChinaisburneddirectlybypowerplants,becominganimportantsourceofhazardoustraceelementemissions,suchasmercury(Hg),arsenic(As),andselenium(Se),etc.Basedoncoalconsumptionbyeachpowerplant,emissionfactorsclassifiedbydifferentboilerpatternsandairpollutioncontroldevicesconfiguration,atmosphericemissionsofHg,As,andSefromcoal-firedpowerplantsinChinaareevaluated.ThenationaltotalemissionsofHg,As,andSefromcoal-firedpowerplantsin2007arecalculatedat132t,550t,and787t,respectively.Furthermore,accordingtothepercentageofcoalconsumedbyunitsequippedwithdifferenttypesofPMdevicesandFGDsystems,speciationofmercuryisestimatedasfollows:80.48tofHg,49.98tofHg2+,and1.89tofHgP,representing60.81%,37.76%,and1.43%ofthetotals,respectively.TheemissionsofHg,As,andSeinChina'seasternandcentralprovincesaremuchhigherthanthoseinthewest,exceptforprovincesinvolvedintheprogramofelectricitytransmissionfromwesttoeastChina,suchasSichuan,Guizhou,Yunnan,Shaanxi,etc.©2011ElsevierB.V.Allrightsreserved.
1.IntroductionThemajoruseofcoalisthegenerationofpowerthroughcombustion(Pavageauetal.,2002).Duringthecombustionprocess,significantamountsofvolatiletoxictraceelementssuchasmercury(Hg),arsenic(As),andselenium(Se)arereleasedanddistributedamongfluegasandflyash(Pavageauetal.,2002;Otero-Reyetal.,2003;Al-Abedetal.,2008).ThedangerouseffectsofHg,As,andSeontheenvironmentandpublichealthhavereceivedwiderangeofattentionthroughouttheworld(LenzandLens,2009;Dukeretal.,2005;Nelson,2007;WiedinmyerandFriedli,2007;ZhangandWong,2007).InChina,coalconstitutesabout70%ofthetotalprimaryenergyconsumption(YouandXu,2009).About55%ofthetotalcoalconsumedwasburneddirectlybypowerplantsin2007(NBS,NDRC,2009);anditispredictedthattheproportionwillincreaseto65%in2050(YouandXu,2009).Thus,coal-firedpowerplantshavebecomeonemainsourceofatmosphericconventionalairpollutantsemissions(PM,SO2,NOX),aswellashazardousairpollutantsemissions(Hg,As,andSe,etc.)inChina(WangandGao,2001;Wuetal.,2006;Streetsetal.,2005;Wangetal.,2008a).Inrecentyears,thereisawidespreadconcernoverthecontrolandreductionofatmosphericHgemissionsinChina(Wuetal.,2006;Streetsetal.,2005;FengandHong,1996;Wangetal.,2000;Jiangetal.,2005).Wuetal.(2006)estimatedthatmercuryemissionfromcoal-firedpowerplantsinChinaincreasedfrom63.4tto100.1twithanannualgrowthrateof5.9%during1995–2003.However,thecomprehensiveanddetailedstudiesonAsandSeemissionsarequitelimited.Wangetal.(2008a)estimatedthat442.31tofAswerereleasedfromcoalcombustionin1997,and76.9tofwhichwerefromcoal-firedpowerplants.Controlofhazardouselementsemissionsfromcoal-firedpowerplantsrequiresanunderstandingofthemannerinwhichtheyoccurincoal,theirbehaviorduringcombustion,theirabatementthroughvariousairpollutioncontroldevices(APCD),theirforminthestackgas,aswellasthefinalamountreleasedintotheatmosphere.Inthispaper,atmosphericemissionsofHg,As,andSefromcoal-firedpowerplantsinChinaundertheexistingparticulatematters(PM)andsulfurdioxides(SO2)controlconditionsareevaluatedanddiscussedindetail
byprovincesandregionsin2007.
2.MethodologyAtmosphericemissionsofHg,As,andSefromcoal-firedpowerplantsarecalculatedbycombiningthedetailedcoalconsumptiondata,elementcontentsincoal,andthespecificemissionfactorswhichareclassifiedbydifferentboilerpatternsandairpollutioncontrol
ScienceoftheTotalEnvironment409(2011)3078–3081⁎Correspondingauthorat:SchoolofEnvironment,BeijingNormalUniversity,No.19XinjiekouwaiStreet,Beijing100875,China.Tel./fax:+861058800176.E-mailaddress:hztian@bnu.edu.cn(H.Tian).
0048-9697/$–seefrontmatter©2011ElsevierB.V.Allrightsreserved.doi:10.1016/j.scitotenv.2011.04.039
ContentslistsavailableatScienceDirectScienceoftheTotalEnvironment
journalhomepage:www.elsevier.com/locate/scitotenv
