竹纤维基本特性研究

接压,使退绕张力保持恒定。

二段式陶瓷制栅栏式张力器使二段张力器分别动作,从而使张力更加稳定。

这3种方式比较,Autoconer338型和Orion型的络纱张力的控制是闭环式的,属于被动地先检测张力,然后再调整补偿。

但在1000～2000mΠmin高线速度时,被动地调整,在张力波动大的情况下很难得到均衡的张力,只能降速卷绕。

村田公司的络纱张力的控制是开环式的,它的跟踪式气圈控制装置安装在纱路的下部,在张力装置的下方,使纱线张力控制相对稳定。

2.6　其　它村田自动络筒机还可配置减少毛羽装置,采用喷气方式减少毛羽,得到高附加值的少毛羽纱。

Au2 toconer338型的吸风系统采用变频电机来产生负压,电机转速随所需空气用量而变化,保证得到恒定的负压值。

由于电机速度随空气消耗量变化而调节,因此Autoconer338型的控制系统使机器维持在低消耗状态运动。

3　结束语 以上介绍了国外3家著名自动络筒机生产厂家新产品的某些性能,并对3种机型进行了部分分析和对比。

络筒机的质量是络纱质量的关键所在,用户采购的型号应与纱线的特性要求相一致,这样才能更好地发挥自动络筒机的作用。

参考文献1　高鼎铭.国外三种新型自动络筒机的对比分析.棉纺织技术, 1994(11):29～30.2　秦贞俊.国外第三代自动络筒机的技术进步.棉纺织技术,2003(1):63～64.第25卷第6期2004年12月纺　织　学　报Journal of T extile ResearchV ol.25,N o.6Dec.,2004竹纤维基本特性研究赵　博(中原工学院,郑州,450007)李　虹(东华大学)石陶然(河南南阳纺织集团)摘　要:介绍测试竹纤维的方法及所使用的标准和竹纤维的组成,测试了竹纤维的基本性能和特性,为开发新产品提供参考依据。

关键词:再生竹纤维　组成　结构　性能中图分类号:TS102151 文献标识码:A 文章编号:025329721(2004)0620100202 竹纤维以竹子为原料,经过人工催化处理,将甲种纤维含量在35%左右的纤维素纤维提高到93%以上,同时采用水解-碱法及多段漂白精制成竹浆粕,经过纺丝制成再生纤维素纤维,其主要成分为纤维素。

生产竹纤维的竹子生长在远离城市的山区,不使用农药,且竹纤维能够100%降解,生产过程中对环境、空气及水等无污染,是21世纪又一种新型绿色无污染的环保型纯天然纤维。

竹纤维不仅集天然纤维与人造纤维的优点于一身,而且还具有独特的天然抗菌性能,同时又有良好的生态环保性,其染色性能优良,且有一定抗菌功能和保健功能,它的出现满足了人们对面料凉爽性、功能性、舒适性等的追求,是目前倍受消费者青睐的理想面料。

本文对竹纤维的形态特征及基本特性进行研究分析,为进一步对纤维的全面定性和新产品开发提供参考依据。

1　竹纤维的加工 纤维的加工流程为:竹浆粕→粉碎→浸渍→碱化→磺化→初溶解→溶解→头道过滤→二道过滤→熟成→纺前过滤→纺丝→塑化→水洗→切断→精练→烘干→打包。

2　实验条件2.1　材　料1165dtex×38mm竹纤维素纤维。

2.2　测试方法采用电子扫描显微镜观察纤维的形态结构,用密度梯度管法测密度,用绞盘法测摩擦性能,用人工模拟方法测耐日晒牢度,用鉴别纤维的溶解法判别对化学试剂的稳定性[1]。

用YG001N型电子单纤维强力仪测定强力,其它物理性能测试采用有关国家标准测试方法[2,3]。

3　结果与讨论3.1　竹纤维的形态结构竹纤维的横截面呈天然中空,大部分为接近圆形,有的为梅花型排列,边沿具有不规则的锯齿形,纵向形态具有光滑均一的特性,呈多条较浅的沟槽,有利于导湿和吸放湿,具有良好的透气性能。

这种结构使竹纤维表面具有一定的摩擦系数,纤维具有较好的摩擦力和抱合力,有利于纤维纺成纱[4]。

3.2　竹纤维的主要性能测试与分析竹纤维的主要性能及其测试方法见表1。

表1　竹纤维的性能特点纤维性能指标测试标准与方法长度(mm)(机切)38.00(排列整齐)G BΠT14335—1993线密度(dtex) 1.65G BΠT14336—1993回潮率(%)(在标准状态下)11.8G BΠT14341—1993质量比电阻(Ω・gΠcm2)8.8G BΠT14342—1993动摩擦系数0.102绞盘法(纤维与钢轴)静摩擦系数0.247绞盘法(纤维与钢轴)干断裂强度(cNΠdtex) 4.41G BΠT14337—1993湿断裂强度(cNΠdtex) 3.90G BΠT14337—1993干断裂伸长(%)19.8G BΠT14337—1993湿断裂伸长(%)22.4G BΠT14337—1993密度(gΠcm3) 1.34密度梯度法弹性回复率(%)(伸长率2%)60～70定伸长法卷曲弹性回复率(%)65G BΠT14338—1993耐日光性(强力变异系数)(%) (强度)17.5～18.9强度有所下降紫外线照射紫外线灯照射双折射率(%)0.00375Z BW04004.10—1989耐碱性好耐酸性稍差耐热性175～185℃长时间处理变色、强力下降抗紫外线一般透气量(gΠmm2・s) 1.652(居各纤维之首)抗菌性能抵抗虫蛀,不受霉菌侵蚀,具有天然杀菌性能染色性能染色适合性强,染色性能良好,吸色均匀透彻,色牢度强,多次洗涤后仍能保持鲜艳的色彩吸湿性能(%,回潮率)在标准状态下11.8接近普通粘胶,吸湿快干性能佳G BΠT14341—1993 由表1可见:1)切断长度为38mm,排列整齐,光泽亮丽,手感轻柔滑糯。

2)动、静摩擦系数差值相对较大,使纺出的纱条间有一定的摩擦力和抱合力,适合加工手感柔软、悬垂性佳的高档产品。

3)干态断裂强力接近超细旦涤纶纤维(014dtex),断裂伸长与大豆蛋白纤维和普通粘胶纤维接近。

4)强力高,耐磨性好,说明竹纤维的初始模量大,钩结强度和结节强度好,纤维具有较大的抵抗变形的能力,湿态断裂伸长率大于干态断裂伸长率,生产中要注意它的干湿性能变化,及时调整生产工艺参数,使生产正常进行。

5)纤维表面上具有一定的卷曲数,这使它表面上具有一定的摩擦力和抱合力,有利于纺纱加工。

弹性回复率与它的结构有关,初始模量大,因而弹性回复率相对稍低。

6)在标准状态下,竹纤维回潮率与普通粘胶的回潮率接近,但低于毛纤维和普通毛型粘胶长丝的回潮率。

竹纤维呈天然高度中空,说明具有良好的吸湿性、渗透性和放湿性及透气性能,适合加工夏季针织面料和高档衬衫等产品[4]。

7)比电阻相对较高、纺纱过程中根据纺纱产品加入适量的油剂等抗静电剂,以提高其可纺性能。

8)针织产品的透气量最大,透气性能较好,均高于丙纶、腈纶和粘胶长丝,这与竹纤维特殊的天然横截面高度中空有直接关系。

9)纤维的卷曲率为1135%,残留率0142%,弹性回复率(伸长率2%)为60%～70%。

因此相对于一般的合纤,该卷曲率指标偏低,弹性差。

10)双折射率低,说明大分子的取向度较低[5]。

11)耐碱性好,耐酸性稍差,溶解后有少许残留物质。

染色性能优良,不易褪色,吸收性和渗透性强,其白度与普通粘胶纤维接近,且稳定性强。

12)竹纤维经紫外线照射后,强力下降很少,说明纤维耐光性较好。

13)与其它纤维相比,具有更优良的吸湿快干性能,适合加工夏季服装和贴身产品。

14)具有天然的杀菌性能,在服用中不会对皮肤造成任何不良反应。

由于在竹纤维生产过程中全部实施绿色生产,故属于环保凉爽型纤维。

4　结　论 11竹纤维具有良好的物理和机械性能,耐磨性好,吸湿快干性佳,韧性高,且具有天然抗菌性,适合加工具有特效功能的产品。

21竹纤维天然横截面高度中空,富有丝质效应,手感柔和光滑,是高档内衣等的理想面料,将其用于服饰,市场前景十分看好。

31在纺织加工中要合理选择工艺参数,并且要进一步了解竹纤维的性能,以充分认识其特点,以利于开发出体现竹纤维独特性能的新产品。

参考文献1　李青山.纺织纤维鉴别手册.北京:中国纺织出版社,1998:27～34.2　于伟东.纺织物理.上海:东华大学出版社,2002:147～164.3　李汝勤.纤维和纺织品的测试原理与仪器.上海:中国纺织大学出版社,1995:67～94.4　姚　穆等.纺织材料学.北京:中国纺织出版社,1996:45～51.5　严灏景.纤维材料学导论.北京:纺织工业出版社,1990:74～84.1012004年　第6期纺织学报【　】Measurem lnt and C alculation of the B lended R ation of the Soybean ΠPolyester B lended YarnThe com putation of the mean and standard deviation of the blended ration by the statistical method is discussed.The method can derive not only the mean but als o the standard deviation of the blended ration of the s oybean Πpolyester blended yarn.It is very im portant to the production.Yang Qingbin et al (92)………Discussion about Improving Combed Yarn Q u ality and Product DevelopingC ombed yarn is one of symbols of yarn rank.Quality index of combed yarn is setdown ,and s ome key process of combing w orking procedure is studied.Results show that novel yarn can be developed by increasing application field of combing machine.Yang Yuanzhao et al (94)…………………………………………Comp arison of the new Autom atic ConersThe properties ,such as the yarn courses ,the functions of on 2line testing ,the splicers ,the functions of ribbon breaking ,the balloon control and the tension control ,of the automatic coners of the third generation made by three foreign com paines were com pared and analyzed.Zhang Chunfang (98)…………………E lementary Properties of the R eclaimed B amboo Cellulose FiberThe tested method ,used standard ,the com position and processing technology of bamboo cellulose fiber are introduced ,a series of basic properties are tested.This provides a definite reference basis in developing new type production.Zhao Bo et al (100)………………………………………………………………Some Ideas on E liminating Set 2m arks by Im age Processing MethodThe cause of set marks on w oven fabrics is analyzed and the comm on methods of elim ination are introduced.An image processing method has been proposed to elim inate the set 2marks and the other functions of this method are als o presented.Zeng Yongqi et al (102)…………………………………………………Selection of Sizing Agent and Orthogonal Optimization of Sizing I nstructionSeveral comm on sizing agents used in the textitle plant was introduced.Orthog onal test to optim ize the best sizing instruction is used.S o the better econom ic effect is g ot.Zhang Chaohui et al (104)……………………………………………………………………………………………………………………Weaving Design of Tubular Multilayer Woven Preform with Ch angeable Cross 2sectionThe warp number in each layer can be equivalent in the designing of tubular preform with large diameter and small thickness ,however it must be varied in the fabric with small diameter and large thickness s o as to obtain a uniform structure.In the weaving process ,yarns should be added (or reduced )in every warp layer in correspondence with the increase (or decrease )of the fabric diameter.Guo Xingfeng et al (106)……………………………………………………………Wearability of the Polypropylene Fiber with UV R esistanceThe wearability of m odified polypropylene fiber by blending the inorganic reagent with UV resistance and the UV resistance of its fabric were studied apart by m odern test instruments ,such as PRT 21,YG 001A ,CARY 250etc..The results showed that its UV resistance was enhanced greatly ,while the m odified fiber has not changed considerably in it ’s main wearbilities.Zhao Jiasen et al (108)………………………………………………………………………………………Method to Design I rregular Weaves by ComputerBased on the cellular automata theory ,a new method of designing irregular weave by com puter is introduced.The method is sim ple and easy to achieve ,and can be used to im prove the design performance of weaves CAD system.Zhang Yongning et al (110)…………………………………………………………Computer System Application in Measuring and M atching ColorsDiscusses the usage of the W insrici com puter system application of measuring and matching colors in im itasting sam ple of dyeing ,introduces the setting method of basic D 2base and the problems in application ,and analyzes the reas ons of incorretly matching.Tan Yan et al (112)………………………………………Study on Dyeing B eh avior of B R eactive Dyes in T encel F abricsT encel fabric is dyed with B Reactive Dyes.The dyeing behaviors and various in fluencing factors are discussed ,suitable dyeing process of T encel fabrics with B Reactive Dyes is obtained.Li Xiaochun et al (114)…………………………………………………………………………………………………………Dynamic Analysis of B eating 2up Mech anism of TT 96R apier LoomBy using MEC 2B mechanical dynam ic tester ,the m ovement of beating 2up of TT 96rapier loom is measured by com puter processing data and protracting curve.The primary technical parameters of beating 2up are als o discussed.Zheng Zhiyu (116)………………………………………………………………………R esearch on the Auxiliaries Applied in the T extile Finishing of CellulaseThe auxiliaries which can activate cellulase and im prove the effect of cellulase finshing were studied.The result indicated that effect of celluase finishing w ould be im proved and the cost w ould be decreased when the auxiliaries were applied properly in the process of cellulase finishing.Zhang Ruiping (118)…………Dimensional Properties of K nitted F abricsThe dimensional properties of weft plain ,rib ,air inclusion ,full cardigan and full gauge 1×1rib are discussed.The conclusion is that stitch density plotted vs.1Π1and fabric thickness plotted vs.1Π1followed linear curves.Both loop length and fabric structure in fluence the stitch density ,the thickness and the loop m orphological structure of a fabric.Tan Lei (120)……………………………………………………………………………………………………………Cellulosic F abric B leaching with G reen B leaching AgentPeracetic acid is a fav ourite ecological bleaching agent.S ome factors affecting the bleaching linen and cotton fabric with peracetic acid such as concentration ,pH value ,tem perature and time were studied ,and the optimum bleaching condition of pH 7,tem perature 60-70℃was suggested.Yang Wenfang et al (122)…………………………………………………………………………………………………………………………………………………………Building a C alculation Model on Arbitrary Style with Sw eater CAD SystemIntroduces the practical method about how calculating the arbitrary style with sweater CAD system ,and builds the whole mathematics m odel on it.Liu Zhe et al (125)………………………………………………………………………………………………………………………………………………Comprehensive R eview sExploitation and T echnology Application of B amboo FiberThe significance and the technology feasibility of bamboo fiber ’s exploitation is analyzed ,and the exploitation foreground is prospected.Wan Yuqin et al (127)……………………………………………………………………………………………………………………………………………………Development and Application of Multimedia T eaching Softw are on Dyeing and Finishing ProcessThe purpose and meaning of developing multimedia teaching s oftware on dyeing and finishing process are described ,and the developing ways and process are summarized.The practice proves that develop of multimedia teaching s oftware on dyeing and finishing process is success ful.Ren Jili et al (129)………………Propeties of Soybean 2Protein Fiber and F abricsThe principle of producing s oybean 2protein fiber is introduced.The mechanical property and dyeing property of s oybean 2protein fiber ,the wearability of m oisture transm ission and stecvilztion of the fabcics are disscussed.Li Yiyou (131)……………………………………………………………………………Study on Airb ag F abric M aterial and its DesignThe w orking principle of airbag and the property demands for airbag fabrics are outlined.The weaving and finishing techniques of airbag fabric are discussed.Cui Yihua (133)……………………………………………………………………………………………………………………………………………Study on F ashion M arketing M anagement System B ased on Web (P art Ⅰ)Accoridng to the related theories and practical situations of enterprises ,theoretical m odels for the m odule of sales suitable for our country were estabilished by em ploying advanced and practical management theories and netw ork in formation technologies.Li Chuang et al (135)…………………………………………R elationship B etw een Time V alue and Consumption G roup of T extilesBased on the value theory and the market research ,the time value of customer is analyzed.It is showed that s ome customers attached vary great im portance to the time value.It gives s ome reference to enterprises for projecting their marketing strategics.Hu Shouzhong (137)……………………………………………。
