小波矩特征提取代码

这是我上研究生时写的小波矩特征提取代码：

%新归一化方法小波矩特征提取----------------------------------------------------------

F=imread('a1.bmp');

F=im2bw(F);

F=imresize(F,[128 128]);

%求取最上点

for i=1:128

for j=1:128

if (F(i,j)==1)

ytop=i;

xtop=j;

break;

end

end

if(F(i,j)==1)

break;

end

end

%求取最下点

for i=1:128

for j=1:128

if (F(129-i,j)==1)

ybottom=129-i;

xbottom=j;

break;

end

end

if(F(129-i,j)==1)

break;

end

end

%求取最左点

for i=1:128

for j=1:128

if (F(j,i)==1)

yleft=j;

xleft=i;

break;

end

end

if(F(j,i)==1)

break;

end

%求取最右点

for i=1:128

for j=1:128

if (F(j,129-i)==1)

yright=j;

xright=129-i;

break;

end

end

if(F(j,129-i)==1)

break;

end

end

%求取中心点

x0=(xright-xleft)/2+xleft;

y0=(ybottom-ytop)/2+ytop;

x0=round(x0);

y0=round(y0);

%图像平移

F=double(F);

[M,N]=size(F);

F1=zeros(M,N);

M0=M/2;

N0=N/2;

for i=1:M

for j=1:N

if F(i,j)==1

F1(i+M0-y0,j+N0-x0)=1;

end

end

end

%figure,imshow(F1);

%图像缩放

max=0;

for i=1:128

for j=1:128

if(F(i,j)==1)

d=sqrt((i-y0)^2+(j-x0)^2);

if(max

max=d;

end

end

end

%max=round(max);

a=200.0/(max*2);

F2=imresize(F1,a);

%figure,imshow(F2);

%将所有图像均复制到500*500的图像的大小

[M,N]=size(F2);

m0=M/2;

m0=round(m0);

n0=N/2;

n0=round(n0);

f3=zeros(500,500);

y1=round((500-M)/2);

x1=round((500-N)/2);

for i=1:M

for j=1:N

if(F2(i,j)==1)

f3(y1+i,x1+j)=1;

end

end

end

%figure,imshow(f3);

%图像从笛卡儿坐标转换为极坐标------------------------------------------------------------ %角度间隔为2*pi/(128*128),128个像素长设为图像的单位圆半径

%f1矩阵里面放着对应极半径和角度的值

f1=zeros(128,16384);

%直角坐标与极坐标建立起一一对应的关系

for i=1:128

for j=1:16384

a=j*2*pi/16384.0;

r=i;

y=round(r*sin(a));

x=round(r*cos(a));

if (f3(250+x,250+y)==1)

f1(i,j)=1;

end

end

end

F3=zeros(512,512);

%将极坐标转换后的图像显示出来

for i=1:128

for j=1:16384

if f1(i,j)==1

a=j*2*pi/16384.0;

x=round(i*cos(a));

y=round(i*sin(a));

F3(256+x,256+y)=1;

end

end

end

F3(256,256)=1;

%figure,imshow(F3);

%小波矩特征提取------------------------------------------------------------------- %进行角度积分得到Sq(r)------------------

N=16384;

Sq=zeros(128,4);

for r=1:128

for q=1:4

for m=1:N

Sq(r,q)=(f1(r,m)*exp(-j*2.0*pi*(m-1)*(q-1)/N))+Sq(r,q);

end

Sq(r,q)=1.0/N*Sq(r,q);

end

end

%小波矩特征提取-------------------------

x=3;

a=0.697066;

f0=0.409177;

w=sqrt(0.561145);

F1=zeros(3,9,4);

tt=4*a^(x+1)/sqrt(2*pi*(x+1))*w;

for q=1:4

for m=1:3

rr=2^m+1;

for n=1:rr

for r=1:128

%pp=2*(2^(m-1)*(r-1)/128.0-(n-1))-1;

pp=2*(2^(m-1)*r/128.0-(n-1))-1;

cc=cos(2*pi*f0*pp)*exp(-1.0*pp^2/(2*(w^2)*(x+1)));

fan=2^((m-1)/2)*tt*cc;

%Fmnq(m,n,q)=abs(Sq(r,q)*fan*(r-1)/128)+Fmnq(m,n,q);

F1(m,n,q)=abs(Sq(r,q)*fan*r)+F1(m,n,q);

end

end

end

end
