C型钢理论重量表[1]
c型钢理论重量表、常用C型钢的理论重量
c型钢理论重量表|常用C型钢的理论重量C型钢经热卷板冷弯加工而成，壁薄自重轻，截面性能优良，强度高，与传统槽钢相比，同等强度可节约材料30%。
C型钢广泛用于钢结构建筑的檩条、墙梁，也可自行组合成轻量型屋架、托架等建筑构件。
由于c型钢规格太多，下面只列出部分。
截面积和理论重量的计算方法可参考c型钢理论重量计算器型号尺寸(mm)(毫米) 截面积理论重量h高度b底边 a t厚度cm2(平方厘米) kg/m(公斤/米)C80 80 40 15 2 3.64 2.86 C100 100 50 15 2.5 5.5 4.32 C120 120 50 20 2.5 6.25 4.91 C120 120 60 20 3 8.04 6.31 C140 140 60 20 3 8.64 6.78 C160 160 70 20 3 9.84 7.72 C180 180 70 20 3 10.44 8.20 C200 200 70 20 3 11.04 8.67 C220 220 70 20 3 11.64 9.14 C240 240 100 20 3 12.24 9.61 C260 260 100 20 3 12.84 10.08 C280 280 100 20 3 13.44 10.55 C300 300 100 20 3 14.04 11.02c型钢截面如图所示，有一个红色长方形，两个绿色长方形，两个蓝色长方形组成。
h b-2*taab-2*t红色长方形面积=高×厚绿色长方形面积=(底-厚×2)×厚×2蓝色长方形面积=边×厚×2截面积=(高+(底-厚×2)×2+边×2)×厚钢材密度(比重)7.85克/立方厘米型钢截面特性查询及计算工具下载大家计算型钢截面积，苦于找不到计算方法，我也是在网上搜索了好久终于找到一个，不敢独享，现在贡献出来和大家分享。
C、Z型钢理论重量表
C、Z型钢理论重量表 C型钢理论质量表
型号 尺 寸(mm) h b a t C型钢80 80 40 15 1.5 C型钢80 80 50 15 2.0 C型钢100 100 40 15 2.0 C型钢100 100 50 20 2.5 C型钢120 120 50 20 2.2 C型钢120 120 60 20 2.75 C型钢140 140 50 20 2.0 C型钢140 140 60 20 2.5 C型钢140 140 70 20 3.0 C型钢160 160 50 20 2.2 C型钢160 160 60 20 2.5 C型钢160 160 70 20 2.75 C型钢180 180 70 20 2.3 C型钢180 180 75 20 2.5 C型钢180 180 80 20 3.0 C型钢200 200 70 20 2.5 C型钢200 200 80 20 2.75 C型钢200 200 85 20 3.0 C型钢220 220 75 20 2.5 C型钢220 220 80 20 2.75 C型钢220 220 85 20 3.0 C型钢250 250 75 20 2.5 C型钢250 250 80 25 2.75 C型钢250 250 85 25 3.0 C型钢280 280 70 20 2.3 C型钢280 280 75 20 2.5 C型钢280 280 80 25 3.0 C型钢300 300 80 20 2.5 C型钢300 300 100 25 3.0
Z型钢理论质量表
型号 尺 寸(mm) h b a t Z型钢80 80 40 15 1.5 Z型钢80 80 50 15 2.0 Z型钢100 100 40 15 2.0 Z型钢100 100 50 20 2.5 Z型钢120 120 50 20 2.2 Z型钢120 120 60 20 2.75 Z型钢140 140 50 20 2.0 Z型钢140 140 60 20 2.5 Z型钢140 140 70 20 3.0 Z型钢160 160 50 20 2.2 Z型钢160 160 60 20 2.5 Z型钢160 160 70 20 2.75 Z型钢180 180 70 20 2.3 Z型钢180 180 75 20 2.5 Z型钢180 180 80 20 3.0 Z型钢200 200 70 20 2.5 Z型钢200 200 80 20 2.75 Z型钢200 200 85 20 3.0 Z型钢220 220 75 20 2.5 Z型钢220 220 80 20 2.75 Z型钢220 220 85 20 3.0 Z型钢250 250 75 20 2.5 Z型钢250 250 80 25 2.75 Z型钢250 250 85 25 3.0 Z型钢280 280 70 20 2.3 Z型钢280 280 75 20 2.5 Z型钢280 280 80 25 3.0 Z型钢300 300 80 20 2.5 Z型钢300 300 100 25 3.0
C型钢的理论重量
C型钢的理论重量型号每米重(kg) 型号每米重(kg)C 80 × 50 × 20 × 2.25 3.886 C 180 × 60 × 20 × 3.0 8.007C 80 × 50 × 20 × 2.50 4.318 C 180 × 70 × 20 × 3.0 8.478C 80 × 50 × 20 × 2.75 4.749 C 180 × 80 × 20 × 3.0 8.949C 80 × 50 × 20 × 3.00 5.181 C 200 × 50 × 20 × 2.5 6.673 C 100 × 50 × 20 ×2.25 4.239 C 200 × 60 × 20 × 2.5 7.065 C 100 × 50 × 20 × 2.50 4.710 C 200 × 70 × 20 × 2.5 7.458 C 100 × 50 × 20 × 2.75 5.181 C 200 × 80 × 20 × 2.5 7.850 C 100 × 50 × 20 × 3.00 5.652 C 200 × 50 × 20 × 3.0 8.007 C 120 × 50 × 20 × 2.25 4.592 Ｃ200 × 60 × 20 × 3.0 8.478 C 120 × 50 × 20 × 2.50 5.103 C 200 × 70 × 20 × 3.0 8.949 C 120 × 50 × 20 × 2.75 5.613 C 200 × 80 × 20 × 3.0 9.420 C 120 × 50 × 20 × 3.00 6.123 C 220 × 50 × 20 × 2.5 7.065 C 140 × 50 × 20 × 2.50 5.495 C 220 × 60 × 20 × 2.5 7.458 C 140 × 60 × 20 × 2.50 5.888 C 220 × 70 × 20 × 2.5 7.850 C 140 × 50 × 20 × 3.00 6.594 C 220 × 80 × 20 × 2.5 8.243 C 140 × 60 × 20 × 3.00 7.065 C 220 × 50 × 20 × 3.0 8.478 C 160 × 50 × 20 × 2.50 5.888 C 220 × 60 × 20 × 3.0 8.949 C 160 × 60 × 20 × 2.50 6.280 C 220 × 70 × 20 × 3.0 9.420 C 160 × 70 × 20 × 2.50 6.673 C 220 × 80 × 20 × 3.0 9.891 C 160 × 50 × 20 × 3.00 7.065 C 240 × 50 × 20 × 2.5 7.458 C 160 × 60 × 20 × 3.00 7.536 C 240 × 60 × 20 × 2.5 7.850 C 160 × 70 × 20 × 3.00 8.007 C 240 × 70 × 20 × 2.5 8.243 C 180 × 50 × 20 × 2.50 6.280 C 240 × 80 × 20 × 2.5 8.635 C 180 × 60 × 20 × 2.50 6.673 C 240 × 50 × 20 × 3.0 8.949 C 180 × 70 × 20 × 2.50 7.065 C 240 × 60 × 20 × 3.0 9.420 C 180 × 80 × 20 × 2.50 7.458 C 240 × 70 × 20 × 3.0 9.891 C 180 × 50 × 20 × 3.00 7.536 C 240 × 80 × 20 × 3.0 10.362型号尺寸(mm) 截面积理论重量h b a t cm2 kg/mC80 80 40 15 2 3.74 2.72 C100 100 50 15 2.5 5.23 4.11 C120 120 50 20 2.5 5.98 4.7 C120 120 60 20 3 7.65 6.01 C140 140 60 20 3 8.25 6.48 C160 160 70 20 3 9.45 7.42C180 180 70 8.64 C200 200 70 9.12C220 220 70 9.6C240 240 100 11.52C260 260 100 12C280 280 100 12.48C300 300 100 12.961,槽80x40x15x2.0,80,40,15,2,14.52,33.6,347,341600,77900,462,112900000 2,槽100x50x15x2.5,100,50,15,2.5,17.06,39.4,523,813400,171900,1090,3528000003,槽120x50x20x2.5,120,50,20,2.5,17.06,40.3,598,1294000,209600,1246,6609000004,槽120x60x20x3.0,120,60,20,3,21.06,48.7,765,1706800,373600,2296,11532000005,槽140x60x20x3.0,140,60,20,3,19.64,46.1,825,2454200,394900,2476,15898000006,槽150x50x20x1.6,150,50,20,1.6,15.24,27.2,422,1362930,141870,360,6638300007,槽150x50x20x2.0,150,50,20,2,15.24,27.2,528,1703660,177330,700,6297900008,槽150x50x20x2.5,150,50,20,2.5,15.24,27.2,660,2129580,221660,1380,10372300009,槽150x50x20x3.0,150,50,20,3,15.24,27.2,792,2555490,266000,2380,124453000010,槽150x60x20x1.6,150,60,20,1.6,19,45,451,1514130,214620,390,99587000011,槽150x60x20x2.0,150,60,20,2,19,45,564,1892660,268520,750,124484000012,槽150x60x20x2.5,150,60,20,2.5,19,45,705,2365830,335650,1470,155605000013,槽150x60x20x3.0,150,60,20,3,19,45,846,2838990,402780,2540,186726000014,槽160x60x20x2.0,160,60,20,2,18.41,44,582,2195200,274190,780,141725000015,槽160x60x20x2.5,160,60,20,2.5,18.41,44,728,2744000,342730,1520,1771660000 16,槽160x60x20x3.0,160,60,20,2.5,18.41,44,874,3292800,411280,2620,2125880000 17,槽160x70x20x3.0,160,70,20,3,22.24,52.5,742,3736400,604200,2836,307050000018,槽180x60x20x2.0,160,60,20,2,17.33,42.1,619,2861760,284520,830,1804350000 19,槽180x60x20x2.5,160,60,20,2.5,17.33,42.1,774,3602200,355650,1610,2255440000 20,槽180x60x20x3.0,160,60,20,3,17.33,42.1,926,4322640,426780,2790,270652000021,槽180x70x20x2.0,180,70,20,2,21.1,50,687,3439300,451800,870,255475000022,槽180x70x20x2.2,180,70,20,2.2,21.1,50,752,3749000,489700,1254,285654000023,槽180x70x20x2.5,180,70,20,2.5,21.1,50,848,4202000,544200,1710,319343000024,槽180x70x20x3.0,180,70,20,3,21.1,50,983,4730880,609240,2950,383212000025,槽200x65x20x2.0,200,65,20,2,18.1,44,673,3850560,353370,900,269349000026,槽200x65x20x2.5,200,65,20,2.5,18.1,44,842,4813200,441720,1760,336686000027,槽200x65x20x3.0,200,65,20,3,18.1,44,1010,5775840,530060,3030,404023000028,槽200x70x20x2.0,200,70,20,2,20,44,727,4400400,467100,920,318550000029,槽200x70x20x2.2,200,70,20,2.2,20,48,796,4798700,506400,1200,354852000030,槽200x70x20x2.5,200,70,20,2.5,20,48,898,5382100,562700,1800,398187000031,槽200x70x20x3.0,200,70,20,3,20,48,1037,6027840,629540,3120,477824000032,槽220x70x20x2.5,220,70,20,2.5,19,46,910,6263600,539850,1900,487715000033,槽220x70x20x3.0,220,70,20,3,19,46,1092,7516320,647820,3280,585258000034,槽220x70x20x3.2,220,70,20,3.2,19,46,1165,8017410,691000,3980,624267000035,槽220x75x20x2.0,220,75,20,2,20.8,51,787,5744500,568800,1290,410923000036,槽220x75x20x2.2,220,75,20,2.2,20.8,51,862,6268500,617100,1760,460930200037,槽220x75x20x2.5,220,75,20,2.5,20.7,51,973,7037600,686600,1950,570718000038,槽220x75x20x3.0,220,75,20,3,20.7,51,1119,7621240,761170,3360,684862000039,槽220x75x20x3.2,220,75,20,3.2,20.7,51,1194,8342660,811910,4080,730520000040,槽250x70x20x2.5,250,70,20,2.5,17.6,44,978,8441830,560030,2040,6427600000 41,槽250x70x20x3.0,250,70,20,3,17.6,44,1174,10130190,672040,3530,7713120000 42,槽250x70x20x3.2,250,70,20,3.2,17.6,44,1252,10805540,716840,4280,8227320000 43,槽250x80x20x2.5,250,80,20,2.5,21,51,1024,9098080,766550,2140,8721010000 44,槽250x80x20x3.0,250,80,20,3,21,51,1229,10917690,919850,3690,10465300000各行数字含义（以最后一行为例）：槽250x80x20x3.0：截面高度H=250mm；截面宽度B=80mm；卷边宽度C=20mm；厚度t=3mm；Y轴距离z0=21mm；偏心距e=51mm；截面面积A=1229mm2；惯性矩Ix=10917690mm4；惯性矩Iy=919850mm4；截面模量Wx=87342mm3；截面模量Wy=15591mm3；回转半径ix=94.3mm；回转半径iy=27.4mm；抗扭惯性矩It=3690mm4；扇形惯性矩Iw=10465300000mm4；单位重量=A*7850/1000000=9.648Kg/m；可以不要什么C型钢的规格重量表的，我给发个截图上来，然后给一个计算公式，可以按照这个公式计算各种规格C型钢的单位重量的，按照这个公式计算基本误差的，可以试一试。
c型钢理论重量表
c型钢：C型钢都是由C型钢成型机自动加工成型的。
C型钢成型机根据给定的C型钢尺寸就可以自动完成C型钢的成型工艺。
c型钢理论重量表：型号尺寸(mm)截面积理论重量hbatcm2kg/mC8080401523.742.72C10050 15 2.5 5.23 4.11 C120 120 50 20 2.5 5.98 4.7 C120 120 60 20 3 7.65 6.01 C140 14020 3 8.25 6.48 C160 160 70 20 3 9.45 7.42 C180 180 70 8.64 C200 200 70 9.12 C220 2209.6C24024010011.52C26026010012C28028010012.48C30030010012.96C型钢C型钢经热卷板冷弯加工而成，壁薄自重轻，截面性能优良，强度高，与传统槽钢相比，同等强度可节约材料30%。
C型钢适用范围：C型钢广泛用于钢结构建筑的檩条、墙梁，也可自行组合成轻量型屋架、托架等建筑构件。
此外，还可用于机械轻工制造中的柱、梁和臂等。
C型钢柃条按高度不同分为80、100、120、140、160五种规格，长度可根据工程设计确定，但考虑到运输和安装等条件，全长一般不超过12米。
C型钢都是由C型钢成型机自动加工成型的。
C型钢成型机根据给定的C型钢尺寸就可以自动完成C型钢的成型工艺。
放料①——矫平②——成型③——定型④——矫直⑤——测长⑥——冲拉筋圆孔⑦——冲椭圆连接孔⑧——成型切断⑨C型钢理论重量表尺寸重量尺寸重量80*40*20*2.53.542kg180*60*20*2.56.289kg80*40*20*2.753.853kg180*70*20*2.7580*40*20*3.0 4.156kg180*60*20*3.0 7.453kg100*50*20*2.5 4.327kg180*70*20*2.5 6.682kg100*50*20*2.75 4.716kg180*70*20*2.75 7.307kg100*50*20*3.0 5.098kg180*70*20*3.0 7.924kg120*50*20*2.5 4.719kg200*60*20*2.5 6.682kg120*50*20*2.75200*60*20*2.75 7.307kg120*50*20*3.0 5.569kg200*60*20*3.0 7.924kg140*50*20*2.5 5.112kg200*70*20*2.5 7.074kg140*50*20*2.75 5.58kg200*70*20*2.75 7.739kg140*50*20*3.0 6.04kg200*70*20*3.0 8.395kg160*50*20*2.5 5.897kg250*70*20*2.5160*50*20*2.75 6.443kg250*70*20*2.75 8.818kg160*60*20*3.0 6.982kg250*70*20*3.0 9.573kg。
C型钢理论重量表(20210214172532)
C型钢理论重量表ThiS manuscript WaS revised by the OffiCe On DeCember 10, 2020.C型钢理论重量表注:本表规格不全,可以根据工程要求加工订做。
马钢H型钢规格（I）马钢H 型钢规格（U ）TyPe PrOfiIe SiZeDimenSionG kgHB tl t2 r HW200 ×200X200 200 200 812 16 50.5200×20420020412121656.7200250 X250X250 250 250 914 16 72.4250X25525025514141682.2250300 X294X302 294 302 12 12 20 85.0300×300 300 300 10 15 20 94.5300300X305300305151520106350 X344X 348 344 348 10 16 20 115350X350350350121920137350400 X388X402 388 402 15 15 24 141394X398394398111824147350X357 350 357 19 19 20 156388X402 388 402 15 15 24 141 394X405 394 405 18 18 24 169 400×400 400 400 13 21 24 172 400X408 400 408 21 21 24 197 414X405 414 405 18 28 24 233 428X407 428 4072035 24 284400400 ×H型钢规格宽、中、窄翼缘型钢截面尺寸、理论重量热轧等边角钢(GB 9787-88)b —边宽；d —边厚热轧不等边角钢注：带括号的型号不推荐使用。
热轧工字钢斜度:1:6(普通)12% (轻型)注：带*符号的型号，是须经供需双方协议供应的品种。
C型钢理论重量表
c型钢理论重量一览表来源：【百纳网】2010-7-12 字体大小：[ 大中小]c型钢理论重量一般都是多少?市场调研发现很多朋友很想了解c型钢理论重量。
今天就给大家附上c型钢理论重量一览表还有起代表的意义。
u形c形z形型钢行业报告显示c 型钢经热卷板冷弯加工而成，壁薄自重轻，截面性能优良，强度高，与传统槽钢相比，同等强度可节约材料30%。
c型钢适用范围：c型钢广泛用于钢结构建筑的檩条、墙梁，也可自行组合成轻量型屋架、托架等建筑构件。
此外，还可用于机械轻工制造中的柱、梁和臂等。
c型钢理论重量一览表c型钢理论重量一览表1,槽80x40x15x2.0,80,40,15,2,14.52,33.6,347,341600,77900,462,1129000002,槽100x50x15x2.5,100,50,15,2.5,17.06,39.4,523,813400,171900,1090,3528000003,槽120x50x20x2.5,120,50,20,2.5,17.06,40.3,598,1294000,209600,1246,6609000004,槽120x60x20x3.0,120,60,20,3,21.06,48.7,765,1706800,373600,2296,11532000005,槽140x60x20x3.0,140,60,20,3,19.64,46.1,825,2454200,394900,2476,15898000006,槽150x50x20x1.6,150,50,20,1.6,15.24,27.2,422,1362930,141870,360,6638300007,槽150x50x20x2.0,150,50,20,2,15.24,27.2,528,1703660,177330,700,6297900008,槽150x50x20x2.5,150,50,20,2.5,15.24,27.2,660,2129580,221660,1380,10372300009,槽150x50x20x3.0,150,50,20,3,15.24,27.2,792,2555490,266000,2380,1244530000 10,槽150x60x20x1.6,150,60,20,1.6,19,45,451,1514130,214620,390,995870000 11,槽150x60x20x2.0,150,60,20,2,19,45,564,1892660,268520,750,1244840000 12,槽150x60x20x2.5,150,60,20,2.5,19,45,705,2365830,335650,1470,1556050000 13,槽150x60x20x3.0,150,60,20,3,19,45,846,2838990,402780,2540,1867260000 c型钢理论重量一览表14,槽160x60x20x2.0,160,60,20,2,18.41,44,582,2195200,274190,780,141725000015,槽160x60x20x2.5,160,60,20,2.5,18.41,44,728,2744000,342730,1520,177166000016,槽160x60x20x3.0,160,60,20,2.5,18.41,44,874,3292800,411280,2620,212588000017,槽160x70x20x3.0,160,70,20,3,22.24,52.5,742,3736400,604200,2836,307050000018,槽180x60x20x2.0,160,60,20,2,17.33,42.1,619,2861760,284520,830,180435000019,槽180x60x20x2.5,160,60,20,2.5,17.33,42.1,774,3602200,355650,1610,225544000020,槽180x60x20x3.0,160,60,20,3,17.33,42.1,926,4322640,426780,2790,2706520000 21,槽180x70x20x2.0,180,70,20,2,21.1,50,687,3439300,451800,870,2554750000180x70x20x2.2,180,70,20,2.2,21.1,50,752,3749000,489700,1254,285654000023,槽180x70x20x2.5,180,70,20,2.5,21.1,50,848,4202000,544200,1710,3193430000 24,槽180x70x20x3.0,180,70,20,3,21.1,50,983,4730880,609240,2950,3832120000 25,槽200x65x20x2.0,200,65,20,2,18.1,44,673,3850560,353370,900,269349000026,槽200x65x20x2.5,200,65,20,2.5,18.1,44,842,4813200,441720,1760,3366860000 27,槽200x65x20x3.0,200,65,20,3,18.1,44,1010,5775840,530060,3030,4040230000 28,槽200x70x20x2.0,200,70,20,2,20,44,727,4400400,467100,920,318550000029,槽200x70x20x2.2,200,70,20,2.2,20,48,796,4798700,506400,1200,3548520000 30,槽200x70x20x2.5,200,70,20,2.5,20,48,898,5382100,562700,1800,3981870000 31,槽200x70x20x3.0,200,70,20,3,20,48,1037,6027840,629540,3120,4778240000 32,槽220x70x20x2.5,220,70,20,2.5,19,46,910,6263600,539850,1900,4877150000 c型钢理论重量一览表33,槽220x70x20x3.0,220,70,20,3,19,46,1092,7516320,647820,3280,5852580000 34,槽220x70x20x3.2,220,70,20,3.2,19,46,1165,8017410,691000,3980,6242670000 35,槽220x75x20x2.0,220,75,20,2,20.8,51,787,5744500,568800,1290,410923000036,槽220x75x20x2.2,220,75,20,2.2,20.8,51,862,6268500,617100,1760,460930200037,槽220x75x20x2.5,220,75,20,2.5,20.7,51,973,7037600,686600,1950,5707180000 38,槽220x75x20x3.0,220,75,20,3,20.7,51,1119,7621240,761170,3360,6848620000220x75x20x3.2,220,75,20,3.2,20.7,51,1194,8342660,811910,4080,730520000040,槽250x70x20x2.5,250,70,20,2.5,17.6,44,978,8441830,560030,2040,642760000041,槽250x70x20x3.0,250,70,20,3,17.6,44,1174,10130190,672040,3530,771312000042,槽250x70x20x3.2,250,70,20,3.2,17.6,44,1252,10805540,716840,4280,8227320000 43,槽250x80x20x2.5,250,80,20,2.5,21,51,1024,9098080,766550,2140,8721010000 44,槽250x80x20x3.0,250,80,20,3,21,51,1229,10917690,919850,3690,10465300000 c型钢理论重量一览表各行数字含义(以最后一行为例)：槽250x80x20x3.0：截面高度h=250mm;截面宽度b=80mm;卷边宽度c=20mm;厚度t=3mm;y轴距离z0=21mm;偏心距e=51mm;截面面积a=1229mm2;惯性矩ix=10917690mm4;惯性矩iy=919850mm4;截面模量wx=87342mm3;截面模量wy=15591mm3;回转半径ix=94.3mm;回转半径iy=27.4mm;抗扭惯性矩it=3690mm4;扇形惯性矩iw=10465300000mm4;单位重量=a*7850/1000000=9.648kg/m;以上就是有关c型钢理论重量的详细内容，仅供参考。
- 1、下载文档前请自行甄别文档内容的完整性，平台不提供额外的编辑、内容补充、找答案等附加服务。
- 2、"仅部分预览"的文档,不可在线预览部分如存在完整性等问题,可反馈申请退款(可完整预览的文档不适用该条件!)。
- 3、如文档侵犯您的权益，请联系客服反馈,我们会尽快为您处理(人工客服工作时间：9:00-18:30)。
c型钢理论重量表
型号
尺 寸(mm) 截面积 理论重量
h b a t cm2 kg/m
C80 80 40 15 2 3.74 2.72
C100 100 50 15 2.5 5.23 4.11
C120 120 50 20 2.5 5.98 4.7
C120 120 60 20 3 7.65 6.01
C140 140 60 20 3 8.25 6.48
C160 160 70 20 3 9.45 7.42
C160 160 60 20 3 6.982
C180 180 70 8.64
C200 200 70 9.12
C220 220 70 9.6
C240 240 100 11.52
C260 260 100 12
C280 280 100 12.48
C300 300 100 12.96
C型钢比重=(外形总长-N个角*2T)*T*7.85
C型钢基本尺寸及主要参数
h-高度 Height
b-中腿边长 Mid Flange
a-小腿边长 Small Flange
t-厚度 Thickness
：
h-高度 Height
b-中腿边长 Mid Flange
a-小腿边长 Small Flange
t-厚度 Thickness
C型钢基本尺寸及主要参数
序号 尺 寸 截面积 重量 型钢重心 型钢重心 型钢重心 截面模数
mm Cm2 kg Cm Cm4 Cm Cm3
h b a t F M Ey1 Ex1 Jx Jy Lx Ly Wx Wy
1 100 50 20 2.5 5.510 4.71 1.835 5.0 84.932 19.889 3.925 1.899 16.987 6.321
2 100 50 20 3.0 6.495 5.652 1.848 5.0 98.560 22.802 3.895 1.873 19.712 7.235
3 140 60 20 2.5 7.010 5.889 1.974 7.0 212.137 34.786 5.500 2.227 30.305 8.642
4 140 60 20 3.0 8.295 7.065 1.969 7.0 248.006 40.132 5.467 2.199 35.429 9.956
5 160 60 20 3.0 8.895 7.536 1.846 8.0 339.955 41.989 6.182 2.172 42.494 10.109
6 160 70 20 3.0 9.495 8.007 2.229 8.0 376.933 61.266 6.300 2.540 47.116 12.843
