1. ADANG BAY

Position : Panamax Vessel 01-42-00 South / 116-30 East – Draft more than 13 m

01-43-50 South / 116-26-10 East – Draft abt 12 m

01-42-50 South / 116-26-30 East – Draft abt 16 m

04-42-00 South / 116-26-30 East – Draft abt 22 m

Port Restriction: No restriction (open sea)

Pilot: Not compulsory

Loading Facility/Method : 1. By ship's Gear and Grabs

- Capacity 7 Cbm / 5 Pcs of shipper's Grabs

- Capacity 12 Cbm / 4 Pcs of shipper's Grabs

2. Loading by floating Crane for Gearless vessel's

Loading Rate : - Abt 10,000-12,000 MT/day (Ship's Gear)

- Abt 10,000-15,000 MT/day (Floating Crane)

Working Time: 24 hours/day, 7 days/week SHINC, Excluding National Major Holiday 2.APAR BAY (PETANGIS)

Position : Lat 02-00-00 South / Long 116-43-00 )Draft abt 16 m

Port Restriction : No Restriction (open sea)

Pilot : No Compulsory

Loading Facility/Method : By ship's Cranes and Floating Cranes 2 (Two) unit

- 6 (six) Units Tug Boat

- 5 (five) Barges With Capacity 7,000 MT/Unit

- Fresh Water and Bunker is not available

Loading Rate : By Floating Crane abt. 20,000 MT/Day

By ship's Crane abt. 5,000 – 7,000 MT

Working Rate : 14 hours/Day, 7days/week SHINC, excluding Nationality Major Holiday

3.BALIKPAPAN COAL TERMINAL

Position : Lat 01-21-00 South / Long 116-47-00 East

Pilot Boarding Position : Lat 01-21-20 South / Long 116-56-54 East

Meanwhile following are the update formula for calculating the sailing draft at Balikpapan Coal Terminal as follow:

13 M LWS + HIGH TIDE WATER

Loading Facilities : One Luffing Traveling Conveyor

Average loading rate : 1,750 MT/Hour

Port Restriction : - Maximum LOA : 250 Mtrs

- Maximum Beam : 43 Mtrs

- Maximum DWT : 90,000 MT

- Maximum Air Draft : 17 m

- Maximum Sailing Draft : 13 Mtrs + high tide (depen on high tide water)

Working Time :24 hours/day, 7 days/week SHINC, Excluding National Major Holiday

4. BONTANG COAL TERMINAL

Terminal Position : Lat 00-00-01 South / Long 117-32-16 East

Anchor Position: 1. Lat 00-00-00 South / Long 117-35-02 East

2. Lat 00-00-02 South / Long 117-35-00 East

Pilot Boarding Ground: Lat 00-00-00 South / Long 117-35-00 East

Loading Facility : By Loader Quadrant Type (One Unit)

Loading Rate: About 1,700 – 2,000 MT/Hour

Working Time: 24 Hours/Day, 7 days/week SHINC, Excluding National Major Holidays Berth Owner: PT. INDOMINCO MANDIRI

5. INDONESIAN BULK TERMINAL (SOUTH PULAU LAUT COAL TERMINAL)

Berth Position: Lat 04-02-00 South / Long 116-00-37 East

Anchor Position : Lat 04-02-00 South / Long 116-00-00 East / max depth 20m

Port Restriction : Max LOA : 230 m

Max Beam : 35 m

Max DWT : 80,000 tons

Loading Method : One Unit Starveling Conveyor

Working Time : 24 Hours/Day, 7days/week SHINC, Excluding Nationality Major Holiday 6.JORONG ANCHORAGE

Position : Lat 04-07-06 South / Long 115-04-05 East (Handy)

Lat 04-12-05 South / Long 115-05-09 East (Panamax)

Safe Draft Max : 16 m

Port Restriction : No Restriction (Open Sea)

Loading Method : By Ship's gear and using grabs from barges to ship's hold with loading rate average 8,000 – 10,000 MT/Day

Working Hours : 24 Hours/Day, 7days/week SHINC, Excluding Nationality Major Holiday 7. MUARA PANTAI (BERAU ANCHORAGE)

Position : Lat 01-56-40 North / Long 118-07-20 East (21 m depth)

Lat 01-57-40 North / Long 118-05-30 East (17 m depth)

Port Restriction : No Restriction (Open Sea)

Pilot : No Compulsory

Loading Facility/Methods : 1. Loading by ship's Crane
