1Design,Implementation,andTestingofa

HybridToolforNetworkTopologyDiscovery

AlessioBotta,WalterdeDonato,AntonioPescap´e,andGiorgioVentreUniversityofNapoli“FedericoII”,Italy{a.botta,walter.dedonato,pescape,giorgio}@unina.it

AbstractInthisTechnicalReportwereportouractivitiesontheDesign,Implementation,andTestingofaHybridToolforNetworkTopologyDiscoverywecalledHynetd.

I.INTRODUCTION

Computernetworksarebecomingevermoreubiquitousand,asaconsequence,moreandmorecomplex.Theknowledgeofthetopologyofanetworkallowstoimproveitsmanagementandtoexecutemoreaccuratesimulations.Intheﬁrstcase,substantialadvantagesinfaultmanagement,performanceanalysisandserviceallocationareobtainable.Inthesecondone,thereisabeneﬁtbecauseoftheautomaticgenerationofrealistictopologiesisadifﬁculttask[1].Inaddition,duetodynamicbehaviorandlargesizeofrealnetworktopologies,thediscoveryprocesshastobenecessarilyperformedinanautomaticfashionanditshouldsupplycompleteandcorrectresultsassoonaspossible,generatingasfewtrafﬁcaspossible.Inthepastyears,severaltechniquesandtoolshavebeenproposed.WehaveclassiﬁedtheminActive,Passive,andHybrid.TheﬁrstisbasedontoolssuchasPingandTraceroute,inferringtopologyinformationfromnetworkbehavior,andthesecondoneusesSNMPandtoobtaininformationfromdevices.Usingactivemethodologyintroducestwoadditionalproblems:(i)recognizingtheinterfacesbelongingtothesamenetworkdevice,problemknownasaliasresolution;(ii)reconstructingcorrectsubnetidsandnet-masks.Finally,wereferasHybridatoolthatusesbothmethodologies.Inourpreviouswork[2]weproposedapreliminaryversionofanalgorithmimplementedinHynetd(v.0.1),ahybridtoolthatassumesminimumprerequisitesonthenetwork(i.e.oneormoreaddressrangestobescanned).InthistechnicalreportwepresentthenewHynetdversion(v.0.2)havinganewandamoreefﬁcientarchitectureandcontainingsometechniquestoimprovediscoveryefﬁciencyandperformance.Moreprecisely,weintroducenewapproachesandmodiﬁedtheﬁrstversioninorderto:(i)performthestepsfollowedbythealgorithminaparallelfashion;(ii)reducetheredundancyoftheinformationcollectedand,therefore,(iii)toreducethetrafﬁcoverhead;(iv)improvethealiasresolutionphase;(v)increasetheaccuracyofthelinkreconstructionphase.Todemonstratetheimprovedperformanceofthenovelapproach,weprovideresultsofacarefulcomparisonwithboththeﬁrstversionandwithNetworkView3.5[25],acommercialtopologydiscoverysoftware.Theexperimentalevaluation

March28,2007DRAFT2hasbeencarriedoutintermsofaccuracy,trafﬁcoverhead,anddiscoverytimeovertwonetworkscenarios(smallandlargescaletopologies).Therestofthepaperisorganizedasfollows.Section2presentsareviewofthemostrelevantworksabouttopologydiscovery.InSection3thedesignofHynetd0.2isshown.Section4explainsitsarchitecture,innovations,andimprovements.InSection5wepresentsmallandlargescaleexperimentalanalysis.Finally,Section6endsthepaperwithconclusionsandissuesforresearch.

II.REVIEWINGTHELITERATURE

Since1993manyworksdealingwithTopologyDiscoveryhavebeenpublished.Theydifferintermsofmethod-ologyused,numberofemployedprobes,prerequisitesandexploredprotocollayers.InthissectionwerevisesuchworksaccordingtotheclassiﬁcationofthemethodologiesweproposedinSectionI.First,wereporttheworksusinganactivemethodology.Theauthorsof[3]proposeanalgorithmnamedInedthatusesPingandTraceroutefromasinglesourcepoint.Theyintroduce,fortheﬁrsttime,twotechniquestoresolvethealiasresolutionproblemwhicharebasedonDNSinverselook-upandthesourceaddressofICMPportunreachablepackets(knownasSourceAddresstechnique)respectively.TheSkitterproject[7]facestheproblemofInternettopologydiscoveryattwodifferentlayers,thatareIPandAutonomousSystems(AS).Oneofitscomponents,namelyifﬁnder,performsthealiasresolutionbyusingacombinationoftheSourceAddressandthePingwithRecordRouteoption(PingRRinthefollowing).MoreoverthisistheonlyprojectsupportingtheTracerouteIPoption[8],evenifitisnotwidelysupportedbyoperationaldevices.Mercatorproject[11]triestodiscovertheInternettopologyusingactiveonlymethodologies.Itistheﬁrsttoexploitsourceroutinginordertoincreasethenumberofdiscoveredinterfacesandtorevealtransversallinks.Barfordetal.in[12],byusingtheTraceroutetool,studytheutilityofaddinginformationsourceswhenperformingwide-areameasurementsinthecontextofInternettopologydiscovery.Theyshowthattheutilityofadditionalmeasurementsitesrapidlydeclinesevenaftertheﬁrsttwosites.TheRocketfuelproject[15]isaimedtodiscoverISPtopologiesandpresentsacentralizedarchitecturethatemploysmanyprobes.Itintroducesanewtechniquetoresolvealiases,namedAllyalgorithm,thatexploits‘id’ﬁeldofIPheaderextractedfromICMPportunreachableerrorpackets.In[17]MagoniandHoerdtpresentNec(NetworkCartographer)whoseaimistomaptheheartoftheInternetasfastaspossiblewiththehighestattainableaccuracy.Theirapproachfocusesonroutersandlayer3linksandintroducessomeheuristicstominimizethenumberofIPaddresspairsinvolvedinaliasresolution.In[19]GuneseSarac,afterananalysisofallaliasresolutiontechniquesproposedinliterature,introduceanewmethodthatexploitsthepartialsymmetryofroutesfromasourcetoadestination.ThisapproachdoesnotgenerateadditionaltrafﬁcoverheadbecauseitonlyusesTraceroutediscoveredpaths.Traceroute@home[16]introducestheDoubletreealgorithmwhoseefﬁciencyhasbeenprovedtoreducetrafﬁc
