外文翻译-公路和机场路面设计
英语翻译(一级公路路基路面综合设计)

Newly built highway asphalt tong road surfaceearlytime damage analysisAbstract: Article damage which appears in view of the newly built highwayasphalt tong road surface early time, summarizes characteristic which it appears,analyzes reason which it forms, for seeks the preventing and controllingcountermeasure to provide the basis.Key word: Highway; Asphalt; tong road surface; Damage; AnalysisFirst, bituminous pavement conventional damage characteristic and origin (1)crack.The longitudinal crack is parallel basically to the path middle line, is apartfrom road edge 3~5m, sometimes follows has the few seams.The rectiunear figurecrack mainly is under the big load repetition function produces, assumes the arc also the both sides the crack which extends to the embankment edge mainly is formsbecause of the roadbed differential settlement.The transverse crack nearly is vertical to the path middle line, the spacing different, sometimes follows has the few seams, and increases year by year.Thebituminous pavement low temperature contraction and the semi-rigid basic unitcontraction crack response has the transverse crack two primary causes.At the same time, fills in digs the border the unequal settlement to be able to produce assumes the arc the transverse crack.The net crack initial shape is in appears the single scroll or the multi-strip parallel longitudinal seal along the wheelpath, after but appears crosswise or thediagonal company in during the parallel longitudinal seal joins, the cracking net, the partial concomitance settlement, squirts the thick liquid phenomenon, it is under the driving load repeatedly function, the partial structural-load-carrying capacityinsufficiency or the excessive subsidence produce.(2)distortion.The settlement refers to the asphalt tong road sign surface the part to behollow, it is, after or because partial excavates, the concomitance road surface knotconfiguration the backfill earth-pressure which the roadbed subsidence or thedifferential settlement distort create which solid insufficient creates destroys, after patching damages continues to develop.The wheel rut refers to bed which in the wheelpath appears, the external factor is the channelizing traffic and the load function number of times increases, the internal cause is asphalt concrete high temperature stable Holland anti-changes abilitydifference to have the lateral shear flow distortion.Pushes the distortion to refer in the vehicle speed frequent change street intersection and so on place, because the vehicles get on the brakes frequently and the start, road surface distortion which and under the great horizontal shear togetherfunction produces in the high temperature.(3) superficial damage.The weeping refers to in the bituminous pavement free asphaltbeing heated to inflate, because the asphalt concrete crevice is unable to hold, the asphalt migrates to the superficial phenomenon, the asphalt amount usedexcessively are many, the design percentage of voids excessively is small, thebituminous mixture segregation causes the smalls too to concentrate and theasphalt high temperature stability bad is upwardly causes the weeping theimportant reason.The weeping occurs in the weather burning hot season, but theweather cold season does not have the reversible process, affects the road surface structure depth and the anti-slippery performance.The polish is changes theaggregate pellet which the surface appears externally to be an expert to goodexpert the tire under the rubbing effect to change the smooth phenomenongradually.The primary cause is under the wheel repetition function, uses theaggregate not wear-resisting creates.Second, new damage phenomenon and origin(1)new weeping phenomenon.Oil stain weeping becomes which by the punctual oilstain development, occurs carries the SMA Holland to open the level to cultivate the asphalt concrete surface layer the road surface, separable three levels: Light, small oil stain diameter 1~2㎝fragmentary distribution; The oil stain increases increases, the diameter 1~5㎝different; Heavy, the oil stain diameter, the area or the densityincrease, gradually continually Large expanse of.The oil stain weeping has theuniversality, widely exists in SMA and in the AK anti-slippery surface layer roadsurface.。
土木工程英语证书考试(PEC)-道路勘测设计专业术语

土木工程英语证书(PEC)考试-道路勘测设计专业术语道路road公路highway都市道路city road;urban road厂矿道路factories and mines road林区道路forest road乡村道路country road车辆换算系数vehicle conversion factor城间道路interurban road都市出入口公路city approach highway道路工程road engineering丝绸之路the silk road道路网road metwork道路(网)密度density of road network道路技术原则technical standard of road设计车辆design vehicle特种车辆special vehicle计算行车速度(设计车速) design speed道路建筑限界boundary line of road construction道路用地范围right of way净空clearance等级道路classified road辅道relief road高速公路free way;motorway部分控制进入partial control of access等级公路classified highway等外公路substandard highway干线公路arterial highway支线公路feeder highway国家干线公路(国道) natilnal trunk highway省干线公路(省道) provincial trunk highway县公路(县道) county road乡公路(乡道) township road (county road)绕行公路bypass公路自然区划clinatic zoning for highway(都市)迅速路expressway(都市)主干路arterial road(都市)次干路secondary trunk road(都市)支路branch road街道street郊区道路suburban road居住区道路residential street工业区道路industial district road厂外道路ractory-out road厂内道路factory-in road(厂内)主干道arterial road(厂内)次干道secondary trunk road(厂内)支道branch road露天矿山道路opencast mine road生产干线prductive arterial road生产支线productive branch road联络线linking-up road林区公路fores thighway运材道路haul road集材道路skid road护林防火道路protection forest fire-proof road 连接道路linking-up road冻板道路freeze road木排道corduroy road自行车道cycle track;cycle path畜力车道cattle-pass驮道bridler road项目提议书project Proposal可行性研究feasibility study项目任务书Project charter设计规范design specification初步设计Preliminary Design施工图设计construction documents design 交通构成traffic composition混合交通mixed traffic交通流traffic flow车流vehicle stream交通密度traffic density车头间距spachead way车头时距time headway车(辆)间净距vehicular gap延误delay点速度spot speed行驶速度running speed区间速度overall speed运行速度operating speed临界速度iptimum speed;critical speed 时间平均速度time mean speed空间平均速度space mean speed经济车速economic speed自由车速free-flow speed交通量traffic volume年平均日交通量annual average daily traffic月平均日交通量monthly average daily traffic年第30位最大小时交通量thirtieth highest annual hourly volume 年最大小时交通量maximum annual hourly volume高峰小时交通量peak hourly volume设计小时交通量design hourly volume通行能力traffic capacity基本通行能力basic trsffic capacity也许通行能力possible traffic capacity设计通行能力design traffic capacity道路服务水平level of servic e交叉口通行能力capacity of imtersection道路交通规划traffic planning交通调查traffic survey交通量调查traffic volume survey交通量观测站traffic volume observation起迄点调查origin-destination study出行trip境内交通local traffic过境交通through traffic出境交通outbound traffic入境交通inboud traffic交通发生traffic generation交通分布traffic distribution交通方式划分model split交通量分派traffic assignment交通量预测traffic volume prognosis路网通行能力capacity of metwork道路网规划road network planning棋盘式道路系统gridiron road systim环形辐射式道路系统ring and radial road system自由式道路系统free style road system混合式道路系统combination-type road system(都市)道路面积率road area ratio(都市)人均道路面积road area ratio牵引力tractive effort行驶阻力driving resistance滚动阻力rolling resistance空气阻力air friction;air resistance坡度阻力slope resistance;grade resistance(都市道路)平面设计alignment design;plane design道路中线center line of road道路轴线road axis道路路线route of road道路线形road alignment平面线形horizontal alignment横向力系数lateral force ratio缓和曲线transition curve;easement curve离心加速度centrifugal acceleration回旋线spiral curve;clothoid交点intersection point, IP主点major point偏角angle of deflection偏角法method of deflection angle几何要素geometry element圆曲线参数parameter of circular curve切线支距法tangent offset method缓和曲线参数parameter of easement curve急弯sharp curve缓弯flat curve坐标coordinate线形要素alignment elment平曲线horizontal curve最小平曲线半径minimum radius of horizontal xurve 汽车最小转弯半径minimum turning radius圆曲线circular curve复曲线compound curve复曲线点point of compound curve, PCC反向曲线reverse curve同向曲线adjacent curve in one direction断背曲线broken-back curve回头曲线switch-back curve;reverse loop卵形曲线ovoid curve视线sight line视距sight distance停车视距stopping sight distance超车视距overtaking sight distance[司机]反应距离[driver]reaction distance[司机]感觉反应距离[driver] perception-reaction distance [司机]感觉反应时间[driver] perception-reaction time [司机]判断时间[driver] judgement time[司机]识别距离[driver] decipherment distance侧向视野field of lateral vision侧向余宽lateral clearance侧向最小安全间距minimum safe lateral clearance纵断面设计profile design;design of vertical alignment 纵面线形vertical alignment高程(标高) elevation地面高程groud elevation设计高程designed elevation(路线)纵断面图vertical profile map中桩填挖高度height of cut and fill at center stake纵坡longitudinal gradient最大纵坡maximum longitudinal gradient最小纵坡minimum longitudinal gradient变坡点grade change point平均纵坡average gradient坡长限制grade length limitation纵坡折减grade compensation缓和坡段transitional gradient竖曲线vertical curve凸形竖曲线convex vertical curve凹形竖曲线concave vertical curve路幅roadway车行道(行车道) carriage way车道lane内侧车道fast lane中间车道cemter lane外侧车道nearside lane附加车道auxiliary lane变速车道speed-change lane加速车道acceleration lane减速车道deceleration lane超车车道overtaking lane爬坡车道climbing lane停车车道parking lane紧急停车带emergency parking strip;lay-by错车道passing bay回车道(回车场) turmaround loop专用车道accommodation lane错车洞passing bay in tunnel单行路one-way road车道宽度lane-width人行道side walk;foot way分隔带separator;central reserve路缘带marginal strip路肩shoulder;verge硬路肩hard shoulder路缘石curb平缘石flush curb立缘石(侧石) vertical curb平石gutter apron街沟(偏沟) gutter路侧带curb side strip绿化带green belt横坡cross slope路拱crown路拱曲线camber curve合成坡度resultant gradient平曲线加宽curve widening加宽过渡段transition zone of curve widening超高superelevation超高缓和段superelevation runoff断面渐变段transition zone of cross section超高横坡度superelevation slope土方调配cut-fill transition土方调配图cut-fill transition program土方调配经济运距economical hauling distance横断面图cross-cectional profile路基subgrade路堤embankment路堑cutting半填半挖式路基part-cut part-fill subrade台口式路基benched subgrade路基宽度width of subgrade路基设计高程design elevation of subgrade(路基)最小填土高度minimum height of fill边坡side slope边坡平台plain stage of slope边坡坡度grade of side slope边坡修整slope trimming(边)坡顶top of slope(边)坡脚toe of slope护坡道berm边坡平台plain stage of slope碎落台stage for heaping soil and brocken rock 护坡slope protection挡土墙retaining wall重力式挡土墙gravity retaining wall衡重式挡土墙balance weight retaining wall悬臂式挡土墙cantilever retaining wall扶壁式挡土墙counterfort retaining wall柱板式挡土墙pile and plank retaining wall锚杆式挡土墙anchored retaining wall by tie rods 锚锭板式挡土墙anchored bulkhead retaining wall 加筋土挡土墙reinforced earth retaining wall石笼rock rilled gabion抛石riprap护栏guard rail护墙guard wall标柱guard post防护栅safety fence防炫屏(遮光栅) anti-dizzling screen隔音墙acoustic防沙设施sand protection facilities防雪设施snow protection facilities道路限界架boundary frame on road道路照明设施ighting facilies of road交通广场traffic square停车场parking lot反坡安全线adverse grade for safety公交(车辆)停靠站bus bay ;parking station综合管道(综合管廊) composite pipe line渡口ferry道路绿化road planting街道绿化street planting行道树street trees绿篱hedge;living fence功能栽植function planting护路林shelter belt里程碑ki lometer stone百米桩hectometer stake踏勘reconnaissance(道路工程)方案图road project(道路)平面示意图plane sketch线形设计alignment design公路景观设计highway landscape design(都市道路)竖向设计design of elevation选线route selection路线控制点control point定线location of line纸上定线paper location比较线alternative line展线route deveopment初测preliminary survey定测location survey地貌topographic feature地物culture地形topographyf台地terrace垭口pass;saddle back平原区plain terrain微丘区rolling terrain重丘区hilly terrain山岭区mountainous terrain沿溪线valley line山脊线ridge line山坡线(山腰线) hill-side line越岭线ridge line(道路)隧道tunnel半山洞half tunnel明洞open cut tunnel导线traverse导线测量traverse survey中线测量center line survey施工测量construction survey竣工测量final survey(路线)平面图plan view交点intersection point虚交点inaginary intersection point 转点turning point转角intersection angle偏角deflection angle方位角azimuth angle象限角bearing angle方向角direction angle切线长tangent length曲线长curve length外(矢)距external distance测站instrument station测点observation point中桩center stake加桩additional stake护桩reference stake断链broken chainage水准测量leveling survey水准点bench mark绝对基面absolute datum地形测量topographic survey基线base line地形图topographic map等高线comtour line横断面测量cross-sectional survey坑探intersection plan钻探boring(道路)地质剖面图geological section(道路)地质柱状图boring log地下水位uderground water level摄影测量photogrammetry航空摄影测量aerial photogrammetry地面立体摄影测量ground stereophotogrammetry地面控制点测量ground control-point survey航摄基线aerophoto base影像地图ohotographic map航摄像片判读aerophto interpretation综合法测图planimetric photo全能法测图universal photo微分法测图differential photo像片镶嵌图photo mosaic(平面)交叉口intersection;road crossing交叉口进口intersection entrance,approach交叉口出口intersection exit加宽转角式交叉口intersection with widende corners 拓宽路口式交叉口flaredintersection分道转弯式交叉口channelized intersection渠化交通channelization交错weaving交错路段weaving section合流converging分流diverging冲突点conflic t point交错点weaving point交通岛traffic island导流岛channelization island中心岛center-island安全岛refug island道口铺面paved crossing道口限界架boundary frame on crossing交通安全设施traffic safety device人行横道cross walk斑马线zebra crossing人行地道pedestrian underpass人行天桥pedestrian overcrossing分隔设施separate facilities视距三角形sight triangle路口视距sight distance of intersection标志视认性sign legibility(平曲线)横净距lateral elear distance of curvecut corner for sight line道路曲线最内侧旳车道行车(路口)截角视野field of vision道路交叉(路线交叉) Road intersection,crossing, junction 交叉角intersection angle(铁路)道口railroad grade crossing平面交叉at-grade intersection;grade crossing 多岔交叉multiple-leg intersection环形交叉rotary intersection;roundabout微形环交mini-roundabout十字形交叉cross roads丁字形交叉(T形交叉) T intersection错位交叉staggered junctionY形交叉Y intersection交叉口平面图intersection plan立体交叉grade-separated junction上跨铁路立体交叉overpass grade separation下穿铁路立体交叉underpass grade separation简朴立体交叉grade separation互通式立体交叉interchange苜蓿叶形立体交叉clover-leaf interchange半苜蓿叶形立交partial clover-leaf interchange定向式立体交叉directional interchange半定向式立交semi-directional interchange菱形立体交叉diamond in terchange喇叭形立体交叉trumpet interchange环形立体交叉rotary interchange分隔式立体交叉interchange woth special bicycle track 匝道ramp单向匝道one-wayramp双向匝道two-way ramp环形匝道loop ramp车道分布lane distribution车道分界线lane line车道平衡lane balance车道收费机lane toll machine车道通行能力lane capacity车道系数coefficient of lanes车道拥有率lane occupancy ratio出口匝道控制exit ramp control路基排水subgrade drainage地表水surface water地下水underground water毛细水capillary water边沟intercepting ditch截水沟intercepting ditch排水沟drainage ditch急流槽chute跌水drop water蒸发池evaporation pond盲沟blind drain;blind ditch渗水井seepage well过水路面ford暴雨强度intensity of rainstorm(排水)设计重现期design frequency街道排水street drainage管道排水pipe drainage渠道排水gutter drainage(立体交叉)泵站排水drainage by pumping station雨水口inlet;gully检查井manhole雨水口支管branch pipe of inlet泄水口drain opening取土坑borrow pit弃土堆waste bank管线综合设计under-ground pipes comprehensive design 路面pavement暗涵buried culvert饱和流量saturation volume饱和流率saturation volume rate暴雨径流rainstorm run-off暴雨强度rainstorm intensity。
路面设计外文翻译---柔性路面设计

英文翻译Flexible pavement designGenerally speaking,pavements(and bases) may be divided into two broad classifications or tipes:rigid and flexible. As commonly used in the United States,the term “rigid pavement”is applied to wearing surfaces constructed of Portland-cement concrete. A pavement constructed of concrete is assumed to possess considerable flexural strength that will permit it to act as a beam and allow it to bridge over minor irregularities which may occor in the base or subgrade on which it rests;hence the term “rigid”.Similarity,a concrete base that supports a brick or block layer might be described as “rigid”.All other types of pavement have traditionally been classed as “flexible”.A commonly used definition is that “a flexible pavement is a structure that maintains contact with and distributes loads to the subgrade and depends on aggregate interlock,particlefriction,and cohesion for stability”.Thus,the classical flexible pavement include primarily those pavement that are composed of a series of granular layers topped by a relatively thin high-quality bituminous wearing surface .Typically,the highest-quatily materials are at or near the surface.It should be pointed out that certain pavementsthat have an asphalt surface may behave more like the classical “rigid”pavement,for example, pavement that have very thick asphalt surface or that have base courses composed of aggregate treated with asphalt,cement, or lime-fly ash. However,for convenience of presentation,these pavements will be considered to be in the flexible class.The structure of flexible pavement is composed of a “wearing surface”, base, subbase(not always used), and subgrade . The wearing surface and the base often comprise two or more layers that are somewhat different in composition and that are put down in separate construction operations.On many heavy-duty pavements,asubbase of select material is often placed between the base and subgrade.the wearing surface may range in thickness from less than 1 in. in the case of a bituminous surface used for low-cost, light-traffic loads to 6 in. or more of alphaltconcrete used for heavily traveled routes. The wearing surface must be capable of withstanding the wear and abrasive effects of moving vehicles and must possess sufficient stability to prevent it from shoving and rutting under traffic loads. In addition,it serves a useful purpose in preventing the entrance of excessive quantities of surface water into the base subgrade from directly above.The base is a layer (or layers) of very high stability and density. Its principle purpose is to distribute or “spread” the stresses created by wheel loads acting on the wearing surface so that the stresses transmitted to the subgrade will not be sufficiently great to result in excessive deformation or displacement of that foundation layer. The base must also be of such character that it is not damaged by capillary water and/or frost action. Locally available materials are extensively used for base construction, and materials preferred for this type of construction vary wwidely in different sections of the country. For example, the base may be composed of gravel or crushed rock or it may bae a granular material treated with asphalt,cement,or lime-fly ash stabilizing agents.Asubbase of granular material or stabilized material may be used in areas where frost action is severe, in locations where the subgrade soil is extremely weak. It may also be used , in the interests of economy ,in locations where suitable subbase material are cheap than base materials of higher quality.The subgrade is the foundation layer, the structure that must eventually support all the loads which come onto the pavement. In some cases this layer will simply be the natural earth surface. In other or more usual instances it will be compacted soil existing in a cut section or the upper layer of an embankment section. In the fundamental concept of the action of flexible pavement,the combined thickness of subbase (if used), base, and wearing surface must be great enough to reduce the stresses occuring in the subgrade to values that are not sufficiently great to cause excessive distortion or displacement of the subgrade soil layer.The principle factors entering into the problem of the thickness design of flexible pavement are:(1)Traffic loading.(2)Climate or environment.(3)Material characteristics.A number of other elements must also be considered in order to arrive at a final thickness design. This include cost, construction, maintenance,an design period. Thus, the students should realize that the design process is complex, and it is highly unlikely that any extremely simple method of approach will prove entirely successful under all conditions.Protection of the subgrade from the loading imposed by traffic is one of the primariy functions of a pavement structure. The designer must privide a pavement that can withstand a large number of repeated applications of variable-magnitude loading.The magnitude of maximum loading is commonly controlled by legal load limits. Traffic surveys and loadometer studies are often used to establish the relative magnitude and occurrence of the various loading to which a pavement is subjected. Prediction or estimation of the total traffic that will use a pavement during its design ife is a very difficult but obviously important task.The climate or environment in which a flexible pavement is to be established has an important influence on the behavior and performance of the various in the pavement and subgrade. Probablly the two climate factors of major significance are temperature and moisture.The magnitude of temperature and its fluctuations affect the properties of certain materials. For example, high temperatures cause asphaltic concrete to lose stability whereas at low temperatures asphaltic concrete becomes very hard and stiff. Low temperature and temperature fluctuations are also associated with frost heave and freeze-thaw damage.Granular materials, if not properly graded, can experience frost heave. Likewise, the subgrade can exhibit extensive loss in strength if it becomes frozen. Certain stabilized materials (lime, cement, and lime-fly ash treated) can suffer substantial damage if a large number of freeze-thaw cycles occur in the material.Moisture also has an important influence on the behavior and performance ofmany materials. Moisture is an important ingredient in frost-related damage. Subgrade soils and other paving materials weaken appreciably when saturated, and certain clayey soil exhibit substantial moisture-included volume change.Subgrade moisture conditions change is affecting road structural strength, stiffness and stability of the important factors. Subgrade moisture influence has the following main factors: atmospheric precipitation and evaporation, infiltration of surface water, groundwater impact, temperature changes caused by humidity. Cyclical atmospheric temperature changes throughout the year, day and night temperatures for each day a certain extent cyclical changes. Surface directly exposed to the air, and experiencing the impact of these changes, in particular surface material most affected. Road surface temperature change with the weather temperature is roughly synchronized. Surface layer temperature at different depths within the same generation as the cyclical changes in atmospheric temperature, but the magnitude of change increases with the depth gradually decreased.One of frost damage is frozen, it not only affects the normal running of vehicles, and sometimes the destruction of the pavement structure. Produce frost heave for two reasons: First, as water is frozen, the volume will increase by 9%; second is due to the weak foundation soil to freeze the area with water movement results. Subgrade frost heaving caused by three factors: the sensitivity of frozen soil subgrade; temperature decreased slowly; groundwater supply of water to keep the frozen zone.The advent of spring, began to melt the frozen roadbed, will lose their bearing capacity of soil, leading to road damage, a phenomenon known as the spring melt boil, boil and mainly due to the melting process is top down, when the embankment top soil begins to melt, the water can not be excluded, so the soil has been saturated melting. If by this time a large number of heavy vehicles, road structure would be seriously damaged.Of the road is a sticky, elastic-plastic materials and the combination of mineral aggregate particles consisting of roads, including the addition of cement concrete as a surface layer and the surface structure of a variety of other grass-roots level. Flexible pavement design including pavement layer combination of design, structuralcalculation and the road pavement material mix design. This chapter elaborates the following aspects: elastic layered system theory, the pavement layer combination of design principles, road design standards and parameters, calculation of pavement thickness and the bending stress check.In reality, the road base material and the soil is not in any case have elastic properties. Non-linear elastic - viscous - plastic theory, under certain conditions more accurately describe the stress state of the road, but taking into account the role of the transient driving wheels in the pavement structure, the stress was small, so you can road as each layer is an ideal elastic body, multi-layer linear elastic theory to application to design calculations. Multi-layer linear elastic theory must be used the following basic assumptions:yers of material are continuous, homogeneous, isotropic and to obey Hooke's law, and the displacement and deformation is small;2. The next level (soil basis) in the horizontal direction and vertical direction down to infinity, The elastic layer is above all have a certain thickness, but the horizontal direction is infinite;3. layers of infinite distance in the horizontal direction and the next layer down to infinite depths, the stress, strain and displacement is zero;4. layers the contact conditions between fully continuous;5. do not count weight.Flexible Pavement Structure Design's mission is to design principles in general under the guidance of the road, according to the road level, requirements and design life of the cumulative equivalent standard axle load axle, considering the supply of road materials, the degree of influence of natural factors and the specific construction conditions, determine a reasonable level of the pavement structure and select the appropriate economic composition materials, combined into both withstand traffic loads and the role of natural factors, but also give full play to the maximum performance of structural materials, subgrade layer pavement system. Combination of flexible pavement structural design should follow the following basic principles:1, route, embankment, road do take into consideration the overall design;2, according to the structure, function and transport layer characteristics of selected structural levels;3, the strength to adapt to traffic load and stiffness combination;4, pay attention to its own characteristics each layer, make layer combination;5, the appropriate number of layers and thickness;6, to consider the impact of water temperature conditions to ensure stability.柔性路面设计一般来讲,路面(和路基)可以分为两种类型:刚性路面和柔性路面。
交通工程公路建设中英文对照外文翻译文献

中英文对照外文翻译文献(文档含英文原文和中文翻译)英文原文:The Basics of a Good RoadWe have known how to build good roads for a long time. Archaeologists have found ancient Egyptian roadsthat carried blocks to the pyramids in 4600 BCE. Later,the Romans built an extensive road system, using the same principles we use today. Some of these roads are still in service.If you follow the basic concepts of road building, you will create a road that will last. The ten commandments of a good road are:(1)Get water away from the road(2)Build on a firm foundation(3)Use the best materials(4)Compact all layers properly(5)Design for traffic loads and volumes(6)Design for maintenance(7)Pave only when ready(8)Build from the bottom up(9)Protect your investment(10)Keep good records1.Get water away from the roadWe can’t overemphasize the importance of good drainage.Engineers estimate that at least 90% of a road’s problems can be related to excess water or to poor waterdrainage. Too much water in any layer of a road’sstructure can weaken that layer, leading to failure.In the surface layer, water can cause cracks and potholes. In lower layers it undermines support, causing cracks and potholes. A common sign of water in an asphalt road surface is alligator cracking — an interconnected pattern of cracks forming small irregular shaped pieces that look like alligator skin. Edge cracking, frost heaves, and spring breakup of pavements also point to moisture problems.To prevent these problems remember that water:• flows downhill• needs to flow someplace• is a problem if it is not flowingEffective drainage systems divert, drain and dispose of water. To do this they use interceptor ditches and slopes,road crowns, and ditch and culvert systems.Divert —Interceptor ditches, located between the road and higher ground along the road, keep the water from reaching the roadway. These ditches must slope so they carry water away from the road.Drain —Creating a crown in the road so it is higher along the centerline than at the edges encourages water to flow off the road. Typically a paved crown should be 1⁄4" higher than the shoulder for each foot of width from the centerline to the edge. For gravel surfaces the crown should be 1⁄2" higher per foot of width. For this flow path to work, the road surface must be relatively water tight. Road shoulders also must be sloped away from the road to continue carrying the flow away. Superelevations (banking) at the outside of curves will also help drainthe road surface.Dispose —A ditch and culvert system carries water away from the road structure. Ditches should be at least one foot lower than the bottom of the gravel road layer that drains the roadway. They must be kept clean and must be sloped to move water into natural drainage. If water stays in the ditches it can seep back into the road structure and undermine its strength. Ditches should also be protected from erosion by planting grass, or installing rock and other erosion control measures. Erosion can damage shoulders and ditches, clog culverts, undermine roadbeds, and contaminate nearby streams and lakes. Evaluate your ditch and culvert system twice a year to ensure that it works. In the fall, clean out leaves and branches that can block flow. In spring, check for and remove silts from plowing and any dead plant material left from the fall.2.Build on a firm foundationA road is only as good as its foundation. A highway wears out from the top down but falls apart from the bottom. The road base must carry the entire structure and the traffic that uses it.To make a firm foundation you may need to stabilize the roadbed with chemical stabilizers, large stone called breaker run, or geotextile fabric. When you run into conditions where you suspect that the native soil is unstable, work with an engineer to investigate the situation and design an appropriate solution.3.Use the best materialsWith all road materials you “pay now or pay later.” Inferior materials may require extensive maintenance throughout the road’s life. They may also force you to replace the road prematurely.Crushed aggregate is the best material for the base course. The sharp angles of thecrushed material interlock when they are compacted. This supports the pavement and traffic by transmitting the load from particle to particle. By contrast, rounded particles act like ballbearings, moving under loads.Angular particles are more stable than rounded particles.Asphalt and concrete pavement materials must be of the highest quality, designed for the conditions, obtained from established firms, and tested to ensure it meets specifications. 4.Compact all layersIn general, the more densely a material is compacted, the stronger it is. Compaction alsoshrinks or eliminates open spaces (voids) between particles. This means that less water can enter the structure. Water in soil can weaken the structure or lead to frost heaves. This is especially important for unsurfaced (gravel) roads. Use gravel which has a mix of sizes (well-graded aggregate) so smaller particles can fill the voids between larger ones. Goodcompaction of asphalt pavement lengthens its life.5.Design for traffic loads and volumesDesign for the highest anticipated load the road will carry. A road that has been designed only for cars will not stand up to trucks. One truck with 9 tons on a single rear axle does as much damage to a road as nearly 10,000 cars.Rural roads may carry log trucks, milk trucks, fire department pumper trucks, or construction equipment. If you don’t know what specific loads the road will carry, a good rule of thumb is to design for the largest piece of highway maintenance equipment that will be used on the road.A well-constructed and maintained asphalt road should last 20 years without major repairs or reconstruction. In designing a road, use traffic counts that project numbers and sizes of vehicles 20 years into the future. These are only projections, at best, but they will allow you to plan for traffic loadings through a road’s life.6.Design for maintenanceWithout maintenance a road will rapidly deteriorate and fail. Design your roads so they can be easily maintained. This means:• adequate ditches that can be cleaned regularly• culverts that are marked for easy locating in the spring• enough space for snow after it is plowed off the road• proper cross slopes for safety, maintenance and to avoid snow drifts• roadsi des that are planted or treated to prevent erosion• roadsides that can be mowed safelyA rule of thumb for adequate road width is to make it wide enough for a snowplow to pass another vehicle without leaving the travelled way.Mark culverts with a post so they can be located easily.7.Pave only when readyIt is not necessary to pave all your roads immediately. There is nothing wrong with a well-built and wellmaintained gravel road if traffic loads and volume do not require a paved surface. Three hundred vehicles per day is the recommended minimum to justify paving.Don’t assume that laying down asphalt will fix a gravel road that is failing. Before you pave, make sure you have an adequate crushed stone base that drains well and is properly compacted. The recommended minimum depth of crushed stone base is 10" depending on subgrade soils. A road paved only when it is ready will far outperform one that is constructed too quickly.8.Ê Build from the bottom upThis commandment may seem obvious, but it means that you shouldn’t top dress or resurface a road if the problem is in an underlying layer. Before you do any road improvement, locate the cause of any surface problems. Choose an improvement technique that will address the problem. This may mean recycling or removing all road materials down to the native soil and rebuilding everything. Doing any work that doesn’t solve the problem is a waste of money and effort.9.Ê Protect your investmentThe road system can be your municipality’s biggest investment. Just as a home needs painting or a new roof, a road must be maintained. Wisconsin’s severe climate requires more road maintenance than in milder places. Do these important maintenance activities: Surface —grade, shape, patch, seal cracks, control dust, remove snow and iceDrainage —clean and repair ditches and culverts; remove all excess materialRoadside —cut brush, trim trees and roadside plantings, control erosionTraffic service —clean and repair or replace signsDesign roads with adequate ditches so they can be maintained with a motor grader. Clean and grade ditches to maintain proper pitch and peak efficiency. After grading, remove all excess material from the shoulder.10.Keep good recordsYour maintenance will be more efficient with good records. Knowing the road’s construction, life, and repair history makes it much easier to plan and budget its future repairs. Records can also help you evaluate the effectiveness of the repair methods and materials you used.Good record keeping starts with an inventory of the system. It should include the history andsurface condition of the roadway, identify and evaluate culverts and bridges, note ditch conditions, shoulders, signs, and such structures as retaining walls and guardrails.Update your inventory each year or when you repair or change a road section. A formal pavement management system can help use these records and plan and budget road improvements.ResourcesThe Basics of a Good Road#17649, UW-Madison, 15 min. videotape. Presents the Ten Commandments of a Good Road. Videotapes are loaned free through County Extension offices.Asphalt PASER Manual(39 pp), Concrete PASER Manual (48 pp), Gravel PASER Manual (32 pp). These booklets contain extensive photos and descriptions of road surfacesto help you understand types of distress conditions and their causes. A simple procedure for rating the condition helps you manage your pavements and plan repairs.Roadware, a computer program which stores and reports pavement condition information. Developed by the Transportation Information Center and enhanced by the Wisconsin Department of Transportation, it uses the PASER rating system to provide five-year cost budgets and roadway repair/reconstruction priority lists.Wisconsin Transportation Bulletin factsheets, available from the Transportation Information Center (T.I.C.).Road Drainage, No. 4. Describes drainage for roadways, shoulders, ditches, and culverts.Gravel Roads, No. 5. Discusses the characteristics of a gravel road and how to maintain one.Using Salt and Sand for Winter Road Maintenance,No. 6. Basic information and practical tips on how to use de-icing chemicals and sand.Culverts—Proper Use and Installation, No. 15. Selecting and sizing culverts, designing, installing and maintaining them.Geotextiles in Road Construction/Maintenance andErosion Control, No. 16. Definitions and common applications of geotextiles on roadways and for erosion control.T.I.C. workshops are offered at locations around the state.Crossroads,an 8-page quarterly newsletter published by the T.I.C. carries helpful articles, workshop information, and resource lists. For more information on any of these materials, contact the T.I.C. at 800/442-4615.译文:一个良好的公路的基础长久以来我们已经掌握了如何铺设好一条道路的方法,考古学家发现在4600年古埃及使用建造金字塔的石块铺设道路,后来,罗马人使用同样的方法建立了一个庞大的道路系统,这种方法一直沿用到今天。
交通工程专业外文翻译外文文献英文文献

土木工程学院交通工程专业中英文翻译Road Design专业:交通工程英文原文The Basics of a Good RoadWe have known how to build good roads for a long time. Archaeologists have found ancient Egyptian roadsthat carried blocks to the pyramids in 4600 BCE. Later,the Romans built an extensive road system, using the same principles we use today. Some of these roads are still in service.If you follow the basic concepts of road building, you will create a road that will last. The ten commandments of a good road are:(1)Get water away from the road(2)Build on a firm foundation(3)Use the best materials(4)Compact all layers properly(5)Design for traffic loads and volumes(6)Design for maintenance(7)Pave only when ready(8)Build from the bottom up(9)Protect your investment(10)Keep good records1.Get water away from the roadWe can’t overemphasize the importance of good drainage.Engineers estimate that at least 90% of a road’s problems can be related to excess water or to poor waterdrainage. Too much water in any layer of a road’sstructure can weaken that la yer, leading to failure.In the surface layer, water can cause cracks and potholes. In lower layers it undermines support, causing cracks and potholes. A common sign of water in an asphalt road surface is alligator cracking — an interconnected pattern of cracks forming small irregular shaped pieces that look like alligator skin. Edge cracking, frost heaves, and spring breakup of pavements also point to moistureproblems.To prevent these problems remember that water:• flows downhill• needs to flow somepla ce• is a problem if it is not flowingEffective drainage systems divert, drain and dispose of water. To do this they use interceptor ditches and slopes,road crowns, and ditch and culvert systems.Divert —Interceptor ditches, located between the road and higher ground along the road, keep the water from reaching the roadway. These ditches must slope so they carry water away from the road.Drain —Creating a crown in the road so it is higher along the centerline than at the edges encourages water to flow off the road. Typically a paved crown should be 1⁄4" higher than the shoulder for each foot of width from the centerline to the edge. For gravel surfaces the crown should be 1⁄2" higher per foot of width. For this flow path to work, the road surface must be relatively water tight. Road shoulders also must be sloped away from the road to continue carrying the flow away. Superelevations (banking) at the outside of curves will also help drainthe road surface.Dispose —A ditch and culvert system carries water away from the road structure. Ditches should be at least one foot lower than the bottom of the gravel road layer that drains the roadway. They must be kept clean and must be sloped to move water into natural drainage. If water stays in the ditches it can seep back into the road structure and undermine its strength. Ditches should also be protected from erosion by planting grass, or installing rock and other erosion control measures. Erosion can damage shoulders and ditches, clog culverts, undermine roadbeds, and contaminate nearby streams and lakes. Evaluate your ditch and culvert system twice a year to ensure that it works. In the fall, clean out leaves and branches that can block flow. In spring, check for and remove silts from plowing and any dead plant material left from the fall.2.Build on a firm foundationA road is only as good as its foundation. A highway wears out from the top down but falls apart from the bottom. The road base must carry the entire structure and the traffic that uses it.To make a firm foundation you may need to stabilize the roadbed with chemical stabilizers, large stone called breaker run, or geotextile fabric. When you run into conditions where you suspect that the native soil is unstable, work with an engineer to investigate the situation and design an appropriate solution.3.Use the best materialsWith all road materials you “pay now or pay later.” Inferior materials may require extensive maintenance throughout the road’s life. They may also force you to replace the road prematurely.Crushed aggregate is the best material for the base course. The sharp angles of thecrushed material interlock when they are compacted. This supports the pavement and traffic by transmitting the load from particle to particle. By contrast, rounded particles act like ballbearings, moving under loads.Angular particles are more stable than rounded particles.Asphalt and concrete pavement materials must be of the highest quality, designed for the conditions, obtained from established firms, and tested to ensure it meets specifications.4.Compact all layersIn general, the more densely a material is compacted, the stronger it is. Compaction also shrinks or eliminates open spaces (voids) between particles. This means that less water can enter the structure. Water in soil can weaken the structure or lead to frost heaves. This is especially important for unsurfaced (gravel) roads. Use gravel which has a mix of sizes (well-graded aggregate) so smaller particles can fill the voids between larger ones. Goodcompaction of asphalt pavement lengthens its life.5.Design for traffic loads and volumesDesign for the highest anticipated load the road will carry. A road that has been designed only for cars will not stand up to trucks. One truck with 9 tons on a single rear axle does as much damage to a road as nearly 10,000 cars.Rural roads may carry log trucks, milk trucks, fire department pumper trucks, or construction equipment. If you don’t know what specific loads the road will carry, a good rule of thumb is to design for the largest piece of highway maintenance equipment that will be used on the road.A well-constructed and maintained asphalt road should last 20 years without major repairs or reconstruction. In designing a road, use traffic counts that project numbers and sizes of vehicles 20 years into the future. These are only projections, at best, but they will allow you to plan for traffic loadings through a road’s life.6.Design for maintenanceWithout maintenance a road will rapidly deteriorate and fail. Design your roads so they can be easily maintained. This means:• adequate ditches that can be cleaned regularly• culverts that are marked for easy locating in the spring• enough space for snow after it is plowed off the road• proper cross slopes for safet y, maintenance and to avoid snow drifts• roadsides that are planted or treated to prevent erosion• roadsides that can be mowed safelyA rule of thumb for adequate road width is to make it wide enough for a snowplow to pass another vehicle without leaving the travelled way.Mark culverts with a post so they can be located easily.7.Pave only when readyIt is not necessary to pave all your roads immediately. There is nothing wrong with a well-built and wellmaintained gravel road if traffic loads and volume do not require a paved surface. Three hundred vehicles per day is the recommended minimum to justify paving.Don’t assume that laying down asphalt will fix a gravel road that is failing. Before you pave, make sure you have an adequate crushed stone base that drains well and is properly compacted. The recommended minimum depth of crushed stone base is 10" depending on subgrade soils. A road paved only when it is ready will far outperform one that is constructed too quickly.8.Ê Build from the bottom upThis commandment may seem obvious, but it means that you shouldn’t top dress or resurface a road if the problem is in an underlying layer. Before you do any road improvement, locate the cause of any surface problems. Choose an improvement technique that will address the problem. This may mean recycling or removing all road materials down to the native soil and rebuilding everything. Doing any work that doesn’t solve the problem is a waste of money and effort.9.Ê Protect your investmentThe road system can be your municipality’s biggest investment. Just as a home needs painting or a new roof, a road must be maintained. Wisconsin’s severe climate requires more road maintenance than in milder places. Do these important maintenance activities: Surface —grade, shape, patch, seal cracks, control dust, remove snow and iceDrainage —clean and repair ditches and culverts; remove all excess materialRoadside —cut brush, trim trees and roadside plantings, control erosionTraffic service —clean and repair or replace signsDesign roads with adequate ditches so they can be maintained with a motor grader. Clean and grade ditches to maintain proper pitch and peak efficiency. After grading, remove all excess material from the shoulder.10.Keep good recordsYour maintenance will be more efficient with good records. Knowing the road’s construction, life, and repair history makes it much easier to plan and budget its future repairs. Records can also help you evaluate the effectiveness of the repair methods and materials you used.Good record keeping starts with an inventory of the system. It should include the history and surface condition of the roadway, identify and evaluate culverts and bridges, note ditch conditions, shoulders, signs, and such structures as retaining walls and guardrails.Update your inventory each year or when you repair or change a road section. A formal pavement management system can help use these records and plan and budget road improvements.ResourcesThe Basics of a Good Road#17649, UW-Madison, 15 min. videotape. Presents the Ten Commandments of a Good Road. Videotapes are loaned free through County Extension offices.Asphalt PASER Manual(39 pp), Concrete PASER Manual (48 pp), Gravel PASER Manual (32 pp). These booklets contain extensive photos and descriptions of road surfacesto help you understand types of distress conditions and their causes. A simple procedure for rating the condition helps you manage your pavements and plan repairs.Roadware, a computer program which stores and reports pavement condition information. Developed by the Transportation Information Center and enhanced by the Wisconsin Department of Transportation, it uses the PASER rating system to provide five-year cost budgets and roadway repair/reconstruction priority lists.Wisconsin Transportation Bulletin factsheets, available from the Transportation Information Center (T.I.C.).Road Drainage, No. 4. Describes drainage for roadways, shoulders, ditches, and culverts.Gravel Roads, No. 5. Discusses the characteristics of a gravel road and how to maintain one.Using Salt and Sand for Winter Road Maintenance,No. 6. Basic information and practical tips on how to use de-icing chemicals and sand.Culverts—Proper Use and Installation, No. 15. Selecting and sizing culverts, designing, installing and maintaining them.Geotextiles in Road Construction/Maintenance andErosion Control, No. 16. Definitions and common applications of geotextiles on roadways and for erosion control.T.I.C. workshops are offered at locations around the state.Crossroads,an 8-page quarterly newsletter published by the T.I.C. carries helpful articles, workshop information, and resource lists. For more information on any of these materials, contact the T.I.C. at 800/442-4615.中文译文一个良好的公路的基础长久以来我们已经掌握了如何铺设好一条道路的方法,考古学家发现在4600年古埃及使用建造金字塔的石块铺设道路,后来,罗马人使用同样的方法建立了一个庞大的道路系统,这种方法一直沿用到今天。
道路工程毕业设计外文翻译---高速公路设计与施工

原文Highway Design and Construction: The Innovation Challenge Author: Robert E. Skinner Jr.Innovations and advances in research are changing the way highways are built in America.The Egyptians were pouring concrete in 2500 BC, and the Romans used it to construct the Pantheon and the Colosseum. By the mid-1800s, Europeans were building bridges with concrete, and the first “modern” concrete highway pavements appear ed in the latter part of the 19th century. Naturally occurring asphalts, which have been used for waterproofing for thousands of years, came into common use in road construction in the 1800s. The first iron bridge was constructed in 1774, but by the end of the 19th century steel had largely replaced iron in bridge construction. These materials—concrete, asphalt, and steel—are now the mainstays of highway and bridge construction throughout the world, as well as of most types of public works infrastructure. Concrete and steel, the most versatile of these materials, are used for bridges and other highway structures; concrete and asphalt are used for roadway pavements.Everyone is familiar with concrete, asphalt, and steel, and some of us have worked with them, perhaps on home improvement projects. This familiarity, coupled with the long history of their many uses, has led many otherwise technically savvy people to believe that these materials are well understood, that their performance can be easily and reliably predicted, and that the technical challenges in using them for highways were overcome long ago. However, such notions are largely incorrect and misleading.For example, consider concrete, which is a mixture of portland cement, sand, aggregate (gravel or crushed stone), and water. Its performance characteristics are determined by the proportions and characteristics of the components, as well as by how it is mixed and formed. The underlying chemical reactions of concrete are surprisingly complex, not completely understood, and vary with the type of stone. Steel may be added for tensile strength (reinforced concrete), and a variety of additives have been identified to improve the workabilityand performance of concrete in particular applications and conditions. Damage and deterioration to concrete can result from excessive loadings and environmental conditions, such as freeze-thaw cycles and chemical reactions with salts used for deicing._________________________Many factors contribute to theurgent need for innovation inhighway construction._________________________Concrete is the most heavily used substance in the world after water (Sedgwick, 1991). Worldwide, concrete construction annually consumes about 1.6 billion tons of cement, 10 billion tons of sand and crushed stone, and 1 billion tons of water (M.S. Kahn, 2007). Given transportation costs, there is a huge financial incentive to using local sources of stone, even if the properties of that stone are less than ideal. Thus concrete is not a homogenous material. In truth, an unlimited number of combinations and permutations are possible.Much the same can be said of asphalt—technically, asphaltic concrete—which is also a mixture of aggregate (gravel or crushed stone), sand, and cement (asphalt binder); economics promote the use of locally available materials; and the underlying chemistry is not well understood. The characteristics of asphalt binder, for instance, vary depending on the source of crude oil from which it is derived.The metallurgy of steel is probably better understood than the chemistry of either asphalt or concrete, but it too is a mixture with virtually limitless combinations. Strength, toughness, corrosion resistance, and weldability are some of the performance characteristics that vary with the type of steel alloy used and the intended applications.As uses evolve and economic conditions change, we have a continuing need for a more sophisticated understanding of these common materials. Even though they are “mature” products, there is still room for significant incremental improvements in their performance. Because fundamental knowledge is still wanting, there is also considerable potential for breakthroughs in their performance.Factors That Affect Highway ConstructionAll other things being equal, stronger, longer lasting, less costly highway materials are desirable and, given the quantities involved, there are plenty of incentives for innovation. In highway transportation, however, all other things are not equal. A number of other factors contribute to the urgent and continuing need for innovation.First, traffic volume and loadings continue to increase. Every day the U.S. highway network carries more traffic, including heavy trucks that were unimagined when the system wasoriginally conceived and constructed. The 47,000-mile interstate highway system today carries more traffic than the entire U.S. highway system carried in 1956 when the interstates were laid out. The U.S. Department of Transportation (DOT) estimates that in metropolitan areas the annual cost of traffic congestion for businesses and citizens is nearly $170 billion (PB Consult, Inc., 2007).On rural interstates, overall traffic more than doubled between 1970 and 2005; at the same time, the loadings on those highways increased six-fold, mainly due to the increase in the number of trucks and the number of miles they travel. (Truck traffic increased from about 5.7 percent of all vehicle-miles traveled on U.S. highways in 1965 to 7.5 percent in 2000 [FHWA, 2005]).Second, traffic disruptions must be kept to a minimum during construction. Our overstressed highway system is not very resilient. Thus disruptions of any sort, such as lane and roadway closings, especially in major metropolitan areas and on key Interstate routes, can cause massive traffic snarls. This means that repair and reconstruction operations must often be done at night, which introduces a variety of additional complexities and safety issues. Occasionally, heroic measures must be taken to keep traffic moving during construction. For example, during construction of the “Big Dig” in Boston, the elevated Central Artery was in continuous service while cut-cover tunnels were constructed directly below it.Third, environmental, community, and safety requirements have become more stringent. For many good reasons, expectations of what a highway should be, how it should operate, and how it should interact with the environment and adjacent communities are constantly evolving. Designs to promote safety, measures to mitigate a growing list of environmental impacts, and attention to aesthetics have fundamentally changed the scope of major highway projects in the United States. For example, on Maryland’s $2.4 billion Intercounty Connector project in suburban Washington, D.C., which is now under construction, environmental mitigation accounts for 15 percent of project costs, or about $15 million per mile (AASHTO, 2008). Fourth, costs continue to rise. Building and maintaining highways cost effectively is an ever-present goal of good engineering. But cost increases in highway construction have been extraordinary due in part to the expanded scope of highway projects and construction in demanding settings. In addition, the costs of the mainstay materials—portland cement, asphalt binder, and steel—have risen dramatically as the world, particularly China, has gone on a construction binge. The Federal Highway Administration’s cost indices for portland cement concrete pavement, asphalt pavement, and structural steel increased by 51 percent, 58 percent, and 70 percent respectively between 1995 and 2005 (FHWA, 2006).Fortunately, research and innovation in construction have never stopped, although they are not always sufficiently funded and they seem to fly beneath the radar of many scientists and engineers. Nevertheless, there have been great successes, which are cumulatively changing how highways are built in America.The Superpave Design SystemIn response to widespread concerns about premature failures of hot-mix asphalt pavements in the early 1980s, a well funded, congressionally mandated, crash research program was conducted to improve our understanding of asphalt pavements and their performance. The seven-year Strategic Highway Research Program (SHRP), which was managed by the National Research Council, developed a new system of standard specifications, test methods, andengineering practices for the selection of materials and the mix proportions for hot-mix asphalt pavement.The new system has improved matches between combinations of asphalt binder and crushed stone and the climatic and traffic conditions on specific highways. State departments of transportation (DOTs) spend more than $10 billion annually on these pavements, so even modest improvements in pavement durability and useful life can lead to substantial cost savings for agencies and time savings for motorists (TRB, 2001).SHRP rolled out the Superpave system in 1993, but it took years for individual states and their paving contractors to switch to the new system, which represents a significant departure, not only in design, but also in the procedures and equipment used for testing. Each state DOT had to be convinced that the benefits would outweigh the modest additional costs of Superpave mixes, as well as the time and effort to train its staff and acquire necessary equipment.A survey in 2005 showed that 50 state DOTs (including the District of Columbia and Puerto Rico) were using Superpave (Figure 1). The remaining two states indicated that they would be doing so by the end of 2006. Throughout the implementation period, researchers continued to refine the system (e.g., using recycled asphalt pavements in the mix design [TRB, 2005]).It may be years before the cost benefits of Superpave can be quantified. A 1997 study by the Te xas Transportation Institute projected that, when fully implemented, Superpave’s annualized net savings over 20 years would approach $1.8 billion annually—approximately $500 million in direct savings to the public and $1.3 billion to highway users (Little et al., 1997).Moreover, analyses by individual states and cities have found that Superpave has dramatically improved performance with little or no increase in cost. Superpave is not only an example of a successful research program. It also demonstrates that a vigorous, sustained technology-transfer effort is often required for innovation in a decentralized sector, such as highway transportation.Prefabricated ComponentsThe offsite manufacturing of steel and other components of reinforced concrete for bridges and tunnels is nothing new. But the need for reconstructing or replacing heavily used highway facilities has increased the use of prefabricated components in startling ways. In some cases components are manufactured thousands of miles from the job site; in others, they are manufactured immediately adjacent to the site. Either way, we are rethinking how design and construction can be integrated.When the Texas Department of Transportation needed to replace 113 bridge spans on an elevated interstate highway in Houston, it found that the existing columns were reusable, but the bent caps (the horizontal connections between columns) had to be replaced. As an alternative to the conventional, time-consuming, cast-in-place approach, researchers at the University of Texas devised new methods of installing precast concrete bents. In this project, the precast bents cut construction time from 18 months to slightly more than 3 months (TRB, 2001).As part of a massive project to replace the San Francisco-Oakland Bay Bridge, the California Department of Transportation and the Bay Area Toll Authority had to replace a 350-foot, 10-lane section of a viaduct on Yerba Buena Island. In this case, the contractor, C.C. Myers, prefabricated the section immediately adjacent to the existing viaduct. The entire bridge was then shut down for the 2007 Labor Day weekend, while the existing viaduct was demolished and the new 6,500-ton segment was “rolled” into place (Figure 2). The entire operation was accomplished 11 hours ahead of schedule (B. Kahn, 2007).Probably the most extensive and stunning collection of prefabricated applications on a single project was on the Central Artery/Tunnel Project (“Big Dig”) in Boston. For the Ted Williams Tunnel, a dozen 325-foot-long steel tunnel sections were constructed in Baltimore, shipped to Boston, floated into place, and then submerged. However, for the section of the tunnel that runs beneath the Four Points Channel, which is part of the I-90 extension, bridge restrictions made this approach infeasible. Instead, a huge casting basin was constructed adjacent to the channel where 30- to 50-ton concrete tunnel sections were manufactured The basin was flooded and the sections winched into position with cables and then submerged.An even more complicated process was used to build the extension tunnel under existing railroad tracks, which had poor underlying soil conditions. Concrete and steel boxes were built at one end of the tunnel, then gradually pushed into place through soil that had been frozen using a network of brine-filled pipes (Vanderwarker, 2001).Specialty Portland Cement ConcretesNew generations of specialty concretes have improved one or more aspects of performance and allow for greater flexibility in highway design and construction. High-performance concrete typically has compressive strengths of at least 10,000 psi. Today, ultra-high-performance concretes with formulations that include silica fume, quartz flour, water reducers, and steel or organic fibers have even greater durability and compressive strengths up to 30,000 psi. These new concretes can enable construction with thinner sections and longer spans (M.S. Kahn, 2007).Latex-modified concrete overlays have been used for many years to extend the life of existing, deteriorating concrete bridge decks by the Virginia DOT, which pioneered the use of very early strength latex-modified concretes for this application. In high-traffic situations, the added costs of the concrete have been more than offset by savings in traffic-control costs and fewer delays for drivers (Sprinkel, 2006).When the air temperature dips below 40, costly insulation techniques must be used when pouring concrete for highway projects. By using commercially available admixtures that depress the freezing point of water, the U.S. Cold-Weather Research and Engineering Laboratory has developed new concrete formulations that retain their strength and durability at temperatures as low as 23?F. Compared to insulation techniques, this innovation has significantly decreased construction costs and extended the construction season in cold weather regions (Korhonen, 2004).As useful as these and other specialty concretes are, nanotechnology and nanoengineering techniques, which are still in their infancy, have the potential to make even more dramatic improvements in theperformance and cost of concrete.Waste and Recycled MaterialsHighway construction has a long history of using industrial waste and by-product materials. The motivations of the construction industry were simple—to help dispose of materials that are otherwise difficult to manage and to reduce the initial costs of highway construction. The challenge has been to use these materials in ways that do not compromise critical performance properties and that do not introduce substances that are potenti-ally harmful to people or the environment. At the same time, as concerns about sustainability have become more prominent in public thinking, the incentives to use by-product materials have increased. In addition, because the reconstruction and resurfacing of highways create their own waste, recycling these construction materials makes economic and environmental sense.Research and demonstration projects have generated many successful uses of by-product and recycled materials in ways that simultaneously meet performance, environmental, and economic objectives. For example, “crumb rubber” from old tires is increasingly being used as an additive in certain hot-mix asphalt pavement designs, and a number of patents have been issued related to the production and design of crumb rubber or asphalt rubber pavements (CDOT, 2003; Epps, 1994).Several states, notably California and Arizona, use asphalt rubber hot mix as an overlay for distressed flexible and rigid pavements and as a means of reducing highway noise. Materials derived from discarded tires have also been successfully used as lightweight fill for highway embankments and backfill for retaining walls, as well as for asphalt-based sealers and membranes (Epps, 1994; TRB, 2001).Fly ash, a residue from coal-burning power plants, and silica fume, a residue from metal-producing furnaces, are increasingly being used as additives to portland cement concrete. Fly-ash concretes can reduce alkali-silica reactions that lead to the premature deterioration of concrete (Lane, 2001), and silica fume is a component of the ultra-high-performance concrete described above.After many years of experimentation and trials, reclaimed asphalt pavement (RAP) is now routinely used in virtually all 50 states as a substitute for aggregate and a portion of the asphalt binder in hot-mix asphalt, including Superpave mixes. The reclaimed material typically constitutes 25 to 50 percent of the “new” mix (TFHRC, 1998). The National Asphalt Pavement Association estimates that 90 percent of the asphalt pavement removed each year is recycled and that approximately 125 millions tons of RAP are produced, with an annual savings of $300 million (North Central Superpave Center, 2004).Visualization, Global Positioning Systems, and Other New Tools For more than 20 years, highway engineers have used two-dimensional, computer-aided drafting and design (CADD) systems to accelerate the design process and reduce costs. The benefits of CADD systems have derived essentially from automating the conventional design process, with engineers doing more or less what they had done before, although much faster and with greater flexibility.New generations of three- and four-dimensional systems are introducing new ways of designing roads, as well as building them (Figure 4). For example, three-dimensional visualization techniques are clearly useful for engineers. But, perhaps more importantly, they have improved the communication of potential designs to affected communities and public officials; in fact, they represent an entirely new design paradigm. Four-dimensional systems help engineers and contractors analyze the constructability of proposed designs well in advance of actual constructionGlobal positioning systems are being used in surveying/layout, in automated guidance systems for earth-moving equipment, and for monitoring quantities. Other innovations include in situ temperature sensors coupled with data storage, transmission, and processing devices that provide onsite information about the maturity and strength of concrete as it cures (Hannon, 2007; Hixson, 2006).ConclusionThe examples described above suggest the wide range of exciting innovations in the design and construction of highways. These innovations address materials, roadway and bridge designs, design and construction methods, road safety, and a variety of environmental, community, and aesthetic concerns. Looking to the future, however, challenges to the U.S. highway system will be even more daunting—accommodating more traffic and higher loadings; reducing traffic disruptions during construction; meeting more stringent environmental, community, and safety requirements; and continuing pressure to reduce costs. Addressing these challenges will require a commitment to innovation and the research that supports innovation.中文翻译高速公路设计与施工:创新的挑战作者:小罗伯特·E·斯金纳研究方式的创新和进步正在改变着美国公路建设的方式。
交通运输交通系统中英文对照外文翻译文献

中英文对照外文翻译文献(文档含英文原文和中文翻译)译文:交通系统交通运输一直是土木工程最重要的一个方面。
古罗马工程师的巨大成就之一就是公路系统,它使罗马与帝国的各个省之间的快速交通成为可能。
在工程方面的第一所培训学校就是桥梁和公路学校,它于1747年创建于法国。
而在英国,一位道路建筑家,托马斯·泰尔福特于1820年担任了土木工程学会的第一任主席。
现代公路仍然根据18世纪及19世纪初法国人皮埃尔·特埃萨凯,英国人泰尔福特,以及苏格兰人约翰·L·马克当所制定的原则进行建造。
这些人设计出了最初的现代道路,这种道路具有坚实的垫层,基础就建在垫层的上面。
他们设计的道路还具有排水良好而且不渗水的磨耗层,即直接承受车辆交通磨耗的表层。
特埃萨凯和泰尔福特均采用较厚的石头基础,在其上面铺筑由较小碎石组成的基层和由更小的石头组成的磨耗层。
他们的道路还微微隆起成曲线,形成路拱和反拱以便使雨水流走。
马克当认识到当土壤被夯实或压紧之后,只要保证干燥,其本身就可承受道路的重量,因而他能够通过在压实的垫层上铺碎石基层来省掉建造石头基础所需要的昂贵费用。
当时车辆的铁质车轮把表层石头碾压成连续的,较为平整的,更加不透水的表面。
早19世纪,货车和客车都采用铁或钢制车轮,这种道路是适用的。
当汽车在20世纪初出现之后,其橡胶轮胎毁坏了这种平整的路面。
因此,就采用焦油或沥青掺拌碎石,使路面表层更坚固的黏合一起。
现在,遍布全世界的数百万公里的道路采用这种路面。
在20世纪,道路建设基本上仅在两方面进行了改进。
第一种改进是采用混凝土作为磨耗层。
另一种改进则是交通工程,即设计高速的大交通量的、造价经济并且对于车辆和旅客都安全的公路。
交通工程已建成了现代高速公路,这种公路具有限定的入口和最安全的管理。
老式道路常用的拐角形交叉已不使用,而采用互通式立体交叉或其他更为复杂的设计。
现代高速公路通常设有专门的车道,在那里当车辆要驶出公路时可减速驶入时可加速。
外文翻译---低流量农村公路的统一设计

附录A 外文翻译A.1 原文CONSISTENCY IN DESIGN FOR LOW-VOLUMERURAL ROADS3By Clarkson H. Oglesby, H. M. ASCE (Reviewed by the Highway Division) ABSTRACT: The 2,000,000 miles of low-volume rural roads in the United States are different than the high-volume roads and should be designed differently. Traffic volumes on them are low, averaging about 110 vehicles/day or about one vehicle entering a given mile from both ends every three minutes during peak hours. This contrasts with one vehicle every four seconds at capacity. Geometries on many of these roads have not changed since they were built in the 1920s and 1930s. Today, road improvements should be based on designs that are consistent and safe, but economical, because needs are great and funds are scarce. Present-day design practices for high volume roads require that each of their features meet a stipulated design speed set by modern surfaces and vehicles. This practice does not fit the low-volume situation since, whenever possible, drivers will exceed any affordable design speed. They must be slowed down when situations warrant it. A consistent approach to design which realizes cheap but safe improvements to low-volume roads is proposed. It involves integrating geometric design and positive guidance approaches. Positive guidance employs striping, signing, and other devices and strategies to mobilize drivers' senses so that they will drive sensibly. Selecting the less costly between geometry and positive guidance techniques will produce safer roads more cheaply.INTRODUCTIONThere are approximately 3,200,000 mile (5,100,000 km) of rural roads in the United States. A rough estimate places some 2,000,000 (3,000,000km) of these in a low-volume category; this commonly includes those with average daily traffic less than 400 vehicles/day in both directions. On most of these roads volumes are considerably lower. One estimate places this average at 110 vehicles/day or a possible 20 in the peak hour. This means one vehicle every three minutes entering a given mile from both ends. In contrast, a major two-lane road, operating at capacity, will carry possibly 1,800 vehicles/hour so that a vehicle will enter a given mile every four seconds or 90 times as often.The money available to those responsible for high-volume roads is on the order of ten times as great per mile as for low-volume roads. It follows that strategies for new construction, upgrading, or maintenance of low-volume rural roads will be entirely different than for higher-volume roads, if the very limited money availablefor these purposes is to be used wisely.Given the uniqueness of the low-volume road problem, it seems appropriate to examine and possibly redefine what is meant by "consistency in design" for them. This paper attempts that task by examining the following topics as it applies to them:1. The origin and current status of local rural roads.2. How "consistency" in present-day geometric standards for new construction or renovation of low-volume roads has developed.3. Factors that have impinged on design standards for low-volume rural roads.4. Conclusions.ORIGIN AND CURRENT STATUS OF LOCAL RURAL ROADS For the purpose of this paper, local rural roads are those that provide access to and thereby support activities on rural lands. These include farming, ranching, recreation, and access to forests or other natural resources. This definition excludes those roads, once rural or near towns, that are now in suburbia.Relatively little mileage has been added to low-volume rural systems in the last 50 years. They were developed when the aim was "to get the farmer out of the mud." They are often characterized by narrow roadways and rights-of-way. In the middle west and west, where much of the land had been laid out in sections one mile square, rights-of-way were 66 ft (20 m). This width was dedicated to land access along the edges of adjacent sections. In the eastern states, many rights-of-way were narrower, often 33 ft (10 m) or less. In rolling or mountainous country, tortuous alignments were fitted closely to the contour of the ground. Today these often restrict speeds to 30 mile/hr (48 km/h) or less.In these earlier years, travel was mainly in horse-drawn vehicle. Even in the 1930s, when the last of these land-access roads were being constructed, speeds were low because neither vehicles nor road surfacings permitted fast travel. For reasons such as these, the concept of design speed did not exist. Today, the performance of motor vehicles is far different and the sizes and weights of trucks have increased dramatically. Furthermore, for possibly two-thirds of this low-volume rural mileage, gravel or earth surfaces have been paved, surface treated, or otherwise made relatively smooth and free of corrugations or dust. Presently, then, drivers expect to travel at higher speeds and only slow down when forced to do so by intersections or restricted vertical or horizontal alignment. On higher volume roads, many of which have been successively improved, this slowing is seldom required. And when it is, elaborate measures are taken to alert drivers. But this matching of improvements with speed has been far less frequent on low-volume rural roads because money has been scarce. Of that available, more than two-thirds (in 1978) has gone to maintenance and other purposes, leaving little for new construction or betterment.It would be untrue and unfair to say that those responsible for low-volume rural roads have done nothing to overcome this mismatch between driver expectations regarding speed and the roads. Through strategies such as spot improvements and scrounging money from their budgets and higher governmental levels for rebuilding certain roads, they have done much. But the gap still remains large. This, of course, applies not only to road geometry, but to surfacings and bridges as well.How CONSISTENCY IN PRESENT-DAY GEOMETRIC STANDARDS FOR NEWCONSTRUCTION OR RENOVATION OF LOW VOLUME RURAL ROADS HAS DEVELOPEDAs noted, most of the need for and geometries of low-volume rural roads developed fifty or more years ago to fit specific situations. Unless altered by maintenance, betterment, reconstruction, or complete replacement, they have changed little since. At that time, main rural roads were built to meet the same conditions and their geometry was not an issue. For example, as late as 1940, a leading highway engineering text book, by T. R. Agg (1), devotes only 22 pages to the entire subject of geometric design. In it Agg stated that "considerable latitude is allowable in adapting the design to the particular situation (which may be topographical, financial, or political) as long as the design does no violence to basic principles." Agg calls for "the exercise of originality and good engineering judgment—that does not necessarily follow stereotyped standards."It was at about this same time (1937) that AASHO (now AASHTO) created a Committee on Planning and Design Policies. Its aim was to incorporate, in practice, highway design features that would result in maximum safety and utility. From this effort, in the period 1938-1944, came seven policy statements on geometric design that were adopted by AASHO. These were consolidated without change in 1950 into a single volume, Policies on Geometric Highway Design (3). A reworking resulted in a 1954 document called A Policy on Geometric Design (4). This document, commonly called the Blue Book, was redone again and published in 1965 under the same title (5). In 1969, a publication applying more specifically to low-volume rural roads was issued (2). Since that time the appropriateness of these policies, which set standards for all aspects of geometric design, have been under almost continuous review and a comprehensive revision is under preparation.From the beginning, those responsible for developing standards for geometric design have been attempting to keep pace with changes in the characteristics of motor vehicles and the expectations of drivers. This has led to a substantial raising of design controls or features.FACTORS THAT HAVE IMPINGED ON GEOMETRIC STANDARDSFOR LOW-VOLUME RURAL ROADSIn tracing the development of geometric standards and their application over the years in terms of their impact on low-volume rural roads policies, several factors can be seen. These include the following:1. Low-volume road engineers or administrators have made few direct inputs into geometric standards. They have been developed by specialists in geometric design, most of them in the Federal Highway Administration. They were adopted after review by geometric-design specialists in the state highway agencies working through AASHTO. Because these agencies deal primarily with high-volume situations, it is claimed that their representatives are not sensitive to the low-volume road situation. For example, the standards for low-volume as well as those for high-volume roads were based on the "design speed" concept, which has been defined as "The maximumsafe speed that can be maintained over a specific section of highway when conditions are so favorable that the design features of the highway govern." This definition implies that only the "reckless few" among drivers will exceed the design speed anywhere along the road. But this is not the way drivers behave on low-volume rural roads. Rather, whenever possible, even on short stretches, they will accelerate to their "fear level" speed. This can well be 50 or 60 mph (80 or 96 km/h) on a road with a stipulated. design speed of 20 or 30 mph (32 or 48 km/h). The problem on such roads becomes one of slowing drivers down to safe speeds as they approach road sections over which they must travel slowly. It might be said that the low "design speeds" stipulated in the standards for certain low-volume roads provide justification and professional support for designers using less costly alternatives at specific locations so that scarce dollars can be spread over greater mileages. Otherwise the "design speed" concept has little meaning in the low-volume rural road situation.2. Standards, once adopted, can become a straitjacket that prevents low-volume road engineers from following Agg's recommendation from 1940 which, to repeat, was "to allow considerable latitude in adapting the design to particular situations (topographical, financial, or political)." This freedom began to disappear when higher-level agencies, because they controlled the money, could dictate design details. Low-volume road engineers sometimes partially overcame this difficulty by having two sets of standards. The more costly set is employed when money from higher-level agencies is involved. The less costly one, done with local funds, does not have a standard cross section, but calls for widening or other improvements at spot locations.A related issue is the influence of these rigid standards when injured motorists sue road agencies and their engineers for negligence when roads do not meet them. This is an important but unanswered question.3. There has been a widely held but unproved notion that by insisting that standards of geometric design be followed, accidents will be reduced. Unfortunately, given the large mileage on existing low-volume roads and scarce funds for improving their geometry, exercising this option is seldom possible. Rather, for low-volume roads, the view that "The design is inadequate and appears dangerous so accidents happen" must be replaced with the notion, "if it seems dangerous, take advantage of driver fear and caution in appropriate ways and accidents won't happen." CONCLUSIONThis paper, which deals with consistency in design standards for lowvolume rural roads, has traced the development for low-volume rural roads, most of which came into being when the aim was to get the farmer out of the mud. It indicated how high geometric design standards, which came later, were developed by those concerned with high volume roads, but who dictated their use because they controlled the money. It challenged the notion that "if it seems dangerous, accidents happen," and proposed that "if it seems dangerous, accidents don't happen." It pointed out that vehicle, road, and driver all combine in safe and efficient vehicle operation; and that as the level of improvement dropped, the driver's ability became more and more important. It described the concept of "positive guidance" and proposed that, at least for low-volume rural roads, consistency in design be redefined to include bothgeometry and positive guidance. Given measures of the relative costs and potential for accident reduction of geometry and guidance, choices could be made rationally.A.2 译文低流量农村公路的统一设计由Clarkson·奥格尔斯比,H. M. ASCE(公路司)摘要:美国的200万英里的低流量的农村公路与高流量的道路不同,应采用不同的设计。
