调整 data . cache system 分区大小打开线刷 OPPO R831T 刷机包,会看到一些文件
这里说下每个刷机文件对应的文件名
PRELOADER→preloader.bin
MBR→MBR
EBR1→EBR1
UBOOT→lk.bin
BOOTIMG→boot.img
RECOVERY→recovery.img
SEC_RO→secro.img
LOGO→logo.bin
EBR2→EBR2
ANDROID→system.img
这就是线刷工具能识别到的文件名,一定要改成对应的名称
要打开
MT6572_Android_scatter_emmcTXT
这个时候就要用到Notepad++ 了,打开桌面上的新建文件夹单机scatter_emmc.txt文件,再用Notepad++打开
于是看到一下内容
############################################################################## ##############################
#
# General Setting
#
############################################################################## ##############################
- general: MTK_PLATFORM_CFG
info:
- config_version: V1.1.1
platform: MT6572
project: OPPO72_13079
storage: EMMC
boot_channel: MSDC_0
block_size: 0x20000
############################################################################## ##############################
#
# Layout Setting
#
############################################################################## ##############################
partition_name: PRELOADER
file_name: preloader_OPPO72_13079.bin is_download: true
type: SV5_BL_BIN
linear_start_addr: 0x0
physical_start_addr: 0x0
partition_size: 0xc00000
region: EMMC_BOOT_1
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: BOOTLOADERS
reserve: 0x00
- partition_index: SYS1
partition_name: MBR
file_name: MBR
is_download: true
type: NORMAL_ROM
linear_start_addr: 0xc00000
physical_start_addr: 0x0
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00
- partition_index: SYS2
partition_name: EBR1
file_name: EBR1
is_download: true
type: NORMAL_ROM
linear_start_addr: 0xc80000
physical_start_addr: 0x0
partition_size: 0x80000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: UPDATE
reserve: 0x00
partition_name: PRO_INFO
file_name: NONE
is_download: false
type: NONE
linear_start_addr: 0xd00000 physical_start_addr: 0x0
partition_size: 0x300000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00
- partition_index: SYS4
partition_name: NVRAM
file_name: NONE
is_download: false
type: NONE
linear_start_addr: 0x1000000 physical_start_addr: 0x0
partition_size: 0x500000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: BINREGION
reserve: 0x00
- partition_index: SYS5
partition_name: PROTECT_F
file_name: NONE
is_download: false
type: NONE
linear_start_addr: 0x1500000 physical_start_addr: 0x0
partition_size: 0xa00000
region: EMMC_USER
storage: HW_STORAGE_EMMC
boundary_check: true
is_reserved: false
operation_type: PROTECTED
reserve: 0x00
